GIN improvements part2: fast scan

On Sat, Jun 15, 2013 at 2:55 AM, Alexander Korotkov <aekorotkov@gmail.com>wrote:

attached patch implementing "fast scan" technique for GIN. This is second
patch of GIN improvements, see the 1st one here:

/messages/by-id/CAPpHfduxv-iL7aedwPW0W5fXrWGAKfxijWM63_hZujaCRxnmFQ@mail.gmail.com
This patch allow to skip parts of posting trees when their scan is not
necessary. In particular, it solves "frequent_term & rare_term" problem of
FTS.
It introduces new interface method pre_consistent which behaves like
consistent, but:
1) allows false positives on input (check[])
2) allowed to return false positives

Some example: "frequent_term & rare_term" becomes pretty fast.

create table test as (select to_tsvector('english', 'bbb') as v from
generate_series(1,1000000));
insert into test (select to_tsvector('english', 'ddd') from
generate_series(1,10));
create index test_idx on test using gin (v);

postgres=# explain analyze select * from test where v @@
to_tsquery('english', 'bbb & ddd');
QUERY PLAN

-----------------------------------------------------------------------------------------------------------------------
Bitmap Heap Scan on test (cost=942.75..7280.63 rows=5000 width=17)
(actual time=0.458..0.461 rows=10 loops=1)
Recheck Cond: (v @@ '''bbb'' & ''ddd'''::tsquery)
-> Bitmap Index Scan on test_idx (cost=0.00..941.50 rows=5000
width=0) (actual time=0.449..0.449 rows=10 loops=1)
Index Cond: (v @@ '''bbb'' & ''ddd'''::tsquery)
Total runtime: 0.516 ms
(5 rows)

Attached version of patch has some refactoring and bug fixes.

------
With best regards,
Alexander Korotkov.

On 17.06.2013 15:55, Alexander Korotkov wrote:

On Sat, Jun 15, 2013 at 2:55 AM, Alexander Korotkov<aekorotkov@gmail.com>wrote:

attached patch implementing "fast scan" technique for GIN. This is second
patch of GIN improvements, see the 1st one here:

/messages/by-id/CAPpHfduxv-iL7aedwPW0W5fXrWGAKfxijWM63_hZujaCRxnmFQ@mail.gmail.com
This patch allow to skip parts of posting trees when their scan is not
necessary. In particular, it solves "frequent_term& rare_term" problem of
FTS.
It introduces new interface method pre_consistent which behaves like
consistent, but:
1) allows false positives on input (check[])
2) allowed to return false positives

Some example: "frequent_term& rare_term" becomes pretty fast.

create table test as (select to_tsvector('english', 'bbb') as v from
generate_series(1,1000000));
insert into test (select to_tsvector('english', 'ddd') from
generate_series(1,10));
create index test_idx on test using gin (v);

postgres=# explain analyze select * from test where v @@
to_tsquery('english', 'bbb& ddd');
QUERY PLAN

-----------------------------------------------------------------------------------------------------------------------
Bitmap Heap Scan on test (cost=942.75..7280.63 rows=5000 width=17)
(actual time=0.458..0.461 rows=10 loops=1)
Recheck Cond: (v @@ '''bbb''& ''ddd'''::tsquery)
-> Bitmap Index Scan on test_idx (cost=0.00..941.50 rows=5000
width=0) (actual time=0.449..0.449 rows=10 loops=1)
Index Cond: (v @@ '''bbb''& ''ddd'''::tsquery)
Total runtime: 0.516 ms
(5 rows)

Attached version of patch has some refactoring and bug fixes.

Good timing, I just started looking at this.

I think you'll need to explain how this works. There are no docs, and
almost no comments.

(and this shows how poorly I understand this, but) Why does this require
the "additional information" patch? What extra information do you store
on-disk, in the additional information?

The pre-consistent method is like the consistent method, but it allows
false positives. I think that's because during the scan, before having
scanned for all the keys, the gin AM doesn't yet know if the tuple
contains all of the keys. So it passes the keys it doesn't yet know
about as 'true' to pre-consistent. Could that be generalized, to pass a
tri-state instead of a boolean for each key to the pre-consistent
method? For each key, you would pass "true", "false", or "don't know". I
think you could then also speed up queries like "!english & bbb".

- Heikki

--
Sent via pgsql-hackers mailing list (pgsql-hackers@postgresql.org)
To make changes to your subscription:
http://www.postgresql.org/mailpref/pgsql-hackers

On Mon, Jun 17, 2013 at 5:09 PM, Heikki Linnakangas <hlinnakangas@vmware.com

wrote:

On 17.06.2013 15:55, Alexander Korotkov wrote:

On Sat, Jun 15, 2013 at 2:55 AM, Alexander Korotkov<aekorotkov@gmail.com>
**wrote:

attached patch implementing "fast scan" technique for GIN. This is second

patch of GIN improvements, see the 1st one here:

http://www.postgresql.org/**message-id/CAPpHfduxv-**
iL7aedwPW0W5fXrWGAKfxijWM63_**hZujaCRxnmFQ@mail.gmail.com</messages/by-id/CAPpHfduxv-iL7aedwPW0W5fXrWGAKfxijWM63_hZujaCRxnmFQ@mail.gmail.com&gt;
This patch allow to skip parts of posting trees when their scan is not
necessary. In particular, it solves "frequent_term& rare_term" problem
of

FTS.
It introduces new interface method pre_consistent which behaves like
consistent, but:
1) allows false positives on input (check[])
2) allowed to return false positives

Some example: "frequent_term& rare_term" becomes pretty fast.

create table test as (select to_tsvector('english', 'bbb') as v from
generate_series(1,1000000));
insert into test (select to_tsvector('english', 'ddd') from
generate_series(1,10));
create index test_idx on test using gin (v);

postgres=# explain analyze select * from test where v @@
to_tsquery('english', 'bbb& ddd');

QUERY PLAN

------------------------------**------------------------------**
------------------------------**-----------------------------
Bitmap Heap Scan on test (cost=942.75..7280.63 rows=5000 width=17)
(actual time=0.458..0.461 rows=10 loops=1)
Recheck Cond: (v @@ '''bbb''& ''ddd'''::tsquery)
-> Bitmap Index Scan on test_idx (cost=0.00..941.50 rows=5000
width=0) (actual time=0.449..0.449 rows=10 loops=1)
Index Cond: (v @@ '''bbb''& ''ddd'''::tsquery)
Total runtime: 0.516 ms
(5 rows)

Attached version of patch has some refactoring and bug fixes.

Good timing, I just started looking at this.

I think you'll need to explain how this works. There are no docs, and
almost no comments.

Sorry for that. I'll post patch with docs and comments in couple days.

(and this shows how poorly I understand this, but) Why does this require

the "additional information" patch?

In principle, it doesn't require "additional information" patch. Same
optimization could be done without "additional information". The reason why
it requires "additional information" patch is that otherwise I have to
implement and maintain 2 versions of "fast scan": with and without
"additional information".

What extra information do you store on-disk, in the additional information?

It depends on opclass. In regex patch it is part of graph associated with
trigram. In fulltext search it is word positions. In array similarity
search it could be length of array for better estimation of similarity (not
implemented yet). So it's anything which is stored with each ItemPointer
and is useful for consistent or index driven sorting (see patch #3).

The pre-consistent method is like the consistent method, but it allows
false positives. I think that's because during the scan, before having
scanned for all the keys, the gin AM doesn't yet know if the tuple contains
all of the keys. So it passes the keys it doesn't yet know about as 'true'
to pre-consistent.

Could that be generalized, to pass a tri-state instead of a boolean for

each key to the pre-consistent method? For each key, you would pass "true",
"false", or "don't know". I think you could then also speed up queries like
"!english & bbb".

I would like to illustrate that on example. Imagine you have fulltext query
"rare_term & frequent_term". Frequent term has large posting tree while
rare term has only small posting list containing iptr1, iptr2 and iptr3. At
first we get iptr1 from posting list of rare term, then we would like to
check whether we have to scan part of frequent term posting tree where iptr
< iptr1. So we call pre_consistent([false, true]), because we know that
rare term is not present for iptr < iptr2. pre_consistent returns false. So
we can start scanning frequent term posting tree from iptr1. Similarly we
can skip lags between iptr1 and iptr2, iptr2 and iptr3, from iptr3 to
maximum possible pointer.

And yes, it could be generalized to tri-state instead of a boolean. I had
that idea first. But I found superiority of exact "true" quite narrow.
Let's see it on the example. If you have "!term1 & term2" there are few
cases:
1) term1 is rare, term2 is frequent => you can exclude only some entries
from posting tree of term2, performance benefit will be negligible
2) term1 is frequent, term2 is rare => you should actually scan term2
posting list and then check term1 posting tree like in example about
"rare_term & frequent_term", so there is no need of tri-state to handle
this situation
3) term1 is frequent, term2 is frequent => this case probably could be
optimized by tri-state. But in order to actully skip some parts of term2
posting tree you need item pointers in term1 to go sequential. It seems for
me to be very narrow case.
4) term1 is rare, term2 is rare => don't need optimization

BTW, version of patch with some bug fixes is attached.

------
With best regards,
Alexander Korotkov.

On 18.06.2013 23:59, Alexander Korotkov wrote:

I would like to illustrate that on example. Imagine you have fulltext query
"rare_term& frequent_term". Frequent term has large posting tree while
rare term has only small posting list containing iptr1, iptr2 and iptr3. At
first we get iptr1 from posting list of rare term, then we would like to
check whether we have to scan part of frequent term posting tree where iptr
< iptr1. So we call pre_consistent([false, true]), because we know that
rare term is not present for iptr< iptr2. pre_consistent returns false. So
we can start scanning frequent term posting tree from iptr1. Similarly we
can skip lags between iptr1 and iptr2, iptr2 and iptr3, from iptr3 to
maximum possible pointer.

Thanks, now I understand the rare-term & frequent-term problem. Couldn't
you do that with the existing consistent function? I don't see why you
need the new pre-consistent function for this.

- Heikki

--
Sent via pgsql-hackers mailing list (pgsql-hackers@postgresql.org)
To make changes to your subscription:
http://www.postgresql.org/mailpref/pgsql-hackers

On Wed, Jun 19, 2013 at 11:48 AM, Heikki Linnakangas <
hlinnakangas@vmware.com> wrote:

On 18.06.2013 23:59, Alexander Korotkov wrote:

I would like to illustrate that on example. Imagine you have fulltext
query
"rare_term& frequent_term". Frequent term has large posting tree while

rare term has only small posting list containing iptr1, iptr2 and iptr3.
At
first we get iptr1 from posting list of rare term, then we would like to
check whether we have to scan part of frequent term posting tree where
iptr
< iptr1. So we call pre_consistent([false, true]), because we know that
rare term is not present for iptr< iptr2. pre_consistent returns false.
So
we can start scanning frequent term posting tree from iptr1. Similarly we
can skip lags between iptr1 and iptr2, iptr2 and iptr3, from iptr3 to
maximum possible pointer.

Thanks, now I understand the rare-term & frequent-term problem. Couldn't
you do that with the existing consistent function? I don't see why you need
the new pre-consistent function for this.

In the case of two entries I can. But in the case of n entries things
becomes more complicated. Imagine you have "term_1 & term_2 & ... & term_n"
query. When you get some item pointer from term_1 you can skip all the
lesser item pointers from term_2, term_3 ... term_n. But if all you have
for it is consistent function you have to call it with following check
arguments:
1) [false, false, false, ... , false]
2) [false, true, false, ... , false]
3) [false, false, true, ... , false]
4) [false, true, true, ..., false]
......
i.e. you have to call it 2^(n-1) times. But if you know the query specific
(i.e. in opclass) it's typically easy to calculate exactly what we need in
single pass. That's why I introduced pre_consistent.

------
With best regards,
Alexander Korotkov.

On Wed, Jun 19, 2013 at 12:30 PM, Alexander Korotkov
<aekorotkov@gmail.com>wrote:

On Wed, Jun 19, 2013 at 11:48 AM, Heikki Linnakangas <
hlinnakangas@vmware.com> wrote:

On 18.06.2013 23:59, Alexander Korotkov wrote:

I would like to illustrate that on example. Imagine you have fulltext
query
"rare_term& frequent_term". Frequent term has large posting tree while

rare term has only small posting list containing iptr1, iptr2 and iptr3.
At
first we get iptr1 from posting list of rare term, then we would like to
check whether we have to scan part of frequent term posting tree where
iptr
< iptr1. So we call pre_consistent([false, true]), because we know that
rare term is not present for iptr< iptr2. pre_consistent returns false.
So
we can start scanning frequent term posting tree from iptr1. Similarly we
can skip lags between iptr1 and iptr2, iptr2 and iptr3, from iptr3 to
maximum possible pointer.

Thanks, now I understand the rare-term & frequent-term problem. Couldn't
you do that with the existing consistent function? I don't see why you need
the new pre-consistent function for this.

In the case of two entries I can. But in the case of n entries things
becomes more complicated. Imagine you have "term_1 & term_2 & ... & term_n"
query. When you get some item pointer from term_1 you can skip all the
lesser item pointers from term_2, term_3 ... term_n. But if all you have
for it is consistent function you have to call it with following check
arguments:
1) [false, false, false, ... , false]
2) [false, true, false, ... , false]
3) [false, false, true, ... , false]
4) [false, true, true, ..., false]
......
i.e. you have to call it 2^(n-1) times.

To be precise you don't need the first check argument I listed. So, it's
2^(n-1)-1 calls.

------
With best regards,
Alexander Korotkov.

On 19.06.2013 11:30, Alexander Korotkov wrote:

On Wed, Jun 19, 2013 at 11:48 AM, Heikki Linnakangas<
hlinnakangas@vmware.com> wrote:

On 18.06.2013 23:59, Alexander Korotkov wrote:

I would like to illustrate that on example. Imagine you have fulltext
query
"rare_term& frequent_term". Frequent term has large posting tree while

rare term has only small posting list containing iptr1, iptr2 and iptr3.
At
first we get iptr1 from posting list of rare term, then we would like to
check whether we have to scan part of frequent term posting tree where
iptr
< iptr1. So we call pre_consistent([false, true]), because we know that
rare term is not present for iptr< iptr2. pre_consistent returns false.
So
we can start scanning frequent term posting tree from iptr1. Similarly we
can skip lags between iptr1 and iptr2, iptr2 and iptr3, from iptr3 to
maximum possible pointer.

Thanks, now I understand the rare-term& frequent-term problem. Couldn't
you do that with the existing consistent function? I don't see why you need
the new pre-consistent function for this.

In the case of two entries I can. But in the case of n entries things
becomes more complicated. Imagine you have "term_1& term_2& ...& term_n"
query. When you get some item pointer from term_1 you can skip all the
lesser item pointers from term_2, term_3 ... term_n. But if all you have
for it is consistent function you have to call it with following check
arguments:
1) [false, false, false, ... , false]
2) [false, true, false, ... , false]
3) [false, false, true, ... , false]
4) [false, true, true, ..., false]
......
i.e. you have to call it 2^(n-1) times. But if you know the query specific
(i.e. in opclass) it's typically easy to calculate exactly what we need in
single pass. That's why I introduced pre_consistent.

Hmm. So how does that work with the pre-consistent function? Don't you
need to call that 2^(n-1)-1 times as well?

- Heikki

--
Sent via pgsql-hackers mailing list (pgsql-hackers@postgresql.org)
To make changes to your subscription:
http://www.postgresql.org/mailpref/pgsql-hackers

On Wed, Jun 19, 2013 at 12:49 PM, Heikki Linnakangas <
hlinnakangas@vmware.com> wrote:

On 19.06.2013 11:30, Alexander Korotkov wrote:

On Wed, Jun 19, 2013 at 11:48 AM, Heikki Linnakangas<
hlinnakangas@vmware.com> wrote:

On 18.06.2013 23:59, Alexander Korotkov wrote:

I would like to illustrate that on example. Imagine you have fulltext

query
"rare_term& frequent_term". Frequent term has large posting tree while

rare term has only small posting list containing iptr1, iptr2 and iptr3.
At
first we get iptr1 from posting list of rare term, then we would like to
check whether we have to scan part of frequent term posting tree where
iptr
< iptr1. So we call pre_consistent([false, true]), because we know
that
rare term is not present for iptr< iptr2. pre_consistent returns
false.
So
we can start scanning frequent term posting tree from iptr1. Similarly
we
can skip lags between iptr1 and iptr2, iptr2 and iptr3, from iptr3 to
maximum possible pointer.

Thanks, now I understand the rare-term& frequent-term problem. Couldn't

you do that with the existing consistent function? I don't see why you
need
the new pre-consistent function for this.

In the case of two entries I can. But in the case of n entries things
becomes more complicated. Imagine you have "term_1& term_2& ...&
term_n"

query. When you get some item pointer from term_1 you can skip all the
lesser item pointers from term_2, term_3 ... term_n. But if all you have
for it is consistent function you have to call it with following check
arguments:
1) [false, false, false, ... , false]
2) [false, true, false, ... , false]
3) [false, false, true, ... , false]
4) [false, true, true, ..., false]
......
i.e. you have to call it 2^(n-1) times. But if you know the query specific
(i.e. in opclass) it's typically easy to calculate exactly what we need in
single pass. That's why I introduced pre_consistent.

Hmm. So how does that work with the pre-consistent function? Don't you
need to call that 2^(n-1)-1 times as well?

I call pre-consistent once with [false, true, true, ..., true].
Pre-consistent knows that each true passed to it could be false positive.
So, if it returns false it guarantees that consistent will be false for all
possible combinations.

------
With best regards,
Alexander Korotkov.

On 19.06.2013 11:56, Alexander Korotkov wrote:

On Wed, Jun 19, 2013 at 12:49 PM, Heikki Linnakangas<
hlinnakangas@vmware.com> wrote:

On 19.06.2013 11:30, Alexander Korotkov wrote:

On Wed, Jun 19, 2013 at 11:48 AM, Heikki Linnakangas<
hlinnakangas@vmware.com> wrote:

On 18.06.2013 23:59, Alexander Korotkov wrote:

I would like to illustrate that on example. Imagine you have fulltext

query
"rare_term& frequent_term". Frequent term has large posting tree while

rare term has only small posting list containing iptr1, iptr2 and iptr3.
At
first we get iptr1 from posting list of rare term, then we would like to
check whether we have to scan part of frequent term posting tree where
iptr
< iptr1. So we call pre_consistent([false, true]), because we know
that
rare term is not present for iptr< iptr2. pre_consistent returns
false.
So
we can start scanning frequent term posting tree from iptr1. Similarly
we
can skip lags between iptr1 and iptr2, iptr2 and iptr3, from iptr3 to
maximum possible pointer.

Thanks, now I understand the rare-term& frequent-term problem. Couldn't

you do that with the existing consistent function? I don't see why you
need
the new pre-consistent function for this.

In the case of two entries I can. But in the case of n entries things
becomes more complicated. Imagine you have "term_1& term_2& ...&
term_n"

query. When you get some item pointer from term_1 you can skip all the
lesser item pointers from term_2, term_3 ... term_n. But if all you have
for it is consistent function you have to call it with following check
arguments:
1) [false, false, false, ... , false]
2) [false, true, false, ... , false]
3) [false, false, true, ... , false]
4) [false, true, true, ..., false]
......
i.e. you have to call it 2^(n-1) times. But if you know the query specific
(i.e. in opclass) it's typically easy to calculate exactly what we need in
single pass. That's why I introduced pre_consistent.

Hmm. So how does that work with the pre-consistent function? Don't you
need to call that 2^(n-1)-1 times as well?

I call pre-consistent once with [false, true, true, ..., true].
Pre-consistent knows that each true passed to it could be false positive.
So, if it returns false it guarantees that consistent will be false for all
possible combinations.

Ok, I see.

I spent some time pondering this. I'd like to find a way to do something
about this without requiring another user-defined function. A couple of
observations:

1. The profile of that rare-term & frequent-term quest, without any
patch, looks like this:

28,55% postgres ginCompareItemPointers
19,36% postgres keyGetItem
15,20% postgres scanGetItem
7,75% postgres checkcondition_gin
6,25% postgres gin_tsquery_consistent
4,34% postgres TS_execute
3,85% postgres callConsistentFn
3,64% postgres FunctionCall8Coll
3,19% postgres check_stack_depth
2,60% postgres entryGetNextItem
1,35% postgres entryGetItem
1,25% postgres MemoryContextReset
1,12% postgres MemoryContextSwitchTo
0,31% libc-2.17.so __memcpy_ssse3_back
0,24% postgres collectMatchesForHeapRow

I was quite surprised by seeing ginCompareItemPointers at the top. It
turns out that it's relatively expensive to do comparisons in the format
we keep item pointers, packed in 6 bytes, in 3 int16s. I hacked together
a patch to convert ItemPointers into uint64s, when dealing with them in
memory. That helped quite a bit.

Another important thing in the above profile is that calling
consistent-function is taking up a lot of resources. And in the example
test case you gave, it's called with the same arguments every time.
Caching the result of consistent-function would be a big win.

I wrote a quick patch to do that caching, and together with the
itempointer hack, I was able to halve the runtime of that test case.
That's impressive, we probably should pursue that low-hanging fruit, but
it's still slower than your "fast scan" patch by a factor of 100x. So
clearly we do need an algorithmic improvement here, along the lines of
your patch, or something similar.

2. There's one trick we could do even without the pre-consistent
function, that would help the particular test case you gave. Suppose
that you have two search terms A and B. If you have just called
consistent on a row that matched term A, but not term B, you can skip
any subsequent rows in the scan that match A but not B. That means that
you can skip over to the next row that matches B. This is essentially
the same thing you do with the pre-consistent function, it's just a
degenerate case of it. That helps as long as the search contains only
one frequent term, but if it contains multiple, then you have to still
stop at every row that matches more than one of the frequent terms.

3. I'm still not totally convinced that we shouldn't just build the
"truth table" by calling the regular consistent function with all the
combinations of matching keys, as discussed above. I think that would
work pretty well in practice, for queries with up to 5-10 frequent
terms. Per the profiling, it probably would make sense to pre-compute
such a table anyway, to avoid calling consistent repeatedly.

4. If we do go with a new function, I'd like to just call it
"consistent" (or consistent2 or something, to keep it separate form the
old consistent function), and pass it a tri-state input for each search
term. It might not be any different for the full-text search
implementation, or any of the other ones for that matter, but I think it
would be a more understandable API.

- Heikki

--
Sent via pgsql-hackers mailing list (pgsql-hackers@postgresql.org)
To make changes to your subscription:
http://www.postgresql.org/mailpref/pgsql-hackers

On Fri, Jun 21, 2013 at 11:43 PM, Heikki Linnakangas <
hlinnakangas@vmware.com> wrote:

On 19.06.2013 11:56, Alexander Korotkov wrote:

On Wed, Jun 19, 2013 at 12:49 PM, Heikki Linnakangas<
hlinnakangas@vmware.com> wrote:

On 19.06.2013 11:30, Alexander Korotkov wrote:

On Wed, Jun 19, 2013 at 11:48 AM, Heikki Linnakangas<

hlinnakangas@vmware.com> wrote:

On 18.06.2013 23:59, Alexander Korotkov wrote:

I would like to illustrate that on example. Imagine you have fulltext

query
"rare_term& frequent_term". Frequent term has large posting tree
while

rare term has only small posting list containing iptr1, iptr2 and
iptr3.
At
first we get iptr1 from posting list of rare term, then we would like
to
check whether we have to scan part of frequent term posting tree where
iptr
< iptr1. So we call pre_consistent([false, true]), because we know
that
rare term is not present for iptr< iptr2. pre_consistent returns
false.
So
we can start scanning frequent term posting tree from iptr1. Similarly
we
can skip lags between iptr1 and iptr2, iptr2 and iptr3, from iptr3 to
maximum possible pointer.

Thanks, now I understand the rare-term& frequent-term problem.

Couldn't

you do that with the existing consistent function? I don't see why you
need
the new pre-consistent function for this.

In the case of two entries I can. But in the case of n entries things
becomes more complicated. Imagine you have "term_1& term_2& ...&
term_n"

query. When you get some item pointer from term_1 you can skip all the
lesser item pointers from term_2, term_3 ... term_n. But if all you have
for it is consistent function you have to call it with following check
arguments:
1) [false, false, false, ... , false]
2) [false, true, false, ... , false]
3) [false, false, true, ... , false]
4) [false, true, true, ..., false]
......
i.e. you have to call it 2^(n-1) times. But if you know the query
specific
(i.e. in opclass) it's typically easy to calculate exactly what we need
in
single pass. That's why I introduced pre_consistent.

Hmm. So how does that work with the pre-consistent function? Don't you
need to call that 2^(n-1)-1 times as well?

I call pre-consistent once with [false, true, true, ..., true].
Pre-consistent knows that each true passed to it could be false positive.
So, if it returns false it guarantees that consistent will be false for
all
possible combinations.

Ok, I see.

I spent some time pondering this. I'd like to find a way to do something
about this without requiring another user-defined function. A couple of
observations:

1. The profile of that rare-term & frequent-term quest, without any patch,
looks like this:

28,55% postgres ginCompareItemPointers
19,36% postgres keyGetItem
15,20% postgres scanGetItem
7,75% postgres checkcondition_gin
6,25% postgres gin_tsquery_consistent
4,34% postgres TS_execute
3,85% postgres callConsistentFn
3,64% postgres FunctionCall8Coll
3,19% postgres check_stack_depth
2,60% postgres entryGetNextItem
1,35% postgres entryGetItem
1,25% postgres MemoryContextReset
1,12% postgres MemoryContextSwitchTo
0,31% libc-2.17.so __memcpy_ssse3_back
0,24% postgres collectMatchesForHeapRow

I was quite surprised by seeing ginCompareItemPointers at the top. It
turns out that it's relatively expensive to do comparisons in the format we
keep item pointers, packed in 6 bytes, in 3 int16s. I hacked together a
patch to convert ItemPointers into uint64s, when dealing with them in
memory. That helped quite a bit.

Another important thing in the above profile is that calling
consistent-function is taking up a lot of resources. And in the example
test case you gave, it's called with the same arguments every time. Caching
the result of consistent-function would be a big win.

I wrote a quick patch to do that caching, and together with the
itempointer hack, I was able to halve the runtime of that test case. That's
impressive, we probably should pursue that low-hanging fruit, but it's
still slower than your "fast scan" patch by a factor of 100x. So clearly we
do need an algorithmic improvement here, along the lines of your patch, or
something similar.

For sure, many advantages can be achieved without "fast scan". For example,
sphinx is known to be fast, but it straightforwardly scan each posting list
just like GIN now.

2. There's one trick we could do even without the pre-consistent function,
that would help the particular test case you gave. Suppose that you have
two search terms A and B. If you have just called consistent on a row that
matched term A, but not term B, you can skip any subsequent rows in the
scan that match A but not B. That means that you can skip over to the next
row that matches B. This is essentially the same thing you do with the
pre-consistent function, it's just a degenerate case of it. That helps as
long as the search contains only one frequent term, but if it contains
multiple, then you have to still stop at every row that matches more than
one of the frequent terms.

Yes, two terms case is confluent and there is no direct need of
preConsistent.

3. I'm still not totally convinced that we shouldn't just build the "truth
table" by calling the regular consistent function with all the combinations
of matching keys, as discussed above. I think that would work pretty well
in practice, for queries with up to 5-10 frequent terms. Per the profiling,
it probably would make sense to pre-compute such a table anyway, to avoid
calling consistent repeatedly.

Why do you mention 5-10 _frequent_ items? If we have 5-10 frequent items
and 20 rare items we would have to create "truth table" of frequent items
for each new combination of rare items. For 20 rare items truth
combinations can be unique for each item pointer, in that case you would
have to calculate small "truth table" of frequent items for each item
pointers. And then it can appear to be not so small. I mean it seems to me
that we should take into account both "frequent" and "rare" items when
talking about "truth table".

4. If we do go with a new function, I'd like to just call it "consistent"
(or consistent2 or something, to keep it separate form the old consistent
function), and pass it a tri-state input for each search term. It might not
be any different for the full-text search implementation, or any of the
other ones for that matter, but I think it would be a more understandable
API.

Understandable API makes sense. But for now, I can't see even potentional
usage of third state (exact false). Also, with preConsistent interface "as
is" in some cases we can use old consistent method as both consistent and
preConsistent when it implements monotonous boolean function. For example,
it's consistent function for opclasses of arrays.

Revised version of patch is attaches with more comments and docs.

------
With best regards,
Alexander Korotkov.

On Tue, Jun 25, 2013 at 2:20 AM, Alexander Korotkov <aekorotkov@gmail.com>wrote:

4. If we do go with a new function, I'd like to just call it "consistent"

(or consistent2 or something, to keep it separate form the old consistent
function), and pass it a tri-state input for each search term. It might not
be any different for the full-text search implementation, or any of the
other ones for that matter, but I think it would be a more understandable
API.

Understandable API makes sense. But for now, I can't see even potentional
usage of third state (exact false).

Typo here. I meant "exact true".

Also, with preConsistent interface "as is" in some cases we can use old
consistent method as both consistent and preConsistent when it implements
monotonous boolean function. For example, it's consistent function for
opclasses of arrays.

Now, I got the point of three state consistent: we can keep only one
consistent in opclasses that support new interface. exact true and exact
false values will be passed in the case of current patch consistent; exact
false and unknown will be passed in the case of current patch
preConsistent. That's reasonable.

------
With best regards,
Alexander Korotkov.

On 28.06.2013 22:31, Alexander Korotkov wrote:

Now, I got the point of three state consistent: we can keep only one
consistent in opclasses that support new interface. exact true and exact
false values will be passed in the case of current patch consistent; exact
false and unknown will be passed in the case of current patch
preConsistent. That's reasonable.

I'm going to mark this as "returned with feedback". For the next
version, I'd like to see the API changed per above. Also, I'd like us to
do something about the tidbitmap overhead, as a separate patch before
this, so that we can assess the actual benefit of this patch. And a new
test case that demonstrates the I/O benefits.

- Heikki

--
Sent via pgsql-hackers mailing list (pgsql-hackers@postgresql.org)
To make changes to your subscription:
http://www.postgresql.org/mailpref/pgsql-hackers

Hi,

this is a follow-up to the message I posted to the thread about
additional info in GIN.

I've applied both ginaddinfo.7.patch and gin_fast_scan.4.patch on commit
b8fd1a09, but I'm observing a lot of failures like this:

STATEMENT: SELECT id FROM messages WHERE body_tsvector @@
plainto_tsquery('english', 'email free') LIMIT 100
ERROR: buffer 238068 is not owned by resource owner Portal

There's a GIN index on messages(body_tsvector). I haven't dug into why
it fails like this.

Tomas

--
Sent via pgsql-hackers mailing list (pgsql-hackers@postgresql.org)
To make changes to your subscription:
http://www.postgresql.org/mailpref/pgsql-hackers

On Sun, Jun 30, 2013 at 3:00 PM, Heikki Linnakangas <hlinnakangas@vmware.com

wrote:

On 28.06.2013 22:31, Alexander Korotkov wrote:

Now, I got the point of three state consistent: we can keep only one
consistent in opclasses that support new interface. exact true and exact
false values will be passed in the case of current patch consistent; exact
false and unknown will be passed in the case of current patch
preConsistent. That's reasonable.

I'm going to mark this as "returned with feedback". For the next version,
I'd like to see the API changed per above. Also, I'd like us to do
something about the tidbitmap overhead, as a separate patch before this, so
that we can assess the actual benefit of this patch. And a new test case
that demonstrates the I/O benefits.

Revised version of patch is attached.
Changes are so:
1) Patch rebased against packed posting lists, not depends on additional
information now.
2) New API with tri-state logic is introduced.

------
With best regards,
Alexander Korotkov.

On 14.11.2013 19:26, Alexander Korotkov wrote:

On Sun, Jun 30, 2013 at 3:00 PM, Heikki Linnakangas <hlinnakangas@vmware.com

wrote:

On 28.06.2013 22:31, Alexander Korotkov wrote:

Now, I got the point of three state consistent: we can keep only one
consistent in opclasses that support new interface. exact true and exact
false values will be passed in the case of current patch consistent; exact
false and unknown will be passed in the case of current patch
preConsistent. That's reasonable.

I'm going to mark this as "returned with feedback". For the next version,
I'd like to see the API changed per above. Also, I'd like us to do
something about the tidbitmap overhead, as a separate patch before this, so
that we can assess the actual benefit of this patch. And a new test case
that demonstrates the I/O benefits.

Revised version of patch is attached.
Changes are so:
1) Patch rebased against packed posting lists, not depends on additional
information now.
2) New API with tri-state logic is introduced.

Thanks! A couple of thoughts after a 5-minute glance:

* documentation

* How about defining the tri-state consistent function to also return a
tri-state? True would mean that the tuple definitely matches, false
means the tuple definitely does not match, and Unknown means it might
match. Or does return value true with recheck==true have the same
effect? If I understood the patch, right, returning Unknown or True
wouldn't actually make any difference, but it's conceivable that we
might come up with more optimizations in the future that could take
advantage of that. For example, for a query like "foo OR (bar AND baz)",
you could immediately return any tuples that match foo, and not bother
scanning for bar and baz at all.

- Heikki

--
Sent via pgsql-hackers mailing list (pgsql-hackers@postgresql.org)
To make changes to your subscription:
http://www.postgresql.org/mailpref/pgsql-hackers

I checked out master and put together a test case using a small percentage
of production data for a known problem we have with Pg 9.2 and text search
scans.

A small percentage in this case means 10 million records randomly selected;
has a few billion records.

Tests ran for master successfully and I recorded timings.

Applied the patch included here to master along with
gin-packed-postinglists-14.patch.
Run make clean; ./configure; make; make install.
make check (All 141 tests passed.)

initdb, import dump

The GIN index fails to build with a segfault.

DETAIL: Failed process was running: CREATE INDEX textsearch_gin_idx ON kp
USING gin (to_tsvector('simple'::regconfig, string)) WHERE (score1 IS NOT
NULL);

#0 XLogCheckBuffer (holdsExclusiveLock=1 '\001', lsn=lsn@entry=0x7fffcf341920,
bkpb=bkpb@entry=0x7fffcf341960, rdata=0x468f11 <ginFindLeafPage+529>,
rdata=0x468f11 <ginFindLeafPage+529>) at xlog.c:2339
#1 0x00000000004b9ddd in XLogInsert (rmid=rmid@entry=13 '\r',
info=info@entry=16 '\020', rdata=rdata@entry=0x7fffcf341bf0) at xlog.c:936
#2 0x0000000000468a9e in createPostingTree (index=0x7fa4e8d31030,
items=items@entry=0xfb55680, nitems=nitems@entry=762,
buildStats=buildStats@entry=0x7fffcf343dd0) at gindatapage.c:1324
#3 0x00000000004630c0 in buildFreshLeafTuple (buildStats=0x7fffcf343dd0,
nitem=762, items=0xfb55680, category=<optimized out>, key=34078256,
attnum=<optimized out>, ginstate=0x7fffcf341df0) at gininsert.c:281
#4 ginEntryInsert (ginstate=ginstate@entry=0x7fffcf341df0,
attnum=<optimized out>, key=34078256, category=<optimized out>,
items=0xfb55680, nitem=762,
buildStats=buildStats@entry=0x7fffcf343dd0) at gininsert.c:351
#5 0x00000000004635b0 in ginbuild (fcinfo=<optimized out>) at
gininsert.c:531
#6 0x0000000000718637 in OidFunctionCall3Coll
(functionId=functionId@entry=2738,
collation=collation@entry=0, arg1=arg1@entry=140346257507968,
arg2=arg2@entry=140346257510448, arg3=arg3@entry=32826432) at
fmgr.c:1649
#7 0x00000000004ce1da in index_build
(heapRelation=heapRelation@entry=0x7fa4e8d30680,
indexRelation=indexRelation@entry=0x7fa4e8d31030,
indexInfo=indexInfo@entry=0x1f4e440, isprimary=isprimary@entry=0
'\000', isreindex=isreindex@entry=0 '\000') at index.c:1963
#8 0x00000000004ceeaa in index_create
(heapRelation=heapRelation@entry=0x7fa4e8d30680,

indexRelationName=indexRelationName@entry=0x1f4e660
"textsearch_gin_knn_idx", indexRelationId=16395, indexRelationId@entry=0,
relFileNode=<optimized out>, indexInfo=indexInfo@entry=0x1f4e440,
indexColNames=indexColNames@entry=0x1f4f728,
accessMethodObjectId=accessMethodObjectId@entry=2742,
tableSpaceId=tableSpaceId@entry=0,
collationObjectId=collationObjectId@entry=0x1f4fcc8,

classObjectId=classObjectId@entry=0x1f4fce0,
coloptions=coloptions@entry=0x1f4fcf8,
reloptions=reloptions@entry=0, isprimary=0 '\000',
isconstraint=0 '\000', deferrable=0 '\000', initdeferred=0 '\000',
allow_system_table_mods=0 '\000', skip_build=0 '\000', concurrent=0 '\000',
is_internal=0 '\000') at index.c:1082
#9 0x0000000000546a78 in DefineIndex (stmt=<optimized out>,
indexRelationId=indexRelationId@entry=0, is_alter_table=is_alter_table@entry=0
'\000',
check_rights=check_rights@entry=1 '\001', skip_build=skip_build@entry=0
'\000', quiet=quiet@entry=0 '\000') at indexcmds.c:594
#10 0x000000000065147e in ProcessUtilitySlow
(parsetree=parsetree@entry=0x1f7fb68,

queryString=0x1f7eb10 "CREATE INDEX textsearch_gin_idx ON kp USING gin
(to_tsvector('simple'::regconfig, string)) WHERE (score1 IS NOT NULL);",
context=<optimized out>, params=params@entry=0x0,
completionTag=completionTag@entry=0x7fffcf344c10 "", dest=<optimized out>)
at utility.c:1163
#11 0x000000000065079e in standard_ProcessUtility (parsetree=0x1f7fb68,
queryString=<optimized out>, context=<optimized out>, params=0x0,
dest=<optimized out>, completionTag=0x7fffcf344c10 "") at utility.c:873
#12 0x000000000064de61 in PortalRunUtility (portal=portal@entry=0x1f4c350,
utilityStmt=utilityStmt@entry=0x1f7fb68, isTopLevel=isTopLevel@entry=1
'\001',
dest=dest@entry=0x1f7ff08, completionTag=completionTag@entry=0x7fffcf344c10
"") at pquery.c:1187
#13 0x000000000064e9e5 in PortalRunMulti (portal=portal@entry=0x1f4c350,
isTopLevel=isTopLevel@entry=1 '\001', dest=dest@entry=0x1f7ff08,
altdest=altdest@entry=0x1f7ff08,
completionTag=completionTag@entry=0x7fffcf344c10
"") at pquery.c:1318
#14 0x000000000064f459 in PortalRun (portal=portal@entry=0x1f4c350,
count=count@entry=9223372036854775807, isTopLevel=isTopLevel@entry=1
'\001',
dest=dest@entry=0x1f7ff08, altdest=altdest@entry=0x1f7ff08,
completionTag=completionTag@entry=0x7fffcf344c10 "") at pquery.c:816
#15 0x000000000064d2d5 in exec_simple_query (
query_string=0x1f7eb10 "CREATE INDEX textsearch_gin_idx ON kp USING gin
(to_tsvector('simple'::regconfig, string)) WHERE (score1 IS NOT NULL);") at
postgres.c:1048
#16 PostgresMain (argc=<optimized out>, argv=argv@entry=0x1f2ad40,
dbname=0x1f2abf8 "rbt", username=<optimized out>) at postgres.c:3992
#17 0x000000000045b1b4 in BackendRun (port=0x1f47280) at postmaster.c:4085
#18 BackendStartup (port=0x1f47280) at postmaster.c:3774
#19 ServerLoop () at postmaster.c:1585
#20 0x000000000060d031 in PostmasterMain (argc=argc@entry=3,
argv=argv@entry=0x1f28b20)
at postmaster.c:1240
#21 0x000000000045bb25 in main (argc=3, argv=0x1f28b20) at main.c:196

On Thu, Nov 14, 2013 at 12:26 PM, Alexander Korotkov
<aekorotkov@gmail.com>wrote:

On Fri, Nov 15, 2013 at 3:25 AM, Rod Taylor <rbt@simple-knowledge.com>wrote:

I checked out master and put together a test case using a small percentage
of production data for a known problem we have with Pg 9.2 and text search
scans.

A small percentage in this case means 10 million records randomly
selected; has a few billion records.

Tests ran for master successfully and I recorded timings.

Applied the patch included here to master along with
gin-packed-postinglists-14.patch.
Run make clean; ./configure; make; make install.
make check (All 141 tests passed.)

initdb, import dump

The GIN index fails to build with a segfault.

Thanks for testing. See fixed version in thread about packed posting lists.

------
With best regards,
Alexander Korotkov.

On Fri, Nov 15, 2013 at 12:34 AM, Heikki Linnakangas <
hlinnakangas@vmware.com> wrote:

On 14.11.2013 19:26, Alexander Korotkov wrote:

On Sun, Jun 30, 2013 at 3:00 PM, Heikki Linnakangas <
hlinnakangas@vmware.com

wrote:

On 28.06.2013 22:31, Alexander Korotkov wrote:

Now, I got the point of three state consistent: we can keep only one

consistent in opclasses that support new interface. exact true and exact
false values will be passed in the case of current patch consistent;
exact
false and unknown will be passed in the case of current patch
preConsistent. That's reasonable.

I'm going to mark this as "returned with feedback". For the next version,
I'd like to see the API changed per above. Also, I'd like us to do
something about the tidbitmap overhead, as a separate patch before this,
so
that we can assess the actual benefit of this patch. And a new test case
that demonstrates the I/O benefits.

Revised version of patch is attached.
Changes are so:
1) Patch rebased against packed posting lists, not depends on additional
information now.
2) New API with tri-state logic is introduced.

Thanks! A couple of thoughts after a 5-minute glance:

* documentation

Will provide documented version this week.

* How about defining the tri-state consistent function to also return a
tri-state? True would mean that the tuple definitely matches, false means
the tuple definitely does not match, and Unknown means it might match. Or
does return value true with recheck==true have the same effect? If I
understood the patch, right, returning Unknown or True wouldn't actually
make any difference, but it's conceivable that we might come up with more
optimizations in the future that could take advantage of that. For example,
for a query like "foo OR (bar AND baz)", you could immediately return any
tuples that match foo, and not bother scanning for bar and baz at all.

The meaning of recheck flag when input contains unknown is undefined now. :)
For instance, we could define it in following ways:
1) Like returning Unknown meaning that consistent with true of false
instead of input Unknown could return either true or false.
2) Consistent with true of false instead of input Unknown could return
recheck. This meaning is probably logical, but I don't see any usage of it.

I'm not against idea of tri-state returning value for consisted, because
it's logical continuation of its tri-state input. However, I don't see
usage of distinguish True and Unknown in returning value for now :)

In example you give we can return foo immediately, but we have to create
full bitmap. So we anyway will have to scan (bar AND baz). We could skip
part of trees for bar and baz. But it's possible only when foo contains
large amount of sequential TIDS so we can be sure that we didn't miss any
TIDs. This seems to be very narrow use-case for me.

Another point is that one day we probably could immediately return tuples
in gingettuple. And with LIMIT clause and no sorting we can don't search
for other tuples. However, gingettuple was removed because of reasons of
concurrency. And my patches for index-based ordering didn't return it in
previous manner: it collects all the results and then returns them
one-by-one.

------
With best regards,
Alexander Korotkov.

I tried again this morning using gin-packed-postinglists-16.patch and
gin-fast-scan.6.patch. No crashes.

It is about a 0.1% random sample of production data (10,000,000 records)
with the below structure. Pg was compiled with debug enabled in both cases.

Table "public.kp"
Column | Type | Modifiers
--------+---------+-----------
id | bigint | not null
string | text | not null
score1 | integer |
score2 | integer |
score3 | integer |
score4 | integer |
Indexes:
"kp_pkey" PRIMARY KEY, btree (id)
"kp_string_key" UNIQUE CONSTRAINT, btree (string)
"textsearch_gin_idx" gin (to_tsvector('simple'::regconfig, string))
WHERE score1 IS NOT NULL

This is a query tested. All data is in Pg buffer cache for these timings.
Words like "the" and "and" are very common (~9% of entries, each) and a
word like "hotel" is much less common (~0.2% of entries).

SELECT id,string
FROM kp
WHERE score1 IS NOT NULL
AND to_tsvector('simple', string) @@ to_tsquery('simple', ?)
-- ? is substituted with the query strings
ORDER BY score1 DESC, score2 ASC
LIMIT 1000;

 Limit  (cost=56.04..56.04 rows=1 width=37) (actual time=250.010..250.032
rows=142 loops=1)
   ->  Sort  (cost=56.04..56.04 rows=1 width=37) (actual
time=250.008..250.017 rows=142 loops=1)
         Sort Key: score1, score2
         Sort Method: quicksort  Memory: 36kB
         ->  Bitmap Heap Scan on kp  (cost=52.01..56.03 rows=1 width=37)
(actual time=249.711..249.945 rows=142 loops=1)
               Recheck Cond: ((to_tsvector('simple'::regconfig, string) @@
'''hotel'' & ''and'' & ''the'''::tsquery) AND (score1 IS NOT NULL))
               ->  Bitmap Index Scan on textsearch_gin_idx
(cost=0.00..52.01 rows=1 width=0) (actual time=249.681..249.681 rows=142
loops=1)
                     Index Cond: (to_tsvector('simple'::regconfig, string)
@@ '''hotel'' & ''and'' & ''the'''::tsquery)
 Total runtime: 250.096 ms

Times are from \timing on.

MASTER
=======
the: 888.436 ms 926.609 ms 885.502 ms
and: 944.052 ms 937.732 ms 920.050 ms
hotel: 53.992 ms 57.039 ms 65.581 ms
and & the & hotel: 260.308 ms 248.275 ms 248.098 ms

These numbers roughly match what we get with Pg 9.2. The time savings
between 'the' and 'and & the & hotel' is mostly heap lookups for the score
and the final sort.

The size of the index on disk is about 2% smaller in the patched version.

PATCHED
=======
the: 1055.169 ms 1081.976 ms 1083.021 ms
and: 912.173 ms 949.364 ms 965.261 ms
hotel: 62.591 ms 64.341 ms 62.923 ms
and & the & hotel: 268.577 ms 259.293 ms 257.408 ms
hotel & and & the: 253.574 ms 258.071 ms 250.280 ms

I was hoping that the 'and & the & hotel' case would improve with this
patch to be closer to the 'hotel' search, as I thought that was the kind of
thing it targeted. Unfortunately, it did not. I actually applied the
patches, compiled, initdb/load data, and ran it again thinking I made a
mistake.

Reordering the terms 'hotel & and & the' doesn't change the result.

On Fri, Nov 15, 2013 at 1:51 AM, Alexander Korotkov <aekorotkov@gmail.com>wrote:
