[WIP PATCH] Index scan offset optimisation using visibility map
Hello.
WIP-Patch for optimisation of OFFSET + IndexScan using visibility map.
Patch based on idea of Maxim Boguk [1]/messages/by-id/CAK-MWwQpZobHfuTtHj9+9G+5=ck+aX-ANWHtBK_0_D_qHYxWuw@mail.gmail.com with some inspiration from Douglas
Doole [2]/messages/by-id/CADE5jYLuugnEEUsyW6Q_4mZFYTxHxaVCQmGAsF0yiY8ZDggi-w@mail.gmail.com.
---------
Everyone knows - using OFFSET (especially big) is not an good practice.
But in reality they widely used mostly for paging (because it is simple).
Typical situation is some table (for example tickets) with indexes used for
paging\sorting:
VACUUM FULL;
VACUUM ANALYZE ticket;
SET work_mem = '512MB';
SET random_page_cost = 1.0;
CREATE TABLE ticket AS
SELECT
id,
TRUNC(RANDOM() * 100 + 1) AS project_id,
NOW() + (RANDOM() * (NOW()+'365 days' - NOW())) AS created_date,
repeat((TRUNC(RANDOM() * 100 + 1)::text), 1000) as payload
FROM GENERATE_SERIES(1, 1000000) AS g(id);
CREATE INDEX simple_index ON ticket using btree(project_id, created_date);
And some typical query to do offset on tickets of some project with paging,
some filtration (based on index) and sorting:
SELECT * FROM ticket
WHERE project_id = ?
AND created_date > '20.06.2017'
ORDER BY created_date offset 500 limit 100;
At the current moment IndexScan node will be required to do 600 heap
fetches to execute the query.
But first 500 of them are just dropped by the NodeLimit.
The idea of the patch is to push down offset information in
ExecSetTupleBound (like it done for Top-sort) to IndexScan in case
of simple scan (without projection, reordering and qual). In such situation
we could use some kind of index only scan
(even better because we dont need index data) to avoid fetching tuples
while they are just thrown away by nodeLimit.
Patch is also availble on Github:
https://github.com/michail-nikolaev/postgres/commit/a368c3483250e4c02046d418a27091678cb963f4?diff=split
And some test here:
https://gist.github.com/michail-nikolaev/b7cbe1d6f463788407ebcaec8917d1e0
So, at the moment everything seems to work (check-world is ok too) and I
got next result for test ticket table:
| offset | master | patch
| 100 | ~1.3ms | ~0.7ms
| 1000 | ~5.6ms | ~1.1ms
| 10000 | ~46.7ms | ~3.6ms
To continue development I have following questions:
0) Maybe I missed something huge...
1) Is it required to support non-mvvc (dirty) snapshots? They are not
supported for IndexOnlyScan - not sure about IndexScan.
2) Should I try to pass informaiton about such optimisation to
planner/optimizer? It is not too easy with current desigh but seems
possible.
3) If so, should I add something to EXPLAIN?
4) If so, should I add some counters to EXPLAIN ANALYZE? (for example
number of heap fetch avoided).
5) Should I add description of optimisation to
https://www.postgresql.org/docs/10/static/queries-limit.html ?
6) Maybe you have some ideas for additional tests I need to add.
Thanks a lot.
[1]: /messages/by-id/CAK-MWwQpZobHfuTtHj9+9G+5=ck+aX-ANWHtBK_0_D_qHYxWuw@mail.gmail.com
/messages/by-id/CAK-MWwQpZobHfuTtHj9+9G+5=ck+aX-ANWHtBK_0_D_qHYxWuw@mail.gmail.com
[2]: /messages/by-id/CADE5jYLuugnEEUsyW6Q_4mZFYTxHxaVCQmGAsF0yiY8ZDggi-w@mail.gmail.com
/messages/by-id/CADE5jYLuugnEEUsyW6Q_4mZFYTxHxaVCQmGAsF0yiY8ZDggi-w@mail.gmail.com
Attachments:
offset_index_only.patchapplication/x-patch; name=offset_index_only.patchDownload
*** a/src/backend/executor/execParallel.c
--- b/src/backend/executor/execParallel.c
***************
*** 1303,1310 **** ParallelQueryMain(dsm_segment *seg, shm_toc *toc)
pwcxt.seg = seg;
ExecParallelInitializeWorker(queryDesc->planstate, &pwcxt);
! /* Pass down any tuple bound */
! ExecSetTupleBound(fpes->tuples_needed, queryDesc->planstate);
/*
* Run the plan. If we specified a tuple bound, be careful not to demand
--- 1303,1310 ----
pwcxt.seg = seg;
ExecParallelInitializeWorker(queryDesc->planstate, &pwcxt);
! /* Pass down any tuple bound. Offset cannot be optimized because parallel execution. */
! ExecSetTupleBound(fpes->tuples_needed, 0, queryDesc->planstate);
/*
* Run the plan. If we specified a tuple bound, be careful not to demand
*** a/src/backend/executor/execProcnode.c
--- b/src/backend/executor/execProcnode.c
***************
*** 785,793 **** ExecShutdownNode(PlanState *node)
*
* Set a tuple bound for a planstate node. This lets child plan nodes
* optimize based on the knowledge that the maximum number of tuples that
! * their parent will demand is limited. The tuple bound for a node may
! * only be changed between scans (i.e., after node initialization or just
! * before an ExecReScan call).
*
* Any negative tuples_needed value means "no limit", which should be the
* default assumption when this is not called at all for a particular node.
--- 785,794 ----
*
* Set a tuple bound for a planstate node. This lets child plan nodes
* optimize based on the knowledge that the maximum number of tuples that
! * their parent will demand is limited. Also tuples skipped may be used by
! * child nodes to optimize retrieval of tuples which immediately skipped by
! * parent (nodeLimit). The tuple bound for a node may only be changed
! * between scans (i.e., after node initialization or just before an ExecReScan call).
*
* Any negative tuples_needed value means "no limit", which should be the
* default assumption when this is not called at all for a particular node.
***************
*** 797,803 **** ExecShutdownNode(PlanState *node)
* only unchanging conditions are tested here.
*/
void
! ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
{
/*
* Since this function recurses, in principle we should check stack depth
--- 798,804 ----
* only unchanging conditions are tested here.
*/
void
! ExecSetTupleBound(int64 tuples_needed, int64 tuples_skipped, PlanState *child_node)
{
/*
* Since this function recurses, in principle we should check stack depth
***************
*** 839,845 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
int i;
for (i = 0; i < maState->ms_nplans; i++)
! ExecSetTupleBound(tuples_needed, maState->mergeplans[i]);
}
else if (IsA(child_node, ResultState))
{
--- 840,846 ----
int i;
for (i = 0; i < maState->ms_nplans; i++)
! ExecSetTupleBound(tuples_needed, 0, maState->mergeplans[i]);
}
else if (IsA(child_node, ResultState))
{
***************
*** 853,859 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
* rows will be demanded from the Result child anyway.
*/
if (outerPlanState(child_node))
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
else if (IsA(child_node, SubqueryScanState))
{
--- 854,860 ----
* rows will be demanded from the Result child anyway.
*/
if (outerPlanState(child_node))
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
}
else if (IsA(child_node, SubqueryScanState))
{
***************
*** 864,870 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
SubqueryScanState *subqueryState = (SubqueryScanState *) child_node;
if (subqueryState->ss.ps.qual == NULL)
! ExecSetTupleBound(tuples_needed, subqueryState->subplan);
}
else if (IsA(child_node, GatherState))
{
--- 865,871 ----
SubqueryScanState *subqueryState = (SubqueryScanState *) child_node;
if (subqueryState->ss.ps.qual == NULL)
! ExecSetTupleBound(tuples_needed, tuples_skipped, subqueryState->subplan);
}
else if (IsA(child_node, GatherState))
{
***************
*** 881,887 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
gstate->tuples_needed = tuples_needed;
/* Also pass down the bound to our own copy of the child plan */
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
else if (IsA(child_node, GatherMergeState))
{
--- 882,888 ----
gstate->tuples_needed = tuples_needed;
/* Also pass down the bound to our own copy of the child plan */
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
}
else if (IsA(child_node, GatherMergeState))
{
***************
*** 890,896 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
gstate->tuples_needed = tuples_needed;
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
/*
--- 891,905 ----
gstate->tuples_needed = tuples_needed;
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
! }
! else if (IsA(child_node, IndexScanState))
! {
! IndexScanState* isState = (IndexScanState *) child_node;
!
! /* Simple case of IndexScan could use index-only optimisation for skipping offset. */
! if (!isState->ss.ps.qual && !isState->ss.ps.ps_ProjInfo && isState->iss_NumOrderByKeys == 0)
! isState->iss_tuples_skipped = isState->iss_tuples_skipped_remaning = tuples_skipped;
}
/*
*** a/src/backend/executor/nodeIndexscan.c
--- b/src/backend/executor/nodeIndexscan.c
***************
*** 31,41 ****
--- 31,43 ----
#include "access/nbtree.h"
#include "access/relscan.h"
+ #include "access/visibilitymap.h"
#include "catalog/pg_am.h"
#include "executor/execdebug.h"
#include "executor/nodeIndexscan.h"
#include "lib/pairingheap.h"
#include "miscadmin.h"
+ #include "storage/predicate.h"
#include "nodes/nodeFuncs.h"
#include "optimizer/clauses.h"
#include "utils/array.h"
***************
*** 118,123 **** IndexNext(IndexScanState *node)
--- 120,131 ----
node->iss_ScanDesc = scandesc;
+ if (node->iss_tuples_skipped != 0)
+ {
+ /* Set it up for index-only scan if we are going to use it for skipped tupples. */
+ node->iss_VMBuffer = InvalidBuffer;
+ }
+
/*
* If no run-time keys to calculate or they are ready, go ahead and
* pass the scankeys to the index AM.
***************
*** 128,167 **** IndexNext(IndexScanState *node)
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
}
! /*
! * ok, now that we have what we need, fetch the next tuple.
*/
! while ((tuple = index_getnext(scandesc, direction)) != NULL)
{
! CHECK_FOR_INTERRUPTS();
!
/*
! * Store the scanned tuple in the scan tuple slot of the scan state.
! * Note: we pass 'false' because tuples returned by amgetnext are
! * pointers onto disk pages and must not be pfree()'d.
! */
! ExecStoreTuple(tuple, /* tuple to store */
! slot, /* slot to store in */
! scandesc->xs_cbuf, /* buffer containing tuple */
! false); /* don't pfree */
/*
! * If the index was lossy, we have to recheck the index quals using
! * the fetched tuple.
*/
! if (scandesc->xs_recheck)
{
! econtext->ecxt_scantuple = slot;
! ResetExprContext(econtext);
! if (!ExecQual(node->indexqualorig, econtext))
{
! /* Fails recheck, so drop it and loop back for another */
! InstrCountFiltered2(node, 1);
! continue;
}
- }
! return slot;
}
/*
--- 136,287 ----
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
}
! /**
! * Use visibility buffer while tuples are skipped by parent nodeLimit.
! * Code below based on IndexOnlyNext. Refer to nodeIndexonlyscan.h for
! * comments about memory ordering and concurrency.
*/
! if (node->iss_tuples_skipped_remaning != 0) /* Parent limit still just ignoring our output. */
{
! ItemPointer tid = NULL;
/*
! * Fetch the next tuple. xs_want_itup is set to false because we not need any index data.
! */
! while ((tid = index_getnext_tid(scandesc, direction)) != NULL)
! {
! CHECK_FOR_INTERRUPTS();
! tuple = NULL;
! /*
! * We don't support rechecking ORDER BY distances. We should be in IndexNextWithReorder if so.
! */
! Assert(!(scandesc->numberOfOrderBys > 0 && scandesc->xs_recheckorderby));
!
! /*
! * Only MVCC snapshots are supported here. TODO: is it ok?
! */
! if (scandesc->xs_continue_hot)
! elog(ERROR, "non-MVCC snapshots are not supported in index scans for index-only offset");
!
! /*
! * Refer to IndexOnlyNext for information about VM_ALL_VISIBLE usage during index scan.
! * If recheck is required - just skip visibility map check because we need heap tuple anyway.
! */
! if (scandesc->xs_recheck ||
! !VM_ALL_VISIBLE(scandesc->heapRelation,
! ItemPointerGetBlockNumber(tid),
! &node->iss_VMBuffer)
! )
! {
! tuple = index_fetch_heap(scandesc);
! if (tuple == NULL)
! continue; /* no visible tuple, try next index entry */
+ /*
+ * Note: at this point we are holding a pin on the heap page, as
+ * recorded in scandesc->xs_cbuf. We could release that pin now,
+ * but it's not clear whether it's a win to do so. The next index
+ * entry might require a visit to the same heap page.
+ */
+ }
+
+ /*
+ * If the index was lossy, we have to recheck the index quals.
+ */
+ if (scandesc->xs_recheck)
+ {
+ /*
+ * Store the scanned tuple in the scan tuple slot of the scan state.
+ * Note: we pass 'false' because tuples returned by amgetnext are
+ * pointers onto disk pages and must not be pfree()'d.
+ */
+ ExecStoreTuple(tuple, /* tuple to store */
+ slot, /* slot to store in */
+ scandesc->xs_cbuf, /* buffer containing tuple */
+ false); /* don't pfree */
+
+ econtext->ecxt_scantuple = slot;
+ ResetExprContext(econtext);
+ if (!ExecQual(node->indexqualorig, econtext))
+ {
+ /* Fails recheck, so drop it and loop back for another */
+ InstrCountFiltered2(node, 1);
+ continue;
+ }
+ }
+ else
+ {
+ /*
+ * We know there is a tuple in index passing all checks.
+ * Parent nodeLimit will skip it anyway - so just prepare fake non-empty slot.
+ */
+ ExecClearTuple(slot);
+ slot->tts_isempty = false;
+ slot->tts_nvalid = 0;
+ }
+
+ /*
+ * Predicate locks for index-only scans must be acquired at the page
+ * level when the heap is not accessed, since tuple-level predicate
+ * locks need the tuple's xmin value. If we had to visit the tuple
+ * anyway, then we already have the tuple-level lock and can skip the
+ * page lock.
+ */
+ if (tuple == NULL)
+ PredicateLockPage(scandesc->heapRelation,
+ ItemPointerGetBlockNumber(tid),
+ estate->es_snapshot);
+
+ /*
+ * Decrement counter for remaning skipped tuples.
+ * If last tuple skipped - release the buffer.
+ */
+ if (--node->iss_tuples_skipped_remaning == 0 && node->iss_VMBuffer != InvalidBuffer)
+ {
+ /* If we had to return one more tuple then regular index scan will used. */
+ ReleaseBuffer(node->iss_VMBuffer);
+ node->iss_VMBuffer = InvalidBuffer;
+ }
+
+ return slot;
+ }
+ }
+ else
+ {
/*
! * ok, now that we have what we need, fetch the next tuple.
*/
! while ((tuple = index_getnext(scandesc, direction)) != NULL)
{
! CHECK_FOR_INTERRUPTS();
!
! /*
! * Store the scanned tuple in the scan tuple slot of the scan state.
! * Note: we pass 'false' because tuples returned by amgetnext are
! * pointers onto disk pages and must not be pfree()'d.
! */
! ExecStoreTuple(tuple, /* tuple to store */
! slot, /* slot to store in */
! scandesc->xs_cbuf, /* buffer containing tuple */
! false); /* don't pfree */
!
! /*
! * If the index was lossy, we have to recheck the index quals using
! * the fetched tuple.
! */
! if (scandesc->xs_recheck)
{
! econtext->ecxt_scantuple = slot;
! ResetExprContext(econtext);
! if (!ExecQual(node->indexqualorig, econtext))
! {
! /* Fails recheck, so drop it and loop back for another */
! InstrCountFiltered2(node, 1);
! continue;
! }
}
! return slot;
! }
}
/*
***************
*** 609,614 **** ExecReScanIndexScan(IndexScanState *node)
--- 729,735 ----
node->iss_ScanKeys, node->iss_NumScanKeys,
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
node->iss_ReachedEnd = false;
+ node->iss_tuples_skipped_remaning = node->iss_tuples_skipped; /* Reset counter for skipped tuples to skip them again. */
ExecScanReScan(&node->ss);
}
***************
*** 818,823 **** ExecEndIndexScan(IndexScanState *node)
--- 939,951 ----
indexScanDesc = node->iss_ScanDesc;
relation = node->ss.ss_currentRelation;
+ /* Release VM buffer pin, if any. */
+ if (node->iss_VMBuffer != InvalidBuffer)
+ {
+ ReleaseBuffer(node->iss_VMBuffer);
+ node->iss_VMBuffer = InvalidBuffer;
+ }
+
/*
* Free the exprcontext(s) ... now dead code, see ExecFreeExprContext
*/
*** a/src/backend/executor/nodeLimit.c
--- b/src/backend/executor/nodeLimit.c
***************
*** 298,309 **** recompute_limits(LimitState *node)
node->lstate = LIMIT_RESCAN;
/*
! * Notify child node about limit. Note: think not to "optimize" by
! * skipping ExecSetTupleBound if compute_tuples_needed returns < 0. We
! * must update the child node anyway, in case this is a rescan and the
* previous time we got a different result.
*/
! ExecSetTupleBound(compute_tuples_needed(node), outerPlanState(node));
}
/*
--- 298,309 ----
node->lstate = LIMIT_RESCAN;
/*
! * Notify child node about limit and offset. Note: think not to "optimize"
! * by skipping ExecSetTupleBound if compute_tuples_needed < 0 and offset = 0.
! * We must update the child node anyway, in case this is a rescan and the
* previous time we got a different result.
*/
! ExecSetTupleBound(compute_tuples_needed(node), node->offset, outerPlanState(node));
}
/*
*** a/src/include/executor/executor.h
--- b/src/include/executor/executor.h
***************
*** 226,232 **** extern void ExecSetExecProcNode(PlanState *node, ExecProcNodeMtd function);
extern Node *MultiExecProcNode(PlanState *node);
extern void ExecEndNode(PlanState *node);
extern bool ExecShutdownNode(PlanState *node);
! extern void ExecSetTupleBound(int64 tuples_needed, PlanState *child_node);
/* ----------------------------------------------------------------
--- 226,232 ----
extern Node *MultiExecProcNode(PlanState *node);
extern void ExecEndNode(PlanState *node);
extern bool ExecShutdownNode(PlanState *node);
! extern void ExecSetTupleBound(int64 tuples_needed, int64 tuples_skipped, PlanState *child_node);
/* ----------------------------------------------------------------
*** a/src/include/nodes/execnodes.h
--- b/src/include/nodes/execnodes.h
***************
*** 1219,1224 **** typedef struct IndexScanState
--- 1219,1227 ----
bool *iss_OrderByTypByVals;
int16 *iss_OrderByTypLens;
Size iss_PscanLen;
+ int64 iss_tuples_skipped; /* tuple offset, see ExecSetTupleBound */
+ int64 iss_tuples_skipped_remaning; /* tuple offset counter */
+ Buffer iss_VMBuffer; /* buffer used for visibility map in case of iss_tuples_skipped > 0 */
} IndexScanState;
/* ----------------
Hi, Michail!
Thanks for the patch!
1 февр. 2018 г., в 1:17, Michail Nikolaev <michail.nikolaev@gmail.com> написал(а):
Hello.
WIP-Patch for optimisation of OFFSET + IndexScan using visibility map.
While the patch seems to me useful improvement, I see few problems with code:
1. Both branches of "if (node->iss_tuples_skipped_remaning != 0)" seem too similar. There is a lot of duplicate comments et c. I think that this branch should be refactored to avoid code duplication.
2. Most of comments are formatted not per project style.
Besides this, patch looks good. Please, add it to the following commitfest so that work on the patch could be tracked.
Best regards, Andrey Borodin.
Hello.
Thanks a lot for review.
Patch updated + rebased on master. check-world is passing.
Still not sure about comment formatting. Have you seen any style guid about
it except "strict ANSI C comment formatting"? Anyway still need to work on
comments.
Also, non-MVCC snaphots are now supported.
Github is updated too.
https://github.com/postgres/postgres/compare/master...michail-nikolaev:offset_index_only
Still not sure about questions 0, 2, 3, 4, 5, and 6 from initial mail
(about explain, explain analyze, documentation and optimiser).
Thanks.
пн, 5 февр. 2018 г. в 23:36, Andrey Borodin <x4mmm@yandex-team.ru>:
Show quoted text
Hi, Michail!
Thanks for the patch!
1 февр. 2018 г., в 1:17, Michail Nikolaev <michail.nikolaev@gmail.com>
написал(а):
Hello.
WIP-Patch for optimisation of OFFSET + IndexScan using visibility map.
While the patch seems to me useful improvement, I see few problems with
code:
1. Both branches of "if (node->iss_tuples_skipped_remaning != 0)" seem too
similar. There is a lot of duplicate comments et c. I think that this
branch should be refactored to avoid code duplication.
2. Most of comments are formatted not per project style.Besides this, patch looks good. Please, add it to the following commitfest
so that work on the patch could be tracked.Best regards, Andrey Borodin.
Attachments:
offset_index_only_v2.patchapplication/octet-stream; name=offset_index_only_v2.patchDownload
*** a/src/backend/executor/execParallel.c
--- b/src/backend/executor/execParallel.c
***************
*** 1303,1310 **** ParallelQueryMain(dsm_segment *seg, shm_toc *toc)
pwcxt.seg = seg;
ExecParallelInitializeWorker(queryDesc->planstate, &pwcxt);
! /* Pass down any tuple bound */
! ExecSetTupleBound(fpes->tuples_needed, queryDesc->planstate);
/*
* Run the plan. If we specified a tuple bound, be careful not to demand
--- 1303,1310 ----
pwcxt.seg = seg;
ExecParallelInitializeWorker(queryDesc->planstate, &pwcxt);
! /* Pass down any tuple bound. Offset cannot be optimized because parallel execution. */
! ExecSetTupleBound(fpes->tuples_needed, 0, queryDesc->planstate);
/*
* Run the plan. If we specified a tuple bound, be careful not to demand
*** a/src/backend/executor/execProcnode.c
--- b/src/backend/executor/execProcnode.c
***************
*** 785,793 **** ExecShutdownNode(PlanState *node)
*
* Set a tuple bound for a planstate node. This lets child plan nodes
* optimize based on the knowledge that the maximum number of tuples that
! * their parent will demand is limited. The tuple bound for a node may
! * only be changed between scans (i.e., after node initialization or just
! * before an ExecReScan call).
*
* Any negative tuples_needed value means "no limit", which should be the
* default assumption when this is not called at all for a particular node.
--- 785,794 ----
*
* Set a tuple bound for a planstate node. This lets child plan nodes
* optimize based on the knowledge that the maximum number of tuples that
! * their parent will demand is limited. Also tuples skipped may be used by
! * child nodes to optimize retrieval of tuples which immediately skipped by
! * parent (nodeLimit). The tuple bound for a node may only be changed
! * between scans (i.e., after node initialization or just before an ExecReScan call).
*
* Any negative tuples_needed value means "no limit", which should be the
* default assumption when this is not called at all for a particular node.
***************
*** 797,803 **** ExecShutdownNode(PlanState *node)
* only unchanging conditions are tested here.
*/
void
! ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
{
/*
* Since this function recurses, in principle we should check stack depth
--- 798,804 ----
* only unchanging conditions are tested here.
*/
void
! ExecSetTupleBound(int64 tuples_needed, int64 tuples_skipped, PlanState *child_node)
{
/*
* Since this function recurses, in principle we should check stack depth
***************
*** 839,845 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
int i;
for (i = 0; i < maState->ms_nplans; i++)
! ExecSetTupleBound(tuples_needed, maState->mergeplans[i]);
}
else if (IsA(child_node, ResultState))
{
--- 840,846 ----
int i;
for (i = 0; i < maState->ms_nplans; i++)
! ExecSetTupleBound(tuples_needed, 0, maState->mergeplans[i]);
}
else if (IsA(child_node, ResultState))
{
***************
*** 853,859 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
* rows will be demanded from the Result child anyway.
*/
if (outerPlanState(child_node))
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
else if (IsA(child_node, SubqueryScanState))
{
--- 854,860 ----
* rows will be demanded from the Result child anyway.
*/
if (outerPlanState(child_node))
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
}
else if (IsA(child_node, SubqueryScanState))
{
***************
*** 864,870 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
SubqueryScanState *subqueryState = (SubqueryScanState *) child_node;
if (subqueryState->ss.ps.qual == NULL)
! ExecSetTupleBound(tuples_needed, subqueryState->subplan);
}
else if (IsA(child_node, GatherState))
{
--- 865,871 ----
SubqueryScanState *subqueryState = (SubqueryScanState *) child_node;
if (subqueryState->ss.ps.qual == NULL)
! ExecSetTupleBound(tuples_needed, tuples_skipped, subqueryState->subplan);
}
else if (IsA(child_node, GatherState))
{
***************
*** 881,887 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
gstate->tuples_needed = tuples_needed;
/* Also pass down the bound to our own copy of the child plan */
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
else if (IsA(child_node, GatherMergeState))
{
--- 882,888 ----
gstate->tuples_needed = tuples_needed;
/* Also pass down the bound to our own copy of the child plan */
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
}
else if (IsA(child_node, GatherMergeState))
{
***************
*** 890,896 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
gstate->tuples_needed = tuples_needed;
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
/*
--- 891,905 ----
gstate->tuples_needed = tuples_needed;
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
! }
! else if (IsA(child_node, IndexScanState))
! {
! IndexScanState* isState = (IndexScanState *) child_node;
!
! /* Simple case of IndexScan could use index-only optimisation for skipping offset. */
! if (!isState->ss.ps.qual && !isState->ss.ps.ps_ProjInfo && isState->iss_NumOrderByKeys == 0)
! isState->iss_tuples_skipped = isState->iss_tuples_skipped_remaning = tuples_skipped;
}
/*
*** a/src/backend/executor/nodeIndexscan.c
--- b/src/backend/executor/nodeIndexscan.c
***************
*** 31,41 ****
--- 31,43 ----
#include "access/nbtree.h"
#include "access/relscan.h"
+ #include "access/visibilitymap.h"
#include "catalog/pg_am.h"
#include "executor/execdebug.h"
#include "executor/nodeIndexscan.h"
#include "lib/pairingheap.h"
#include "miscadmin.h"
+ #include "storage/predicate.h"
#include "nodes/nodeFuncs.h"
#include "optimizer/clauses.h"
#include "utils/array.h"
***************
*** 86,91 **** IndexNext(IndexScanState *node)
--- 88,94 ----
IndexScanDesc scandesc;
HeapTuple tuple;
TupleTableSlot *slot;
+ ItemPointer tid;
/*
* extract necessary information from index scan node
***************
*** 118,123 **** IndexNext(IndexScanState *node)
--- 121,135 ----
node->iss_ScanDesc = scandesc;
+ if (node->iss_tuples_skipped != 0)
+ {
+ /* NodeLimit optimisation is alllowed only for simple scans. See ExecSetTupleBound for details. */
+ Assert((!node->ss.ps.qual && !node->ss.ps.ps_ProjInfo && node->iss_NumOrderByKeys == 0));
+
+ /* Set it up for index-only scan if we are going to use it for skipped tupples. */
+ node->iss_VMBuffer = InvalidBuffer;
+ }
+
/*
* If no run-time keys to calculate or they are ready, go ahead and
* pass the scankeys to the index AM.
***************
*** 128,171 **** IndexNext(IndexScanState *node)
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
}
! /*
! * ok, now that we have what we need, fetch the next tuple.
! */
! while ((tuple = index_getnext(scandesc, direction)) != NULL)
{
CHECK_FOR_INTERRUPTS();
-
/*
! * Store the scanned tuple in the scan tuple slot of the scan state.
! * Note: we pass 'false' because tuples returned by amgetnext are
! * pointers onto disk pages and must not be pfree()'d.
! */
! ExecStoreTuple(tuple, /* tuple to store */
! slot, /* slot to store in */
! scandesc->xs_cbuf, /* buffer containing tuple */
! false); /* don't pfree */
!
/*
! * If the index was lossy, we have to recheck the index quals using
! * the fetched tuple.
! */
! if (scandesc->xs_recheck)
{
! econtext->ecxt_scantuple = slot;
! if (!ExecQualAndReset(node->indexqualorig, econtext))
{
! /* Fails recheck, so drop it and loop back for another */
! InstrCountFiltered2(node, 1);
! continue;
}
}
return slot;
}
/*
* if we get here it means the index scan failed so we are at the end of
! * the scan..
*/
node->iss_ReachedEnd = true;
return ExecClearTuple(slot);
--- 140,245 ----
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
}
! /**
! * Use visibility buffer while tuples are skipped by parent nodeLimit
! * in case of simple scan. Refer to nodeIndexonlyscan.h for comments
! * about memory ordering and concurrency.
! */
! while ((tid = index_getnext_tid(scandesc, direction)) != NULL)
{
CHECK_FOR_INTERRUPTS();
/*
! * We don't support rechecking ORDER BY distances. We should be in IndexNextWithReorder if so.
! */
! Assert(!(scandesc->numberOfOrderBys > 0 && scandesc->xs_recheckorderby));
!
/*
! * Fetch the next tuple. Use visibility map if possible.
! * xs_want_itup is set to false because we not need any index data.
! */
! if (node->iss_tuples_skipped_remaning == 0 || /* tuples are not skipped by parent node */
! scandesc->xs_recheck || /* or heap data is required */
! scandesc->xs_continue_hot || /* or non-MVCC snapshot */
! !VM_ALL_VISIBLE(scandesc->heapRelation,
! ItemPointerGetBlockNumber(tid),
! &node->iss_VMBuffer) /* or not all tuples are visible in page */
! )
{
! tuple = index_fetch_heap(scandesc);
! if (tuple == NULL)
! continue; /* no visible tuple, try next index entry */
!
! /*
! * Store the scanned tuple in the scan tuple slot of the scan state.
! * Note: we pass 'false' because tuples returned by amgetnext are
! * pointers onto disk pages and must not be pfree()'d.
! */
! ExecStoreTuple(tuple, /* tuple to store */
! slot, /* slot to store in */
! scandesc->xs_cbuf, /* buffer containing tuple */
! false); /* don't pfree */
!
! /*
! * If the index was lossy, we have to recheck the index quals.
! */
! if (scandesc->xs_recheck)
{
! econtext->ecxt_scantuple = slot;
! if (!ExecQualAndReset(node->indexqualorig, econtext))
! {
! /* Fails recheck, so drop it and loop back for another */
! InstrCountFiltered2(node, 1);
! continue;
! }
}
+
+ /*
+ * Note: at this point we are holding a pin on the heap page, as
+ * recorded in scandesc->xs_cbuf. We could release that pin now,
+ * but it's not clear whether it's a win to do so. The next index
+ * entry might require a visit to the same heap page.
+ */
+ }
+ else /* tuples is skipped by parent node and visible */
+ {
+ /*
+ * Predicate locks for index-only scans must be acquired at the page
+ * level when the heap is not accessed, since tuple-level predicate
+ * locks need the tuple's xmin value. If we had to visit the tuple
+ * anyway, then we already have the tuple-level lock and can skip the
+ * page lock.
+ */
+ PredicateLockPage(scandesc->heapRelation,
+ ItemPointerGetBlockNumber(tid),
+ estate->es_snapshot);
+ /*
+ * We know there is a tuple in index passing all checks.
+ * Parent nodeLimit will skip it anyway - so just prepare fake non-empty slot.
+ */
+ ExecClearTuple(slot);
+ slot->tts_isempty = false;
+ slot->tts_nvalid = 0;
}
+ /*
+ * Decrement counter for remaning skipped tuples.
+ * If last tuple skipped - release the buffer.
+ */
+ if (node->iss_tuples_skipped_remaning > 0)
+ node->iss_tuples_skipped_remaning--;
+
+ if (node->iss_tuples_skipped_remaning == 0 && node->iss_VMBuffer != InvalidBuffer)
+ {
+ /* If we had to return one more tuple then regular index scan will used. */
+ ReleaseBuffer(node->iss_VMBuffer);
+ node->iss_VMBuffer = InvalidBuffer;
+ }
return slot;
}
/*
* if we get here it means the index scan failed so we are at the end of
! * the scan.
*/
node->iss_ReachedEnd = true;
return ExecClearTuple(slot);
***************
*** 604,609 **** ExecReScanIndexScan(IndexScanState *node)
--- 678,684 ----
node->iss_ScanKeys, node->iss_NumScanKeys,
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
node->iss_ReachedEnd = false;
+ node->iss_tuples_skipped_remaning = node->iss_tuples_skipped; /* Reset counter for skipped tuples to skip them again. */
ExecScanReScan(&node->ss);
}
***************
*** 813,818 **** ExecEndIndexScan(IndexScanState *node)
--- 888,900 ----
indexScanDesc = node->iss_ScanDesc;
relation = node->ss.ss_currentRelation;
+ /* Release VM buffer pin, if any. */
+ if (node->iss_VMBuffer != InvalidBuffer)
+ {
+ ReleaseBuffer(node->iss_VMBuffer);
+ node->iss_VMBuffer = InvalidBuffer;
+ }
+
/*
* Free the exprcontext(s) ... now dead code, see ExecFreeExprContext
*/
*** a/src/backend/executor/nodeLimit.c
--- b/src/backend/executor/nodeLimit.c
***************
*** 298,309 **** recompute_limits(LimitState *node)
node->lstate = LIMIT_RESCAN;
/*
! * Notify child node about limit. Note: think not to "optimize" by
! * skipping ExecSetTupleBound if compute_tuples_needed returns < 0. We
! * must update the child node anyway, in case this is a rescan and the
* previous time we got a different result.
*/
! ExecSetTupleBound(compute_tuples_needed(node), outerPlanState(node));
}
/*
--- 298,309 ----
node->lstate = LIMIT_RESCAN;
/*
! * Notify child node about limit and offset. Note: think not to "optimize"
! * by skipping ExecSetTupleBound if compute_tuples_needed < 0 and offset = 0.
! * We must update the child node anyway, in case this is a rescan and the
* previous time we got a different result.
*/
! ExecSetTupleBound(compute_tuples_needed(node), node->offset, outerPlanState(node));
}
/*
*** a/src/include/executor/executor.h
--- b/src/include/executor/executor.h
***************
*** 227,233 **** extern void ExecSetExecProcNode(PlanState *node, ExecProcNodeMtd function);
extern Node *MultiExecProcNode(PlanState *node);
extern void ExecEndNode(PlanState *node);
extern bool ExecShutdownNode(PlanState *node);
! extern void ExecSetTupleBound(int64 tuples_needed, PlanState *child_node);
/* ----------------------------------------------------------------
--- 227,233 ----
extern Node *MultiExecProcNode(PlanState *node);
extern void ExecEndNode(PlanState *node);
extern bool ExecShutdownNode(PlanState *node);
! extern void ExecSetTupleBound(int64 tuples_needed, int64 tuples_skipped, PlanState *child_node);
/* ----------------------------------------------------------------
*** a/src/include/nodes/execnodes.h
--- b/src/include/nodes/execnodes.h
***************
*** 1224,1229 **** typedef struct IndexScanState
--- 1224,1232 ----
bool *iss_OrderByTypByVals;
int16 *iss_OrderByTypLens;
Size iss_PscanLen;
+ int64 iss_tuples_skipped; /* tuple offset, see ExecSetTupleBound */
+ int64 iss_tuples_skipped_remaning; /* tuple offset counter */
+ Buffer iss_VMBuffer; /* buffer used for visibility map in case of iss_tuples_skipped > 0 */
} IndexScanState;
/* ----------------
Michail Nikolaev <michail.nikolaev@gmail.com> writes:
Still not sure about comment formatting. Have you seen any style guid about
it except "strict ANSI C comment formatting"? Anyway still need to work on
comments.
The short answer is "make the new code look like the code around it".
But there is actually documentation on the point:
https://www.postgresql.org/docs/current/static/source-format.html
The rest of that chapter is recommendable reading as well.
regards, tom lane
Hi!
I've played with patch. I observe that in some expected scenarios it reduces read buffers significantly.
14 февр. 2018 г., в 0:04, Michail Nikolaev <michail.nikolaev@gmail.com> написал(а):
Patch updated + rebased on master. check-world is passing.
Minor spots:
There are some trailing whitespaces at line ends
Offset cannot be optimized because parallel execution
I'd replace with
Offset cannot be optimized [in spite of | due to] parallel execution
More important thing: now nodeindexonlyscan.c and nodeindexscan.c share more similar code and comments. I do not think it is strictly necessary to avoid, but we certainly have to answer the question:
Is it possible to refactor code to avoid duplication?
Currently, patch is not invasive, touches only some relevant code. If refactoring will make it shotgun-suregery, I think it is better to avoid it.
Still not sure about questions 0, 2, 3, 4, 5, and 6 from initial mail (about explain, explain analyze, documentation and optimiser).
I think that I'd be cool if EXPLAIN ANALYZE printed heap fetch information if "Index-Only" way was used. But we already have this debug information in form of reduced count in "Buffers". There is nothing to add to plain EXPLAIN, in my opinion.
From my point of view, you should add to patch some words here
https://www.postgresql.org/docs/current/static/indexes-index-only-scans.html
and, if patch will be accepted, here
https://wiki.postgresql.org/wiki/Index-only_scans
I do not know if it is possible to take into account this optimization in cost estimation.
Does Limit node take cost of scanning into startup cost?
Thanks!
Best regards, Andrey Borodin.
Hi, Michail!
Here are points that we need to address before advancing the patch.
20 февр. 2018 г., в 11:45, Andrey Borodin <x4mmm@yandex-team.ru> написал(а):
Minor spots:
There are some trailing whitespaces at line endsOffset cannot be optimized because parallel execution
I'd replace with
Offset cannot be optimized [in spite of | due to] parallel execution
From my point of view, you should add to patch some words here
https://www.postgresql.org/docs/current/static/indexes-index-only-scans.html
And few thoughts about plan cost estimation. Plz check create_limit_path() logic on cost estimation. I don't think you have enough information there to guess about possibility of IoS offset computation.
I do not know if it is possible to take into account this optimization in cost estimation.
Does Limit node take cost of scanning into startup cost?
I'm marking patch as WoA, plz ping it to Need Review when done.
Thanks!
Best regards, Andrey Borodin.
Hello, Andrey.
Thanks for review.
I have updated comments according your review also renamed some fields for
consistency.
Additional some notes added to documentation.
Updated patch in attach, github updated too.
Attachments:
offset_index_only_v3.patchapplication/octet-stream; name=offset_index_only_v3.patchDownload
diff --git a/doc/src/sgml/indices.sgml b/doc/src/sgml/indices.sgml
index 0818196..02da20c 100644
*** a/doc/src/sgml/indices.sgml
--- b/doc/src/sgml/indices.sgml
***************
*** 1309,1314 **** SELECT target FROM tests WHERE subject = 'some-subject' AND success;
--- 1309,1321 ----
such cases and allow index-only scans to be generated, but older versions
will not.
</para>
+
+ <para>
+ In addition, in some cases index only scan technique may be internally used for optimization of queries including <literal>OFFSET</literal>.
+ That is applicable to queries executed using index scan, not using <literal>GROUP BY</literal>
+ and where all the data values required by a <literal>WHERE</literal> predicate are available in the index.
+ Index type must support index only scans as well.
+ </para>
</sect1>
diff --git a/src/backend/executoindex 14b0b89..9a2d214 100644
*** a/src/backend/executor/execParallel.c
--- b/src/backend/executor/execParallel.c
***************
*** 1303,1310 **** ParallelQueryMain(dsm_segment *seg, shm_toc *toc)
pwcxt.seg = seg;
ExecParallelInitializeWorker(queryDesc->planstate, &pwcxt);
! /* Pass down any tuple bound */
! ExecSetTupleBound(fpes->tuples_needed, queryDesc->planstate);
/*
* Run the plan. If we specified a tuple bound, be careful not to demand
--- 1303,1310 ----
pwcxt.seg = seg;
ExecParallelInitializeWorker(queryDesc->planstate, &pwcxt);
! /* Pass down any tuple bound. Offset cannot be optimized due to parallel execution. */
! ExecSetTupleBound(fpes->tuples_needed, 0, queryDesc->planstate);
/*
* Run the plan. If we specified a tuple bound, be careful not to demand
diff --git a/src/backend/executor/execProcindex 43a27a9..c6807be 100644
*** a/src/backend/executor/execProcnode.c
--- b/src/backend/executor/execProcnode.c
***************
*** 785,793 **** ExecShutdownNode(PlanState *node)
*
* Set a tuple bound for a planstate node. This lets child plan nodes
* optimize based on the knowledge that the maximum number of tuples that
! * their parent will demand is limited. The tuple bound for a node may
! * only be changed between scans (i.e., after node initialization or just
! * before an ExecReScan call).
*
* Any negative tuples_needed value means "no limit", which should be the
* default assumption when this is not called at all for a particular node.
--- 785,794 ----
*
* Set a tuple bound for a planstate node. This lets child plan nodes
* optimize based on the knowledge that the maximum number of tuples that
! * their parent will demand is limited. Also tuples skipped may be used by
! * child nodes to optimize retrieval of tuples which are immediately skipped
! * by parent (nodeLimit). The tuple bound for a node may only be changed
! * between scans (i.e., after node initialization or just before an ExecReScan call).
*
* Any negative tuples_needed value means "no limit", which should be the
* default assumption when this is not called at all for a particular node.
***************
*** 797,803 **** ExecShutdownNode(PlanState *node)
* only unchanging conditions are tested here.
*/
void
! ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
{
/*
* Since this function recurses, in principle we should check stack depth
--- 798,804 ----
* only unchanging conditions are tested here.
*/
void
! ExecSetTupleBound(int64 tuples_needed, int64 tuples_skipped, PlanState *child_node)
{
/*
* Since this function recurses, in principle we should check stack depth
***************
*** 839,845 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
int i;
for (i = 0; i < maState->ms_nplans; i++)
! ExecSetTupleBound(tuples_needed, maState->mergeplans[i]);
}
else if (IsA(child_node, ResultState))
{
--- 840,846 ----
int i;
for (i = 0; i < maState->ms_nplans; i++)
! ExecSetTupleBound(tuples_needed, 0, maState->mergeplans[i]);
}
else if (IsA(child_node, ResultState))
{
***************
*** 853,859 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
* rows will be demanded from the Result child anyway.
*/
if (outerPlanState(child_node))
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
else if (IsA(child_node, SubqueryScanState))
{
--- 854,860 ----
* rows will be demanded from the Result child anyway.
*/
if (outerPlanState(child_node))
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
}
else if (IsA(child_node, SubqueryScanState))
{
***************
*** 864,870 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
SubqueryScanState *subqueryState = (SubqueryScanState *) child_node;
if (subqueryState->ss.ps.qual == NULL)
! ExecSetTupleBound(tuples_needed, subqueryState->subplan);
}
else if (IsA(child_node, GatherState))
{
--- 865,871 ----
SubqueryScanState *subqueryState = (SubqueryScanState *) child_node;
if (subqueryState->ss.ps.qual == NULL)
! ExecSetTupleBound(tuples_needed, tuples_skipped, subqueryState->subplan);
}
else if (IsA(child_node, GatherState))
{
***************
*** 881,887 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
gstate->tuples_needed = tuples_needed;
/* Also pass down the bound to our own copy of the child plan */
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
else if (IsA(child_node, GatherMergeState))
{
--- 882,888 ----
gstate->tuples_needed = tuples_needed;
/* Also pass down the bound to our own copy of the child plan */
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
}
else if (IsA(child_node, GatherMergeState))
{
***************
*** 890,896 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
gstate->tuples_needed = tuples_needed;
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
/*
--- 891,905 ----
gstate->tuples_needed = tuples_needed;
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
! }
! else if (IsA(child_node, IndexScanState))
! {
! IndexScanState* isState = (IndexScanState *) child_node;
!
! /* Simple case of IndexScan could use index-only optimisation for skipping offset. */
! if (!isState->ss.ps.qual && !isState->ss.ps.ps_ProjInfo && isState->iss_NumOrderByKeys == 0)
! isState->iss_TuplesSkipped = isState->iss_TuplesSkippedRemaning = tuples_skipped;
}
/*
diff --git a/src/backend/executor/nodeIndeindex 01c9de8..9285f75 100644
*** a/src/backend/executor/nodeIndexscan.c
--- b/src/backend/executor/nodeIndexscan.c
***************
*** 31,41 ****
--- 31,43 ----
#include "access/nbtree.h"
#include "access/relscan.h"
+ #include "access/visibilitymap.h"
#include "catalog/pg_am.h"
#include "executor/execdebug.h"
#include "executor/nodeIndexscan.h"
#include "lib/pairingheap.h"
#include "miscadmin.h"
+ #include "storage/predicate.h"
#include "nodes/nodeFuncs.h"
#include "optimizer/clauses.h"
#include "utils/array.h"
***************
*** 86,91 **** IndexNext(IndexScanState *node)
--- 88,94 ----
IndexScanDesc scandesc;
HeapTuple tuple;
TupleTableSlot *slot;
+ ItemPointer tid;
/*
* extract necessary information from index scan node
***************
*** 118,123 **** IndexNext(IndexScanState *node)
--- 121,135 ----
node->iss_ScanDesc = scandesc;
+ if (node->iss_TuplesSkipped != 0)
+ {
+ /* NodeLimit optimisation is allowed only for simple scans. See ExecSetTupleBound for details. */
+ Assert((!node->ss.ps.qual && !node->ss.ps.ps_ProjInfo && node->iss_NumOrderByKeys == 0));
+
+ /* Set it up for index-only scan if we are going to use it for skipped tupples. */
+ node->iss_VMBuffer = InvalidBuffer;
+ }
+
/*
* If no run-time keys to calculate or they are ready, go ahead and
* pass the scankeys to the index AM.
***************
*** 128,171 **** IndexNext(IndexScanState *node)
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
}
! /*
! * ok, now that we have what we need, fetch the next tuple.
! */
! while ((tuple = index_getnext(scandesc, direction)) != NULL)
{
CHECK_FOR_INTERRUPTS();
-
/*
! * Store the scanned tuple in the scan tuple slot of the scan state.
! * Note: we pass 'false' because tuples returned by amgetnext are
! * pointers onto disk pages and must not be pfree()'d.
! */
! ExecStoreTuple(tuple, /* tuple to store */
! slot, /* slot to store in */
! scandesc->xs_cbuf, /* buffer containing tuple */
! false); /* don't pfree */
!
/*
! * If the index was lossy, we have to recheck the index quals using
! * the fetched tuple.
! */
! if (scandesc->xs_recheck)
{
! econtext->ecxt_scantuple = slot;
! if (!ExecQualAndReset(node->indexqualorig, econtext))
{
! /* Fails recheck, so drop it and loop back for another */
! InstrCountFiltered2(node, 1);
! continue;
}
}
return slot;
}
/*
* if we get here it means the index scan failed so we are at the end of
! * the scan..
*/
node->iss_ReachedEnd = true;
return ExecClearTuple(slot);
--- 140,248 ----
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
}
! /**
! * Use visibility buffer while tuples are skipped by parent nodeLimit
! * in case of simple scan. Refer to nodeIndexonlyscan.h for comments
! * about memory ordering and concurrency.
! */
! while ((tid = index_getnext_tid(scandesc, direction)) != NULL)
{
CHECK_FOR_INTERRUPTS();
/*
! * We don't support rechecking ORDER BY distances. We should be in IndexNextWithReorder if so.
! */
! Assert(!(scandesc->numberOfOrderBys > 0 && scandesc->xs_recheckorderby));
!
/*
! * Fetch the next tuple. Use visibility map if possible.
! * xs_want_itup is set to false because we do not need any index data.
! */
! if (node->iss_TuplesSkippedRemaning == 0 || /* tuples are not skipped by parent node */
! scandesc->xs_recheck || /* or heap data is required */
! scandesc->xs_continue_hot || /* or non-MVCC snapshot */
! !VM_ALL_VISIBLE(scandesc->heapRelation,
! ItemPointerGetBlockNumber(tid),
! &node->iss_VMBuffer) /* or not all tuples are visible in page */
! )
{
! tuple = index_fetch_heap(scandesc);
! if (tuple == NULL)
! continue; /* no visible tuple, try next index entry */
!
! /*
! * Store the scanned tuple in the scan tuple slot of the scan state.
! * Note: we pass 'false' because tuples returned by amgetnext are
! * pointers onto disk pages and must not be pfree()'d.
! */
! ExecStoreTuple(tuple, /* tuple to store */
! slot, /* slot to store in */
! scandesc->xs_cbuf, /* buffer containing tuple */
! false); /* don't pfree */
!
! /*
! * If the index was lossy, we have to recheck the index quals.
! */
! if (scandesc->xs_recheck)
{
! econtext->ecxt_scantuple = slot;
! if (!ExecQualAndReset(node->indexqualorig, econtext))
! {
! /* Fails recheck, so drop it and loop back for another */
! InstrCountFiltered2(node, 1);
! continue;
! }
}
+
+ /*
+ * Note: at this point we are holding a pin on the heap page, as
+ * recorded in scandesc->xs_cbuf. We could release that pin now,
+ * but it's not clear whether it's a win to do so. The next index
+ * entry might require a visit to the same heap page.
+ */
+ }
+ else /* tuples is skipped by parent node and visible */
+ {
+ /*
+ * Predicate locks for index-only scans must be acquired at the page
+ * level when the heap is not accessed, since tuple-level predicate
+ * locks need the tuple's xmin value. If we had to visit the tuple
+ * anyway, then we already have the tuple-level lock and can skip the
+ * page lock.
+ */
+ PredicateLockPage(scandesc->heapRelation,
+ ItemPointerGetBlockNumber(tid),
+ estate->es_snapshot);
+ /*
+ * We know there is a tuple in index passing all checks.
+ * Parent nodeLimit will skip it anyway - so just prepare fake non-empty slot.
+ */
+ ExecClearTuple(slot);
+ slot->tts_isempty = false;
+ slot->tts_nvalid = 0;
}
+ /*
+ * Decrement counter for remaning skipped tuples.
+ * If last tuple skipped - release the buffer.
+ */
+ if (node->iss_TuplesSkippedRemaning > 0)
+ node->iss_TuplesSkippedRemaning--;
+
+ if (node->iss_TuplesSkippedRemaning == 0 && node->iss_VMBuffer != InvalidBuffer)
+ {
+ /*
+ * If we had to return one more tuple then regular index scan will used.
+ * So, we can unpin VM buffer.
+ */
+ ReleaseBuffer(node->iss_VMBuffer);
+ node->iss_VMBuffer = InvalidBuffer;
+ }
return slot;
}
/*
* if we get here it means the index scan failed so we are at the end of
! * the scan.
*/
node->iss_ReachedEnd = true;
return ExecClearTuple(slot);
***************
*** 604,609 **** ExecReScanIndexScan(IndexScanState *node)
--- 681,687 ----
node->iss_ScanKeys, node->iss_NumScanKeys,
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
node->iss_ReachedEnd = false;
+ node->iss_TuplesSkippedRemaning = node->iss_TuplesSkipped; /* Reset counter for skipped tuples to skip them again. */
ExecScanReScan(&node->ss);
}
***************
*** 813,818 **** ExecEndIndexScan(IndexScanState *node)
--- 891,903 ----
indexScanDesc = node->iss_ScanDesc;
relation = node->ss.ss_currentRelation;
+ /* Release VM buffer pin, if any. */
+ if (node->iss_VMBuffer != InvalidBuffer)
+ {
+ ReleaseBuffer(node->iss_VMBuffer);
+ node->iss_VMBuffer = InvalidBuffer;
+ }
+
/*
* Free the exprcontext(s) ... now dead code, see ExecFreeExprContext
*/
diff --git a/src/backend/executor/nodeLimitindex 56d98b4..2a896df 100644
*** a/src/backend/executor/nodeLimit.c
--- b/src/backend/executor/nodeLimit.c
***************
*** 298,309 **** recompute_limits(LimitState *node)
node->lstate = LIMIT_RESCAN;
/*
! * Notify child node about limit. Note: think not to "optimize" by
! * skipping ExecSetTupleBound if compute_tuples_needed returns < 0. We
! * must update the child node anyway, in case this is a rescan and the
* previous time we got a different result.
*/
! ExecSetTupleBound(compute_tuples_needed(node), outerPlanState(node));
}
/*
--- 298,309 ----
node->lstate = LIMIT_RESCAN;
/*
! * Notify child node about limit and offset. Note: think not to "optimize"
! * by skipping ExecSetTupleBound if compute_tuples_needed < 0 and offset = 0.
! * We must update the child node anyway, in case this is a rescan and the
* previous time we got a different result.
*/
! ExecSetTupleBound(compute_tuples_needed(node), node->offset, outerPlanState(node));
}
/*
diff --git a/src/include/executor/execuindex 45a077a..da2cfc1 100644
*** a/src/include/executor/executor.h
--- b/src/include/executor/executor.h
***************
*** 220,226 **** extern void ExecSetExecProcNode(PlanState *node, ExecProcNodeMtd function);
extern Node *MultiExecProcNode(PlanState *node);
extern void ExecEndNode(PlanState *node);
extern bool ExecShutdownNode(PlanState *node);
! extern void ExecSetTupleBound(int64 tuples_needed, PlanState *child_node);
/* ----------------------------------------------------------------
--- 220,226 ----
extern Node *MultiExecProcNode(PlanState *node);
extern void ExecEndNode(PlanState *node);
extern bool ExecShutdownNode(PlanState *node);
! extern void ExecSetTupleBound(int64 tuples_needed, int64 tuples_skipped, PlanState *child_node);
/* ----------------------------------------------------------------
diff --git a/src/include/nodes/execnodindex a953820..43cb2d0 100644
*** a/src/include/nodes/execnodes.h
--- b/src/include/nodes/execnodes.h
***************
*** 1228,1233 **** typedef struct IndexScanState
--- 1228,1236 ----
bool *iss_OrderByTypByVals;
int16 *iss_OrderByTypLens;
Size iss_PscanLen;
+ int64 iss_TuplesSkipped; /* tuple offset, see ExecSetTupleBound */
+ int64 iss_TuplesSkippedRemaning; /* tuple offset counter */
+ Buffer iss_VMBuffer; /* buffer used for visibility map in case of iss_tuples_skipped > 0 */
} IndexScanState;
/* ----------------
Hello Michail,
On Tue, March 6, 2018 4:03 pm, Michail Nikolaev wrote:
Hello, Andrey.
Thanks for review.
I have updated comments according your review also renamed some fields for
consistency.
Additional some notes added to documentation.Updated patch in attach, github updated too.
That is a cool idea, and can come in very handy if you regulary need large
offsets. Cannot comment on the code, but there is at least one regular
typo:
+ * Decrement counter for remaning skipped tuples.
+ * If last tuple skipped - release the buffer.
+ */
+ if (node->iss_TuplesSkippedRemaning > 0)
+ node->iss_TuplesSkippedRemaning--;The English word is "remaining", with "ai" instead of "a" :)
Also the variable name "iss_TuplesSkipped" has its grammar at odds with
the purpose the code seems to be.
It could be named "SkipTuples" (e.g. this is the number of tuples we need
to skip, not the number we have skipped), and the other one then
"iss_SkipTuplesRemaining" so they are consistent with each other.
Others might have a better name for these two, of course.
Best wishes,
Tels
7 марта 2018 г., в 3:25, Tels <nospam-pg-abuse@bloodgate.com> написал(а):
It could be named "SkipTuples" (e.g. this is the number of tuples we need
to skip, not the number we have skipped), and the other one then
"iss_SkipTuplesRemaining" so they are consistent with each other.
I agree that name sounds strange (even for my globish ear).
I'm not sure, but may be this
! Assert(!(scandesc->numberOfOrderBys > 0 && scandesc->xs_recheckorderby));
should be if() elog(ERROR,...); ?
Also, I think that this check could be removed from loop. We do not expect that it's state will change during execution, do we?
Besides this, I think the patch is ready for committer.
Best regards, Andrey Borodin.
Hello.
Andrey, Tels - thanks for review.
It could be named "SkipTuples" (e.g. this is the number of tuples we need
to skip, not the number we have skipped), and the other one then
"iss_SkipTuplesRemaining" so they are consistent with each other.
Agreed, done.
Also, I think that this check could be removed from loop. We do not
expect that it's state will change during execution, do we?
Removed.
Patch is attached, github is updated too.
Michail.
Attachments:
offset_index_only_v4.patchapplication/octet-stream; name=offset_index_only_v4.patchDownload
diff --git a/doc/src/sgml/indices.sgml b/doc/src/sgml/indices.sgml
index 0818196..02da20c 100644
*** a/doc/src/sgml/indices.sgml
--- b/doc/src/sgml/indices.sgml
***************
*** 1309,1314 **** SELECT target FROM tests WHERE subject = 'some-subject' AND success;
--- 1309,1321 ----
such cases and allow index-only scans to be generated, but older versions
will not.
</para>
+
+ <para>
+ In addition, in some cases index only scan technique may be internally used for optimization of queries including <literal>OFFSET</literal>.
+ That is applicable to queries executed using index scan, not using <literal>GROUP BY</literal>
+ and where all the data values required by a <literal>WHERE</literal> predicate are available in the index.
+ Index type must support index only scans as well.
+ </para>
</sect1>
diff --git a/src/backend/executoindex 14b0b89..9a2d214 100644
*** a/src/backend/executor/execParallel.c
--- b/src/backend/executor/execParallel.c
***************
*** 1303,1310 **** ParallelQueryMain(dsm_segment *seg, shm_toc *toc)
pwcxt.seg = seg;
ExecParallelInitializeWorker(queryDesc->planstate, &pwcxt);
! /* Pass down any tuple bound */
! ExecSetTupleBound(fpes->tuples_needed, queryDesc->planstate);
/*
* Run the plan. If we specified a tuple bound, be careful not to demand
--- 1303,1310 ----
pwcxt.seg = seg;
ExecParallelInitializeWorker(queryDesc->planstate, &pwcxt);
! /* Pass down any tuple bound. Offset cannot be optimized due to parallel execution. */
! ExecSetTupleBound(fpes->tuples_needed, 0, queryDesc->planstate);
/*
* Run the plan. If we specified a tuple bound, be careful not to demand
diff --git a/src/backend/executor/execProcindex 43a27a9..e6504e3 100644
*** a/src/backend/executor/execProcnode.c
--- b/src/backend/executor/execProcnode.c
***************
*** 783,793 **** ExecShutdownNode(PlanState *node)
/*
* ExecSetTupleBound
*
! * Set a tuple bound for a planstate node. This lets child plan nodes
* optimize based on the knowledge that the maximum number of tuples that
! * their parent will demand is limited. The tuple bound for a node may
! * only be changed between scans (i.e., after node initialization or just
! * before an ExecReScan call).
*
* Any negative tuples_needed value means "no limit", which should be the
* default assumption when this is not called at all for a particular node.
--- 783,794 ----
/*
* ExecSetTupleBound
*
! * Set a tuple bound for a planstate node. This lets child plan nodes
* optimize based on the knowledge that the maximum number of tuples that
! * their parent will demand is limited. Also tuples_to_skip may be used by
! * child nodes to optimize retrieval of tuples which are immediately skipped
! * by parent (nodeLimit). The tuple bound for a node may only be changed
! * between scans (i.e., after node initialization or just before an ExecReScan call).
*
* Any negative tuples_needed value means "no limit", which should be the
* default assumption when this is not called at all for a particular node.
***************
*** 797,803 **** ExecShutdownNode(PlanState *node)
* only unchanging conditions are tested here.
*/
void
! ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
{
/*
* Since this function recurses, in principle we should check stack depth
--- 798,804 ----
* only unchanging conditions are tested here.
*/
void
! ExecSetTupleBound(int64 tuples_needed, int64 tuples_to_skip, PlanState *child_node)
{
/*
* Since this function recurses, in principle we should check stack depth
***************
*** 839,845 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
int i;
for (i = 0; i < maState->ms_nplans; i++)
! ExecSetTupleBound(tuples_needed, maState->mergeplans[i]);
}
else if (IsA(child_node, ResultState))
{
--- 840,846 ----
int i;
for (i = 0; i < maState->ms_nplans; i++)
! ExecSetTupleBound(tuples_needed, 0, maState->mergeplans[i]);
}
else if (IsA(child_node, ResultState))
{
***************
*** 853,859 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
* rows will be demanded from the Result child anyway.
*/
if (outerPlanState(child_node))
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
else if (IsA(child_node, SubqueryScanState))
{
--- 854,860 ----
* rows will be demanded from the Result child anyway.
*/
if (outerPlanState(child_node))
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
}
else if (IsA(child_node, SubqueryScanState))
{
***************
*** 864,870 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
SubqueryScanState *subqueryState = (SubqueryScanState *) child_node;
if (subqueryState->ss.ps.qual == NULL)
! ExecSetTupleBound(tuples_needed, subqueryState->subplan);
}
else if (IsA(child_node, GatherState))
{
--- 865,871 ----
SubqueryScanState *subqueryState = (SubqueryScanState *) child_node;
if (subqueryState->ss.ps.qual == NULL)
! ExecSetTupleBound(tuples_needed, tuples_to_skip, subqueryState->subplan);
}
else if (IsA(child_node, GatherState))
{
***************
*** 881,887 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
gstate->tuples_needed = tuples_needed;
/* Also pass down the bound to our own copy of the child plan */
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
else if (IsA(child_node, GatherMergeState))
{
--- 882,888 ----
gstate->tuples_needed = tuples_needed;
/* Also pass down the bound to our own copy of the child plan */
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
}
else if (IsA(child_node, GatherMergeState))
{
***************
*** 890,896 **** ExecSetTupleBound(int64 tuples_needed, PlanState *child_node)
gstate->tuples_needed = tuples_needed;
! ExecSetTupleBound(tuples_needed, outerPlanState(child_node));
}
/*
--- 891,905 ----
gstate->tuples_needed = tuples_needed;
! ExecSetTupleBound(tuples_needed, 0, outerPlanState(child_node));
! }
! else if (IsA(child_node, IndexScanState))
! {
! IndexScanState* isState = (IndexScanState *) child_node;
!
! /* Simple case of IndexScan could use index-only optimisation while skipping offset. */
! if (!isState->ss.ps.qual && !isState->ss.ps.ps_ProjInfo && isState->iss_NumOrderByKeys == 0)
! isState->iss_SkipTuples = isState->iss_SkipTuplesRemaining = tuples_to_skip;
}
/*
diff --git a/src/backend/executor/nodeIndeindex 01c9de8..60bd19d 100644
*** a/src/backend/executor/nodeIndexscan.c
--- b/src/backend/executor/nodeIndexscan.c
***************
*** 31,41 ****
--- 31,43 ----
#include "access/nbtree.h"
#include "access/relscan.h"
+ #include "access/visibilitymap.h"
#include "catalog/pg_am.h"
#include "executor/execdebug.h"
#include "executor/nodeIndexscan.h"
#include "lib/pairingheap.h"
#include "miscadmin.h"
+ #include "storage/predicate.h"
#include "nodes/nodeFuncs.h"
#include "optimizer/clauses.h"
#include "utils/array.h"
***************
*** 86,91 **** IndexNext(IndexScanState *node)
--- 88,94 ----
IndexScanDesc scandesc;
HeapTuple tuple;
TupleTableSlot *slot;
+ ItemPointer tid;
/*
* extract necessary information from index scan node
***************
*** 118,123 **** IndexNext(IndexScanState *node)
--- 121,135 ----
node->iss_ScanDesc = scandesc;
+ if (node->iss_SkipTuples != 0)
+ {
+ /* NodeLimit optimisation is allowed only for simple scans. See ExecSetTupleBound for details. */
+ Assert((!node->ss.ps.qual && !node->ss.ps.ps_ProjInfo && node->iss_NumOrderByKeys == 0));
+
+ /* Set it up for index-only scan if we are going to use it for skipped tupples. */
+ node->iss_VMBuffer = InvalidBuffer;
+ }
+
/*
* If no run-time keys to calculate or they are ready, go ahead and
* pass the scankeys to the index AM.
***************
*** 128,171 **** IndexNext(IndexScanState *node)
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
}
! /*
! * ok, now that we have what we need, fetch the next tuple.
! */
! while ((tuple = index_getnext(scandesc, direction)) != NULL)
{
CHECK_FOR_INTERRUPTS();
/*
! * Store the scanned tuple in the scan tuple slot of the scan state.
! * Note: we pass 'false' because tuples returned by amgetnext are
! * pointers onto disk pages and must not be pfree()'d.
! */
! ExecStoreTuple(tuple, /* tuple to store */
! slot, /* slot to store in */
! scandesc->xs_cbuf, /* buffer containing tuple */
! false); /* don't pfree */
!
! /*
! * If the index was lossy, we have to recheck the index quals using
! * the fetched tuple.
! */
! if (scandesc->xs_recheck)
{
! econtext->ecxt_scantuple = slot;
! if (!ExecQualAndReset(node->indexqualorig, econtext))
{
! /* Fails recheck, so drop it and loop back for another */
! InstrCountFiltered2(node, 1);
! continue;
}
}
return slot;
}
/*
* if we get here it means the index scan failed so we are at the end of
! * the scan..
*/
node->iss_ReachedEnd = true;
return ExecClearTuple(slot);
--- 140,244 ----
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
}
! /**
! * Use visibility buffer while tuples are skipped by parent nodeLimit
! * in case of simple scan. Refer to nodeIndexonlyscan.h for comments
! * about memory ordering and concurrency.
! */
! while ((tid = index_getnext_tid(scandesc, direction)) != NULL)
{
CHECK_FOR_INTERRUPTS();
/*
! * Fetch the next tuple. Use visibility map if possible.
! * xs_want_itup is set to false because we do not need any index data.
! */
! if (node->iss_SkipTuplesRemaining == 0 || /* tuples are not skipped by parent node */
! scandesc->xs_recheck || /* or heap data is required */
! scandesc->xs_continue_hot || /* or non-MVCC snapshot */
! !VM_ALL_VISIBLE(scandesc->heapRelation,
! ItemPointerGetBlockNumber(tid),
! &node->iss_VMBuffer) /* or not all tuples are visible in page */
! )
{
! tuple = index_fetch_heap(scandesc);
! if (tuple == NULL)
! continue; /* no visible tuple, try next index entry */
!
! /*
! * Store the scanned tuple in the scan tuple slot of the scan state.
! * Note: we pass 'false' because tuples returned by amgetnext are
! * pointers onto disk pages and must not be pfree()'d.
! */
! ExecStoreTuple(tuple, /* tuple to store */
! slot, /* slot to store in */
! scandesc->xs_cbuf, /* buffer containing tuple */
! false); /* don't pfree */
!
! /*
! * If the index was lossy, we have to recheck the index quals.
! */
! if (scandesc->xs_recheck)
{
! econtext->ecxt_scantuple = slot;
! if (!ExecQualAndReset(node->indexqualorig, econtext))
! {
! /* Fails recheck, so drop it and loop back for another */
! InstrCountFiltered2(node, 1);
! continue;
! }
}
+
+ /*
+ * Note: at this point we are holding a pin on the heap page, as
+ * recorded in scandesc->xs_cbuf. We could release that pin now,
+ * but it's not clear whether it's a win to do so. The next index
+ * entry might require a visit to the same heap page.
+ */
+ }
+ else /* tuple is skipped by parent node and visible */
+ {
+ /*
+ * Predicate locks for index-only scans must be acquired at the page
+ * level when the heap is not accessed, since tuple-level predicate
+ * locks need the tuple's xmin value. If we had to visit the tuple
+ * anyway, then we already have the tuple-level lock and can skip the
+ * page lock.
+ */
+ PredicateLockPage(scandesc->heapRelation,
+ ItemPointerGetBlockNumber(tid),
+ estate->es_snapshot);
+ /*
+ * We know there is a tuple in index passing all checks.
+ * Parent nodeLimit will skip it anyway - so just prepare fake non-empty slot.
+ */
+ ExecClearTuple(slot);
+ slot->tts_isempty = false;
+ slot->tts_nvalid = 0;
}
+ /*
+ * Decrement counter for remaining skipped tuples.
+ * If last tuple skipped - release the buffer.
+ */
+ if (node->iss_SkipTuplesRemaining > 0)
+ node->iss_SkipTuplesRemaining--;
+
+ if (node->iss_SkipTuplesRemaining == 0 && node->iss_VMBuffer != InvalidBuffer)
+ {
+ /*
+ * If we had to return one more tuple then regular index scan will used.
+ * So, we can unpin VM buffer.
+ */
+ ReleaseBuffer(node->iss_VMBuffer);
+ node->iss_VMBuffer = InvalidBuffer;
+ }
return slot;
}
/*
* if we get here it means the index scan failed so we are at the end of
! * the scan.
*/
node->iss_ReachedEnd = true;
return ExecClearTuple(slot);
***************
*** 604,609 **** ExecReScanIndexScan(IndexScanState *node)
--- 677,683 ----
node->iss_ScanKeys, node->iss_NumScanKeys,
node->iss_OrderByKeys, node->iss_NumOrderByKeys);
node->iss_ReachedEnd = false;
+ node->iss_SkipTuplesRemaining = node->iss_SkipTuples; /* Reset counter for skipped tuples to skip them again. */
ExecScanReScan(&node->ss);
}
***************
*** 813,818 **** ExecEndIndexScan(IndexScanState *node)
--- 887,899 ----
indexScanDesc = node->iss_ScanDesc;
relation = node->ss.ss_currentRelation;
+ /* Release VM buffer pin, if any. */
+ if (node->iss_VMBuffer != InvalidBuffer)
+ {
+ ReleaseBuffer(node->iss_VMBuffer);
+ node->iss_VMBuffer = InvalidBuffer;
+ }
+
/*
* Free the exprcontext(s) ... now dead code, see ExecFreeExprContext
*/
diff --git a/src/backend/executor/nodeLimitindex 56d98b4..2a896df 100644
*** a/src/backend/executor/nodeLimit.c
--- b/src/backend/executor/nodeLimit.c
***************
*** 298,309 **** recompute_limits(LimitState *node)
node->lstate = LIMIT_RESCAN;
/*
! * Notify child node about limit. Note: think not to "optimize" by
! * skipping ExecSetTupleBound if compute_tuples_needed returns < 0. We
! * must update the child node anyway, in case this is a rescan and the
* previous time we got a different result.
*/
! ExecSetTupleBound(compute_tuples_needed(node), outerPlanState(node));
}
/*
--- 298,309 ----
node->lstate = LIMIT_RESCAN;
/*
! * Notify child node about limit and offset. Note: think not to "optimize"
! * by skipping ExecSetTupleBound if compute_tuples_needed < 0 and offset = 0.
! * We must update the child node anyway, in case this is a rescan and the
* previous time we got a different result.
*/
! ExecSetTupleBound(compute_tuples_needed(node), node->offset, outerPlanState(node));
}
/*
diff --git a/src/include/executor/execuindex 45a077a..58d9447 100644
*** a/src/include/executor/executor.h
--- b/src/include/executor/executor.h
***************
*** 220,226 **** extern void ExecSetExecProcNode(PlanState *node, ExecProcNodeMtd function);
extern Node *MultiExecProcNode(PlanState *node);
extern void ExecEndNode(PlanState *node);
extern bool ExecShutdownNode(PlanState *node);
! extern void ExecSetTupleBound(int64 tuples_needed, PlanState *child_node);
/* ----------------------------------------------------------------
--- 220,226 ----
extern Node *MultiExecProcNode(PlanState *node);
extern void ExecEndNode(PlanState *node);
extern bool ExecShutdownNode(PlanState *node);
! extern void ExecSetTupleBound(int64 tuples_needed, int64 tuples_to_skip, PlanState *child_node);
/* ----------------------------------------------------------------
diff --git a/src/include/nodes/execnodindex a953820..875011e 100644
*** a/src/include/nodes/execnodes.h
--- b/src/include/nodes/execnodes.h
***************
*** 1228,1233 **** typedef struct IndexScanState
--- 1228,1236 ----
bool *iss_OrderByTypByVals;
int16 *iss_OrderByTypLens;
Size iss_PscanLen;
+ int64 iss_SkipTuples; /* tuple offset, see ExecSetTupleBound */
+ int64 iss_SkipTuplesRemaining; /* tuple offset counter */
+ Buffer iss_VMBuffer; /* buffer used for visibility map in case of iss_SkipTuples > 0 */
} IndexScanState;
/* ----------------
10 марта 2018 г., в 19:20, Michail Nikolaev <michail.nikolaev@gmail.com> написал(а):
Also, I think that this check could be removed from loop. We do not expect that it's state will change during execution, do we?
Removed.
Sorry, seems like I've incorrectly expressed what I wanted to say.
I mean this Assert() can be checked before loop, not on every loop cycle.
Best regards, Andrey Borodin.
Hello.
Sorry, seems like I've incorrectly expressed what I wanted to say.
I mean this Assert() can be checked before loop, not on every loop cycle.
Yes, I understood it. Condition should be checked every cycle - at least it
is done this way for index only scan:
https://github.com/postgres/postgres/blob/master/src/backend/executor/nodeIndexonlyscan.c#L234
But since original index scan do not contains such check (probably due ot
https://github.com/postgres/postgres/blob/master/src/backend/executor/nodeIndexscan.c#L552)
- I think it could be removed.
Michail.
The following review has been posted through the commitfest application:
make installcheck-world: tested, passed
Implements feature: tested, passed
Spec compliant: tested, passed
Documentation: tested, passed
I've tested this patch with different types of order by, including needing recheck, but everything seems to work as expected.
There are some missing spaces before some comment lines and I'm a bit unsure on some lines of code duplicated between nodeIndexonlyscan.c and nodeIndexscan.c
But besides this, I have no more notes on the code.
I think the patch is ready for committer.
Best regards, Andrey Borodin.
The new status of this patch is: Ready for Committer
Michail Nikolaev <michail.nikolaev@gmail.com> writes:
[ offset_index_only_v4.patch ]
I started to go through this patch with the intention of committing it,
but the more I looked at it the less happy I got. What you've done to
IndexNext() is a complete disaster from a modularity standpoint: it now
knows all about the interactions between index_getnext, index_getnext_tid,
and index_fetch_heap. Or that is, it knows too much and still not enough,
because it's flat out wrong for the case that xs_continue_hot is set.
You can't call index_getnext_tid when that's still true from last time.
I'm not sure about a nicer way to refactor that, but I'd suggest that
maybe you need an additional function in indexam.c that hides all this
knowledge about the internal behavior of an IndexScanDesc.
The PredicateLockPage call also troubles me quite a bit, not only from
a modularity standpoint but because that implies a somewhat-user-visible
behavioral change when this optimization activates. People who are using
serializable mode are not going to find it to be an improvement if their
queries fail and need retries a lot more often than they did before.
I don't know if that problem is bad enough that we should disable skipping
when serializable mode is active, but it's something to think about.
You haven't documented the behavior required for tuple-skipping in any
meaningful fashion, particularly not the expectation that the child plan
node will still return tuples that just need not contain any valid
content. Also, this particular implementation of that:
+ ExecClearTuple(slot);
+ slot->tts_isempty = false;
+ slot->tts_nvalid = 0;is a gross hack and probably wrong. You could use ExecStoreAllNullTuple,
perhaps.
I'm disturbed by the fact that you've not taught the planner about the
potential cost saving from this, so that it won't have any particular
reason to pick a regular indexscan over some other plan type when this
optimization applies. Maybe there's no practical way to do that, or maybe
it wouldn't really matter in practice; I've not looked into it. But not
doing anything feels like a hack.
Setting this back to Waiting on Author.
regards, tom lane
Tom, thanks for inspecting the patch.
There's so many problems that slipped from my attention... But one thing that bothers me most is the problem with predicate locking
13 марта 2018 г., в 0:55, Tom Lane <tgl@sss.pgh.pa.us> написал(а):
The PredicateLockPage call also troubles me quite a bit, not only from
a modularity standpoint but because that implies a somewhat-user-visible
behavioral change when this optimization activates. People who are using
serializable mode are not going to find it to be an improvement if their
queries fail and need retries a lot more often than they did before.
I don't know if that problem is bad enough that we should disable skipping
when serializable mode is active, but it's something to think about.
Users already have to expect this if the scan turns into IoS somewhat accidentally. There will be page predicate locks with possible false positive conflicts. I'm not sure that keeping existing tuple-level lock granularity is necessary.
I think we can do it if we introduce PredicateLockTuple that do not require tuple's xmin, that takes only tid and does not look into heap. But this tweak seems outside of the patch scope and I believe it's better avoid messing with SSI internals without strong reason.
Best regards, Andrey Borodin.
Hello.
Tom, thanks a lot for your thorough review.
What you've done to
IndexNext() is a complete disaster from a modularity standpoint: it now
knows all about the interactions between index_getnext, index_getnext_tid,
and index_fetch_heap.
I was looking into the current IndexOnlyNext implementation as a starting
point - and it knows about index_getnext_tid and index_fetch_heap already.
At the same time I was trying to keep patch non-invasive.
Patched IndexNext now only knowns about index_getnext_tid and
index_fetch_heap - the same as IndexOnlyNext.
But yes, it probably could be done better.
I'm not sure about a nicer way to refactor that, but I'd suggest that
maybe you need an additional function in indexam.c that hides all this
knowledge about the internal behavior of an IndexScanDesc.
I'll try to split index_getnext into two functions. A new one will do
everything index_getnext does except index_fetch_heap.
Or that is, it knows too much and still not enough,
because it's flat out wrong for the case that xs_continue_hot is set.
You can't call index_getnext_tid when that's still true from last time.
Oh.. Yes, clear error here.
< The PredicateLockPage call also troubles me quite a bit, not only from
< a modularity standpoint but because that implies a somewhat-user-visible
< behavioral change when this optimization activates. People who are using
< serializable mode are not going to find it to be an improvement if their
< queries fail and need retries a lot more often than they did before.
< I don't know if that problem is bad enough that we should disable skipping
< when serializable mode is active, but it's something to think about.
Current IndexOnlyScan already does that. And I think a user should expect
such a change in serializable mode.
You haven't documented the behavior required for tuple-skipping in any
meaningful fashion, particularly not the expectation that the child plan
node will still return tuples that just need not contain any valid
content.
Only nodeLimit could receive such tuples and they are immediately
discarded. I'll add some comment to it.
is a gross hack and probably wrong. You could use ExecStoreAllNullTuple,
perhaps.
Oh, nice, missed it.
I'm disturbed by the fact that you've not taught the planner about the
potential cost saving from this, so that it won't have any particular
reason to pick a regular indexscan over some other plan type when this
optimization applies. Maybe there's no practical way to do that, or maybe
it wouldn't really matter in practice; I've not looked into it. But not
doing anything feels like a hack.
I was trying to do it. But current planner architecture does not provide a
nice way to achive it due to the way it handles limit and offset.
So, I think it is better to to be avoided for now.
Setting this back to Waiting on Author.
I'll try to make the required changes in a few days.
Thanks.
Hello everyone.
I need an advice.
I was reworking the patch: added support for the planner, added support for
queries with projection, addded support for predicates which could be
executed over index data.
And.. I realized that my IndexScan is even more index-only than the
original IndexOnlyScan. So, it seems to be a wrong way.
I think the task could be splitted into two:
1. Extended support for index-only-scan
Currently IndexOnlyScan is used only in case when target data is fully
located in
index. If we need some additional columns - regular index scan is used
anyway.
For example, let's consider such table and index:
CREATE TABLE test_events (
time timestamp ,
event varchar(255),
data jsonb
);
CREATE INDEX on test_events USING btree(time, event);
It is some kind of big table with log events. And let's consinder such
query:
SELECT data->>'event_id'
FROM test_events
WHERE
time > (now() - interval '2 year') AND -- indexqual
event = 'tax' AND -- indexqual
extract(ISODOW from time) = 1 --qpquals
ORDER BY time DESC
At the moment IndexScan plan will be used for such query due to result
data. But 1/7 of all heap access will be lost. At the same time
"extract(ISODOW from time) = 1" (qpqualsl) could be easily calculated over
index data.
The idea is simple: extend IndexOnly scan to be used if all query
predicates (both indexqual and qpquals) could be calculated over index
data. And if all checks are passed - just load tuple from heap to return.
It seems like index-data access is really cheap now and such plan will
be faster even for qpquals without high selectivity. At least for
READCOMMITED.
I think I will able to create prototype within a few days (most of work
is done in current patch rework).
Probably it is not an ne idea - so, is it worth implementation? Maybe
I've missed something huge.
2. For extented IndexOnlyScan - add support to avoid heap fetch in case of
OFFSET applied to tuple.
If first part is implemented - OFFSET optimisation is much easier to
achieve.
Thanks,
Michail.
Hi!
The work on the patch goes on, where was some discussion of this patch off-list with author.
Advise-request is still actual.
I think that we should move this patch to next CF. So I'm marking patch as needs review.
Best regards, Andrey Borodin.
Hello everyone.
This letter related to “Extended support for index-only-scan” from my
previous message in the thread.
WIP version of the patch is ready for a while now and I think it is time to
resume the work on the feature. BTW, I found a small article about Oracle
vs Postgres focusing this issue -
https://blog.dbi-services.com/postgres-vs-oracle-access-paths-viii/
Current WIP version of the patch is located here -
https://github.com/postgres/postgres/compare/88ba0ae2aa4aaba8ea0d85c0ff81cc46912d9308...michail-nikolaev:index_only_fetch,
passing all checks. In addition, patch includes small optimization for
caching of amcostestimate results.
For now, I decide to name the plan as “Index Only Fetch Scan”. Therefore:
* In case of “Index Scan” – we touch the index and heap for EVERY tuple we
need to test
* For “Index Only Scan” – we touch the index for every tuple and NEVER
touch the heap
* For “Index Only Fetch Scan” – we touch the index for every tuple and
touch the heap for those tuples we need to RETURN ONLY.
I still have no idea – maybe it should be just “Index Only Scan”, or just
“Index Scan” or whatever. Technically, it is implemented inside
nodeIndexonlyscan.c for now.
I made simple test framework based on pg_bench to compare performance under
different conditions. It seems like performance boost mostly depends on two
parameters – index correlation and predicate selectivity (and percentage of
completely visible pages, of course). Testing script is located here -
https://gist.github.com/michail-nikolaev/23e1520a1db1a09ff2b48d78f0cde91d
There are raw testing results for SSD -
https://gist.github.com/michail-nikolaev/9cfbeee1555c6f051822bf1a2b2fe76d .
In addition, some graphics are attached. Basically speaking - optimization
provides great performance impact, especially for indexes with low
correlation and queries with low predicate selectivity. However, to avoid
3-4% performance degradation in opposite cases – it is required to design
and implement accurate costing solution.
I think it could be a great feature, especially together with covering
indexes. However, am I still not sure how to name it, what is a better way
to implement it (custom plan or part of index-only), is any chance to merge
it once it is ready?
It seems to be kind of big deal – new type of scan (ignoring the fact is it
not so new technically). Of course, it applies only to queries with
predicates that are not used for index traverse but could be resolved using
index data (qpquals).
Additionally, OFFSET optimization could be easily achieved once “Index Only
Fetch” is implemented.
Still need some advice here…
Hi, Michail!
21 мая 2018 г., в 20:43, Michail Nikolaev <michail.nikolaev@gmail.com> написал(а):
This letter related to “Extended support for index-only-scan” from my previous message in the thread.
This is great that you continue your work in this direction! The concept of scan that you propose looks interesting.
I have few questions:
1. Charts are measured in percents of pgbench TPS, right?
2. For example, is 97% actually 3% degrade?
3. The results are obtained on actual "sort of TPC-B" script?
Best regards, Andrey Borodin.
Hello.
1. Charts are measured in percents of pgbench TPS, right?
Yes, correct. Actual values are calculated as TPS_of_patched /
TPS_of_vanilla. TPS was measured using single postgres process (one core)
(I was also did tests with multiple processes, but they shows pretty same
results).
2. For example, is 97% actually 3% degrade?
Yes, such degrade happens for indexes with high correlation and predicates
with low selectivity. In such cases 2-4% overhead is caused by index data
read and page visibility check. But it is possible to detect such cases in
planner and use regular IndexScan instead.
3. The results are obtained on actual "sort of TPC-B" script?
You could check testing script (
https://gist.github.com/michail-nikolaev/23e1520a1db1a09ff2b48d78f0cde91d)
for SQL queries.
But briefly:
* Vanilla pg_bench initialization
* ALTER TABLE pgbench_accounts drop constraint pgbench_accounts_pkey; --
drop non-required constraint
* UPDATE pgbench_accounts SET bid = TRUNC(RANDOM() * {ROWS_N} + 1 --
randomize BID (used for selectivy predicate)
* UPDATE pgbench_accounts SET aid = TRUNC(RANDOM() * {ROWS_N} + 1) WHERE
random() <= (1.0 - {CORRELATION}) -- emulate index correlation by changing
some part of AID values
* CREATE index test_index ON pgbench_accounts USING btree(aid, bid) --
create index used for test
* VACUUM FULL;
* VACUUM ANALYZE pgbench_accounts;
* SELECT * FROM pgbench_accounts WHERE aid > {RANDOM} and bid % 100 <=
{SELECTIVITY} order by aid limit 50
Thanks,
Michail.
On 21/05/18 18:43, Michail Nikolaev wrote:
Hello everyone.
This letter related to “Extended support for index-only-scan” from my
previous message in the thread.WIP version of the patch is ready for a while now and I think it is time to
resume the work on the feature. BTW, I found a small article about Oracle
vs Postgres focusing this issue -
https://blog.dbi-services.com/postgres-vs-oracle-access-paths-viii/Current WIP version of the patch is located here -
https://github.com/postgres/postgres/compare/88ba0ae2aa4aaba8ea0d85c0ff81cc46912d9308...michail-nikolaev:index_only_fetch,
passing all checks. In addition, patch includes small optimization for
caching of amcostestimate results.
Please submit an actual path, extracted e.g. with "git format-patch
-n1", rather than a link to an external site. That is a requirement for
archival purposes, so that people reading the email archives later on
can see what was being discussed. (And that link doesn't return a proper
diff, anyway.)
For now, I decide to name the plan as “Index Only Fetch Scan”. Therefore:
* In case of “Index Scan” – we touch the index and heap for EVERY tuple we
need to test
* For “Index Only Scan” – we touch the index for every tuple and NEVER
touch the heap
* For “Index Only Fetch Scan” – we touch the index for every tuple and
touch the heap for those tuples we need to RETURN ONLY.
Hmm. IIRC there was some discussion on doing that, when index-only scans
were implemented. It's not generally OK to evaluate expressions based on
data that has already been deleted from the table. As an example of the
kind of problems you might get:
Imagine that a user does "DELETE * FROM table WHERE div = 0; SELECT *
FROM table WHERE 100 / div < 10". Would you expect the query to throw a
"division by zero error"? If there was an index on 'div', you might
evaluate the "100 / div" expression based on values from the index,
which still includes entries for the just-deleted tuples with div = 0.
They would be filtered out later, after performing the visibility
checks, but it's too late if you already threw an error.
Now, maybe there's some way around that, but I don't know what. Without
some kind of a solution, this won't work.
- Heikki
Hello.
Thanks a lot for your feedback. I'll try to update patch in few days
(currently stuck at small performance regression in unknown place).
Regarding issue with delete: yes, it is valid point, but record removing
should clear visibility buffer - and tuple will be fetched from heap to
test its existance. In such case expression are not evaluated at all. Not
sure for delete and query in same transaction - I'll check.
Also, need to recheck possible issues with EvalPlanQual.
PS.
Updated link in case someone want to briefly see code until git patch is
ready:
https://github.com/michail-nikolaev/postgres/compare/e3eb8be77ef82ccc8f87c515f96d01bf7c726ca8...michail-nikolaev:index_only_fetch?ts=4
сб, 14 июл. 2018 г. в 0:17, Heikki Linnakangas <hlinnaka@iki.fi>:
Show quoted text
On 21/05/18 18:43, Michail Nikolaev wrote:
Hello everyone.
This letter related to “Extended support for index-only-scan” from my
previous message in the thread.WIP version of the patch is ready for a while now and I think it is time
to
resume the work on the feature. BTW, I found a small article about Oracle
vs Postgres focusing this issue -
https://blog.dbi-services.com/postgres-vs-oracle-access-paths-viii/Current WIP version of the patch is located here -
passing all checks. In addition, patch includes small optimization for
caching of amcostestimate results.Please submit an actual path, extracted e.g. with "git format-patch
-n1", rather than a link to an external site. That is a requirement for
archival purposes, so that people reading the email archives later on
can see what was being discussed. (And that link doesn't return a proper
diff, anyway.)For now, I decide to name the plan as “Index Only Fetch Scan”. Therefore:
* In case of “Index Scan” – we touch the index and heap for EVERY tuplewe
need to test
* For “Index Only Scan” – we touch the index for every tuple and NEVER
touch the heap
* For “Index Only Fetch Scan” – we touch the index for every tuple and
touch the heap for those tuples we need to RETURN ONLY.Hmm. IIRC there was some discussion on doing that, when index-only scans
were implemented. It's not generally OK to evaluate expressions based on
data that has already been deleted from the table. As an example of the
kind of problems you might get:Imagine that a user does "DELETE * FROM table WHERE div = 0; SELECT *
FROM table WHERE 100 / div < 10". Would you expect the query to throw a
"division by zero error"? If there was an index on 'div', you might
evaluate the "100 / div" expression based on values from the index,
which still includes entries for the just-deleted tuples with div = 0.
They would be filtered out later, after performing the visibility
checks, but it's too late if you already threw an error.Now, maybe there's some way around that, but I don't know what. Without
some kind of a solution, this won't work.- Heikki
On Mon, Jul 16, 2018 at 02:11:57PM +0300, Michail Nikolaev wrote:
Thanks a lot for your feedback. I'll try to update patch in few days
(currently stuck at small performance regression in unknown place).
Okay, it has been more than a couple of days and the patch has not been
updated, so I am marking as returned with feedback.
--
Michael
Hello.
Okay, it has been more than a couple of days and the patch has not been
updated, so I am marking as returned with feedback.
Yes, it is more than couple of days passed, but also there is almost no
feedback since 20 Mar after patch design was changed :)
But seriously - I still working on it and was digging into just last night
( https://github.com/michail-nikolaev/postgres/commits/index_only_fetch )
The main issue currently is a cost estimation. In right case (10m relation,
0.5 index correlation, 0.1 selectivity for filter) - it works like a charm
with 200%-400% performance boost.
But the same case with 1.0 selectivity gives 96% comparing to baseline. So,
to do correct cost estimation I need correct selectivity of filter
predicate.
Currently I am thinking to calculate it on fly - and switch to the new
method if selectivity is small. But it feels a little akward.
Thanks,
Michail.
Hi!
2 окт. 2018 г., в 11:55, Michail Nikolaev <michail.nikolaev@gmail.com> написал(а):
Okay, it has been more than a couple of days and the patch has not been
updated, so I am marking as returned with feedback.Yes, it is more than couple of days passed, but also there is almost no feedback since 20 Mar after patch design was changed :)
But seriously - I still working on it
Let's move this to CF 2018-11? Obviously, it is WiP, but it seems that patch is being discussed, author cares about it.
Best regards, Andrey Borodin.
On Wed, Oct 03, 2018 at 10:54:14AM +0500, Andrey Borodin wrote:
Let's move this to CF 2018-11? Obviously, it is WiP, but it seems that
patch is being discussed, author cares about it.
If you are still working on it, which is not something obvious based on
the thread activity, then moving it to next commit fest could make
sense. However please post a new patch first and then address the
comments your patch has received before doing so.
--
Michael
