I'll start a new thread for this, since my external sorting patch has
now evolved well past the original "quicksort with spillover"
idea...although not quite how I anticipated it would. It seems like
I've reached a good point to get some feedback.

I attach a patch series featuring a new, more comprehensive approach
to quicksorting runs during external sorts. What I have now still
includes "quicksort with spillover", but it's just a part of a larger
project. I am quite happy with the improvements in performance shown
by my testing, which I go into below.

Controversy
=========

A few weeks ago, I did not anticipate that I'd propose that
replacement selection sort be used far less (only somewhat less, since
I was only somewhat doubtful about the algorithm at the time). I had
originally planned on continuing to *always* use it for the first run,
to make "quicksort with spillover" possible (thereby sometimes
avoiding significant I/O by not spilling most tuples), but also to
make cases always considered sympathetic to replacement selection
continue to happen. I thought that second or subsequent runs could
still be quicksorted, but that I must still care about this latter
category, the traditional sympathetic cases. This latter category is
mostly just one important property of replacement selection: even
without a strong logical/physical correlation, the algorithm tends to
produce runs that are about twice the size of work_mem. (It's also
notable that replacement selection only produces one run with mostly
presorted input, even where input far exceeds work_mem, which is a
neat trick.)

I wanted to avoid controversy, but the case for the controversy is too
strong for me to ignore: despite these upsides, replacement selection
is obsolete, and should usually be avoided.

Replacement selection sort still has a role to play in making
"quicksort with spillover" possible (when a sympathetic case is
*anticipated*), but other than that it seems generally inferior to a
simple hybrid sort-merge strategy on modern hardware. By modern
hardware, I mean anything manufactured in at least the last 20 years.
We've already seen that the algorithm's use of a heap works badly with
modern CPU caches, but that is just one factor contributing to its
obsolescence.

The big selling point of replacement selection sort in the 20th
century was that it sometimes avoided multi-pass sorts as compared to
a simple sort-merge strategy (remember when tuplesort.c always used 7
tapes? When you need to use 7 actual magnetic tapes, rewinding is
expensive and in general this matters a lot!). We all know that memory
capacity has grown enormously since then, but we must also consider
another factor: At the same time, a simple hybrid sort-merge
strategy's capacity to more or less get the important detail here
right -- to avoid a multi-pass sort -- has increased quadratically
(relative to work_mem/memory capacity). As an example, testing shows
that for a datum tuplesort that requires about 2300MB of work_mem to
be completed as a simple internal sort this patch only needs 30MB to
just do one pass (see benchmark query below). I've mostly regressed
that particular property of tuplesort (it used to be less than 30MB),
but that's clearly the wrong thing to worry about for all kinds of
reasons, probably even in the unimportant cases now forced to do
multiple passes.

Multi-pass sorts
---------------------

I believe, in general, that we should consider a multi-pass sort to be
a kind of inherently suspect thing these days, in the same way that
checkpoints occurring 5 seconds apart are: not actually abnormal, but
something that we should regard suspiciously. Can you really not
afford enough work_mem to only do one pass? Does it really make sense
to add far more I/O and CPU costs to avoid that other tiny memory
capacity cost?

In theory, the answer could be "yes", but it seems highly unlikely.
Not only is very little memory required to avoid a multi-pass merge
step, but as described above the amount required grows very slowly
relative to linear growth in input. I propose to add a
checkpoint_warning style warning (with a checkpoint_warning style GUC
to control it). ISTM that these days, multi-pass merges are like
saving $2 on replacing a stairwell light bulb, at the expense of
regularly stumbling down the stairs in the dark. It shouldn't matter
if you have a 50 terabyte decision support database or if you're
paying Heroku a small monthly fee to run a database backing your web
app: simply avoiding multi-pass merges is probably always the most
economical solution, and by a wide margin.

Note that I am not skeptical of polyphase merging itself, even though
it is generally considered to be a complimentary technique to
replacement selection (some less formal writing on external sorting
seemingly fails to draw a sharp distinction). Nothing has changed
there.

Patch, performance
===============

Let's focus on a multi-run sort, that does not use "quicksort with
spillover", since that is all new, and is probably the most compelling
case for very large databases with hundreds of gigabytes of data to
sort.

I think that this patch requires a machine with more I/O bandwidth
than my laptop to get a proper sense of the improvement made. I've
been using a tmpfs temp_tablespace for testing, to simulate this. That
may leave me slightly optimistic about I/O costs, but you can usually
get significantly more sequential I/O bandwidth by adding additional
disks, whereas you cannot really buy new hardware to improve the
situation with excessive CPU cache misses.

Benchmark
---------------

-- Setup, 100 million tuple table with high cardinality int4 column (2
billion possible int4 values)
create table big_high_cardinality_int4 as
select (random() * 2000000000)::int4 s,
'abcdefghijlmn'::text junk
from generate_series(1, 100000000);
-- Make cost model hinting accurate:
analyze big_high_cardinality_int4;
checkpoint;

Let's start by comparing an external sort that uses 1/3 the memory of
an internal sort against the master branch. That's completely unfair
on the patch, of course, but it is a useful indicator of how well
external sorts do overall. Although an external sort surely cannot be
as fast as an internal sort, it might be able to approach an internal
sort's speed when there is plenty of I/O bandwidth. That's a good
thing to aim for, I think.

-- Master (just enough memory for internal sort):
set work_mem = '2300MB';
select count(distinct(s)) from big_high_cardinality;

***** Runtime after stabilization: ~33.6 seconds *****

-- Patch series, but with just over 1/3 the memory:
set work_mem = '800MB';
select count(distinct(s)) from big_high_cardinality;

***** Runtime after stabilization: ~37.1 seconds *****

The patch only takes ~10% more time to execute this query, which seems
very good considering that ~1/3 the work_mem has been put to use.

trace_sort output for patch during execution of this case:

LOG: begin datum sort: workMem = 819200, randomAccess = f
LOG: switching to external sort with 2926 tapes: CPU 0.39s/2.66u sec
elapsed 3.06 sec
LOG: replacement selection avg tuple size 24.00 crossover: 0.85
LOG: hybrid sort-merge in use from row 34952532 with 100000000.00 total rows
LOG: finished quicksorting run 1: CPU 0.39s/8.84u sec elapsed 9.24 sec
LOG: finished writing quicksorted run 1 to tape 0: CPU 0.60s/9.61u
sec elapsed 10.22 sec
LOG: finished quicksorting run 2: CPU 0.87s/18.61u sec elapsed 19.50 sec
LOG: finished writing quicksorted run 2 to tape 1: CPU 1.07s/19.38u
sec elapsed 20.46 sec
LOG: performsort starting: CPU 1.27s/21.79u sec elapsed 23.07 sec
LOG: finished quicksorting run 3: CPU 1.27s/27.07u sec elapsed 28.35 sec
LOG: finished writing quicksorted run 3 to tape 2: CPU 1.47s/27.69u
sec elapsed 29.18 sec
LOG: performsort done (except 3-way final merge): CPU 1.51s/28.54u
sec elapsed 30.07 sec
LOG: external sort ended, 146625 disk blocks used: CPU 1.76s/35.32u
sec elapsed 37.10 sec

Note that the on-tape runs are small relative to CPU costs, so this
query is a bit sympathetic (consider the time spent writing batches
that trace_sort indicates here). CREATE INDEX would not compare so
well with an internal sort, for example, especially if it was a
composite index or something. I've sized work_mem here in a deliberate
way, to make sure there are 3 runs of similar size by the time the
merge step is reached, which makes a small difference in the patch's
favor. All told, this seems like a very significant overall
improvement.

Now, consider master's performance with the same work_mem setting (a
fair test with comparable resource usage for master and patch):

-- Master
set work_mem = '800MB';
select count(distinct(s)) from big_high_cardinality;

***** Runtime after stabilization: ~120.9 seconds *****

The patch is ~3.25x faster than master here, which also seems like a
significant improvement. That's pretty close to the improvement
previously seen for good "quicksort with spillover" cases, but
suitable for every external sort case that doesn't use "quicksort with
spillover". In other words, no variety of external sort is not
significantly improved by the patch.

I think it's safe to suppose that there are also big benefits when
multiple concurrent sort operations run on the same system. For
example, when pg_restore has multiple jobs.

Worst case
---------------

Even with a traditionally sympathetic case for replacement selection
sort, the patch beats replacement selection with multiple on-tape
runs. When experimenting here, I did not forget to account for our
qsort()'s behavior in the event of *perfectly* presorted input
("Bubble sort best case" behavior [1]Commit a3f0b3d6 -- Peter Geoghegan). Other than that, I have a hard
time thinking of an unsympathetic case for the patch, and could not
find any actual regressions with a fair amount of effort.

Abbreviated keys are not used when merging, but that doesn't seem to
be something that notably counts against the new approach (which will
have shorter runs on average). After all, the reason why abbreviated
keys aren't saved on disk for merging is that they're probably not
very useful when merging. They would resolve far fewer comparisons if
they were used during merging, and having somewhat smaller runs does
not result in significantly more non-abbreviated comparisons, even
when sorting random noise strings.

Avoiding replacement selection *altogether*
=================================

Assuming you agree with my conclusions on replacement selection sort
mostly not being worth it, we need to avoid replacement selection
except when it'll probably allow a "quicksort with spillover". In my
mind, that's now the *only* reason to use replacement selection.
Callers pass a hint to tuplesort indicating how many tuples it is
estimated will ultimately be passed before a sort is performed.
(Typically, this comes from a scan plan node's row estimate, or more
directly from the relcache for things like CREATE INDEX.)

Cost model -- details
----------------------------

Second or subsequent runs *never* use replacement selection -- it is
only *considered* for the first run, right before the possible point
of initial heapification within inittapes(). The cost model is
contained within the new function useselection(). See the second patch
in the series for full details. That's where this is added.

I have a fairly high bar for even using replacement selection for the
first run -- several factors can result in a simple hybrid sort-merge
strategy being used instead of a "quicksort with spillover", because
in general most of the benefit seems to be around CPU cache misses
rather than savings in I/O. Consider my benchmark query above once
more -- with replacement selection used for the first run in the
benchmark case above (e.g., with just the first patch in the series
applied, or setting the "optimize_avoid_selection" debug GUC to
"off"), I found that it took over twice as long to execute, even
though the second-or-subsequent (now smaller) runs were quicksorted
just the same, and were all merged just the same.

The numbers should make it obvious why I gave in to the temptation of
adding an ad-hoc, tuplesort-private cost model. At this point, I'd
rather scrap "quicksort with spillover" (and the use of replacement
selection under all possible circumstances) than scrap the idea of a
cost model. That would make more sense, even though it would give up
on the idea of saving most I/O where the work_mem threshold is only
crossed by a small amount.

Future work
=========

I anticipate a number of other things within the first patch in the
series, some of which are already worked out to some degree.

Asynchronous I/O
-------------------------

This patch leaves open the possibility of using something like
libaio/librt for sorting. That would probably use half of memtuples as
scratch space, while the other half is quicksorted.

Memory prefetching
---------------------------

To test what role memory prefetching is likely to have here, I attach
a custom version of my tuplesort/tuplestore prefetch patch, with
prefetching added to the "quicksort with spillover" and batch dumping
runs WRITETUP()-calling code. This seems to help performance
measurably. However, I guess it shouldn't really be considered as part
of this patch. It can follow the initial commit of the big, base patch
(or will becomes part of the base patch if and when prefetching is
committed first).

cost_sort() changes
--------------------------

I had every intention of making cost_sort() a continuous cost function
as part of this work. This could be justified by "quicksort with
spillover" allowing tuplesort to "blend" from internal to external
sorting as input size is gradually increased. This seemed like
something that would have significant non-obvious benefits in several
other areas. However, I've put off dealing with making any change to
cost_sort() because of concerns about the complexity of overlaying
such changes on top of the tuplesort-private cost model.

I think that this will need to be discussed in a lot more detail. As a
further matter, materialization of sort nodes will probably also
require tweaks to the costing for "quicksort with spillover". Recall
that "quicksort with spillover" can only work for !randomAccess
tuplesort callers.

Run size
------------

This patch continues to have tuplesort determine run size based on the
availability of work_mem only. It does not entirely fix the problem of
having work_mem sizing impact performance in counter-intuitive ways.
In other words, smaller work_mem sizes can still be faster. It does
make that general situation much better, though, because quicksort is
a cache oblivious algorithm. Smaller work_mem sizes are sometimes a
bit faster, but never dramatically faster.

In general, the whole idea of making run size as big as possible is
bogus, unless that enables or is likely to enable a "quicksort with
spillover". The caller-supplied row count hint I've added may in the
future be extended to determine optimal run size ahead of time, when
it's perfectly clear (leaving aside misestimation) that a fully
internal sort (or "quicksort with spillover") will not occur. This
will result in faster external sorts where additional work_mem cannot
be put to good use. As a side benefit, external sorts will not be
effectively wasting a large amount of memory.

The cost model we eventually come up with to determine optimal run
size ought to balance certain things. Assuming a one-pass merge step,
then we should balance the time lost waiting on the first run and time
quicksorting the last run with the gradual increase in the cost during
the merge step. Maybe the non-use of abbreviated keys during the merge
step should also be considered. Alternatively, the run size may be
determined by a GUC that is typically sized at drive controller cache
size (e.g. 1GB) when any kind of I/O avoidance for the sort appears
impossible.

[1]: Commit a3f0b3d6 -- Peter Geoghegan
--
Peter Geoghegan

Bruce Momjian

bruce@momjian.us

over 10 years ago

In reply to: Peter Geoghegan (#1)

Re: Using quicksort for every external sort run

On Thu, Aug 20, 2015 at 3:24 AM, Peter Geoghegan <pg@heroku.com> wrote:

I believe, in general, that we should consider a multi-pass sort to be
a kind of inherently suspect thing these days, in the same way that
checkpoints occurring 5 seconds apart are: not actually abnormal, but
something that we should regard suspiciously. Can you really not
afford enough work_mem to only do one pass? Does it really make sense
to add far more I/O and CPU costs to avoid that other tiny memory
capacity cost?

I think this is the crux of the argument. And I think you're
basically, but not entirely, right.

The key metric there is not how cheap memory has gotten but rather
what the ratio is between the system's memory and disk storage. The
use case I think you're leaving out is the classic "data warehouse"
with huge disk arrays attached to a single host running massive
queries for hours. In that case reducing run size will reduce I/O
requirements directly and halving the amount of I/O sort takes will
halve the time it takes regardless of cpu efficiency. And I have a
suspicion typical data distributions get much better than a 2x
speedup.

But I think you're basically right that this is the wrong use case to
worry about for most users. Even those users that do have large batch
queries are probably not processing so much that they should be doing
multiple passes. The ones that do are are probably more interested in
parallel query, federated databases, column stores, and so on rather
than worrying about just how many hours it takes to sort their
multiple terabytes on a single processor.

I am quite suspicious of quicksort though. It has O(n^2) worst case
and I think it's only a matter of time before people start worrying
about DOS attacks from users able to influence the data ordering. It's
also not very suitable for GPU processing. Quicksort gets most of its
advantage from cache efficiency, it isn't a super efficient algorithm
otherwise, are there not other cache efficient algorithms to consider?

Alternately, has anyone tested whether Timsort would work well?

--
greg

--
Sent via pgsql-hackers mailing list (pgsql-hackers@postgresql.org)
To make changes to your subscription:
http://www.postgresql.org/mailpref/pgsql-hackers

Tom Lane

tgl@sss.pgh.pa.us

over 10 years ago

In reply to: Bruce Momjian (#2)

Re: Using quicksort for every external sort run

Greg Stark <stark@mit.edu> writes:

Alternately, has anyone tested whether Timsort would work well?

I think that was proposed a few years ago and did not look so good
in simple testing.

regards, tom lane

--
Sent via pgsql-hackers mailing list (pgsql-hackers@postgresql.org)
To make changes to your subscription:
http://www.postgresql.org/mailpref/pgsql-hackers

Simon Riggs

simon@2ndQuadrant.com

over 10 years ago

In reply to: Peter Geoghegan (#1)

Re: Using quicksort for every external sort run

On 20 August 2015 at 03:24, Peter Geoghegan <pg@heroku.com> wrote:

The patch is ~3.25x faster than master

I've tried to read this post twice and both times my work_mem overflowed.
;-)

Can you summarize what this patch does? I understand clearly what it
doesn't do...

--
Simon Riggs http://www.2ndQuadrant.com/
<http://www.2ndquadrant.com/>
PostgreSQL Development, 24x7 Support, Remote DBA, Training & Services

Using quicksort for every external sort run

Attachments:

Attachments:
