Use simplehash.h instead of dynahash in SMgr

David Rowley писал 2021-04-24 18:58:

Hackers,

Last year, when working on making compactify_tuples() go faster for
19c60ad69, I did quite a bit of benchmarking of the recovery process.
The next thing that was slow after compactify_tuples() was the hash
lookups done in smgropen().

Currently, we use dynahash hash tables to store the SMgrRelation so we
can perform fast lookups by RelFileNodeBackend. However, I had in mind
that a simplehash table might perform better. So I tried it...

The attached converts the hash table lookups done in smgr.c to use
simplehash instead of dynahash.

This does require a few changes in simplehash.h to make it work. The
reason being is that RelationData.rd_smgr points directly into the
hash table entries. This works ok for dynahash as that hash table
implementation does not do any reallocations of existing items or move
any items around in the table, however, simplehash moves entries
around all the time, so we can't point any pointers directly at the
hash entries and expect them to be valid after adding or removing
anything else from the table.

To work around that, I've just made an additional type that serves as
the hash entry type that has a pointer to the SMgrRelationData along
with the hash status and hash value. It's just 16 bytes (or 12 on
32-bit machines). I opted to keep the hash key in the
SMgrRelationData rather than duplicating it as it keeps the SMgrEntry
struct nice and small. We only need to dereference the SMgrRelation
pointer when we find an entry with the same hash value. The chances
are quite good that an entry with the same hash value is the one that
we want, so any additional dereferences to compare the key are not
going to happen very often.

I did experiment with putting the hash key in SMgrEntry and found it
to be quite a bit slower. I also did try to use hash_bytes() but
found building a hash function that uses murmurhash32 to be quite a
bit faster.

Benchmarking
===========

I did some of that. It made my test case about 10% faster.

The test case was basically inserting 100 million rows one at a time
into a hash partitioned table with 1000 partitions and 2 int columns
and a primary key on one of those columns. It was about 12GB of WAL. I
used a hash partitioned table in the hope to create a fairly
random-looking SMgr hash table access pattern. Hopefully something
similar to what might happen in the real world.

Over 10 runs of recovery, master took an average of 124.89 seconds.
The patched version took 113.59 seconds. About 10% faster.

I bumped shared_buffers up to 10GB, max_wal_size to 20GB and
checkpoint_timeout to 60 mins.

To make the benchmark more easily to repeat I patched with the
attached recovery_panic.patch.txt. This just PANICs at the end of
recovery so that the database shuts down before performing the end of
recovery checkpoint. Just start the database up again to do another
run.

I did 10 runs. The end of recovery log message reported:

master (aa271209f)
CPU: user: 117.89 s, system: 5.70 s, elapsed: 123.65 s
CPU: user: 117.81 s, system: 5.74 s, elapsed: 123.62 s
CPU: user: 119.39 s, system: 5.75 s, elapsed: 125.20 s
CPU: user: 117.98 s, system: 4.39 s, elapsed: 122.41 s
CPU: user: 117.92 s, system: 4.79 s, elapsed: 122.76 s
CPU: user: 119.84 s, system: 4.75 s, elapsed: 124.64 s
CPU: user: 120.60 s, system: 5.82 s, elapsed: 126.49 s
CPU: user: 118.74 s, system: 5.71 s, elapsed: 124.51 s
CPU: user: 124.29 s, system: 6.79 s, elapsed: 131.14 s
CPU: user: 118.73 s, system: 5.67 s, elapsed: 124.47 s

master + v1 patch
CPU: user: 106.90 s, system: 4.45 s, elapsed: 111.39 s
CPU: user: 107.31 s, system: 5.98 s, elapsed: 113.35 s
CPU: user: 107.14 s, system: 5.58 s, elapsed: 112.77 s
CPU: user: 105.79 s, system: 5.64 s, elapsed: 111.48 s
CPU: user: 105.78 s, system: 5.80 s, elapsed: 111.63 s
CPU: user: 113.18 s, system: 6.21 s, elapsed: 119.45 s
CPU: user: 107.74 s, system: 4.57 s, elapsed: 112.36 s
CPU: user: 107.42 s, system: 4.62 s, elapsed: 112.09 s
CPU: user: 106.54 s, system: 4.65 s, elapsed: 111.24 s
CPU: user: 113.24 s, system: 6.86 s, elapsed: 120.16 s

I wrote this patch a few days ago. I'm only posting it now as I know a
couple of other people have expressed an interest in working on this.
I didn't really want any duplicate efforts, so thought I'd better post
it now before someone else goes and writes a similar patch.

I'll park this here and have another look at it when the PG15 branch
opens.

David

Hi, David

It is quite interesting result. Simplehash being open-addressing with
linear probing is friendly for cpu cache. I'd recommend to define
SH_FILLFACTOR with value lower than default (0.9). I believe 0.75 is
suitable most for such kind of hash table.

+	/* rotate hashkey left 1 bit at each step */
+	hashkey = (hashkey << 1) | ((hashkey & 0x80000000) ? 1 : 0);
+	hashkey ^= murmurhash32((uint32) rnode->node.dbNode);

Why do you use so strange rotation expression? I know compillers are
able
to translage `h = (h << 1) | (h >> 31)` to single rotate instruction.
Do they recognize construction in your code as well?

Your construction looks more like "multiplate-modulo" operation in 32bit
Galois field . It is widely used operation in cryptographic, but it is
used modulo some primitive polynomial, and 0x100000001 is not such
polynomial. 0x1000000c5 is, therefore it should be:

hashkey = (hashkey << 1) | ((hashkey & 0x80000000) ? 0xc5 : 0);
or
hashkey = (hashkey << 1) | ((uint32)((int32)hashkey >> 31) & 0xc5);

But why don't just use hash_combine(uint32 a, uint32 b) instead (defined
in hashfn.h)? Yep, it could be a bit slower, but is it critical?

- *	smgrclose() -- Close and delete an SMgrRelation object.
+ *	smgrclose() -- Close and delete an SMgrRelation object but don't
+ *	remove from the SMgrRelationHash table.

I believe `smgrclose_internal()` should be in this comment.

Still I don't believe it worth to separate smgrclose_internal from
smgrclose. Is there measurable performance improvement from this
change? Even if there is, it will be lesser with SH_FILLFACTOR 0.75 .

As well I don't support modification simplehash.h for
SH_ENTRY_INITIALIZER,
SH_ENTRY_CLEANUP and SH_TRUNCATE. The initialization could comfortably
live in smgropen and the cleanup in smgrclose. And then SH_TRUNCATE
doesn't mean much.

Summary:

regards,
Yura Sokolov

Thanks for having a look at this.

"On Sun, 25 Apr 2021 at 10:27, Yura Sokolov <y.sokolov@postgrespro.ru> wrote:

It is quite interesting result. Simplehash being open-addressing with
linear probing is friendly for cpu cache. I'd recommend to define
SH_FILLFACTOR with value lower than default (0.9). I believe 0.75 is
suitable most for such kind of hash table.

You might be right there, although, with the particular benchmark I'm
using the size of the table does not change as a result of that. I'd
need to experiment with varying numbers of relations to see if
dropping the fillfactor helps or hinders performance.

FWIW, the hash stats at the end of recovery are:

LOG: redo done at 3/C6E34F0 system usage: CPU: user: 107.00 s,
system: 5.61 s, elapsed: 112.67 s
LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 997,
max chain: 5, avg chain: 0.490650, total_collisions: 422,
max_collisions: 3, avg_collisions: 0.207677

Perhaps if try using a number of relations somewhere between 2048 *
0.75 and 2048 * 0.9 then I might see some gains. Because I have 2032,
the hash table grew up to 4096 buckets.

I did a quick test dropping the fillfactor down to 0.4. The aim there
was just to see if having 8192 buckets in this test would make it
faster or slower

LOG: redo done at 3/C6E34F0 system usage: CPU: user: 109.61 s,
system: 4.28 s, elapsed: 113.93 s
LOG: size: 8192, members: 2032, filled: 0.248047, total chain: 303,
max chain: 2, avg chain: 0.149114, total_collisions: 209,
max_collisions: 2, avg_collisions: 0.102854

it was slightly slower. I guess since the SMgrEntry is just 16 bytes
wide that 4 of these will sit on each cache line which means there is
a 75% chance that the next bucket over is on the same cache line.
Since the average chain length is just 0.49 then we'll mostly just
need to look at a single cache line to find the entry with the correct
hash key.

+     /* rotate hashkey left 1 bit at each step */
+     hashkey = (hashkey << 1) | ((hashkey & 0x80000000) ? 1 : 0);
+     hashkey ^= murmurhash32((uint32) rnode->node.dbNode);

Why do you use so strange rotation expression? I know compillers are
able
to translage `h = (h << 1) | (h >> 31)` to single rotate instruction.
Do they recognize construction in your code as well?

Not sure about all compilers, I only checked the earliest version of
clang and gcc at godbolt.org and they both use a single "rol"
instruction. https://godbolt.org/z/1GqdE6T3q

Your construction looks more like "multiplate-modulo" operation in 32bit
Galois field . It is widely used operation in cryptographic, but it is
used modulo some primitive polynomial, and 0x100000001 is not such
polynomial. 0x1000000c5 is, therefore it should be:

hashkey = (hashkey << 1) | ((hashkey & 0x80000000) ? 0xc5 : 0);
or
hashkey = (hashkey << 1) | ((uint32)((int32)hashkey >> 31) & 0xc5);

That does not really make sense to me. If you're shifting a 32-bit
variable left 31 places then why would you AND with 0xc5? The only
possible result is 1 or 0 depending on if the most significant bit is
on or off. I see gcc and clang are unable to optimise that into an
"rol" instruction. If I swap the "0xc5" for "1", then they're able to
optimise the expression.

But why don't just use hash_combine(uint32 a, uint32 b) instead (defined
in hashfn.h)? Yep, it could be a bit slower, but is it critical?

I had that function in the corner of my eye when writing this, but
TBH, the hash function performance was just too big a factor to slow
it down any further by using the more expensive hash_combine()
function. I saw pretty good performance gains from writing my own hash
function rather than using hash_bytes(). I didn't want to detract from
that by using hash_combine(). Rotating the bits left 1 slot seems
good enough for hash join and hash aggregate, so I don't have any
reason to believe it's a bad way to combine the hash values. Do you?

If you grep the source for "hashkey = (hashkey << 1) | ((hashkey &
0x80000000) ? 1 : 0);", then you'll see where else we do the same
rotate left trick.

- *   smgrclose() -- Close and delete an SMgrRelation object.
+ *   smgrclose() -- Close and delete an SMgrRelation object but don't
+ *   remove from the SMgrRelationHash table.

I believe `smgrclose_internal()` should be in this comment.

Oops. Yeah, that's a mistake.

Still I don't believe it worth to separate smgrclose_internal from
smgrclose. Is there measurable performance improvement from this
change? Even if there is, it will be lesser with SH_FILLFACTOR 0.75 .

The reason I did that is due to the fact that smgrcloseall() loops
over the entire hash table and removes each entry one by one. The
problem is that if I do a smgrtable_delete or smgrtable_delete_item in
that loop then I'd need to restart the loop each time. Be aware that
a simplehash delete can move entries earlier in the table, so it might
cause us to miss entries during the loop. Restarting the loop each
iteration is not going to be very efficient, so instead, I opted to
make a version of smgrclose() that does not remove from the table so
that I can just wipe out all table entries at the end of the loop. I
called that smgrclose_internal(). Maybe there's a better name, but I
don't really see any realistic way of not having some version that
skips the hash table delete. I was hoping the 5 line comment I added
to smgrcloseall() would explain the reason for the code being written
way.

An additional small benefit is that smgrclosenode() can get away with
a single hashtable lookup rather than having to lookup the entry again
with smgrtable_delete(). Using smgrtable_delete_item() deletes by
bucket rather than key value which should be a good bit faster in many
cases. I think the SH_ENTRY_CLEANUP macro is quite useful here as I
don't need to worry about NULLing out the smgr_owner in yet another
location where I do a hash delete.

As well I don't support modification simplehash.h for
SH_ENTRY_INITIALIZER,
SH_ENTRY_CLEANUP and SH_TRUNCATE. The initialization could comfortably
live in smgropen and the cleanup in smgrclose. And then SH_TRUNCATE
doesn't mean much.

Can you share what you've got in mind here?

The problem I'm solving with SH_ENTRY_INITIALIZER is the fact that in
SH_INSERT_HASH_INTERNAL(), when we add a new item, we do entry->SH_KEY
= key; to set the new entries key. Since I have SH_KEY defined as:

#define SH_KEY data->smgr_rnode

then I need some way to allocate the memory for ->data before the key
is set. Doing that in smrgopen() is too late. We've already crashed by
then for referencing uninitialised memory.

I did try putting the key in SMgrEntry but found the performance to be
quite a bit worse than keeping the SMgrEntry down to 16 bytes. That
makes sense to me as we only need to compare the key when we find an
entry with the same hash value as the one we're looking for. There's a
pretty high chance of that being the entry we want. If I got my hash
function right then the odds are about 1 in 4 billion of it not being
the one we want. The only additional price we pay when we get two
entries with the same hash value is an additional pointer dereference
and a key comparison.

David

David Rowley писал 2021-04-25 05:23:

Thanks for having a look at this.

"On Sun, 25 Apr 2021 at 10:27, Yura Sokolov <y.sokolov@postgrespro.ru>
wrote:

It is quite interesting result. Simplehash being open-addressing with
linear probing is friendly for cpu cache. I'd recommend to define
SH_FILLFACTOR with value lower than default (0.9). I believe 0.75 is
suitable most for such kind of hash table.

You might be right there, although, with the particular benchmark I'm
using the size of the table does not change as a result of that. I'd
need to experiment with varying numbers of relations to see if
dropping the fillfactor helps or hinders performance.

FWIW, the hash stats at the end of recovery are:

LOG: redo done at 3/C6E34F0 system usage: CPU: user: 107.00 s,
system: 5.61 s, elapsed: 112.67 s
LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 997,
max chain: 5, avg chain: 0.490650, total_collisions: 422,
max_collisions: 3, avg_collisions: 0.207677

Perhaps if try using a number of relations somewhere between 2048 *
0.75 and 2048 * 0.9 then I might see some gains. Because I have 2032,
the hash table grew up to 4096 buckets.

I did a quick test dropping the fillfactor down to 0.4. The aim there
was just to see if having 8192 buckets in this test would make it
faster or slower

LOG: redo done at 3/C6E34F0 system usage: CPU: user: 109.61 s,
system: 4.28 s, elapsed: 113.93 s
LOG: size: 8192, members: 2032, filled: 0.248047, total chain: 303,
max chain: 2, avg chain: 0.149114, total_collisions: 209,
max_collisions: 2, avg_collisions: 0.102854

it was slightly slower.

Certainly. That is because in unmodified case you've got fillfactor 0.49
because table just grew. Below somewhat near 0.6 there is no gain in
lower
fillfactor. But if you test it when it closer to upper bound, you will
notice difference. Try to test it with 3600 nodes, for example, if
going down to 1800 nodes is not possible.

+     /* rotate hashkey left 1 bit at each step */
+     hashkey = (hashkey << 1) | ((hashkey & 0x80000000) ? 1 : 0);
+     hashkey ^= murmurhash32((uint32) rnode->node.dbNode);

Why do you use so strange rotation expression? I know compillers are
able
to translage `h = (h << 1) | (h >> 31)` to single rotate instruction.
Do they recognize construction in your code as well?

Not sure about all compilers, I only checked the earliest version of
clang and gcc at godbolt.org and they both use a single "rol"
instruction. https://godbolt.org/z/1GqdE6T3q

Yep, looks like all compilers recognize such construction with single
exception of old icc compiler (both 13.0.1 and 16.0.3):
https://godbolt.org/z/qsrjY5Eof
and all compilers recognize `(h << 1) | (h >> 31)` well

Your construction looks more like "multiplate-modulo" operation in
32bit
Galois field . It is widely used operation in cryptographic, but it is
used modulo some primitive polynomial, and 0x100000001 is not such
polynomial. 0x1000000c5 is, therefore it should be:

hashkey = (hashkey << 1) | ((hashkey & 0x80000000) ? 0xc5 : 0);
or
hashkey = (hashkey << 1) | ((uint32)((int32)hashkey >> 31) &
0xc5);

That does not really make sense to me. If you're shifting a 32-bit
variable left 31 places then why would you AND with 0xc5? The only
possible result is 1 or 0 depending on if the most significant bit is
on or off.

That is why there is cast to signed int before shifting: `(int32)hashkey

31`.

Shift is then also signed ie arithmetic, and results are 0 or
0xffffffff.

But why don't just use hash_combine(uint32 a, uint32 b) instead
(defined
in hashfn.h)? Yep, it could be a bit slower, but is it critical?

I had that function in the corner of my eye when writing this, but
TBH, the hash function performance was just too big a factor to slow
it down any further by using the more expensive hash_combine()
function. I saw pretty good performance gains from writing my own hash
function rather than using hash_bytes(). I didn't want to detract from
that by using hash_combine(). Rotating the bits left 1 slot seems
good enough for hash join and hash aggregate, so I don't have any
reason to believe it's a bad way to combine the hash values. Do you?

Well, if think a bit more, this hash values could be combined with using
just addition: `hash(a) + hash(b) + hash(c)`.

I thought more about consistency in a codebase. But looks like both ways
(`hash_combine(a,b)` and `rotl(a,1)^b`) are used in a code.
- hash_combine is in one time/three lines in hashTupleDesc at
tupledesc.c
- rotl+xor six times:
-- three times/three lines in execGrouping.c with construction like
yours
-- three times in jsonb_util.c, multirangetypes.c and rangetypes.c with
`(h << 1) | (h >> 31)`.
Therefore I step down on recommendation in this place.

Looks like it is possibility for micropatch to unify hash combining :-)

If you grep the source for "hashkey = (hashkey << 1) | ((hashkey &
0x80000000) ? 1 : 0);", then you'll see where else we do the same
rotate left trick.

- *   smgrclose() -- Close and delete an SMgrRelation object.
+ *   smgrclose() -- Close and delete an SMgrRelation object but don't
+ *   remove from the SMgrRelationHash table.

I believe `smgrclose_internal()` should be in this comment.

Oops. Yeah, that's a mistake.

Still I don't believe it worth to separate smgrclose_internal from
smgrclose. Is there measurable performance improvement from this
change? Even if there is, it will be lesser with SH_FILLFACTOR 0.75 .

The reason I did that is due to the fact that smgrcloseall() loops
over the entire hash table and removes each entry one by one. The
problem is that if I do a smgrtable_delete or smgrtable_delete_item in
that loop then I'd need to restart the loop each time. Be aware that
a simplehash delete can move entries earlier in the table, so it might
cause us to miss entries during the loop. Restarting the loop each
iteration is not going to be very efficient, so instead, I opted to
make a version of smgrclose() that does not remove from the table so
that I can just wipe out all table entries at the end of the loop. I
called that smgrclose_internal().

If you read comments in SH_START_ITERATE, you'll see:

* Search for the first empty element. As deletions during iterations
are
* supported, we want to start/end at an element that cannot be
affected
* by elements being shifted.

* Iterate backwards, that allows the current element to be deleted,
even
* if there are backward shifts

Therefore, it is safe to delete during iteration, and it doesn't lead
nor
require loop restart.

An additional small benefit is that smgrclosenode() can get away with
a single hashtable lookup rather than having to lookup the entry again
with smgrtable_delete(). Using smgrtable_delete_item() deletes by
bucket rather than key value which should be a good bit faster in many
cases. I think the SH_ENTRY_CLEANUP macro is quite useful here as I
don't need to worry about NULLing out the smgr_owner in yet another
location where I do a hash delete.

Doubtfully it makes sense since smgrclosenode is called only in
LocalExecuteInvalidationMessage, ie when other backend drops some
relation. There is no useful performance gain from it.

As well I don't support modification simplehash.h for
SH_ENTRY_INITIALIZER,
SH_ENTRY_CLEANUP and SH_TRUNCATE. The initialization could comfortably
live in smgropen and the cleanup in smgrclose. And then SH_TRUNCATE
doesn't mean much.

Can you share what you've got in mind here?

The problem I'm solving with SH_ENTRY_INITIALIZER is the fact that in
SH_INSERT_HASH_INTERNAL(), when we add a new item, we do entry->SH_KEY
= key; to set the new entries key. Since I have SH_KEY defined as:

#define SH_KEY data->smgr_rnode

then I need some way to allocate the memory for ->data before the key
is set. Doing that in smrgopen() is too late. We've already crashed by
then for referencing uninitialised memory.

Oh, now I see.
I could suggest work-around:
- use entry->hash as a whole key value and manually resolve hash
collision with chaining.
But it looks ugly: use hash table and still manually resolve collisions.

Therefore perhaps SH_ENTRY_INITIALIZER has sense.

But SH_ENTRY_CLEANUP is abused in the patch: it is not symmetric to
SH_ENTRY_INITIALIZER. It smells bad. `smgr_owner` is better cleaned
in a way it is cleaned now in smgrclose because it is less obscure.
And SH_ENTRY_CLEANUP should be just `pfree(a->data)`.

And still no reason to have SH_TRUNCATE.

I did try putting the key in SMgrEntry but found the performance to be
quite a bit worse than keeping the SMgrEntry down to 16 bytes. That
makes sense to me as we only need to compare the key when we find an
entry with the same hash value as the one we're looking for. There's a
pretty high chance of that being the entry we want. If I got my hash
function right then the odds are about 1 in 4 billion of it not being
the one we want. The only additional price we pay when we get two
entries with the same hash value is an additional pointer dereference
and a key comparison.

It has sense: whole benefit of simplehash is cache locality, and
it is gained with smaller entry.

regards,
Yura Sokolov

On Sun, 25 Apr 2021 at 18:48, Yura Sokolov <y.sokolov@postgrespro.ru> wrote:

If you read comments in SH_START_ITERATE, you'll see:

* Search for the first empty element. As deletions during iterations
are
* supported, we want to start/end at an element that cannot be
affected
* by elements being shifted.

* Iterate backwards, that allows the current element to be deleted,
even
* if there are backward shifts

Therefore, it is safe to delete during iteration, and it doesn't lead
nor
require loop restart.

I had only skimmed that with a pre-loaded assumption that it wouldn't
be safe. I didn't do a very good job of reading it as I failed to
notice the lack of guarantees were about deleting items other than the
current one. I didn't consider the option of finding a free bucket
then looping backwards to avoid missing entries that are moved up
during a delete.

With that, I changed the patch to get rid of the SH_TRUNCATE and got
rid of the smgrclose_internal which skips the hash delete. The code
is much more similar to how it was now.

In regards to the hashing stuff. I added a new function to
pg_bitutils.h to rotate left and I'm using that instead of the other
expression that was taken from nodeHash.c

For the hash function, I've done some further benchmarking with:

1) The attached v2 patch
2) The attached + plus use_hash_combine.patch.txt which uses
hash_combine() instead of pg_rotate_left32()ing the hashkey each time.
3) The attached v2 with use_hash_bytes.patch.txt applied.
4) Master

I've also included the hash stats from each version of the hash function.

I hope the numbers help indicate the reason I picked the hash function
that I did.

1) v2 patch.
CPU: user: 108.23 s, system: 6.97 s, elapsed: 115.63 s
CPU: user: 114.78 s, system: 6.88 s, elapsed: 121.71 s
CPU: user: 107.53 s, system: 5.70 s, elapsed: 113.28 s
CPU: user: 108.43 s, system: 5.73 s, elapsed: 114.22 s
CPU: user: 106.18 s, system: 5.73 s, elapsed: 111.96 s
CPU: user: 108.04 s, system: 5.29 s, elapsed: 113.39 s
CPU: user: 107.64 s, system: 5.64 s, elapsed: 113.34 s
CPU: user: 106.64 s, system: 5.58 s, elapsed: 112.27 s
CPU: user: 107.91 s, system: 5.40 s, elapsed: 113.36 s
CPU: user: 115.35 s, system: 6.60 s, elapsed: 122.01 s

Median = 113.375 s

LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 997,
max chain: 5, avg chain: 0.490650, total_collisions: 422,
max_collisions: 3, avg_collisions: 0.207677

2) v2 patch + use_hash_combine.patch.txt
CPU: user: 113.22 s, system: 5.52 s, elapsed: 118.80 s
CPU: user: 116.63 s, system: 5.87 s, elapsed: 122.56 s
CPU: user: 115.33 s, system: 5.73 s, elapsed: 121.12 s
CPU: user: 113.11 s, system: 5.61 s, elapsed: 118.78 s
CPU: user: 112.56 s, system: 5.51 s, elapsed: 118.13 s
CPU: user: 114.55 s, system: 5.80 s, elapsed: 120.40 s
CPU: user: 121.79 s, system: 6.45 s, elapsed: 128.29 s
CPU: user: 113.98 s, system: 4.50 s, elapsed: 118.52 s
CPU: user: 113.24 s, system: 5.63 s, elapsed: 118.93 s
CPU: user: 114.11 s, system: 5.60 s, elapsed: 119.78 s

Median = 119.355 s

LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 971,
max chain: 6, avg chain: 0.477854, total_collisions: 433,
max_collisions: 4, avg_collisions: 0.213091

3) v2 patch + use_hash_bytes.patch.txt
CPU: user: 120.87 s, system: 6.69 s, elapsed: 127.62 s
CPU: user: 112.40 s, system: 4.68 s, elapsed: 117.14 s
CPU: user: 113.19 s, system: 5.44 s, elapsed: 118.69 s
CPU: user: 112.15 s, system: 4.73 s, elapsed: 116.93 s
CPU: user: 111.10 s, system: 5.59 s, elapsed: 116.74 s
CPU: user: 112.03 s, system: 5.74 s, elapsed: 117.82 s
CPU: user: 113.69 s, system: 4.33 s, elapsed: 118.07 s
CPU: user: 113.30 s, system: 4.19 s, elapsed: 117.55 s
CPU: user: 112.77 s, system: 5.57 s, elapsed: 118.39 s
CPU: user: 112.25 s, system: 4.59 s, elapsed: 116.88 s

Median = 117.685 s

LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 900,
max chain: 4, avg chain: 0.442913, total_collisions: 415,
max_collisions: 4, avg_collisions: 0.204232

4) master
CPU: user: 117.89 s, system: 5.7 s, elapsed: 123.65 s
CPU: user: 117.81 s, system: 5.74 s, elapsed: 123.62 s
CPU: user: 119.39 s, system: 5.75 s, elapsed: 125.2 s
CPU: user: 117.98 s, system: 4.39 s, elapsed: 122.41 s
CPU: user: 117.92 s, system: 4.79 s, elapsed: 122.76 s
CPU: user: 119.84 s, system: 4.75 s, elapsed: 124.64 s
CPU: user: 120.6 s, system: 5.82 s, elapsed: 126.49 s
CPU: user: 118.74 s, system: 5.71 s, elapsed: 124.51 s
CPU: user: 124.29 s, system: 6.79 s, elapsed: 131.14 s
CPU: user: 118.73 s, system: 5.67 s, elapsed: 124.47 s

Median = 124.49 s

You can see that the bare v2 patch is quite a bit faster than any of
the alternatives. We'd be better of with hash_bytes than using
hash_combine() both for performance and for the seemingly better job
the hash function does at reducing the hash collisions.

David

David Rowley писал 2021-04-25 16:36:

On Sun, 25 Apr 2021 at 18:48, Yura Sokolov <y.sokolov@postgrespro.ru>
wrote:

If you read comments in SH_START_ITERATE, you'll see:

* Search for the first empty element. As deletions during
iterations
are
* supported, we want to start/end at an element that cannot be
affected
* by elements being shifted.

* Iterate backwards, that allows the current element to be deleted,
even
* if there are backward shifts

Therefore, it is safe to delete during iteration, and it doesn't lead
nor
require loop restart.

I had only skimmed that with a pre-loaded assumption that it wouldn't
be safe. I didn't do a very good job of reading it as I failed to
notice the lack of guarantees were about deleting items other than the
current one. I didn't consider the option of finding a free bucket
then looping backwards to avoid missing entries that are moved up
during a delete.

With that, I changed the patch to get rid of the SH_TRUNCATE and got
rid of the smgrclose_internal which skips the hash delete. The code
is much more similar to how it was now.

In regards to the hashing stuff. I added a new function to
pg_bitutils.h to rotate left and I'm using that instead of the other
expression that was taken from nodeHash.c

For the hash function, I've done some further benchmarking with:

1) The attached v2 patch
2) The attached + plus use_hash_combine.patch.txt which uses
hash_combine() instead of pg_rotate_left32()ing the hashkey each time.
3) The attached v2 with use_hash_bytes.patch.txt applied.
4) Master

I've also included the hash stats from each version of the hash
function.

I hope the numbers help indicate the reason I picked the hash function
that I did.

1) v2 patch.
Median = 113.375 s

LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 997,
max chain: 5, avg chain: 0.490650, total_collisions: 422,
max_collisions: 3, avg_collisions: 0.207677

2) v2 patch + use_hash_combine.patch.txt
Median = 119.355 s

LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 971,
max chain: 6, avg chain: 0.477854, total_collisions: 433,
max_collisions: 4, avg_collisions: 0.213091

3) v2 patch + use_hash_bytes.patch.txt
Median = 117.685 s

LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 900,
max chain: 4, avg chain: 0.442913, total_collisions: 415,
max_collisions: 4, avg_collisions: 0.204232

4) master
Median = 124.49 s

You can see that the bare v2 patch is quite a bit faster than any of
the alternatives. We'd be better of with hash_bytes than using
hash_combine() both for performance and for the seemingly better job
the hash function does at reducing the hash collisions.

David

Looks much better! Simpler is almost always better.

Minor remarks:

Comment for SH_ENTRY_INITIALIZER e. May be like:
- SH_ENTRY_INITIALIZER(a) - if defined, this macro is called for new
entries
before key or hash is stored in. For example, it can be used to make
necessary memory allocations.

`pg_rotate_left32(x, 1) == pg_rotate_right(x, 31)`, therefore there's
no need to add `pg_rotate_left32` at all. More over, for hash combining
there's no much difference between `pg_rotate_left32(x, 1)` and
`pg_rotate_right(x, 1)`. (To be honestly, there is a bit of difference
due to murmur construction, but it should not be very big.)

If your test so sensitive to hash function speed, then I'd suggest
to try something even simpler:

static inline uint32
relfilenodebackend_hash(RelFileNodeBackend *rnode)
{
uint32 h = 0;
#define step(x) h ^= (uint32)(x) * 0x85ebca6b; h = pg_rotate_right(h,
11); h *= 9;
step(rnode->node.relNode);
step(rnode->node.spcNode); // spcNode could be different for same
relNode only
// during table movement. Does it pay
to hash it?
step(rnode->node.dbNode);
step(rnode->backend); // does it matter to hash backend?
// It equals to InvalidBackendId for
non-temporary relations
// and temporary relations in same
database never have same
// relNode (have they?).
return murmurhash32(hashkey);
}

I'd like to see benchmark code. It quite interesting this place became
measurable at all.

regards,
Yura Sokolov.

On Mon, 26 Apr 2021 at 05:03, Yura Sokolov <y.sokolov@postgrespro.ru> wrote:

If your test so sensitive to hash function speed, then I'd suggest
to try something even simpler:

static inline uint32
relfilenodebackend_hash(RelFileNodeBackend *rnode)
{
uint32 h = 0;
#define step(x) h ^= (uint32)(x) * 0x85ebca6b; h = pg_rotate_right(h,
11); h *= 9;
step(rnode->node.relNode);
step(rnode->node.spcNode); // spcNode could be different for same
relNode only
// during table movement. Does it pay
to hash it?
step(rnode->node.dbNode);
step(rnode->backend); // does it matter to hash backend?
// It equals to InvalidBackendId for
non-temporary relations
// and temporary relations in same
database never have same
// relNode (have they?).
return murmurhash32(hashkey);
}

I tried that and it got a median result of 113.795 seconds over 14
runs with this recovery benchmark test.

LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 1014,
max chain: 6, avg chain: 0.499016, total_collisions: 428,
max_collisions: 3, avg_collisions: 0.210630

I also tried the following hash function just to see how much
performance might be left from speeding it up:

static inline uint32
relfilenodebackend_hash(RelFileNodeBackend *rnode)
{
uint32 h;

h = pg_rotate_right32((uint32) rnode->node.relNode, 16) ^ ((uint32)
rnode->node.dbNode);
return murmurhash32(h);
}

I got a median of 112.685 seconds over 14 runs with:

LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 1044,
max chain: 7, avg chain: 0.513780, total_collisions: 438,
max_collisions: 3, avg_collisions: 0.215551

So it looks like there might not be too much left given that v2 was
113.375 seconds (median over 10 runs)

I'd like to see benchmark code. It quite interesting this place became
measurable at all.

Sure.

$ cat recoverybench_insert_hash.sh
#!/bin/bash

pg_ctl stop -D pgdata -m smart
pg_ctl start -D pgdata -l pg.log -w
psql -f setup1.sql postgres > /dev/null
psql -c "create table log_wal (lsn pg_lsn not null);" postgres > /dev/null
psql -c "insert into log_wal values(pg_current_wal_lsn());" postgres > /dev/null
psql -c "insert into hp select x,0 from generate_series(1,100000000)
x;" postgres > /dev/null
psql -c "insert into log_wal values(pg_current_wal_lsn());" postgres > /dev/null
psql -c "select 'Used ' ||
pg_size_pretty(pg_wal_lsn_diff(pg_current_wal_lsn(), lsn)) || ' of
WAL' from log_wal limit 1;" postgres
pg_ctl stop -D pgdata -m immediate -w
echo Starting Postgres...
pg_ctl start -D pgdata -l pg.log

$ cat setup1.sql
drop table if exists hp;
create table hp (a int primary key, b int not null) partition by hash(a);
select 'create table hp'||x|| ' partition of hp for values with
(modulus 1000, remainder '||x||');' from generate_Series(0,999) x;
\gexec

config:
shared_buffers = 10GB
checkpoint_timeout = 60min
max_wal_size = 20GB
min_wal_size = 20GB

For subsequent runs, if you apply the patch that does the PANIC at the
end of recovery, you'll just need to start the database up again to
perform recovery again. You can then just tail -f on your postgres
logs to watch for the "redo done" message which will show you the time
spent doing recovery.

David.

Hi,

On 2021-04-25 01:27:24 +0300, Yura Sokolov wrote:

It is quite interesting result. Simplehash being open-addressing with
linear probing is friendly for cpu cache. I'd recommend to define
SH_FILLFACTOR with value lower than default (0.9). I believe 0.75 is
suitable most for such kind of hash table.

It's not a "plain" linear probing hash table (although it is on the lookup
side). During insertions collisions are reordered so that the average distance
from the "optimal" position is ~even ("robin hood hashing"). That allows a
higher load factor than a plain linear probed hash table (for which IIRC
there's data to show 0.75 to be a good default load factor).

There of course may still be a benefit in lowering the load factor, but I'd
not start there.

David's test aren't really suited to benchmarking the load factor, but to me
the stats he showed didn't highlight a need to lower the load factor. Lowering
the fill factor does influence the cache hit ratio...

Greetings,

Andres Freund

Andres Freund писал 2021-04-26 21:46:

Hi,

On 2021-04-25 01:27:24 +0300, Yura Sokolov wrote:

It is quite interesting result. Simplehash being open-addressing with
linear probing is friendly for cpu cache. I'd recommend to define
SH_FILLFACTOR with value lower than default (0.9). I believe 0.75 is
suitable most for such kind of hash table.

It's not a "plain" linear probing hash table (although it is on the
lookup
side). During insertions collisions are reordered so that the average
distance
from the "optimal" position is ~even ("robin hood hashing"). That
allows a
higher load factor than a plain linear probed hash table (for which
IIRC
there's data to show 0.75 to be a good default load factor).

Even for Robin Hood hashing 0.9 fill factor is too high. It leads to too
much movements on insertion/deletion and longer average collision chain.

Note that Robin Hood doesn't optimize average case. Indeed, usually
Robin Hood
has worse (longer) average collision chain than simple linear probing.
Robin Hood hashing optimizes worst case, ie it guarantees there is no
unnecessary
long collision chain.

See discussion on Rust hash table fill factor when it were Robin Hood:
https://github.com/rust-lang/rust/issues/38003

There of course may still be a benefit in lowering the load factor, but
I'd
not start there.

David's test aren't really suited to benchmarking the load factor, but
to me
the stats he showed didn't highlight a need to lower the load factor.
Lowering
the fill factor does influence the cache hit ratio...

Greetings,

Andres Freund

regards,
Yura.

Hi,

On 2021-04-26 22:44:13 +0300, Yura Sokolov wrote:

Even for Robin Hood hashing 0.9 fill factor is too high. It leads to too
much movements on insertion/deletion and longer average collision chain.

That's true for modification heavy cases - but most hash tables in PG,
including the smgr one, are quite read heavy. For workloads where
there's a lot of smgr activity, the other overheads in relation
creation/drop handling are magnitudes more expensive than the collision
handling.

Note that simplehash.h also grows when the distance gets too big and
when there are too many elements to move, not just based on the fill
factor.

I kinda wish we had a chained hashtable implementation with the same
interface as simplehash. It's very use-case dependent which approach is
better, and right now we might be forcing some users to choose linear
probing because simplehash.h is still faster than dynahash, even though
chaining would actually be more appropriate.

Note that Robin Hood doesn't optimize average case.

Right.

See discussion on Rust hash table fill factor when it were Robin Hood:
https://github.com/rust-lang/rust/issues/38003

The first sentence actually confirms my point above, about it being a
question of read vs write heavy.

Greetings,

Andres Freund

David Rowley писал 2021-04-26 09:43:

I tried that and it got a median result of 113.795 seconds over 14
runs with this recovery benchmark test.

LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 1014,
max chain: 6, avg chain: 0.499016, total_collisions: 428,
max_collisions: 3, avg_collisions: 0.210630

I also tried the following hash function just to see how much
performance might be left from speeding it up:

static inline uint32
relfilenodebackend_hash(RelFileNodeBackend *rnode)
{
uint32 h;

h = pg_rotate_right32((uint32) rnode->node.relNode, 16) ^ ((uint32)
rnode->node.dbNode);
return murmurhash32(h);
}

I got a median of 112.685 seconds over 14 runs with:

LOG: size: 4096, members: 2032, filled: 0.496094, total chain: 1044,
max chain: 7, avg chain: 0.513780, total_collisions: 438,
max_collisions: 3, avg_collisions: 0.215551

The best result is with just:

return (uint32)rnode->node.relNode;

ie, relNode could be taken without mixing at all.
relNode is unique inside single database, and almost unique among whole
cluster
since it is Oid.

I'd like to see benchmark code. It quite interesting this place became
measurable at all.

Sure.

$ cat recoverybench_insert_hash.sh
....

David.

So, I've repeated benchmark with different number of partitons (I tried
to catch higher fillfactor) and less amount of inserted data (since I
don't
want to stress my SSD).

partitions/ | dynahash | dynahash + | simplehash | simplehash + |
fillfactor | | simple func | | simple func |
------------+----------+-------------+--------------+
3500/0.43 | 3.73s | 3.54s | 3.58s | 3.34s |
3200/0.78 | 3.64s | 3.46s | 3.47s | 3.25s |
1500/0.74 | 3.18s | 2.97s | 3.03s | 2.79s |

Fillfactor is effective fillfactor in simplehash with than number of
partitions.
I wasn't able to measure with fillfactor close to 0.9 since looks like
simplehash tends to grow much earlier due to SH_GROW_MAX_MOVE.

Simple function is hash function that returns only rnode->node.relNode.
I've test it both with simplehash and dynahash.
For dynahash also custom match function were made.

Conclusion:
- trivial hash function gives better results for both simplehash and
dynahash,
- simplehash improves performance for both complex and trivial hash
function,
- simplehash + trivial function perform best.

I'd like to hear other's people comments on trivial hash function. But
since
generation of relation's Oid are not subject of human interventions, I'd
recommend
to stick with trivial.

Since patch is simple, harmless and gives measurable improvement,
I think it is ready for commit fest.

regards,
Yura Sokolov.
Postgres Proffesional https://www.postgrespro.com

PS. David, please send patch once again since my mail client reattached
files in
previous messages, and commit fest robot could think I'm author.

On Thu, 29 Apr 2021 at 00:28, Yura Sokolov <y.sokolov@postgrespro.ru> wrote:

The best result is with just:

return (uint32)rnode->node.relNode;

ie, relNode could be taken without mixing at all.
relNode is unique inside single database, and almost unique among whole
cluster
since it is Oid.

I admit to having tried that too just to almost eliminate the cost of
hashing. I just didn't consider it something we'd actually do.

The system catalogues are quite likely to all have the same
relfilenode in all databases, so for workloads that have a large
number of databases, looking up WAL records that touch the catalogues
is going to be pretty terrible.

The simplified hash function I wrote with just the relNode and dbNode
would be the least I'd be willing to entertain. However, I just
wouldn't be surprised if there was a good reason for that being bad
too.

So, I've repeated benchmark with different number of partitons (I tried
to catch higher fillfactor) and less amount of inserted data (since I
don't
want to stress my SSD).

partitions/ | dynahash | dynahash + | simplehash | simplehash + |
fillfactor | | simple func | | simple func |
------------+----------+-------------+--------------+
3500/0.43 | 3.73s | 3.54s | 3.58s | 3.34s |
3200/0.78 | 3.64s | 3.46s | 3.47s | 3.25s |
1500/0.74 | 3.18s | 2.97s | 3.03s | 2.79s |

Fillfactor is effective fillfactor in simplehash with than number of
partitions.
I wasn't able to measure with fillfactor close to 0.9 since looks like
simplehash tends to grow much earlier due to SH_GROW_MAX_MOVE.

Thanks for testing that.

I also ran some tests last night to test the 0.75 vs 0.9 fillfactor to
see if it made a difference. The test was similar to last time, but I
trimmed the number of rows inserted from 100 million down to 25
million. Last time I tested with 1000 partitions, this time with each
of: 100 200 300 400 500 600 700 800 900 1000 partitions. There didn't
seem to be any point of testing lower than that as the minimum hash
table size is 512.

The averages over 10 runs were:

nparts ff75 ff90
100 21.898 22.226
200 23.105 25.493
300 25.274 24.251
400 25.139 25.611
500 25.738 25.454
600 26.656 26.82
700 27.577 27.102
800 27.608 27.546
900 27.284 28.186
1000 29 28.153

Or to summarise a bit, we could just look at the sum of all the
results per fillfactor:

sum ff75 2592.79
sum ff90 2608.42 100.6%

fillfactor 75 did come out slightly faster, but only just. It seems
close enough that it might be better just to keep the 90 to save a
little memory and improve caching elsewhere. Also, from below, you
can see that for 300, 500, 600, 700, 1000 tables tests, the hash
tables ended up the same size, yet there's a bit of variability in the
timing result. So the 0.6% gain might just be noise.

I don't think it's worth making the fillfactor 75.

drowley@amd3990x:~/recoverylogs$ grep -rH -m 1 "collisions"
ff75_tb100.log:LOG: size: 1024, members: 231, filled: 0.225586, total
chain: 33, max chain: 2, avg chain: 0.142857, total_collisions: 20,
max_collisions: 2, avg_collisions: 0.086580
ff90_tb100.log:LOG: size: 512, members: 231, filled: 0.451172, total
chain: 66, max chain: 2, avg chain: 0.285714, total_collisions: 36,
max_collisions: 2, avg_collisions: 0.155844

ff75_tb200.log:LOG: size: 1024, members: 431, filled: 0.420898, total
chain: 160, max chain: 4, avg chain: 0.371230, total_collisions: 81,
max_collisions: 3, avg_collisions: 0.187935
ff90_tb200.log:LOG: size: 512, members: 431, filled: 0.841797, total
chain: 942, max chain: 9, avg chain: 2.185615, total_collisions: 134,
max_collisions: 3, avg_collisions: 0.310905

ff90_tb300.log:LOG: size: 1024, members: 631, filled: 0.616211, total
chain: 568, max chain: 9, avg chain: 0.900158, total_collisions: 158,
max_collisions: 4, avg_collisions: 0.250396
ff75_tb300.log:LOG: size: 1024, members: 631, filled: 0.616211, total
chain: 568, max chain: 9, avg chain: 0.900158, total_collisions: 158,
max_collisions: 4, avg_collisions: 0.250396

ff75_tb400.log:LOG: size: 2048, members: 831, filled: 0.405762, total
chain: 341, max chain: 4, avg chain: 0.410349, total_collisions: 162,
max_collisions: 3, avg_collisions: 0.194946
ff90_tb400.log:LOG: size: 1024, members: 831, filled: 0.811523, total
chain: 1747, max chain: 15, avg chain: 2.102286, total_collisions:
269, max_collisions: 3, avg_collisions: 0.323706

ff75_tb500.log:LOG: size: 2048, members: 1031, filled: 0.503418,
total chain: 568, max chain: 5, avg chain: 0.550921, total_collisions:
219, max_collisions: 4, avg_collisions: 0.212415
ff90_tb500.log:LOG: size: 2048, members: 1031, filled: 0.503418,
total chain: 568, max chain: 5, avg chain: 0.550921, total_collisions:
219, max_collisions: 4, avg_collisions: 0.212415

ff75_tb600.log:LOG: size: 2048, members: 1231, filled: 0.601074,
total chain: 928, max chain: 7, avg chain: 0.753859, total_collisions:
298, max_collisions: 4, avg_collisions: 0.242080
ff90_tb600.log:LOG: size: 2048, members: 1231, filled: 0.601074,
total chain: 928, max chain: 7, avg chain: 0.753859, total_collisions:
298, max_collisions: 4, avg_collisions: 0.242080

ff75_tb700.log:LOG: size: 2048, members: 1431, filled: 0.698730,
total chain: 1589, max chain: 9, avg chain: 1.110412,
total_collisions: 391, max_collisions: 4, avg_collisions: 0.273235
ff90_tb700.log:LOG: size: 2048, members: 1431, filled: 0.698730,
total chain: 1589, max chain: 9, avg chain: 1.110412,
total_collisions: 391, max_collisions: 4, avg_collisions: 0.273235

ff75_tb800.log:LOG: size: 4096, members: 1631, filled: 0.398193,
total chain: 628, max chain: 6, avg chain: 0.385040, total_collisions:
296, max_collisions: 3, avg_collisions: 0.181484
ff90_tb800.log:LOG: size: 2048, members: 1631, filled: 0.796387,
total chain: 2903, max chain: 12, avg chain: 1.779890,
total_collisions: 515, max_collisions: 3, avg_collisions: 0.315757

ff75_tb900.log:LOG: size: 4096, members: 1831, filled: 0.447021,
total chain: 731, max chain: 5, avg chain: 0.399235, total_collisions:
344, max_collisions: 3, avg_collisions: 0.187875
ff90_tb900.log:LOG: size: 2048, members: 1831, filled: 0.894043,
total chain: 6364, max chain: 14, avg chain: 3.475696,
total_collisions: 618, max_collisions: 4, avg_collisions: 0.337520

ff75_tb1000.log:LOG: size: 4096, members: 2031, filled: 0.495850,
total chain: 1024, max chain: 6, avg chain: 0.504185,
total_collisions: 416, max_collisions: 3, avg_collisions: 0.204825
ff90_tb1000.log:LOG: size: 4096, members: 2031, filled: 0.495850,
total chain: 1024, max chain: 6, avg chain: 0.504185,
total_collisions: 416, max_collisions: 3, avg_collisions: 0.204825

Another line of thought for making it go faster would be to do
something like get rid of the hash status field from SMgrEntry. That
could be either coded into a single bit we'd borrow from the hash
value, or it could be coded into the least significant bit of the data
field. A pointer to palloc'd memory should always be MAXALIGNed,
which means at least the lower two bits are always zero. We'd just
need to make sure and do something like "data & ~((uintptr_t) 3)" to
trim off the hash status bits before dereferencing the pointer. That
would make the SMgrEntry 12 bytes on a 64-bit machine. However, it
would also mean that some entries would span 2 cache lines, which
might affect performance a bit.

PS. David, please send patch once again since my mail client reattached
files in
previous messages, and commit fest robot could think I'm author.

Authors are listed manually in the CF app. The app will pickup .patch
files from the latest email in the thread and the CF bot will test
those. So it does pay to be pretty careful when attaching patches to
threads that are in the CF app. That's the reason I added the .txt
extension to the recovery panic patch. The CF bot machines would have
complained about that.

David Rowley писал 2021-04-29 02:51:

On Thu, 29 Apr 2021 at 00:28, Yura Sokolov <y.sokolov@postgrespro.ru>
wrote:

The best result is with just:

return (uint32)rnode->node.relNode;

ie, relNode could be taken without mixing at all.
relNode is unique inside single database, and almost unique among
whole
cluster
since it is Oid.

I admit to having tried that too just to almost eliminate the cost of
hashing. I just didn't consider it something we'd actually do.

The system catalogues are quite likely to all have the same
relfilenode in all databases, so for workloads that have a large
number of databases, looking up WAL records that touch the catalogues
is going to be pretty terrible.

Single workload that could touch system catalogues in different
databases is recovery (and autovacuum?). Client backends couldn't
be connected to more than one database.

But netherless, you're right. I oversimplified it intentionally.
I wrote originally:

hashcode = (uint32)rnode->node.dbNode * 0xc2b2ae35;
hashcode ^= (uint32)rnode->node.relNode;
return hashcode;

But before sending mail I'd cut dbNode part.
Still, main point: relNode could be put unmixed into final value.
This way less collisions happen.

The simplified hash function I wrote with just the relNode and dbNode
would be the least I'd be willing to entertain. However, I just
wouldn't be surprised if there was a good reason for that being bad
too.

So, I've repeated benchmark with different number of partitons (I
tried
to catch higher fillfactor) and less amount of inserted data (since I
don't
want to stress my SSD).

partitions/ | dynahash | dynahash + | simplehash | simplehash + |
fillfactor | | simple func | | simple func |
------------+----------+-------------+--------------+
3500/0.43 | 3.73s | 3.54s | 3.58s | 3.34s |
3200/0.78 | 3.64s | 3.46s | 3.47s | 3.25s |
1500/0.74 | 3.18s | 2.97s | 3.03s | 2.79s |

Fillfactor is effective fillfactor in simplehash with than number of
partitions.
I wasn't able to measure with fillfactor close to 0.9 since looks like
simplehash tends to grow much earlier due to SH_GROW_MAX_MOVE.

Thanks for testing that.

I also ran some tests last night to test the 0.75 vs 0.9 fillfactor to
see if it made a difference. The test was similar to last time, but I
trimmed the number of rows inserted from 100 million down to 25
million. Last time I tested with 1000 partitions, this time with each
of: 100 200 300 400 500 600 700 800 900 1000 partitions. There didn't
seem to be any point of testing lower than that as the minimum hash
table size is 512.

The averages over 10 runs were:

nparts ff75 ff90
100 21.898 22.226
200 23.105 25.493
300 25.274 24.251
400 25.139 25.611
500 25.738 25.454
600 26.656 26.82
700 27.577 27.102
800 27.608 27.546
900 27.284 28.186
1000 29 28.153

Or to summarise a bit, we could just look at the sum of all the
results per fillfactor:

sum ff75 2592.79
sum ff90 2608.42 100.6%

fillfactor 75 did come out slightly faster, but only just. It seems
close enough that it might be better just to keep the 90 to save a
little memory and improve caching elsewhere. Also, from below, you
can see that for 300, 500, 600, 700, 1000 tables tests, the hash
tables ended up the same size, yet there's a bit of variability in the
timing result. So the 0.6% gain might just be noise.

I don't think it's worth making the fillfactor 75.

To be clear: I didn't change SH_FILLFACTOR. It were equal to 0.9 .
I just were not able to catch table with fill factor more than 0.78.
Looks like you've got it with 900 partitions :-)

Another line of thought for making it go faster would be to do
something like get rid of the hash status field from SMgrEntry. That
could be either coded into a single bit we'd borrow from the hash
value, or it could be coded into the least significant bit of the data
field. A pointer to palloc'd memory should always be MAXALIGNed,
which means at least the lower two bits are always zero. We'd just
need to make sure and do something like "data & ~((uintptr_t) 3)" to
trim off the hash status bits before dereferencing the pointer. That
would make the SMgrEntry 12 bytes on a 64-bit machine. However, it
would also mean that some entries would span 2 cache lines, which
might affect performance a bit.

Then data pointer will be itself unaligned to 8 bytes. While x86 is
mostly indifferent to this, doubtfully this memory economy will pay
off.

regards,
Yura Sokolov.

On Thu, 29 Apr 2021 at 12:30, Yura Sokolov <y.sokolov@postgrespro.ru> wrote:

David Rowley писал 2021-04-29 02:51:

Another line of thought for making it go faster would be to do
something like get rid of the hash status field from SMgrEntry. That
could be either coded into a single bit we'd borrow from the hash
value, or it could be coded into the least significant bit of the data
field. A pointer to palloc'd memory should always be MAXALIGNed,
which means at least the lower two bits are always zero. We'd just
need to make sure and do something like "data & ~((uintptr_t) 3)" to
trim off the hash status bits before dereferencing the pointer. That
would make the SMgrEntry 12 bytes on a 64-bit machine. However, it
would also mean that some entries would span 2 cache lines, which
might affect performance a bit.

Then data pointer will be itself unaligned to 8 bytes. While x86 is
mostly indifferent to this, doubtfully this memory economy will pay
off.

Actually, I didn't think very hard about that. The struct would still
be 16 bytes and just have padding so the data pointer was aligned to 8
bytes (assuming a 64-bit machine).

David

I've attached an updated patch. I forgot to call SH_ENTRY_CLEANUP,
when it's defined during SH_RESET.

I also tided up a couple of comments and change the code to use
pg_rotate_right32(.., 31) instead of adding a new function for
pg_rotate_left32 and calling that to shift left 1 bit.

David

Hi David,

You're probably aware of this, but just to make it explicit: Jakub
Wartak was testing performance of recovery, and one of the bottlenecks
he found in some of his cases was dynahash as used by SMgr. It seems
quite possible that this work would benefit some of his test workloads.
He last posted about it here:

/messages/by-id/VI1PR0701MB69608CBCE44D80857E59572EF6CA0@VI1PR0701MB6960.eurprd07.prod.outlook.com

though the fraction of dynahash-from-SMgr is not as high there as in
some of other reports I saw.

--
�lvaro Herrera Valdivia, Chile

Hi David, Alvaro, -hackers

Hi David,

You're probably aware of this, but just to make it explicit: Jakub Wartak was
testing performance of recovery, and one of the bottlenecks he found in
some of his cases was dynahash as used by SMgr. It seems quite possible
that this work would benefit some of his test workloads.

I might be a little bit out of the loop, but as Alvaro stated - Thomas did plenty of excellent job related to recovery performance in that thread. In my humble opinion and if I'm not mistaken (I'm speculating here) it might be *not* how Smgr hash works, but how often it is being exercised and that would also explain relatively lower than expected(?) gains here. There are at least two very important emails from him that I'm aware that are touching the topic of reordering/compacting/batching calls to Smgr:
/messages/by-id/CA+hUKG+2Vw3UAVNJSfz5_zhRcHUWEBDrpB7pyQ85Yroep0AKbw@mail.gmail.com
/messages/by-id/CA+hUKGK4StQ=eXGZ-5hTdYCmSfJ37yzLp9yW9U5uH6526H+Ueg@mail.gmail.com

Another potential option that we've discussed is that the redo generation itself is likely a brake of efficient recovery performance today (e.g. INSERT-SELECT on table with indexes, generates interleaved WAL records that touch often limited set of blocks that usually put Smgr into spotlight).

-Jakub Wartak.

Hi Jakub,

On Wed, 5 May 2021 at 20:16, Jakub Wartak <Jakub.Wartak@tomtom.com> wrote:

I might be a little bit out of the loop, but as Alvaro stated - Thomas did plenty of excellent job related to recovery performance in that thread. In my humble opinion and if I'm not mistaken (I'm speculating here) it might be *not* how Smgr hash works, but how often it is being exercised and that would also explain relatively lower than expected(?) gains here. There are at least two very important emails from him that I'm aware that are touching the topic of reordering/compacting/batching calls to Smgr:
/messages/by-id/CA+hUKG+2Vw3UAVNJSfz5_zhRcHUWEBDrpB7pyQ85Yroep0AKbw@mail.gmail.com
/messages/by-id/CA+hUKGK4StQ=eXGZ-5hTdYCmSfJ37yzLp9yW9U5uH6526H+Ueg@mail.gmail.com

I'm not much of an expert here and I didn't follow the recovery
prefetching stuff closely. So, with that in mind, I think there are
lots that could be done along the lines of what Thomas is mentioning.
Batching WAL records up by filenode then replaying each filenode one
by one when our batching buffer is full. There could be some sort of
parallel options there too, where workers replay a filenode each.
However, that wouldn't really work for recovery on a hot-standby
though. We'd need to ensure we replay the commit record for each
transaction last. I think you'd have to batch by filenode and
transaction in that case. Each batch might be pretty small on a
typical OLTP workload, so it might not help much there, or it might
hinder.

But having said that, I don't think any of those possibilities should
stop us speeding up smgropen().

Another potential option that we've discussed is that the redo generation itself is likely a brake of efficient recovery performance today (e.g. INSERT-SELECT on table with indexes, generates interleaved WAL records that touch often limited set of blocks that usually put Smgr into spotlight).

I'm not quite sure if I understand what you mean here. Is this
queuing up WAL records up during transactions and flush them out to
WAL every so often after rearranging them into an order that's more
optimal for replay?

David

Hey David,

I think you'd have to batch by filenode and transaction in that case. Each batch might be pretty small on a typical OLTP workload, so it might not help much there, or it might hinder.

True, it is very workload dependent (I was chasing mainly INSERTs multiValues, INSERT-SELECT) that often hit the same $block, certainly not OLTP. I would even say that INSERT-as-SELECT would be more suited for DWH-like processing.

But having said that, I don't think any of those possibilities should stop us speeding up smgropen().

Of course! I've tried a couple of much more smaller ideas, but without any big gains. I was able to squeeze like 300-400k function calls per second (WAL records/s), that was the point I think where I think smgropen() got abused.

Another potential option that we've discussed is that the redo generation

itself is likely a brake of efficient recovery performance today (e.g. INSERT-
SELECT on table with indexes, generates interleaved WAL records that touch
often limited set of blocks that usually put Smgr into spotlight).

I'm not quite sure if I understand what you mean here. Is this queuing up
WAL records up during transactions and flush them out to WAL every so
often after rearranging them into an order that's more optimal for replay?

Why not both? 😉 We were very concentrated on standby side, but on primary side one could also change how WAL records are generated:

1) Minimalization of records towards same repeated $block eg. Heap2 table_multi_insert() API already does this and it matters to generate more optimal stream for replay:

postgres@test=# create table t (id bigint primary key);
postgres@test=# insert into t select generate_series(1, 10);

results in many calls due to interleave heap with btree records for the same block from Smgr perspective (this is especially visible on highly indexed tables) =>
rmgr: Btree len (rec/tot): 64/ 64, tx: 17243284, lsn: 4/E7000108, prev 4/E70000A0, desc: INSERT_LEAF off 1, blkref #0: rel 1663/16384/32794 blk 1
rmgr: Heap len (rec/tot): 63/ 63, tx: 17243284, lsn: 4/E7000148, prev 4/E7000108, desc: INSERT off 2 flags 0x00, blkref #0: rel 1663/16384/32791 blk 0
rmgr: Btree len (rec/tot): 64/ 64, tx: 17243284, lsn: 4/E7000188, prev 4/E7000148, desc: INSERT_LEAF off 2, blkref #0: rel 1663/16384/32794 blk 1
rmgr: Heap len (rec/tot): 63/ 63, tx: 17243284, lsn: 4/E70001C8, prev 4/E7000188, desc: INSERT off 3 flags 0x00, blkref #0: rel 1663/16384/32791 blk 0
rmgr: Btree len (rec/tot): 64/ 64, tx: 17243284, lsn: 4/E7000208, prev 4/E70001C8, desc: INSERT_LEAF off 3, blkref #0: rel 1663/16384/32794 blk 1
rmgr: Heap len (rec/tot): 63/ 63, tx: 17243284, lsn: 4/E7000248, prev 4/E7000208, desc: INSERT off 4 flags 0x00, blkref #0: rel 1663/16384/32791 blk 0
rmgr: Btree len (rec/tot): 64/ 64, tx: 17243284, lsn: 4/E7000288, prev 4/E7000248, desc: INSERT_LEAF off 4, blkref #0: rel 1663/16384/32794 blk 1
rmgr: Heap len (rec/tot): 63/ 63, tx: 17243284, lsn: 4/E70002C8, prev 4/E7000288, desc: INSERT off 5 flags 0x00, blkref #0: rel 1663/16384/32791 blk 0
[..]
Similar stuff happens for UPDATE. It basically prevents recent-buffer optimization that avoid repeated calls to smgropen().

And here's already existing table_multi_inserts v2 API (Heap2) sample with obvious elimination of unnecessary individual calls to smgopen() via one big MULTI_INSERT instead (for CTAS/COPY/REFRESH MV) :
postgres@test=# create table t (id bigint primary key);
postgres@test=# copy (select generate_series (1, 10)) to '/tmp/t';
postgres@test=# copy t from '/tmp/t';
=>
rmgr: Heap2 len (rec/tot): 210/ 210, tx: 17243290, lsn: 4/E9000028, prev 4/E8004410, desc: MULTI_INSERT+INIT 10 tuples flags 0x02, blkref #0: rel 1663/16384/32801 blk 0
rmgr: Btree len (rec/tot): 102/ 102, tx: 17243290, lsn: 4/E9000100, prev 4/E9000028, desc: NEWROOT lev 0, blkref #0: rel 1663/16384/32804 blk 1, blkref #2: rel 1663/16384/32804 blk 0
rmgr: Btree len (rec/tot): 64/ 64, tx: 17243290, lsn: 4/E9000168, prev 4/E9000100, desc: INSERT_LEAF off 1, blkref #0: rel 1663/16384/32804 blk 1
rmgr: Btree len (rec/tot): 64/ 64, tx: 17243290, lsn: 4/E90001A8, prev 4/E9000168, desc: INSERT_LEAF off 2, blkref #0: rel 1663/16384/32804 blk 1
rmgr: Btree len (rec/tot): 64/ 64, tx: 17243290, lsn: 4/E90001E8, prev 4/E90001A8, desc: INSERT_LEAF off 3, blkref #0: rel 1663/16384/32804 blk 1
[..]
Here Btree it is very localized (at least when concurrent sessions are not generating WAL) and it enables Thomas's recent-buffer to kick in

DELETE is much more simple (thanks to not chewing out those Btree records) and also thanks to Thomas's recent-buffer should theoretically put much less stress on smgropen() already:
rmgr: Heap len (rec/tot): 54/ 54, tx: 17243296, lsn: 4/ED000028, prev 4/EC002800, desc: DELETE off 1 flags 0x00 KEYS_UPDATED , blkref #0: rel 1663/16384/32808 blk 0
rmgr: Heap len (rec/tot): 54/ 54, tx: 17243296, lsn: 4/ED000060, prev 4/ED000028, desc: DELETE off 2 flags 0x00 KEYS_UPDATED , blkref #0: rel 1663/16384/32808 blk 0
rmgr: Heap len (rec/tot): 54/ 54, tx: 17243296, lsn: 4/ED000098, prev 4/ED000060, desc: DELETE off 3 flags 0x00 KEYS_UPDATED , blkref #0: rel 1663/16384/32808 blk 0
rmgr: Heap len (rec/tot): 54/ 54, tx: 17243296, lsn: 4/ED0000D0, prev 4/ED000098, desc: DELETE off 4 flags 0x00 KEYS_UPDATED , blkref #0: rel 1663/16384/32808 blk 0
[..]

2) So what's missing - I may be wrong on this one - something like "index_multi_inserts" Btree2 API to avoid repeatedly overwhelming smgropen() on recovery side for same index's $buffer. Not sure it is worth the effort, though especially recent-buffer fixes that:
rmgr: Btree len (rec/tot): 64/ 64, tx: 17243290, lsn: 4/E9000168, prev 4/E9000100, desc: INSERT_LEAF off 1, blkref #0: rel 1663/16384/32804 blk 1
rmgr: Btree len (rec/tot): 64/ 64, tx: 17243290, lsn: 4/E90001A8, prev 4/E9000168, desc: INSERT_LEAF off 2, blkref #0: rel 1663/16384/32804 blk 1
rmgr: Btree len (rec/tot): 64/ 64, tx: 17243290, lsn: 4/E90001E8, prev 4/E90001A8, desc: INSERT_LEAF off 3, blkref #0: rel 1663/16384/32804 blk 1
right?

3) Concurrent DML sessions mixing WAL records: the buffering on backend's side of things (on private "thread" of WAL - in private memory - that would be simply "copied" into logwriter's main WAL buffer when committing/buffer full) - it would seem like an very interesting idea to limit interleaving concurrent sessions WAL records between each other and exploit the recent-buffer enhancement to avoid repeating the same calls to Smgr, wouldn't it? (I'm just mentioning it as I saw you were benchmarking it here and called out this idea).

I could be wrong though with many of those simplifications, in any case please consult with Thomas as he knows much better and is much more trusted source than me 😉

-J.

The following review has been posted through the commitfest application:
make installcheck-world: tested, passed
Implements feature: tested, passed
Spec compliant: tested, passed
Documentation: not tested

I believe it is ready for committer.

The new status of this patch is: Ready for Committer
