[RFC] Lock-free XLog Reservation from WAL

From 2f4a32b1d09419167fe5040465c8a3464010e012 Mon Sep 17 00:00:00 2001
From: Zhiguo Zhou <zhiguo.zhou@intel.com>
Date: Thu, 2 Jan 2025 12:04:02 +0800
Subject: [PATCH] Lock-free XLog Reservation from WAL

Removed PrevBytePos to eliminate lock contention, allowing atomic updates
to CurrBytePos. Adjusted XLog reservation to exceed current XLog memory
slightly, enabling the next XLog's prev-link update without waiting for
the current XLog. Backends now update next XLog's prev-link before
inserting current log, breaking sequential write convention. Updated
GetXLogBuffer to handle separate access and update LSNs. Increased
NUM_XLOGINSERT_LOCKS.
---
 src/backend/access/transam/xlog.c | 186 +++++++++++++++++++++---------
 1 file changed, 131 insertions(+), 55 deletions(-)

diff --git a/src/backend/access/transam/xlog.c b/src/backend/access/transam/xlog.c
index 6f58412bca..6215ea6977 100644
--- a/src/backend/access/transam/xlog.c
+++ b/src/backend/access/transam/xlog.c
@@ -147,7 +147,7 @@ int			wal_segment_size = DEFAULT_XLOG_SEG_SIZE;
  * to happen concurrently, but adds some CPU overhead to flushing the WAL,
  * which needs to iterate all the locks.
  */
-#define NUM_XLOGINSERT_LOCKS  8
+#define NUM_XLOGINSERT_LOCKS  128

 /*
  * Max distance from last checkpoint, before triggering a new xlog-based
@@ -404,8 +404,7 @@ typedef struct XLogCtlInsert
 	 * prev-link of the next record. These are stored as "usable byte
 	 * positions" rather than XLogRecPtrs (see XLogBytePosToRecPtr()).
 	 */
-	uint64		CurrBytePos;
-	uint64		PrevBytePos;
+	pg_atomic_uint64		CurrBytePos;

 	/*
 	 * Make sure the above heavily-contended spinlock and byte positions are
@@ -700,12 +699,14 @@ static void CopyXLogRecordToWAL(int write_len, bool isLogSwitch,
 								XLogRecData *rdata,
 								XLogRecPtr StartPos, XLogRecPtr EndPos,
 								TimeLineID tli);
+static XLogRecPtr GetPrevRecPtr(XLogRecPtr hdr, TimeLineID tli);
+static void SetPrevRecPtr(XLogRecPtr hdr, XLogRecPtr PrevPos,
+						  TimeLineID tli, bool in_order);
 static void ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos,
-									  XLogRecPtr *EndPos, XLogRecPtr *PrevPtr);
-static bool ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos,
-							  XLogRecPtr *PrevPtr);
+									  XLogRecPtr *EndPos);
+static bool ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos);
 static XLogRecPtr WaitXLogInsertionsToFinish(XLogRecPtr upto);
-static char *GetXLogBuffer(XLogRecPtr ptr, TimeLineID tli);
+static char *GetXLogBuffer(XLogRecPtr ptr, XLogRecPtr upto, TimeLineID tli);
 static XLogRecPtr XLogBytePosToRecPtr(uint64 bytepos);
 static XLogRecPtr XLogBytePosToEndRecPtr(uint64 bytepos);
 static uint64 XLogRecPtrToBytePos(XLogRecPtr ptr);
@@ -862,8 +863,7 @@ XLogInsertRecord(XLogRecData *rdata,
 		 * Reserve space for the record in the WAL. This also sets the xl_prev
 		 * pointer.
 		 */
-		ReserveXLogInsertLocation(rechdr->xl_tot_len, &StartPos, &EndPos,
-								  &rechdr->xl_prev);
+		ReserveXLogInsertLocation(rechdr->xl_tot_len, &StartPos, &EndPos);

 		/* Normal records are always inserted. */
 		inserted = true;
@@ -883,7 +883,7 @@ XLogInsertRecord(XLogRecData *rdata,
 		 */
 		Assert(fpw_lsn == InvalidXLogRecPtr);
 		WALInsertLockAcquireExclusive();
-		inserted = ReserveXLogSwitch(&StartPos, &EndPos, &rechdr->xl_prev);
+		inserted = ReserveXLogSwitch(&StartPos, &EndPos);
 	}
 	else
 	{
@@ -898,14 +898,22 @@ XLogInsertRecord(XLogRecData *rdata,
 		 */
 		Assert(fpw_lsn == InvalidXLogRecPtr);
 		WALInsertLockAcquireExclusive();
-		ReserveXLogInsertLocation(rechdr->xl_tot_len, &StartPos, &EndPos,
-								  &rechdr->xl_prev);
+		ReserveXLogInsertLocation(rechdr->xl_tot_len, &StartPos, &EndPos);
 		RedoRecPtr = Insert->RedoRecPtr = StartPos;
 		inserted = true;
 	}

 	if (inserted)
 	{
+		bool		islargerecord;
+
+		islargerecord = EndPos - StartPos >= (Size) XLOGbuffers * XLOG_BLCKSZ;
+		if (!islargerecord)
+		{
+			SetPrevRecPtr(EndPos, StartPos, insertTLI, false);
+		}
+		while (!(rechdr->xl_prev = GetPrevRecPtr(StartPos, insertTLI)));
+
 		/*
 		 * Now that xl_prev has been filled in, calculate CRC of the record
 		 * header.
@@ -923,6 +931,11 @@ XLogInsertRecord(XLogRecData *rdata,
 							class == WALINSERT_SPECIAL_SWITCH, rdata,
 							StartPos, EndPos, insertTLI);

+		if (islargerecord)
+		{
+			SetPrevRecPtr(EndPos, StartPos, insertTLI, true);
+		}
+
 		/*
 		 * Unless record is flagged as not important, update LSN of last
 		 * important record in the current slot. When holding all locks, just
@@ -1105,13 +1118,11 @@ XLogInsertRecord(XLogRecData *rdata,
  * inline. We use pg_attribute_always_inline here to try to convince it.
  */
 static pg_attribute_always_inline void
-ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
-						  XLogRecPtr *PrevPtr)
+ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos)
 {
 	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	uint64		startbytepos;
 	uint64		endbytepos;
-	uint64		prevbytepos;

 	size = MAXALIGN(size);

@@ -1128,19 +1139,11 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
 	 * because the usable byte position doesn't include any headers, reserving
 	 * X bytes from WAL is almost as simple as "CurrBytePos += X".
 	 */
-	SpinLockAcquire(&Insert->insertpos_lck);
-
-	startbytepos = Insert->CurrBytePos;
+	startbytepos = pg_atomic_fetch_add_u64(&Insert->CurrBytePos, size);
 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;
-
-	SpinLockRelease(&Insert->insertpos_lck);

 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);
-	*PrevPtr = XLogBytePosToRecPtr(prevbytepos);

 	/*
 	 * Check that the conversions between "usable byte positions" and
@@ -1148,7 +1151,6 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
 	 */
 	Assert(XLogRecPtrToBytePos(*StartPos) == startbytepos);
 	Assert(XLogRecPtrToBytePos(*EndPos) == endbytepos);
-	Assert(XLogRecPtrToBytePos(*PrevPtr) == prevbytepos);
 }

 /*
@@ -1161,12 +1163,11 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
  * reserving any space, and the function returns false.
 */
 static bool
-ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
+ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos)
 {
 	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	uint64		startbytepos;
 	uint64		endbytepos;
-	uint64		prevbytepos;
 	uint32		size = MAXALIGN(SizeOfXLogRecord);
 	XLogRecPtr	ptr;
 	uint32		segleft;
@@ -1179,7 +1180,7 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 	 */
 	SpinLockAcquire(&Insert->insertpos_lck);

-	startbytepos = Insert->CurrBytePos;
+	startbytepos = pg_atomic_read_u64(&Insert->CurrBytePos);

 	ptr = XLogBytePosToEndRecPtr(startbytepos);
 	if (XLogSegmentOffset(ptr, wal_segment_size) == 0)
@@ -1190,7 +1191,6 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 	}

 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;

 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);
@@ -1202,17 +1202,13 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 		*EndPos += segleft;
 		endbytepos = XLogRecPtrToBytePos(*EndPos);
 	}
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;
+	pg_atomic_write_u64(&Insert->CurrBytePos, endbytepos);

 	SpinLockRelease(&Insert->insertpos_lck);

-	*PrevPtr = XLogBytePosToRecPtr(prevbytepos);
-
 	Assert(XLogSegmentOffset(*EndPos, wal_segment_size) == 0);
 	Assert(XLogRecPtrToBytePos(*EndPos) == endbytepos);
 	Assert(XLogRecPtrToBytePos(*StartPos) == startbytepos);
-	Assert(XLogRecPtrToBytePos(*PrevPtr) == prevbytepos);

 	return true;
 }
@@ -1236,7 +1232,7 @@ CopyXLogRecordToWAL(int write_len, bool isLogSwitch, XLogRecData *rdata,
 	 * inserting to.
 	 */
 	CurrPos = StartPos;
-	currpos = GetXLogBuffer(CurrPos, tli);
+	currpos = GetXLogBuffer(CurrPos, CurrPos, tli);
 	freespace = INSERT_FREESPACE(CurrPos);

 	/*
@@ -1273,7 +1269,7 @@ CopyXLogRecordToWAL(int write_len, bool isLogSwitch, XLogRecData *rdata,
 			 * page was initialized, in AdvanceXLInsertBuffer, and we're the
 			 * only backend that needs to set the contrecord flag.
 			 */
-			currpos = GetXLogBuffer(CurrPos, tli);
+			currpos = GetXLogBuffer(CurrPos, CurrPos, tli);
 			pagehdr = (XLogPageHeader) currpos;
 			pagehdr->xlp_rem_len = write_len - written;
 			pagehdr->xlp_info |= XLP_FIRST_IS_CONTRECORD;
@@ -1346,7 +1342,7 @@ CopyXLogRecordToWAL(int write_len, bool isLogSwitch, XLogRecData *rdata,
 			 * (which itself calls the two methods we need) to get the pointer
 			 * and zero most of the page.  Then we just zero the page header.
 			 */
-			currpos = GetXLogBuffer(CurrPos, tli);
+			currpos = GetXLogBuffer(CurrPos, CurrPos, tli);
 			MemSet(currpos, 0, SizeOfXLogShortPHD);

 			CurrPos += XLOG_BLCKSZ;
@@ -1364,6 +1360,90 @@ CopyXLogRecordToWAL(int write_len, bool isLogSwitch, XLogRecData *rdata,
 				errmsg_internal("space reserved for WAL record does not match what was written"));
 }

+static XLogRecPtr
+GetPrevRecPtr(XLogRecPtr hdr, TimeLineID tli)
+{
+	uint64		xlprevbytepos;
+	char		*xl_prev_pos;
+	int			freespace;
+
+	XLogRecPtr	res;
+	XLogRecPtr	xl_prev_ptr;
+
+	xlprevbytepos = XLogRecPtrToBytePos(hdr) + offsetof(XLogRecord, xl_prev);
+	xl_prev_ptr = XLogBytePosToRecPtr(xlprevbytepos);
+	xl_prev_pos = GetXLogBuffer(xl_prev_ptr, hdr, tli);
+	freespace = INSERT_FREESPACE(xl_prev_ptr);
+
+	if (freespace >= sizeof(XLogRecPtr))
+	{
+		res = *((XLogRecPtr *) xl_prev_pos);
+	}
+	else
+	{
+		char	*res_data;
+
+		res_data = (char *) &res;
+		memcpy(res_data, xl_prev_pos, freespace);
+
+		if (XLogSegmentOffset(xl_prev_ptr + freespace, wal_segment_size) == 0)
+		{
+			xl_prev_pos += SizeOfXLogLongPHD;
+		}
+		else
+		{
+			xl_prev_pos += SizeOfXLogShortPHD;
+		}
+
+		memcpy(res_data + freespace, xl_prev_pos, sizeof(XLogRecPtr) - freespace);
+	}
+
+	return res;
+}
+
+static void
+SetPrevRecPtr(XLogRecPtr hdr, XLogRecPtr xl_prev_to_insert, TimeLineID tli, bool in_order)
+{
+	uint64		xlprevbytepos;
+	char		*xl_prev_pos;
+	int			freespace;
+
+	XLogRecPtr	xl_prev_ptr;
+
+	xlprevbytepos = XLogRecPtrToBytePos(hdr) + offsetof(XLogRecord, xl_prev);
+	xl_prev_ptr = XLogBytePosToRecPtr(xlprevbytepos);
+
+	if (in_order)
+		xl_prev_pos = GetXLogBuffer(xl_prev_ptr, xl_prev_ptr, tli);
+	else
+		xl_prev_pos = GetXLogBuffer(xl_prev_ptr, xl_prev_to_insert, tli);
+
+	freespace = INSERT_FREESPACE(xl_prev_ptr);
+
+	if (freespace >= sizeof(XLogRecPtr))
+	{
+		*((XLogRecPtr *) xl_prev_pos) = xl_prev_to_insert;
+	}
+	else
+	{
+		char	*xl_prev_to_insert_data;
+
+		xl_prev_to_insert_data = (char *) &xl_prev_to_insert;
+		memcpy(xl_prev_pos, xl_prev_to_insert_data, freespace);
+
+		if (XLogSegmentOffset(xl_prev_ptr + freespace, wal_segment_size) == 0)
+		{
+			xl_prev_pos += SizeOfXLogLongPHD;
+		}
+		else
+		{
+			xl_prev_pos += SizeOfXLogShortPHD;
+		}
+
+		memcpy(xl_prev_pos, xl_prev_to_insert_data + freespace, sizeof(XLogRecPtr) - freespace);
+	}
+}
+
 /*
  * Acquire a WAL insertion lock, for inserting to WAL.
  */
@@ -1522,9 +1602,7 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 		return inserted;

 	/* Read the current insert position */
-	SpinLockAcquire(&Insert->insertpos_lck);
-	bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
+	bytepos = pg_atomic_read_u64(&Insert->CurrBytePos);
 	reservedUpto = XLogBytePosToEndRecPtr(bytepos);

 	/*
@@ -1629,7 +1707,7 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
  * later, because older buffers might be recycled already)
  */
 static char *
-GetXLogBuffer(XLogRecPtr ptr, TimeLineID tli)
+GetXLogBuffer(XLogRecPtr ptr, XLogRecPtr upto, TimeLineID tli)
 {
 	int			idx;
 	XLogRecPtr	endptr;
@@ -1690,14 +1768,14 @@ GetXLogBuffer(XLogRecPtr ptr, TimeLineID tli)
 		 * sure that it's initialized, before we let insertingAt to move past
 		 * the page header.
 		 */
-		if (ptr % XLOG_BLCKSZ == SizeOfXLogShortPHD &&
-			XLogSegmentOffset(ptr, wal_segment_size) > XLOG_BLCKSZ)
-			initializedUpto = ptr - SizeOfXLogShortPHD;
-		else if (ptr % XLOG_BLCKSZ == SizeOfXLogLongPHD &&
-				 XLogSegmentOffset(ptr, wal_segment_size) < XLOG_BLCKSZ)
-			initializedUpto = ptr - SizeOfXLogLongPHD;
+		if (upto % XLOG_BLCKSZ == SizeOfXLogShortPHD &&
+			XLogSegmentOffset(upto, wal_segment_size) > XLOG_BLCKSZ)
+			initializedUpto = upto - SizeOfXLogShortPHD;
+		else if (upto % XLOG_BLCKSZ == SizeOfXLogLongPHD &&
+				 XLogSegmentOffset(upto, wal_segment_size) < XLOG_BLCKSZ)
+			initializedUpto = upto - SizeOfXLogLongPHD;
 		else
-			initializedUpto = ptr;
+			initializedUpto = upto;

 		WALInsertLockUpdateInsertingAt(initializedUpto);

@@ -6018,8 +6096,7 @@ StartupXLOG(void)
 	 * previous incarnation.
 	 */
 	Insert = &XLogCtl->Insert;
-	Insert->PrevBytePos = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
-	Insert->CurrBytePos = XLogRecPtrToBytePos(EndOfLog);
+	pg_atomic_write_u64(&Insert->CurrBytePos, XLogRecPtrToBytePos(EndOfLog));

 	/*
 	 * Tricky point here: lastPage contains the *last* block that the LastRec
@@ -6053,6 +6130,7 @@ StartupXLOG(void)
 		 */
 		XLogCtl->InitializedUpTo = EndOfLog;
 	}
+	SetPrevRecPtr(EndOfLog, endOfRecoveryInfo->lastRec, newTLI, true);

 	/*
 	 * Update local and shared status.  This is OK to do without any locks
@@ -7005,7 +7083,7 @@ CreateCheckPoint(int flags)

 	if (shutdown)
 	{
-		XLogRecPtr	curInsert = XLogBytePosToRecPtr(Insert->CurrBytePos);
+		XLogRecPtr	curInsert = XLogBytePosToRecPtr(pg_atomic_read_u64(&Insert->CurrBytePos));

 		/*
 		 * Compute new REDO record ptr = location of next XLOG record.
@@ -7473,7 +7551,7 @@ CreateOverwriteContrecordRecord(XLogRecPtr aborted_lsn, XLogRecPtr pagePtr,
 	 * insertion lock is just pro forma.
 	 */
 	WALInsertLockAcquire();
-	pagehdr = (XLogPageHeader) GetXLogBuffer(pagePtr, newTLI);
+	pagehdr = (XLogPageHeader) GetXLogBuffer(pagePtr, pagePtr, newTLI);
 	pagehdr->xlp_info |= XLP_FIRST_IS_OVERWRITE_CONTRECORD;
 	WALInsertLockRelease();

@@ -9437,9 +9515,7 @@ GetXLogInsertRecPtr(void)
 	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	uint64		current_bytepos;

-	SpinLockAcquire(&Insert->insertpos_lck);
-	current_bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
+	current_bytepos = pg_atomic_read_u64(&Insert->CurrBytePos);

 	return XLogBytePosToRecPtr(current_bytepos);
 }
--
2.43.0

From c41f7b72d57b4fa4211079f7637f0a8470ec9348 Mon Sep 17 00:00:00 2001
From: =?UTF-8?q?=D0=AE=D1=80=D0=B8=D0=B9=20=D0=A1=D0=BE=D0=BA=D0=BE=D0=BB?=
 =?UTF-8?q?=D0=BE=D0=B2?= <yura@Urijs-MacBook-Air.local>
Date: Mon, 6 Jan 2025 21:54:06 +0300
Subject: [PATCH v1] Lock-free XLog Reservation using lock-free hash-table

Removed PrevBytePos to eliminate lock contention, allowing atomic updates
to CurrBytePos. Use lock-free hash-table based on 4-way Cuckoo Hashing
to store link to PrevBytePos.
---
 src/backend/access/transam/xlog.c | 346 ++++++++++++++++++++++++------
 1 file changed, 285 insertions(+), 61 deletions(-)

diff --git a/src/backend/access/transam/xlog.c b/src/backend/access/transam/xlog.c
index b9ea92a542..2f35e1645a 100644
--- a/src/backend/access/transam/xlog.c
+++ b/src/backend/access/transam/xlog.c
@@ -68,6 +68,8 @@
 #include "catalog/pg_database.h"
 #include "common/controldata_utils.h"
 #include "common/file_utils.h"
+#include "common/hashfn.h"
+#include "common/pg_prng.h"
 #include "executor/instrument.h"
 #include "miscadmin.h"
 #include "pg_trace.h"
@@ -147,7 +149,7 @@ int			wal_segment_size = DEFAULT_XLOG_SEG_SIZE;
  * to happen concurrently, but adds some CPU overhead to flushing the WAL,
  * which needs to iterate all the locks.
  */
-#define NUM_XLOGINSERT_LOCKS  8
+#define NUM_XLOGINSERT_LOCKS  128

 /*
  * Max distance from last checkpoint, before triggering a new xlog-based
@@ -384,6 +386,36 @@ typedef union WALInsertLockPadded
 	char		pad[PG_CACHE_LINE_SIZE];
 } WALInsertLockPadded;

+/*
+ * It links current position with previous one.
+ * - CurrPosId is (CurrBytePos ^ (CurrBytePos>>32))
+ *   Since CurrBytePos grows monotonically and it is aligned to MAXALIGN,
+ *   CurrPosId correctly identifies CurrBytePos for at least 4*2^32 = 32GB of
+ *   WAL logs.
+ * - PrevSize is difference between CurrBytePos and PrevBytePos
+ */
+typedef struct
+{
+	uint32		CurrPosId;
+	uint32		PrevSize;
+}			WALPrevPosLinkVal;
+
+/*
+ * This is an element of lock-free hash-table.
+ * PrevSize's lowest bit is used as a lock, relying on fact it is MAXALIGN-ed.
+ */
+typedef struct
+{
+	pg_atomic_uint32 CurrPosId;
+	pg_atomic_uint32 PrevSize;
+}			WALPrevPosLink;
+
+#define PREV_LINKS_HASH_CAPA 256
+StaticAssertDecl(!(PREV_LINKS_HASH_CAPA & (PREV_LINKS_HASH_CAPA - 1)),
+				 "PREV_LINKS_HASH_CAPA should be power of two");
+
+#define SWAP_ONCE_IN 128
+
 /*
  * Session status of running backup, used for sanity checks in SQL-callable
  * functions to start and stop backups.
@@ -395,26 +427,31 @@ static SessionBackupState sessionBackupState = SESSION_BACKUP_NONE;
  */
 typedef struct XLogCtlInsert
 {
-	slock_t		insertpos_lck;	/* protects CurrBytePos and PrevBytePos */
-
 	/*
 	 * CurrBytePos is the end of reserved WAL. The next record will be
-	 * inserted at that position. PrevBytePos is the start position of the
-	 * previously inserted (or rather, reserved) record - it is copied to the
-	 * prev-link of the next record. These are stored as "usable byte
-	 * positions" rather than XLogRecPtrs (see XLogBytePosToRecPtr()).
+	 * inserted at that position.
+	 *
+	 * The start position of the previously inserted (or rather, reserved)
+	 * record (it is copied to the prev-link of the next record) will be
+	 * stored in PrevLinksHash.
+	 *
+	 * These are stored as "usable byte positions" rather than XLogRecPtrs
+	 * (see XLogBytePosToRecPtr()).
 	 */
-	uint64		CurrBytePos;
-	uint64		PrevBytePos;
+	pg_atomic_uint64 CurrBytePos pg_attribute_aligned(PG_CACHE_LINE_SIZE);

 	/*
-	 * Make sure the above heavily-contended spinlock and byte positions are
-	 * on their own cache line. In particular, the RedoRecPtr and full page
-	 * write variables below should be on a different cache line. They are
-	 * read on every WAL insertion, but updated rarely, and we don't want
-	 * those reads to steal the cache line containing Curr/PrevBytePos.
+	 * PrevLinksHash is a lock-free hash table based on Cuckoo algorith. It is
+	 * mostly 4 way: for every element computed two positions h1, h2, and
+	 * neighbour h1+1 and h2+2 are used as well. This way even on collision we
+	 * have 3 distinct position, which provide us ~75% fill rate without
+	 * unsolvable cycles (due to Cuckoo's theory).
+	 *
+	 * Certainly, we rely on the fact we will delete elements with same speed
+	 * as we add them, and even unsolvable cycles will be destroyed soon by
+	 * concurrent deletions.
 	 */
-	char		pad[PG_CACHE_LINE_SIZE];
+	WALPrevPosLink PrevLinksHash[PREV_LINKS_HASH_CAPA];

 	/*
 	 * fullPageWrites is the authoritative value used by all backends to
@@ -700,6 +737,15 @@ static void CopyXLogRecordToWAL(int write_len, bool isLogSwitch,
 								XLogRecData *rdata,
 								XLogRecPtr StartPos, XLogRecPtr EndPos,
 								TimeLineID tli);
+
+static bool WALPrevPosLinkInsert(WALPrevPosLink * link, WALPrevPosLinkVal val);
+static bool WALPrevPosLinkConsume(WALPrevPosLink * link, WALPrevPosLinkVal * val);
+static bool WALPrevPosLinkSwap(WALPrevPosLink * link, WALPrevPosLinkVal * val);
+static void LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos,
+							   XLogRecPtr *PrevPtr);
+static void LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec);
+static XLogRecPtr ReadInsertCurrBytePos(void);
+
 static void ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos,
 									  XLogRecPtr *EndPos, XLogRecPtr *PrevPtr);
 static bool ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos,
@@ -1086,6 +1132,192 @@ XLogInsertRecord(XLogRecData *rdata,
 	return EndPos;
 }

+/*
+ * Attempt to write into empty link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkInsert(WALPrevPosLink * link, WALPrevPosLinkVal val)
+{
+	uint32		empty = 0;
+
+	/* first check it read-only */
+	if (pg_atomic_read_u32(&link->PrevSize) != 0)
+		return false;
+	if (!pg_atomic_compare_exchange_u32(&link->PrevSize, &empty, 1))
+		/* someone else occupied the entry */
+		return false;
+
+	pg_atomic_write_u32(&link->CurrPosId, val.CurrPosId);
+	/* This write acts as unlock as well. */
+	pg_atomic_write_membarrier_u32(&link->PrevSize, val.PrevSize);
+	return true;
+}
+
+/*
+ * Attempt to consume matched link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkConsume(WALPrevPosLink * link, WALPrevPosLinkVal * val)
+{
+
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId)
+		return false;
+
+	/* Try lock */
+	val->PrevSize = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (val->PrevSize & 1)
+		/* Lock failed */
+		return false;
+
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId)
+	{
+		/* unlock with old value */
+		pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+		return false;
+	}
+
+	pg_atomic_write_u32(&link->CurrPosId, 0);
+	/* This write acts as unlock as well. */
+	pg_atomic_write_membarrier_u32(&link->PrevSize, 0);
+	return true;
+}
+
+/*
+ * Attempt to swap entry: remember existing link and write our.
+ * It could happen we consume empty entry. Caller will detect it by checking
+ * remembered value.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkSwap(WALPrevPosLink * link, WALPrevPosLinkVal * val)
+{
+	uint32		oldCur;
+	uint32		oldPrev;
+
+	/* Attempt to lock entry against concurrent consumer or swapper */
+	oldPrev = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (oldPrev & 1)
+		/* Lock failed */
+		return false;
+
+	oldCur = pg_atomic_read_u32(&link->CurrPosId);
+	pg_atomic_write_u32(&link->CurrPosId, val->CurrPosId);
+	/* This write acts as unlock as well. */
+	pg_atomic_write_membarrier_u32(&link->PrevSize, val->PrevSize);
+
+	val->CurrPosId = oldCur;
+	val->PrevSize = oldPrev;
+	return true;
+}
+
+static pg_attribute_always_inline void
+CalcCuckooPositions(uint32 ptr, uint32 pos[4])
+{
+	uint32		hash = murmurhash32(ptr);
+
+	pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos[1] = (pos[0] + 1) % PREV_LINKS_HASH_CAPA;
+	pos[2] = (hash >> 16) % PREV_LINKS_HASH_CAPA;
+	pos[3] = (pos[2] + 2) % PREV_LINKS_HASH_CAPA;
+}
+
+/*
+ * Write new link (EndPos, StartPos) and find PrevPtr for StartPos.
+ *
+ * Links are stored in lock-free Cuckoo based hash-table.
+ * We use mostly-4 way Cuckoo hashing which provides high fill rate without
+ * hard cycle collisions. Also we rely on concurrent consumers of existing
+ * entry, so cycles will be broken in mean time.
+ *
+ * Cuckoo hashing relies on re-insertion for balancing, so we occasionally
+ * swaps entry and try to insert swapped instead of our.
+ */
+static void
+LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos, XLogRecPtr *PrevPtr)
+{
+	WALPrevPosLink *hashtable = XLogCtl->Insert.PrevLinksHash;
+	WALPrevPosLinkVal lookup = {
+		.CurrPosId = StartPos ^ (StartPos >> 32),
+	};
+	WALPrevPosLinkVal insert = {
+		.CurrPosId = EndPos ^ (EndPos >> 32),
+		.PrevSize = EndPos - StartPos
+	};
+	pg_prng_state prng;
+	uint32		lookup_pos[4];
+	uint32		insert_pos[4];
+	uint32		i;
+	bool		inserted = false;
+	bool		found = false;
+
+	CalcCuckooPositions(lookup.CurrPosId, lookup_pos);
+	CalcCuckooPositions(insert.CurrPosId, insert_pos);
+	pg_prng_seed(&prng, StartPos);
+
+	while (!inserted || !found)
+	{
+		for (i = 0; !found && i < 4; i++)
+			found = WALPrevPosLinkConsume(&hashtable[lookup_pos[i]], &lookup);
+
+		if (inserted)
+			goto next;
+
+		for (i = 0; !inserted && i < 4; i++)
+			inserted = WALPrevPosLinkInsert(&hashtable[insert_pos[i]], insert);
+
+		if (inserted)
+			goto next;
+
+		if (pg_prng_uint32(&prng) % SWAP_ONCE_IN != 0)
+			goto next;
+
+		i = pg_prng_uint32(&prng) % 4;
+		if (!WALPrevPosLinkSwap(&hashtable[insert_pos[i]], &insert))
+			goto next;
+
+		if (insert.PrevSize == 0)
+			/* Lucky case: entry become empty and we inserted into */
+			inserted = true;
+		else if (insert.CurrPosId == lookup.CurrPosId)
+		{
+			/*
+			 * We occasionally replaced entry we looked for. No need to insert
+			 * it again.
+			 */
+			inserted = true;
+			Assert(!found);
+			found = true;
+			lookup.PrevSize = insert.PrevSize;
+			break;
+		}
+		else
+			CalcCuckooPositions(insert.CurrPosId, insert_pos);
+
+next:
+		pg_spin_delay();
+	}
+
+	*PrevPtr = StartPos - lookup.PrevSize;
+}
+
+static pg_attribute_always_inline void
+LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec)
+{
+	WALPrevPosLink *hashtable = XLogCtl->Insert.PrevLinksHash;
+	uint32		insert_pos[4];
+
+	CalcCuckooPositions(EndOfLog ^ (EndOfLog >> 32), insert_pos);
+	pg_atomic_write_u32(&hashtable[insert_pos[0]].CurrPosId,
+						EndOfLog ^ (EndOfLog >> 32));
+	pg_atomic_write_u32(&hashtable[insert_pos[0]].PrevSize,
+						EndOfLog - LastRec);
+}
+
+static pg_attribute_always_inline XLogRecPtr
+ReadInsertCurrBytePos(void)
+{
+	return pg_atomic_read_u64(&XLogCtl->Insert.CurrBytePos);
+}
+
 /*
  * Reserves the right amount of space for a record of given size from the WAL.
  * *StartPos is set to the beginning of the reserved section, *EndPos to
@@ -1118,25 +1350,9 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
 	/* All (non xlog-switch) records should contain data. */
 	Assert(size > SizeOfXLogRecord);

-	/*
-	 * The duration the spinlock needs to be held is minimized by minimizing
-	 * the calculations that have to be done while holding the lock. The
-	 * current tip of reserved WAL is kept in CurrBytePos, as a byte position
-	 * that only counts "usable" bytes in WAL, that is, it excludes all WAL
-	 * page headers. The mapping between "usable" byte positions and physical
-	 * positions (XLogRecPtrs) can be done outside the locked region, and
-	 * because the usable byte position doesn't include any headers, reserving
-	 * X bytes from WAL is almost as simple as "CurrBytePos += X".
-	 */
-	SpinLockAcquire(&Insert->insertpos_lck);
-
-	startbytepos = Insert->CurrBytePos;
+	startbytepos = pg_atomic_fetch_add_u64(&Insert->CurrBytePos, size);
 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;
-
-	SpinLockRelease(&Insert->insertpos_lck);
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);
@@ -1172,26 +1388,24 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 	uint32		segleft;

 	/*
-	 * These calculations are a bit heavy-weight to be done while holding a
-	 * spinlock, but since we're holding all the WAL insertion locks, there
-	 * are no other inserters competing for it. GetXLogInsertRecPtr() does
-	 * compete for it, but that's not called very frequently.
+	 * Currently ReserveXLogInsertLocation is protected with exclusive
+	 * insertion lock, so there is no contention against CurrBytePos, But we
+	 * still do CAS loop for being uniform.
+	 *
+	 * Probably we'll get rid of exclusive lock in a future.
 	 */
-	SpinLockAcquire(&Insert->insertpos_lck);

-	startbytepos = Insert->CurrBytePos;
+repeat:
+	startbytepos = pg_atomic_read_u64(&Insert->CurrBytePos);

 	ptr = XLogBytePosToEndRecPtr(startbytepos);
 	if (XLogSegmentOffset(ptr, wal_segment_size) == 0)
 	{
-		SpinLockRelease(&Insert->insertpos_lck);
 		*EndPos = *StartPos = ptr;
 		return false;
 	}

 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-
 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);

@@ -1202,10 +1416,19 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 		*EndPos += segleft;
 		endbytepos = XLogRecPtrToBytePos(*EndPos);
 	}
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;

-	SpinLockRelease(&Insert->insertpos_lck);
+	if (!pg_atomic_compare_exchange_u64(&Insert->CurrBytePos,
+										&startbytepos,
+										endbytepos))
+	{
+		/*
+		 * Don't use spin delay here: perform_spin_delay primary case is for
+		 * solving single core contention. But on single core we will succeed
+		 * on the next attempt.
+		 */
+		goto repeat;
+	}
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*PrevPtr = XLogBytePosToRecPtr(prevbytepos);

@@ -1507,7 +1730,6 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 	XLogRecPtr	inserted;
 	XLogRecPtr	reservedUpto;
 	XLogRecPtr	finishedUpto;
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	int			i;

 	if (MyProc == NULL)
@@ -1522,9 +1744,7 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 		return inserted;

 	/* Read the current insert position */
-	SpinLockAcquire(&Insert->insertpos_lck);
-	bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
+	bytepos = ReadInsertCurrBytePos();
 	reservedUpto = XLogBytePosToEndRecPtr(bytepos);

 	/*
@@ -5017,12 +5237,18 @@ XLOGShmemInit(void)
 	XLogCtl->InstallXLogFileSegmentActive = false;
 	XLogCtl->WalWriterSleeping = false;

-	SpinLockInit(&XLogCtl->Insert.insertpos_lck);
 	SpinLockInit(&XLogCtl->info_lck);
+	pg_atomic_init_u64(&XLogCtl->Insert.CurrBytePos, 0);
 	pg_atomic_init_u64(&XLogCtl->logInsertResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logWriteResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logFlushResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->unloggedLSN, InvalidXLogRecPtr);
+
+	for (i = 0; i < PREV_LINKS_HASH_CAPA; i++)
+	{
+		pg_atomic_init_u32(&XLogCtl->Insert.PrevLinksHash[i].CurrPosId, 0);
+		pg_atomic_init_u32(&XLogCtl->Insert.PrevLinksHash[i].PrevSize, 0);
+	}
 }

 /*
@@ -6018,8 +6244,13 @@ StartupXLOG(void)
 	 * previous incarnation.
 	 */
 	Insert = &XLogCtl->Insert;
-	Insert->PrevBytePos = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
-	Insert->CurrBytePos = XLogRecPtrToBytePos(EndOfLog);
+	{
+		XLogRecPtr	endOfLog = XLogRecPtrToBytePos(EndOfLog);
+		XLogRecPtr	lastRec = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
+
+		pg_atomic_write_u64(&Insert->CurrBytePos, endOfLog);
+		LinkStartPrevPos(endOfLog, lastRec);
+	}

 	/*
 	 * Tricky point here: lastPage contains the *last* block that the LastRec
@@ -7005,7 +7236,7 @@ CreateCheckPoint(int flags)

 	if (shutdown)
 	{
-		XLogRecPtr	curInsert = XLogBytePosToRecPtr(Insert->CurrBytePos);
+		XLogRecPtr	curInsert = XLogBytePosToRecPtr(ReadInsertCurrBytePos());

 		/*
 		 * Compute new REDO record ptr = location of next XLOG record.
@@ -9434,14 +9665,7 @@ register_persistent_abort_backup_handler(void)
 XLogRecPtr
 GetXLogInsertRecPtr(void)
 {
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
-	uint64		current_bytepos;
-
-	SpinLockAcquire(&Insert->insertpos_lck);
-	current_bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
-
-	return XLogBytePosToRecPtr(current_bytepos);
+	return XLogBytePosToRecPtr(ReadInsertCurrBytePos());
 }

 /*
--
2.39.3 (Apple Git-146)

From 24520c5bf4f88271dfbe72221f50083f3ec9ca8e Mon Sep 17 00:00:00 2001
From: Yura Sokolov <y.sokolov@postgrespro.ru>
Date: Sun, 19 Jan 2025 17:40:28 +0300
Subject: [PATCH v2] Lock-free XLog Reservation using lock-free hash-table

Removed PrevBytePos to eliminate lock contention, allowing atomic updates
to CurrBytePos. Use lock-free hash-table based on 4-way Cuckoo Hashing
to store link to PrevBytePos.
---
 ...-Increase-NUM_XLOGINSERT_LOCKS-to-64.patch |  38 ++
 src/backend/access/transam/xlog.c             | 546 ++++++++++++++++--
 src/tools/pgindent/typedefs.list              |   2 +
 3 files changed, 523 insertions(+), 63 deletions(-)
 create mode 100644 patches/v0-0001-Increase-NUM_XLOGINSERT_LOCKS-to-64.patch

diff --git a/patches/v0-0001-Increase-NUM_XLOGINSERT_LOCKS-to-64.patch b/patches/v0-0001-Increase-NUM_XLOGINSERT_LOCKS-to-64.patch
new file mode 100644
index 00000000000..c6fa8bf830c
--- /dev/null
+++ b/patches/v0-0001-Increase-NUM_XLOGINSERT_LOCKS-to-64.patch
@@ -0,0 +1,38 @@
+From 93a4d4a7e2219a952c2a544047c19db9f0f0f5c0 Mon Sep 17 00:00:00 2001
+From: Yura Sokolov <y.sokolov@postgrespro.ru>
+Date: Thu, 16 Jan 2025 15:06:59 +0300
+Subject: [PATCH v0 1/2] Increase NUM_XLOGINSERT_LOCKS to 64
+
+---
+ src/backend/access/transam/xlog.c | 8 ++++++--
+ 1 file changed, 6 insertions(+), 2 deletions(-)
+
+diff --git a/src/backend/access/transam/xlog.c b/src/backend/access/transam/xlog.c
+index bf3dbda901d..39381693db6 100644
+--- a/src/backend/access/transam/xlog.c
++++ b/src/backend/access/transam/xlog.c
+@@ -147,7 +147,7 @@ int			wal_segment_size = DEFAULT_XLOG_SEG_SIZE;
+  * to happen concurrently, but adds some CPU overhead to flushing the WAL,
+  * which needs to iterate all the locks.
+  */
+-#define NUM_XLOGINSERT_LOCKS  8
++#define NUM_XLOGINSERT_LOCKS  64
+
+ /*
+  * Max distance from last checkpoint, before triggering a new xlog-based
+@@ -1448,7 +1448,11 @@ WALInsertLockRelease(void)
+ 	{
+ 		int			i;
+
+-		for (i = 0; i < NUM_XLOGINSERT_LOCKS; i++)
++		/*
++		 * LWLockRelease hopes we will release in reverse order for faster
++		 * search in held_lwlocks.
++		 */
++		for (i = NUM_XLOGINSERT_LOCKS - 1; i >= 0; i--)
+ 			LWLockReleaseClearVar(&WALInsertLocks[i].l.lock,
+ 								  &WALInsertLocks[i].l.insertingAt,
+ 								  0);
+--
+2.43.0
+
diff --git a/src/backend/access/transam/xlog.c b/src/backend/access/transam/xlog.c
index bf3dbda901d..91067002447 100644
--- a/src/backend/access/transam/xlog.c
+++ b/src/backend/access/transam/xlog.c
@@ -68,6 +68,8 @@
 #include "catalog/pg_database.h"
 #include "common/controldata_utils.h"
 #include "common/file_utils.h"
+#include "common/hashfn.h"
+#include "common/pg_prng.h"
 #include "executor/instrument.h"
 #include "miscadmin.h"
 #include "pg_trace.h"
@@ -384,6 +386,78 @@ typedef union WALInsertLockPadded
 	char		pad[PG_CACHE_LINE_SIZE];
 } WALInsertLockPadded;

+/* #define WAL_LINK_64 0 */
+#ifndef WAL_LINK_64
+#ifdef PG_HAVE_ATOMIC_U64_SIMULATION
+#define WAL_LINK_64 0
+#else
+#define WAL_LINK_64 1
+#endif
+#endif
+
+/*
+ * It links current position with previous one.
+ * - CurrPosId is (CurrBytePos ^ (CurrBytePos>>32))
+ *   Since CurrBytePos grows monotonically and it is aligned to MAXALIGN,
+ *   CurrPosId correctly identifies CurrBytePos for at least 4*2^32 = 32GB of
+ *   WAL logs.
+ * - CurrPosHigh is (CurrBytePos>>32), it is stored for strong uniqueness check.
+ * - PrevSize is difference between CurrBytePos and PrevBytePos
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	uint64		CurrPos;
+	uint64		PrevPos;
+#define WAL_PREV_EMPTY (~((uint64)0))
+#define WALLinkEmpty(l) ((l).PrevPos == WAL_PREV_EMPTY)
+#define WALLinkSamePos(a, b) ((a).CurrPos == (b).CurrPos)
+#define WALLinkCopyPrev(a, b) do {(a).PrevPos = (b).PrevPos;} while(0)
+#else
+	uint32		CurrPosId;
+	uint32		CurrPosHigh;
+	uint32		PrevSize;
+#define WALLinkEmpty(l) ((l).PrevSize == 0)
+#define WALLinkSamePos(a, b) ((a).CurrPosId == (b).CurrPosId && (a).CurrPosHigh == (b).CurrPosHigh)
+#define WALLinkCopyPrev(a, b) do {(a).PrevSize = (b).PrevSize;} while(0)
+#endif
+} WALPrevPosLinkVal;
+
+/*
+ * This is an element of lock-free hash-table.
+ * In 32 bit mode PrevSize's lowest bit is used as a lock, relying on fact it is MAXALIGN-ed.
+ * In 64 bit mode lock protocol is more complex.
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	pg_atomic_uint64 CurrPos;
+	pg_atomic_uint64 PrevPos;
+#else
+	pg_atomic_uint32 CurrPosId;
+	uint32		CurrPosHigh;
+	pg_atomic_uint32 PrevSize;
+	uint32		pad;			/* to align to 16 bytes */
+#endif
+} WALPrevPosLink;
+
+StaticAssertDecl(sizeof(WALPrevPosLink) == 16, "WALPrevPosLink should be 16 bytes");
+
+#define PREV_LINKS_HASH_CAPA (NUM_XLOGINSERT_LOCKS * 2)
+StaticAssertDecl(!(PREV_LINKS_HASH_CAPA & (PREV_LINKS_HASH_CAPA - 1)),
+				 "PREV_LINKS_HASH_CAPA should be power of two");
+StaticAssertDecl(PREV_LINKS_HASH_CAPA < UINT16_MAX,
+				 "PREV_LINKS_HASH_CAPA is too large");
+
+#define PREV_LINKS_LOOKUPS 4
+struct WALPrevLinksLookups
+{
+	uint16		pos[PREV_LINKS_LOOKUPS];
+};
+#define PREV_LINKS_SAME_CACHE_LINE 0
+
+#define SWAP_ONCE_IN 128
+
 /*
  * Session status of running backup, used for sanity checks in SQL-callable
  * functions to start and stop backups.
@@ -395,26 +469,18 @@ static SessionBackupState sessionBackupState = SESSION_BACKUP_NONE;
  */
 typedef struct XLogCtlInsert
 {
-	slock_t		insertpos_lck;	/* protects CurrBytePos and PrevBytePos */
-
 	/*
 	 * CurrBytePos is the end of reserved WAL. The next record will be
-	 * inserted at that position. PrevBytePos is the start position of the
-	 * previously inserted (or rather, reserved) record - it is copied to the
-	 * prev-link of the next record. These are stored as "usable byte
-	 * positions" rather than XLogRecPtrs (see XLogBytePosToRecPtr()).
+	 * inserted at that position.
+	 *
+	 * The start position of the previously inserted (or rather, reserved)
+	 * record (it is copied to the prev-link of the next record) will be
+	 * stored in PrevLinksHash.
+	 *
+	 * These are stored as "usable byte positions" rather than XLogRecPtrs
+	 * (see XLogBytePosToRecPtr()).
 	 */
-	uint64		CurrBytePos;
-	uint64		PrevBytePos;
-
-	/*
-	 * Make sure the above heavily-contended spinlock and byte positions are
-	 * on their own cache line. In particular, the RedoRecPtr and full page
-	 * write variables below should be on a different cache line. They are
-	 * read on every WAL insertion, but updated rarely, and we don't want
-	 * those reads to steal the cache line containing Curr/PrevBytePos.
-	 */
-	char		pad[PG_CACHE_LINE_SIZE];
+	pg_atomic_uint64 CurrBytePos pg_attribute_aligned(PG_CACHE_LINE_SIZE);

 	/*
 	 * fullPageWrites is the authoritative value used by all backends to
@@ -442,6 +508,20 @@ typedef struct XLogCtlInsert
 	 * WAL insertion locks.
 	 */
 	WALInsertLockPadded *WALInsertLocks;
+
+	/*
+	 * PrevLinksHash is a lock-free hash table based on Cuckoo algorith. It is
+	 * mostly 4 way: for every element computed two positions h1, h2, and
+	 * neighbour h1+1 and h2+2 are used as well. This way even on collision we
+	 * have 3 distinct position, which provide us ~75% fill rate without
+	 * unsolvable cycles (due to Cuckoo's theory).
+	 *
+	 * Certainly, we rely on the fact we will delete elements with same speed
+	 * as we add them, and even unsolvable cycles will be destroyed soon by
+	 * concurrent deletions.
+	 */
+	WALPrevPosLink *PrevLinksHash;
+
 } XLogCtlInsert;

 /*
@@ -568,6 +648,9 @@ static XLogCtlData *XLogCtl = NULL;
 /* a private copy of XLogCtl->Insert.WALInsertLocks, for convenience */
 static WALInsertLockPadded *WALInsertLocks = NULL;

+/* same for XLogCtl->Insert.PrevLinksHash */
+static WALPrevPosLink *PrevLinksHash = NULL;
+
 /*
  * We maintain an image of pg_control in shared memory.
  */
@@ -700,6 +783,19 @@ static void CopyXLogRecordToWAL(int write_len, bool isLogSwitch,
 								XLogRecData *rdata,
 								XLogRecPtr StartPos, XLogRecPtr EndPos,
 								TimeLineID tli);
+
+static void WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos);
+static void WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos);
+static void CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos);
+
+static bool WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val);
+static bool WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static bool WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static void LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos,
+							   XLogRecPtr *PrevPtr);
+static void LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec);
+static XLogRecPtr ReadInsertCurrBytePos(void);
+
 static void ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos,
 									  XLogRecPtr *EndPos, XLogRecPtr *PrevPtr);
 static bool ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos,
@@ -1086,6 +1182,327 @@ XLogInsertRecord(XLogRecData *rdata,
 	return EndPos;
 }

+static pg_attribute_always_inline void
+WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos)
+{
+#if WAL_LINK_64
+	val->CurrPos = StartPos;
+	val->PrevPos = PrevPos;
+#else
+	val->CurrPosHigh = StartPos >> 32;
+	val->CurrPosId = StartPos ^ val->CurrPosHigh;
+	val->PrevSize = StartPos - PrevPos;
+#endif
+}
+
+static pg_attribute_always_inline void
+WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos)
+{
+#if WAL_LINK_64
+	*PrevPos = val.PrevPos;
+#else
+	XLogRecPtr	StartPos = val.CurrPosHigh;
+
+	StartPos ^= (StartPos << 32) | val.CurrPosId;
+	*PrevPos = StartPos - val.PrevSize;
+#endif
+}
+
+static pg_attribute_always_inline void
+CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos)
+{
+	uint32		hash;
+
+	StaticAssertStmt(PREV_LINKS_LOOKUPS == 4, "CalcCuckooPositions assumes PREV_LINKS_LOOKUPS == 4");
+
+#if WAL_LINK_64
+	hash = murmurhash32(linkval.CurrPos ^ (linkval.CurrPos >> 32));
+#else
+	hash = murmurhash32(linkval.CurrPosId);
+#endif
+
+#if !PREV_LINKS_SAME_CACHE_LINE
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = pos->pos[0] + 1;
+	pos->pos[2] = (hash >> 16) % PREV_LINKS_HASH_CAPA;
+	pos->pos[3] = pos->pos[2] + 2;
+#else
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = pos->pos[0] ^ 1;
+	pos->pos[2] = pos->pos[0] ^ 2;
+	pos->pos[3] = pos->pos[0] ^ 3;
+#endif
+}
+
+/*
+ * Attempt to write into empty link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val)
+{
+#if WAL_LINK_64
+	uint64		empty = WAL_PREV_EMPTY;
+
+	if (pg_atomic_read_u64(&link->PrevPos) != WAL_PREV_EMPTY)
+		return false;
+	if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &empty, val.PrevPos))
+		return false;
+	/* we could ignore concurrent lock of CurrPos */
+	pg_atomic_write_u64(&link->CurrPos, val.CurrPos);
+	return true;
+#else
+	uint32		empty = 0;
+
+	/* first check it read-only */
+	if (pg_atomic_read_u32(&link->PrevSize) != 0)
+		return false;
+	if (!pg_atomic_compare_exchange_u32(&link->PrevSize, &empty, 1))
+		/* someone else occupied the entry */
+		return false;
+
+	pg_atomic_write_u32(&link->CurrPosId, val.CurrPosId);
+	link->CurrPosHigh = val.CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val.PrevSize);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to consume matched link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+
+	if (pg_atomic_read_u64(&link->CurrPos) != val->CurrPos)
+		return false;
+	/* lock against concurrent swapper */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr != val->CurrPos)
+	{
+		/* link was swapped */
+		pg_atomic_write_u64(&link->CurrPos, oldCurr);
+		return false;
+	}
+	val->PrevPos = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, WAL_PREV_EMPTY);
+
+	/*
+	 * concurrent inserter may already reuse this link, so we don't check
+	 * result of compare_exchange
+	 */
+	oldCurr |= 1;
+	pg_atomic_compare_exchange_u64(&link->CurrPos, &oldCurr, 0);
+	return true;
+#else
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId)
+		return false;
+
+	/* Try lock */
+	val->PrevSize = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (val->PrevSize & 1)
+		/* Lock failed */
+		return false;
+
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId ||
+		link->CurrPosHigh != val->CurrPosHigh)
+	{
+		/* unlock with old value */
+		pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+		return false;
+	}
+
+	pg_atomic_write_u32(&link->CurrPosId, 0);
+	link->CurrPosHigh = 0;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, 0);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to swap entry: remember existing link and write our.
+ * It could happen we consume empty entry. Caller will detect it by checking
+ * remembered value.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+	uint64		oldPrev;
+
+	/* lock against concurrent swapper or consumer */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr == 0)
+	{
+		/* link was empty */
+		oldPrev = WAL_PREV_EMPTY;
+		/* but concurrent inserter may concurrently insert */
+		if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &oldPrev, val->PrevPos))
+			return false;		/* concurrent inserter won. It will overwrite
+								 * CurrPos */
+		/* this write acts as unlock */
+		pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+		val->CurrPos = 0;
+		val->PrevPos = WAL_PREV_EMPTY;
+		return true;
+	}
+	oldPrev = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, val->PrevPos);
+	pg_write_barrier();
+	/* write acts as unlock */
+	pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+	val->CurrPos = oldCurr;
+	val->PrevPos = oldPrev;
+	return true;
+#else
+	uint32		oldPrev;
+	uint32		oldCurId;
+	uint32		oldCurHigh;
+
+	/* Attempt to lock entry against concurrent consumer or swapper */
+	oldPrev = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (oldPrev & 1)
+		/* Lock failed */
+		return false;
+
+	oldCurId = pg_atomic_read_u32(&link->CurrPosId);
+	oldCurHigh = link->CurrPosHigh;
+	pg_atomic_write_u32(&link->CurrPosId, val->CurrPosId);
+	link->CurrPosHigh = val->CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+
+	val->CurrPosId = oldCurId;
+	val->CurrPosHigh = oldCurHigh;
+	val->PrevSize = oldPrev;
+	return true;
+#endif
+}
+
+/*
+ * Write new link (EndPos, StartPos) and find PrevPtr for StartPos.
+ *
+ * Links are stored in lock-free Cuckoo based hash-table.
+ * We use mostly-4 way Cuckoo hashing which provides high fill rate without
+ * hard cycle collisions. Also we rely on concurrent consumers of existing
+ * entry, so cycles will be broken in mean time.
+ *
+ * Cuckoo hashing relies on re-insertion for balancing, so we occasionally
+ * swaps entry and try to insert swapped instead of our.
+ */
+static void
+LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos, XLogRecPtr *PrevPtr)
+{
+	SpinDelayStatus spin_stat;
+	WALPrevPosLinkVal lookup;
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups lookup_pos;
+	struct WALPrevLinksLookups insert_pos;
+	uint32		i;
+	uint32		rand = 0;
+	bool		inserted = false;
+	bool		found = false;
+
+	/* pass StartPos second time to set PrevSize = 0 */
+	WALPrevPosLinkValCompose(&lookup, StartPos, StartPos);
+	WALPrevPosLinkValCompose(&insert, EndPos, StartPos);
+
+	CalcCuckooPositions(lookup, &lookup_pos);
+	CalcCuckooPositions(insert, &insert_pos);
+
+	init_local_spin_delay(&spin_stat);
+
+	while (!inserted || !found)
+	{
+		for (i = 0; !found && i < PREV_LINKS_LOOKUPS; i++)
+			found = WALPrevPosLinkConsume(&PrevLinksHash[lookup_pos.pos[i]], &lookup);
+
+		if (inserted)
+		{
+			/*
+			 * we may sleep only after we inserted our value, since other
+			 * backend waits for it
+			 */
+			perform_spin_delay(&spin_stat);
+			goto next;
+		}
+
+		for (i = 0; !inserted && i < PREV_LINKS_LOOKUPS; i++)
+			inserted = WALPrevPosLinkInsert(&PrevLinksHash[insert_pos.pos[i]], insert);
+
+		if (inserted)
+			goto next;
+
+		rand = pg_prng_uint32(&pg_global_prng_state);
+		if (rand % SWAP_ONCE_IN != 0)
+			goto next;
+
+		i = rand / SWAP_ONCE_IN % PREV_LINKS_LOOKUPS;
+		if (!WALPrevPosLinkSwap(&PrevLinksHash[insert_pos.pos[i]], &insert))
+			goto next;
+
+		if (WALLinkEmpty(insert))
+			/* Lucky case: entry become empty and we inserted into */
+			inserted = true;
+		else if (WALLinkSamePos(lookup, insert))
+		{
+			/*
+			 * We occasionally replaced entry we looked for. No need to insert
+			 * it again.
+			 */
+			inserted = true;
+			Assert(!found);
+			found = true;
+			WALLinkCopyPrev(lookup, insert);
+			break;
+		}
+		else
+			CalcCuckooPositions(insert, &insert_pos);
+
+next:
+		pg_spin_delay();
+		pg_read_barrier();
+	}
+
+	WALPrevPosLinkValGetPrev(lookup, PrevPtr);
+}
+
+static pg_attribute_always_inline void
+LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec)
+{
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups insert_pos;
+
+	WALPrevPosLinkValCompose(&insert, EndOfLog, LastRec);
+	CalcCuckooPositions(insert, &insert_pos);
+#if WAL_LINK_64
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].CurrPos, insert.CurrPos);
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].PrevPos, insert.PrevPos);
+#else
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].CurrPosId, insert.CurrPosId);
+	PrevLinksHash[insert_pos.pos[0]].CurrPosHigh = insert.CurrPosHigh;
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].PrevSize, insert.PrevSize);
+#endif
+}
+
+static pg_attribute_always_inline XLogRecPtr
+ReadInsertCurrBytePos(void)
+{
+	return pg_atomic_read_u64(&XLogCtl->Insert.CurrBytePos);
+}
+
 /*
  * Reserves the right amount of space for a record of given size from the WAL.
  * *StartPos is set to the beginning of the reserved section, *EndPos to
@@ -1118,25 +1535,9 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
 	/* All (non xlog-switch) records should contain data. */
 	Assert(size > SizeOfXLogRecord);

-	/*
-	 * The duration the spinlock needs to be held is minimized by minimizing
-	 * the calculations that have to be done while holding the lock. The
-	 * current tip of reserved WAL is kept in CurrBytePos, as a byte position
-	 * that only counts "usable" bytes in WAL, that is, it excludes all WAL
-	 * page headers. The mapping between "usable" byte positions and physical
-	 * positions (XLogRecPtrs) can be done outside the locked region, and
-	 * because the usable byte position doesn't include any headers, reserving
-	 * X bytes from WAL is almost as simple as "CurrBytePos += X".
-	 */
-	SpinLockAcquire(&Insert->insertpos_lck);
-
-	startbytepos = Insert->CurrBytePos;
+	startbytepos = pg_atomic_fetch_add_u64(&Insert->CurrBytePos, size);
 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;
-
-	SpinLockRelease(&Insert->insertpos_lck);
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);
@@ -1172,26 +1573,24 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 	uint32		segleft;

 	/*
-	 * These calculations are a bit heavy-weight to be done while holding a
-	 * spinlock, but since we're holding all the WAL insertion locks, there
-	 * are no other inserters competing for it. GetXLogInsertRecPtr() does
-	 * compete for it, but that's not called very frequently.
+	 * Currently ReserveXLogInsertLocation is protected with exclusive
+	 * insertion lock, so there is no contention against CurrBytePos, But we
+	 * still do CAS loop for being uniform.
+	 *
+	 * Probably we'll get rid of exclusive lock in a future.
 	 */
-	SpinLockAcquire(&Insert->insertpos_lck);

-	startbytepos = Insert->CurrBytePos;
+repeat:
+	startbytepos = pg_atomic_read_u64(&Insert->CurrBytePos);

 	ptr = XLogBytePosToEndRecPtr(startbytepos);
 	if (XLogSegmentOffset(ptr, wal_segment_size) == 0)
 	{
-		SpinLockRelease(&Insert->insertpos_lck);
 		*EndPos = *StartPos = ptr;
 		return false;
 	}

 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-
 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);

@@ -1202,10 +1601,19 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 		*EndPos += segleft;
 		endbytepos = XLogRecPtrToBytePos(*EndPos);
 	}
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;

-	SpinLockRelease(&Insert->insertpos_lck);
+	if (!pg_atomic_compare_exchange_u64(&Insert->CurrBytePos,
+										&startbytepos,
+										endbytepos))
+	{
+		/*
+		 * Don't use spin delay here: perform_spin_delay primary case is for
+		 * solving single core contention. But on single core we will succeed
+		 * on the next attempt.
+		 */
+		goto repeat;
+	}
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*PrevPtr = XLogBytePosToRecPtr(prevbytepos);

@@ -1507,7 +1915,6 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 	XLogRecPtr	inserted;
 	XLogRecPtr	reservedUpto;
 	XLogRecPtr	finishedUpto;
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	int			i;

 	if (MyProc == NULL)
@@ -1522,9 +1929,7 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 		return inserted;

 	/* Read the current insert position */
-	SpinLockAcquire(&Insert->insertpos_lck);
-	bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
+	bytepos = ReadInsertCurrBytePos();
 	reservedUpto = XLogBytePosToEndRecPtr(bytepos);

 	/*
@@ -4898,6 +5303,8 @@ XLOGShmemSize(void)

 	/* WAL insertion locks, plus alignment */
 	size = add_size(size, mul_size(sizeof(WALInsertLockPadded), NUM_XLOGINSERT_LOCKS + 1));
+	/* prevlinkshash, abuses alignment of WAL insertion locks. */
+	size = add_size(size, mul_size(sizeof(WALPrevPosLink), PREV_LINKS_HASH_CAPA));
 	/* xlblocks array */
 	size = add_size(size, mul_size(sizeof(pg_atomic_uint64), XLOGbuffers));
 	/* extra alignment padding for XLOG I/O buffers */
@@ -4999,6 +5406,9 @@ XLOGShmemInit(void)
 		WALInsertLocks[i].l.lastImportantAt = InvalidXLogRecPtr;
 	}

+	PrevLinksHash = XLogCtl->Insert.PrevLinksHash = (WALPrevPosLink *) allocptr;
+	allocptr += sizeof(WALPrevPosLink) * PREV_LINKS_HASH_CAPA;
+
 	/*
 	 * Align the start of the page buffers to a full xlog block size boundary.
 	 * This simplifies some calculations in XLOG insertion. It is also
@@ -5017,12 +5427,24 @@ XLOGShmemInit(void)
 	XLogCtl->InstallXLogFileSegmentActive = false;
 	XLogCtl->WalWriterSleeping = false;

-	SpinLockInit(&XLogCtl->Insert.insertpos_lck);
 	SpinLockInit(&XLogCtl->info_lck);
 	pg_atomic_init_u64(&XLogCtl->logInsertResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logWriteResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logFlushResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->unloggedLSN, InvalidXLogRecPtr);
+
+	pg_atomic_init_u64(&XLogCtl->Insert.CurrBytePos, 0);
+
+	for (i = 0; i < PREV_LINKS_HASH_CAPA; i++)
+	{
+#if WAL_LINK_64
+		pg_atomic_init_u64(&PrevLinksHash[i].CurrPos, 0);
+		pg_atomic_init_u64(&PrevLinksHash[i].PrevPos, WAL_PREV_EMPTY);
+#else
+		pg_atomic_init_u32(&PrevLinksHash[i].CurrPosId, 0);
+		pg_atomic_init_u32(&PrevLinksHash[i].PrevSize, 0);
+#endif
+	}
 }

 /*
@@ -6018,8 +6440,13 @@ StartupXLOG(void)
 	 * previous incarnation.
 	 */
 	Insert = &XLogCtl->Insert;
-	Insert->PrevBytePos = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
-	Insert->CurrBytePos = XLogRecPtrToBytePos(EndOfLog);
+	{
+		XLogRecPtr	endOfLog = XLogRecPtrToBytePos(EndOfLog);
+		XLogRecPtr	lastRec = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
+
+		pg_atomic_write_u64(&Insert->CurrBytePos, endOfLog);
+		LinkStartPrevPos(endOfLog, lastRec);
+	}

 	/*
 	 * Tricky point here: lastPage contains the *last* block that the LastRec
@@ -7005,7 +7432,7 @@ CreateCheckPoint(int flags)

 	if (shutdown)
 	{
-		XLogRecPtr	curInsert = XLogBytePosToRecPtr(Insert->CurrBytePos);
+		XLogRecPtr	curInsert = XLogBytePosToRecPtr(ReadInsertCurrBytePos());

 		/*
 		 * Compute new REDO record ptr = location of next XLOG record.
@@ -9434,14 +9861,7 @@ register_persistent_abort_backup_handler(void)
 XLogRecPtr
 GetXLogInsertRecPtr(void)
 {
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
-	uint64		current_bytepos;
-
-	SpinLockAcquire(&Insert->insertpos_lck);
-	current_bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
-
-	return XLogBytePosToRecPtr(current_bytepos);
+	return XLogBytePosToRecPtr(ReadInsertCurrBytePos());
 }

 /*
diff --git a/src/tools/pgindent/typedefs.list b/src/tools/pgindent/typedefs.list
index 668bddbfcd7..28001598130 100644
--- a/src/tools/pgindent/typedefs.list
+++ b/src/tools/pgindent/typedefs.list
@@ -3122,6 +3122,8 @@ WALAvailability
 WALInsertLock
 WALInsertLockPadded
 WALOpenSegment
+WALPrevPosLink
+WALPrevPosLinkVal
 WALReadError
 WALSegmentCloseCB
 WALSegmentContext
--
2.43.0

From bbc415b50a39d130ee003ce37a485cbd95e238e3 Mon Sep 17 00:00:00 2001
From: Yura Sokolov <y.sokolov@postgrespro.ru>
Date: Sun, 19 Jan 2025 17:40:28 +0300
Subject: [PATCH v3] Lock-free XLog Reservation using lock-free hash-table

Removed PrevBytePos to eliminate lock contention, allowing atomic updates
to CurrBytePos. Use lock-free hash-table based on 4-way Cuckoo Hashing
to store link to PrevBytePos.
---
 src/backend/access/transam/xlog.c | 587 ++++++++++++++++++++++++++----
 src/tools/pgindent/typedefs.list  |   2 +
 2 files changed, 526 insertions(+), 63 deletions(-)

diff --git a/src/backend/access/transam/xlog.c b/src/backend/access/transam/xlog.c
index bf3dbda901d..2664fc5706f 100644
--- a/src/backend/access/transam/xlog.c
+++ b/src/backend/access/transam/xlog.c
@@ -68,6 +68,8 @@
 #include "catalog/pg_database.h"
 #include "common/controldata_utils.h"
 #include "common/file_utils.h"
+#include "common/hashfn.h"
+#include "common/pg_prng.h"
 #include "executor/instrument.h"
 #include "miscadmin.h"
 #include "pg_trace.h"
@@ -384,6 +386,94 @@ typedef union WALInsertLockPadded
 	char		pad[PG_CACHE_LINE_SIZE];
 } WALInsertLockPadded;

+/* #define WAL_LINK_64 0 */
+#ifndef WAL_LINK_64
+#ifdef PG_HAVE_ATOMIC_U64_SIMULATION
+#define WAL_LINK_64 0
+#else
+#define WAL_LINK_64 1
+#endif
+#endif
+
+/*
+ * It links current position with previous one.
+ * - CurrPosId is (CurrBytePos ^ (CurrBytePos>>32))
+ *   Since CurrBytePos grows monotonically and it is aligned to MAXALIGN,
+ *   CurrPosId correctly identifies CurrBytePos for at least 4*2^32 = 32GB of
+ *   WAL logs.
+ * - CurrPosHigh is (CurrBytePos>>32), it is stored for strong uniqueness check.
+ * - PrevSize is difference between CurrBytePos and PrevBytePos
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	uint64		CurrPos;
+	uint64		PrevPos;
+#define WAL_PREV_EMPTY (~((uint64)0))
+#define WALLinkEmpty(l) ((l).PrevPos == WAL_PREV_EMPTY)
+#define WALLinkSamePos(a, b) ((a).CurrPos == (b).CurrPos)
+#define WALLinkCopyPrev(a, b) do {(a).PrevPos = (b).PrevPos;} while(0)
+#else
+	uint32		CurrPosId;
+	uint32		CurrPosHigh;
+	uint32		PrevSize;
+#define WALLinkEmpty(l) ((l).PrevSize == 0)
+#define WALLinkSamePos(a, b) ((a).CurrPosId == (b).CurrPosId && (a).CurrPosHigh == (b).CurrPosHigh)
+#define WALLinkCopyPrev(a, b) do {(a).PrevSize = (b).PrevSize;} while(0)
+#endif
+} WALPrevPosLinkVal;
+
+/*
+ * This is an element of lock-free hash-table.
+ * In 32 bit mode PrevSize's lowest bit is used as a lock, relying on fact it is MAXALIGN-ed.
+ * In 64 bit mode lock protocol is more complex.
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	pg_atomic_uint64 CurrPos;
+	pg_atomic_uint64 PrevPos;
+#else
+	pg_atomic_uint32 CurrPosId;
+	uint32		CurrPosHigh;
+	pg_atomic_uint32 PrevSize;
+	uint32		pad;			/* to align to 16 bytes */
+#endif
+} WALPrevPosLink;
+
+StaticAssertDecl(sizeof(WALPrevPosLink) == 16, "WALPrevPosLink should be 16 bytes");
+
+#define PREV_LINKS_HASH_CAPA (NUM_XLOGINSERT_LOCKS * 2)
+StaticAssertDecl(!(PREV_LINKS_HASH_CAPA & (PREV_LINKS_HASH_CAPA - 1)),
+				 "PREV_LINKS_HASH_CAPA should be power of two");
+StaticAssertDecl(PREV_LINKS_HASH_CAPA < UINT16_MAX,
+				 "PREV_LINKS_HASH_CAPA is too large");
+
+/*-----------
+ * PREV_LINKS_HASH_STRATEGY - the way slots are chosen in hash table
+ *   1 - 4 positions h1,h1+1,h2,h2+2 - it guarantees at least 3 distinct points,
+ *     but may spread at 4 cache lines.
+ *   2 - 4 positions h,h^1,h^2,h^3 - 4 points in single cache line.
+ *   3 - 8 positions h1,h1^1,h1^2,h1^4,h2,h2^1,h2^2,h2^3 - 8 distinct points in
+ *     in two cache lines.
+ */
+#ifndef PREV_LINKS_HASH_STRATEGY
+#define PREV_LINKS_HASH_STRATEGY 1
+#endif
+
+#if PREV_LINKS_HASH_STRATEGY <= 2
+#define PREV_LINKS_LOOKUPS 4
+#else
+#define PREV_LINKS_LOOKUPS 8
+#endif
+
+struct WALPrevLinksLookups
+{
+	uint16		pos[PREV_LINKS_LOOKUPS];
+};
+
+#define SWAP_ONCE_IN 128
+
 /*
  * Session status of running backup, used for sanity checks in SQL-callable
  * functions to start and stop backups.
@@ -395,26 +485,18 @@ static SessionBackupState sessionBackupState = SESSION_BACKUP_NONE;
  */
 typedef struct XLogCtlInsert
 {
-	slock_t		insertpos_lck;	/* protects CurrBytePos and PrevBytePos */
-
 	/*
 	 * CurrBytePos is the end of reserved WAL. The next record will be
-	 * inserted at that position. PrevBytePos is the start position of the
-	 * previously inserted (or rather, reserved) record - it is copied to the
-	 * prev-link of the next record. These are stored as "usable byte
-	 * positions" rather than XLogRecPtrs (see XLogBytePosToRecPtr()).
+	 * inserted at that position.
+	 *
+	 * The start position of the previously inserted (or rather, reserved)
+	 * record (it is copied to the prev-link of the next record) will be
+	 * stored in PrevLinksHash.
+	 *
+	 * These are stored as "usable byte positions" rather than XLogRecPtrs
+	 * (see XLogBytePosToRecPtr()).
 	 */
-	uint64		CurrBytePos;
-	uint64		PrevBytePos;
-
-	/*
-	 * Make sure the above heavily-contended spinlock and byte positions are
-	 * on their own cache line. In particular, the RedoRecPtr and full page
-	 * write variables below should be on a different cache line. They are
-	 * read on every WAL insertion, but updated rarely, and we don't want
-	 * those reads to steal the cache line containing Curr/PrevBytePos.
-	 */
-	char		pad[PG_CACHE_LINE_SIZE];
+	pg_atomic_uint64 CurrBytePos pg_attribute_aligned(PG_CACHE_LINE_SIZE);

 	/*
 	 * fullPageWrites is the authoritative value used by all backends to
@@ -442,6 +524,31 @@ typedef struct XLogCtlInsert
 	 * WAL insertion locks.
 	 */
 	WALInsertLockPadded *WALInsertLocks;
+
+	/*
+	 * PrevLinksHash is a lock-free hash table based on Cuckoo algorithm.
+	 *
+	 * With default PREV_LINKS_HASH_STRATEGY == 1 it is mostly 4 way: for
+	 * every element computed two positions h1, h2, and neighbour h1+1 and
+	 * h2+2 are used as well. This way even on collision we have 3 distinct
+	 * position, which provide us ~75% fill rate without unsolvable cycles
+	 * (due to Cuckoo's theory). But chosen slots may be in 4 distinct
+	 * cache-lines.
+	 *
+	 * With PREV_LINKS_HASH_STRATEGY == 3 it takes two buckets 4 elements each
+	 * - 8 positions in total, but guaranteed to be in two cache lines. It
+	 * provides very high fill rate - upto 90%.
+	 *
+	 * With PREV_LINKS_HASH_STRATEGY == 2 it takes only one bucket with 4
+	 * elements. Strictly speaking it is not Cuckoo-hashing, but should work
+	 * for our case.
+	 *
+	 * Certainly, we rely on the fact we will delete elements with same speed
+	 * as we add them, and even unsolvable cycles will be destroyed soon by
+	 * concurrent deletions.
+	 */
+	WALPrevPosLink *PrevLinksHash;
+
 } XLogCtlInsert;

 /*
@@ -568,6 +675,9 @@ static XLogCtlData *XLogCtl = NULL;
 /* a private copy of XLogCtl->Insert.WALInsertLocks, for convenience */
 static WALInsertLockPadded *WALInsertLocks = NULL;

+/* same for XLogCtl->Insert.PrevLinksHash */
+static WALPrevPosLink *PrevLinksHash = NULL;
+
 /*
  * We maintain an image of pg_control in shared memory.
  */
@@ -700,6 +810,19 @@ static void CopyXLogRecordToWAL(int write_len, bool isLogSwitch,
 								XLogRecData *rdata,
 								XLogRecPtr StartPos, XLogRecPtr EndPos,
 								TimeLineID tli);
+
+static void WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos);
+static void WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos);
+static void CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos);
+
+static bool WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val);
+static bool WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static bool WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static void LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos,
+							   XLogRecPtr *PrevPtr);
+static void LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec);
+static XLogRecPtr ReadInsertCurrBytePos(void);
+
 static void ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos,
 									  XLogRecPtr *EndPos, XLogRecPtr *PrevPtr);
 static bool ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos,
@@ -1086,6 +1209,341 @@ XLogInsertRecord(XLogRecData *rdata,
 	return EndPos;
 }

+static pg_attribute_always_inline void
+WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos)
+{
+#if WAL_LINK_64
+	val->CurrPos = StartPos;
+	val->PrevPos = PrevPos;
+#else
+	val->CurrPosHigh = StartPos >> 32;
+	val->CurrPosId = StartPos ^ val->CurrPosHigh;
+	val->PrevSize = StartPos - PrevPos;
+#endif
+}
+
+static pg_attribute_always_inline void
+WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos)
+{
+#if WAL_LINK_64
+	*PrevPos = val.PrevPos;
+#else
+	XLogRecPtr	StartPos = val.CurrPosHigh;
+
+	StartPos ^= (StartPos << 32) | val.CurrPosId;
+	*PrevPos = StartPos - val.PrevSize;
+#endif
+}
+
+static pg_attribute_always_inline void
+CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos)
+{
+	uint32		hash;
+#if PREV_LINKS_HASH_STRATEGY == 3
+	uint32		offset;
+#endif
+
+
+#if WAL_LINK_64
+	hash = murmurhash32(linkval.CurrPos ^ (linkval.CurrPos >> 32));
+#else
+	hash = murmurhash32(linkval.CurrPosId);
+#endif
+
+#if PREV_LINKS_HASH_STRATEGY == 1
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = (pos->pos[0] + 1) % PREV_LINKS_HASH_CAPA;
+	pos->pos[2] = (hash >> 16) % PREV_LINKS_HASH_CAPA;
+	pos->pos[3] = (pos->pos[2] + 2) % PREV_LINKS_HASH_CAPA;
+#else
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = pos->pos[0] ^ 1;
+	pos->pos[2] = pos->pos[0] ^ 2;
+	pos->pos[3] = pos->pos[0] ^ 3;
+#if PREV_LINKS_HASH_STRATEGY == 3
+	/* use multiplication compute 0 <= offset < PREV_LINKS_HASH_CAPA-4 */
+	offset = (hash / PREV_LINKS_HASH_CAPA) * (PREV_LINKS_HASH_CAPA - 4);
+	offset /= UINT32_MAX / PREV_LINKS_HASH_CAPA + 1;
+	/* add start of next bucket */
+	offset += (pos->pos[0] | 3) + 1;
+	/* get position in strictly other bucket */
+	pos->pos[4] = offset % PREV_LINKS_HASH_CAPA;
+	pos->pos[5] = pos->pos[4] ^ 1;
+	pos->pos[6] = pos->pos[4] ^ 2;
+	pos->pos[7] = pos->pos[4] ^ 3;
+#endif
+#endif
+}
+
+/*
+ * Attempt to write into empty link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val)
+{
+#if WAL_LINK_64
+	uint64		empty = WAL_PREV_EMPTY;
+
+	if (pg_atomic_read_u64(&link->PrevPos) != WAL_PREV_EMPTY)
+		return false;
+	if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &empty, val.PrevPos))
+		return false;
+	/* we could ignore concurrent lock of CurrPos */
+	pg_atomic_write_u64(&link->CurrPos, val.CurrPos);
+	return true;
+#else
+	uint32		empty = 0;
+
+	/* first check it read-only */
+	if (pg_atomic_read_u32(&link->PrevSize) != 0)
+		return false;
+	if (!pg_atomic_compare_exchange_u32(&link->PrevSize, &empty, 1))
+		/* someone else occupied the entry */
+		return false;
+
+	pg_atomic_write_u32(&link->CurrPosId, val.CurrPosId);
+	link->CurrPosHigh = val.CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val.PrevSize);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to consume matched link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+
+	if (pg_atomic_read_u64(&link->CurrPos) != val->CurrPos)
+		return false;
+	/* lock against concurrent swapper */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr != val->CurrPos)
+	{
+		/* link was swapped */
+		pg_atomic_write_u64(&link->CurrPos, oldCurr);
+		return false;
+	}
+	val->PrevPos = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, WAL_PREV_EMPTY);
+
+	/*
+	 * concurrent inserter may already reuse this link, so we don't check
+	 * result of compare_exchange
+	 */
+	oldCurr |= 1;
+	pg_atomic_compare_exchange_u64(&link->CurrPos, &oldCurr, 0);
+	return true;
+#else
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId)
+		return false;
+
+	/* Try lock */
+	val->PrevSize = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (val->PrevSize & 1)
+		/* Lock failed */
+		return false;
+
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId ||
+		link->CurrPosHigh != val->CurrPosHigh)
+	{
+		/* unlock with old value */
+		pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+		return false;
+	}
+
+	pg_atomic_write_u32(&link->CurrPosId, 0);
+	link->CurrPosHigh = 0;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, 0);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to swap entry: remember existing link and write our.
+ * It could happen we consume empty entry. Caller will detect it by checking
+ * remembered value.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+	uint64		oldPrev;
+
+	/* lock against concurrent swapper or consumer */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr == 0)
+	{
+		/* link was empty */
+		oldPrev = WAL_PREV_EMPTY;
+		/* but concurrent inserter may concurrently insert */
+		if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &oldPrev, val->PrevPos))
+			return false;		/* concurrent inserter won. It will overwrite
+								 * CurrPos */
+		/* this write acts as unlock */
+		pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+		val->CurrPos = 0;
+		val->PrevPos = WAL_PREV_EMPTY;
+		return true;
+	}
+	oldPrev = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, val->PrevPos);
+	pg_write_barrier();
+	/* write acts as unlock */
+	pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+	val->CurrPos = oldCurr;
+	val->PrevPos = oldPrev;
+	return true;
+#else
+	uint32		oldPrev;
+	uint32		oldCurId;
+	uint32		oldCurHigh;
+
+	/* Attempt to lock entry against concurrent consumer or swapper */
+	oldPrev = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (oldPrev & 1)
+		/* Lock failed */
+		return false;
+
+	oldCurId = pg_atomic_read_u32(&link->CurrPosId);
+	oldCurHigh = link->CurrPosHigh;
+	pg_atomic_write_u32(&link->CurrPosId, val->CurrPosId);
+	link->CurrPosHigh = val->CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+
+	val->CurrPosId = oldCurId;
+	val->CurrPosHigh = oldCurHigh;
+	val->PrevSize = oldPrev;
+	return true;
+#endif
+}
+
+/*
+ * Write new link (EndPos, StartPos) and find PrevPtr for StartPos.
+ *
+ * Links are stored in lock-free Cuckoo based hash-table.
+ * We use mostly-4 way Cuckoo hashing which provides high fill rate without
+ * hard cycle collisions. Also we rely on concurrent consumers of existing
+ * entry, so cycles will be broken in mean time.
+ *
+ * Cuckoo hashing relies on re-insertion for balancing, so we occasionally
+ * swaps entry and try to insert swapped instead of our.
+ */
+static void
+LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos, XLogRecPtr *PrevPtr)
+{
+	SpinDelayStatus spin_stat;
+	WALPrevPosLinkVal lookup;
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups lookup_pos;
+	struct WALPrevLinksLookups insert_pos;
+	uint32		i;
+	uint32		rand = 0;
+	bool		inserted = false;
+	bool		found = false;
+
+	/* pass StartPos second time to set PrevSize = 0 */
+	WALPrevPosLinkValCompose(&lookup, StartPos, StartPos);
+	WALPrevPosLinkValCompose(&insert, EndPos, StartPos);
+
+	CalcCuckooPositions(lookup, &lookup_pos);
+	CalcCuckooPositions(insert, &insert_pos);
+
+	init_local_spin_delay(&spin_stat);
+
+	while (!inserted || !found)
+	{
+		for (i = 0; !found && i < PREV_LINKS_LOOKUPS; i++)
+			found = WALPrevPosLinkConsume(&PrevLinksHash[lookup_pos.pos[i]], &lookup);
+
+		if (inserted)
+		{
+			/*
+			 * we may sleep only after we inserted our value, since other
+			 * backend waits for it
+			 */
+			perform_spin_delay(&spin_stat);
+			goto next;
+		}
+
+		for (i = 0; !inserted && i < PREV_LINKS_LOOKUPS; i++)
+			inserted = WALPrevPosLinkInsert(&PrevLinksHash[insert_pos.pos[i]], insert);
+
+		if (inserted)
+			goto next;
+
+		rand = pg_prng_uint32(&pg_global_prng_state);
+		if (rand % SWAP_ONCE_IN != 0)
+			goto next;
+
+		i = rand / SWAP_ONCE_IN % PREV_LINKS_LOOKUPS;
+		if (!WALPrevPosLinkSwap(&PrevLinksHash[insert_pos.pos[i]], &insert))
+			goto next;
+
+		if (WALLinkEmpty(insert))
+			/* Lucky case: entry become empty and we inserted into */
+			inserted = true;
+		else if (WALLinkSamePos(lookup, insert))
+		{
+			/*
+			 * We occasionally replaced entry we looked for. No need to insert
+			 * it again.
+			 */
+			inserted = true;
+			Assert(!found);
+			found = true;
+			WALLinkCopyPrev(lookup, insert);
+			break;
+		}
+		else
+			CalcCuckooPositions(insert, &insert_pos);
+
+next:
+		pg_spin_delay();
+		pg_read_barrier();
+	}
+
+	WALPrevPosLinkValGetPrev(lookup, PrevPtr);
+}
+
+static pg_attribute_always_inline void
+LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec)
+{
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups insert_pos;
+
+	WALPrevPosLinkValCompose(&insert, EndOfLog, LastRec);
+	CalcCuckooPositions(insert, &insert_pos);
+#if WAL_LINK_64
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].CurrPos, insert.CurrPos);
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].PrevPos, insert.PrevPos);
+#else
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].CurrPosId, insert.CurrPosId);
+	PrevLinksHash[insert_pos.pos[0]].CurrPosHigh = insert.CurrPosHigh;
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].PrevSize, insert.PrevSize);
+#endif
+}
+
+static pg_attribute_always_inline XLogRecPtr
+ReadInsertCurrBytePos(void)
+{
+	return pg_atomic_read_u64(&XLogCtl->Insert.CurrBytePos);
+}
+
 /*
  * Reserves the right amount of space for a record of given size from the WAL.
  * *StartPos is set to the beginning of the reserved section, *EndPos to
@@ -1118,25 +1576,9 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
 	/* All (non xlog-switch) records should contain data. */
 	Assert(size > SizeOfXLogRecord);

-	/*
-	 * The duration the spinlock needs to be held is minimized by minimizing
-	 * the calculations that have to be done while holding the lock. The
-	 * current tip of reserved WAL is kept in CurrBytePos, as a byte position
-	 * that only counts "usable" bytes in WAL, that is, it excludes all WAL
-	 * page headers. The mapping between "usable" byte positions and physical
-	 * positions (XLogRecPtrs) can be done outside the locked region, and
-	 * because the usable byte position doesn't include any headers, reserving
-	 * X bytes from WAL is almost as simple as "CurrBytePos += X".
-	 */
-	SpinLockAcquire(&Insert->insertpos_lck);
-
-	startbytepos = Insert->CurrBytePos;
+	startbytepos = pg_atomic_fetch_add_u64(&Insert->CurrBytePos, size);
 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;
-
-	SpinLockRelease(&Insert->insertpos_lck);
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);
@@ -1172,26 +1614,24 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 	uint32		segleft;

 	/*
-	 * These calculations are a bit heavy-weight to be done while holding a
-	 * spinlock, but since we're holding all the WAL insertion locks, there
-	 * are no other inserters competing for it. GetXLogInsertRecPtr() does
-	 * compete for it, but that's not called very frequently.
+	 * Currently ReserveXLogInsertLocation is protected with exclusive
+	 * insertion lock, so there is no contention against CurrBytePos, But we
+	 * still do CAS loop for being uniform.
+	 *
+	 * Probably we'll get rid of exclusive lock in a future.
 	 */
-	SpinLockAcquire(&Insert->insertpos_lck);

-	startbytepos = Insert->CurrBytePos;
+repeat:
+	startbytepos = pg_atomic_read_u64(&Insert->CurrBytePos);

 	ptr = XLogBytePosToEndRecPtr(startbytepos);
 	if (XLogSegmentOffset(ptr, wal_segment_size) == 0)
 	{
-		SpinLockRelease(&Insert->insertpos_lck);
 		*EndPos = *StartPos = ptr;
 		return false;
 	}

 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-
 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);

@@ -1202,10 +1642,19 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 		*EndPos += segleft;
 		endbytepos = XLogRecPtrToBytePos(*EndPos);
 	}
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;

-	SpinLockRelease(&Insert->insertpos_lck);
+	if (!pg_atomic_compare_exchange_u64(&Insert->CurrBytePos,
+										&startbytepos,
+										endbytepos))
+	{
+		/*
+		 * Don't use spin delay here: perform_spin_delay primary case is for
+		 * solving single core contention. But on single core we will succeed
+		 * on the next attempt.
+		 */
+		goto repeat;
+	}
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*PrevPtr = XLogBytePosToRecPtr(prevbytepos);

@@ -1507,7 +1956,6 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 	XLogRecPtr	inserted;
 	XLogRecPtr	reservedUpto;
 	XLogRecPtr	finishedUpto;
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	int			i;

 	if (MyProc == NULL)
@@ -1522,9 +1970,7 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 		return inserted;

 	/* Read the current insert position */
-	SpinLockAcquire(&Insert->insertpos_lck);
-	bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
+	bytepos = ReadInsertCurrBytePos();
 	reservedUpto = XLogBytePosToEndRecPtr(bytepos);

 	/*
@@ -4898,6 +5344,8 @@ XLOGShmemSize(void)

 	/* WAL insertion locks, plus alignment */
 	size = add_size(size, mul_size(sizeof(WALInsertLockPadded), NUM_XLOGINSERT_LOCKS + 1));
+	/* prevlinkshash, abuses alignment of WAL insertion locks. */
+	size = add_size(size, mul_size(sizeof(WALPrevPosLink), PREV_LINKS_HASH_CAPA));
 	/* xlblocks array */
 	size = add_size(size, mul_size(sizeof(pg_atomic_uint64), XLOGbuffers));
 	/* extra alignment padding for XLOG I/O buffers */
@@ -4999,6 +5447,9 @@ XLOGShmemInit(void)
 		WALInsertLocks[i].l.lastImportantAt = InvalidXLogRecPtr;
 	}

+	PrevLinksHash = XLogCtl->Insert.PrevLinksHash = (WALPrevPosLink *) allocptr;
+	allocptr += sizeof(WALPrevPosLink) * PREV_LINKS_HASH_CAPA;
+
 	/*
 	 * Align the start of the page buffers to a full xlog block size boundary.
 	 * This simplifies some calculations in XLOG insertion. It is also
@@ -5017,12 +5468,24 @@ XLOGShmemInit(void)
 	XLogCtl->InstallXLogFileSegmentActive = false;
 	XLogCtl->WalWriterSleeping = false;

-	SpinLockInit(&XLogCtl->Insert.insertpos_lck);
 	SpinLockInit(&XLogCtl->info_lck);
 	pg_atomic_init_u64(&XLogCtl->logInsertResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logWriteResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logFlushResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->unloggedLSN, InvalidXLogRecPtr);
+
+	pg_atomic_init_u64(&XLogCtl->Insert.CurrBytePos, 0);
+
+	for (i = 0; i < PREV_LINKS_HASH_CAPA; i++)
+	{
+#if WAL_LINK_64
+		pg_atomic_init_u64(&PrevLinksHash[i].CurrPos, 0);
+		pg_atomic_init_u64(&PrevLinksHash[i].PrevPos, WAL_PREV_EMPTY);
+#else
+		pg_atomic_init_u32(&PrevLinksHash[i].CurrPosId, 0);
+		pg_atomic_init_u32(&PrevLinksHash[i].PrevSize, 0);
+#endif
+	}
 }

 /*
@@ -6018,8 +6481,13 @@ StartupXLOG(void)
 	 * previous incarnation.
 	 */
 	Insert = &XLogCtl->Insert;
-	Insert->PrevBytePos = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
-	Insert->CurrBytePos = XLogRecPtrToBytePos(EndOfLog);
+	{
+		XLogRecPtr	endOfLog = XLogRecPtrToBytePos(EndOfLog);
+		XLogRecPtr	lastRec = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
+
+		pg_atomic_write_u64(&Insert->CurrBytePos, endOfLog);
+		LinkStartPrevPos(endOfLog, lastRec);
+	}

 	/*
 	 * Tricky point here: lastPage contains the *last* block that the LastRec
@@ -7005,7 +7473,7 @@ CreateCheckPoint(int flags)

 	if (shutdown)
 	{
-		XLogRecPtr	curInsert = XLogBytePosToRecPtr(Insert->CurrBytePos);
+		XLogRecPtr	curInsert = XLogBytePosToRecPtr(ReadInsertCurrBytePos());

 		/*
 		 * Compute new REDO record ptr = location of next XLOG record.
@@ -9434,14 +9902,7 @@ register_persistent_abort_backup_handler(void)
 XLogRecPtr
 GetXLogInsertRecPtr(void)
 {
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
-	uint64		current_bytepos;
-
-	SpinLockAcquire(&Insert->insertpos_lck);
-	current_bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
-
-	return XLogBytePosToRecPtr(current_bytepos);
+	return XLogBytePosToRecPtr(ReadInsertCurrBytePos());
 }

 /*
diff --git a/src/tools/pgindent/typedefs.list b/src/tools/pgindent/typedefs.list
index 668bddbfcd7..28001598130 100644
--- a/src/tools/pgindent/typedefs.list
+++ b/src/tools/pgindent/typedefs.list
@@ -3122,6 +3122,8 @@ WALAvailability
 WALInsertLock
 WALInsertLockPadded
 WALOpenSegment
+WALPrevPosLink
+WALPrevPosLinkVal
 WALReadError
 WALSegmentCloseCB
 WALSegmentContext
--
2.43.0

From d8b1e82bab1ee51b416956b241e824f0b1d125e8 Mon Sep 17 00:00:00 2001
From: Yura Sokolov <y.sokolov@postgrespro.ru>
Date: Sun, 19 Jan 2025 17:40:28 +0300
Subject: [PATCH] Dumb lock-free XLog Reservation without xl_prev

---
 src/backend/access/transam/xlog.c       | 106 ++++++++++--------------
 src/backend/access/transam/xlogreader.c |   2 +-
 2 files changed, 47 insertions(+), 61 deletions(-)

diff --git a/src/backend/access/transam/xlog.c b/src/backend/access/transam/xlog.c
index bf3dbda901d..d45e6408268 100644
--- a/src/backend/access/transam/xlog.c
+++ b/src/backend/access/transam/xlog.c
@@ -395,17 +395,18 @@ static SessionBackupState sessionBackupState = SESSION_BACKUP_NONE;
  */
 typedef struct XLogCtlInsert
 {
-	slock_t		insertpos_lck;	/* protects CurrBytePos and PrevBytePos */
-
 	/*
 	 * CurrBytePos is the end of reserved WAL. The next record will be
-	 * inserted at that position. PrevBytePos is the start position of the
-	 * previously inserted (or rather, reserved) record - it is copied to the
-	 * prev-link of the next record. These are stored as "usable byte
-	 * positions" rather than XLogRecPtrs (see XLogBytePosToRecPtr()).
+	 * inserted at that position.
+	 *
+	 * The start position of the previously inserted (or rather, reserved)
+	 * record (it is copied to the prev-link of the next record) will be
+	 * stored in PrevLinksHash.
+	 *
+	 * These are stored as "usable byte positions" rather than XLogRecPtrs
+	 * (see XLogBytePosToRecPtr()).
 	 */
-	uint64		CurrBytePos;
-	uint64		PrevBytePos;
+	pg_atomic_uint64 CurrBytePos;

 	/*
 	 * Make sure the above heavily-contended spinlock and byte positions are
@@ -715,6 +716,12 @@ static void WALInsertLockAcquireExclusive(void);
 static void WALInsertLockRelease(void);
 static void WALInsertLockUpdateInsertingAt(XLogRecPtr insertingAt);

+static inline XLogRecPtr
+ReadInsertCurrBytePos(void)
+{
+	return pg_atomic_read_u64(&XLogCtl->Insert.CurrBytePos);
+}
+
 /*
  * Insert an XLOG record represented by an already-constructed chain of data
  * chunks.  This is a low-level routine; to construct the WAL record header
@@ -1111,36 +1118,18 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
 	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	uint64		startbytepos;
 	uint64		endbytepos;
-	uint64		prevbytepos;

 	size = MAXALIGN(size);

 	/* All (non xlog-switch) records should contain data. */
 	Assert(size > SizeOfXLogRecord);

-	/*
-	 * The duration the spinlock needs to be held is minimized by minimizing
-	 * the calculations that have to be done while holding the lock. The
-	 * current tip of reserved WAL is kept in CurrBytePos, as a byte position
-	 * that only counts "usable" bytes in WAL, that is, it excludes all WAL
-	 * page headers. The mapping between "usable" byte positions and physical
-	 * positions (XLogRecPtrs) can be done outside the locked region, and
-	 * because the usable byte position doesn't include any headers, reserving
-	 * X bytes from WAL is almost as simple as "CurrBytePos += X".
-	 */
-	SpinLockAcquire(&Insert->insertpos_lck);
-
-	startbytepos = Insert->CurrBytePos;
+	startbytepos = pg_atomic_fetch_add_u64(&Insert->CurrBytePos, size);
 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;
-
-	SpinLockRelease(&Insert->insertpos_lck);

 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);
-	*PrevPtr = XLogBytePosToRecPtr(prevbytepos);
+	*PrevPtr = *StartPos - 1;

 	/*
 	 * Check that the conversions between "usable byte positions" and
@@ -1148,7 +1137,6 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
 	 */
 	Assert(XLogRecPtrToBytePos(*StartPos) == startbytepos);
 	Assert(XLogRecPtrToBytePos(*EndPos) == endbytepos);
-	Assert(XLogRecPtrToBytePos(*PrevPtr) == prevbytepos);
 }

 /*
@@ -1166,32 +1154,29 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	uint64		startbytepos;
 	uint64		endbytepos;
-	uint64		prevbytepos;
 	uint32		size = MAXALIGN(SizeOfXLogRecord);
 	XLogRecPtr	ptr;
 	uint32		segleft;

 	/*
-	 * These calculations are a bit heavy-weight to be done while holding a
-	 * spinlock, but since we're holding all the WAL insertion locks, there
-	 * are no other inserters competing for it. GetXLogInsertRecPtr() does
-	 * compete for it, but that's not called very frequently.
+	 * Currently ReserveXLogInsertLocation is protected with exclusive
+	 * insertion lock, so there is no contention against CurrBytePos, But we
+	 * still do CAS loop for being uniform.
+	 *
+	 * Probably we'll get rid of exclusive lock in a future.
 	 */
-	SpinLockAcquire(&Insert->insertpos_lck);

-	startbytepos = Insert->CurrBytePos;
+repeat:
+	startbytepos = pg_atomic_read_u64(&Insert->CurrBytePos);

 	ptr = XLogBytePosToEndRecPtr(startbytepos);
 	if (XLogSegmentOffset(ptr, wal_segment_size) == 0)
 	{
-		SpinLockRelease(&Insert->insertpos_lck);
 		*EndPos = *StartPos = ptr;
 		return false;
 	}

 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-
 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);

@@ -1202,17 +1187,24 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 		*EndPos += segleft;
 		endbytepos = XLogRecPtrToBytePos(*EndPos);
 	}
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;

-	SpinLockRelease(&Insert->insertpos_lck);
+	if (!pg_atomic_compare_exchange_u64(&Insert->CurrBytePos,
+										&startbytepos,
+										endbytepos))
+	{
+		/*
+		 * Don't use spin delay here: perform_spin_delay primary case is for
+		 * solving single core contention. But on single core we will succeed
+		 * on the next attempt.
+		 */
+		goto repeat;
+	}

-	*PrevPtr = XLogBytePosToRecPtr(prevbytepos);
+	*PrevPtr = *StartPos - 1;

 	Assert(XLogSegmentOffset(*EndPos, wal_segment_size) == 0);
 	Assert(XLogRecPtrToBytePos(*EndPos) == endbytepos);
 	Assert(XLogRecPtrToBytePos(*StartPos) == startbytepos);
-	Assert(XLogRecPtrToBytePos(*PrevPtr) == prevbytepos);

 	return true;
 }
@@ -1507,7 +1499,6 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 	XLogRecPtr	inserted;
 	XLogRecPtr	reservedUpto;
 	XLogRecPtr	finishedUpto;
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	int			i;

 	if (MyProc == NULL)
@@ -1522,9 +1513,7 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 		return inserted;

 	/* Read the current insert position */
-	SpinLockAcquire(&Insert->insertpos_lck);
-	bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
+	bytepos = ReadInsertCurrBytePos();
 	reservedUpto = XLogBytePosToEndRecPtr(bytepos);

 	/*
@@ -5017,12 +5006,13 @@ XLOGShmemInit(void)
 	XLogCtl->InstallXLogFileSegmentActive = false;
 	XLogCtl->WalWriterSleeping = false;

-	SpinLockInit(&XLogCtl->Insert.insertpos_lck);
 	SpinLockInit(&XLogCtl->info_lck);
 	pg_atomic_init_u64(&XLogCtl->logInsertResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logWriteResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logFlushResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->unloggedLSN, InvalidXLogRecPtr);
+
+	pg_atomic_init_u64(&XLogCtl->Insert.CurrBytePos, 0);
 }

 /*
@@ -6018,8 +6008,11 @@ StartupXLOG(void)
 	 * previous incarnation.
 	 */
 	Insert = &XLogCtl->Insert;
-	Insert->PrevBytePos = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
-	Insert->CurrBytePos = XLogRecPtrToBytePos(EndOfLog);
+	{
+		XLogRecPtr	endOfLog = XLogRecPtrToBytePos(EndOfLog);
+
+		pg_atomic_write_u64(&Insert->CurrBytePos, endOfLog);
+	}

 	/*
 	 * Tricky point here: lastPage contains the *last* block that the LastRec
@@ -7005,7 +6998,7 @@ CreateCheckPoint(int flags)

 	if (shutdown)
 	{
-		XLogRecPtr	curInsert = XLogBytePosToRecPtr(Insert->CurrBytePos);
+		XLogRecPtr	curInsert = XLogBytePosToRecPtr(ReadInsertCurrBytePos());

 		/*
 		 * Compute new REDO record ptr = location of next XLOG record.
@@ -9434,14 +9427,7 @@ register_persistent_abort_backup_handler(void)
 XLogRecPtr
 GetXLogInsertRecPtr(void)
 {
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
-	uint64		current_bytepos;
-
-	SpinLockAcquire(&Insert->insertpos_lck);
-	current_bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
-
-	return XLogBytePosToRecPtr(current_bytepos);
+	return XLogBytePosToRecPtr(ReadInsertCurrBytePos());
 }

 /*
diff --git a/src/backend/access/transam/xlogreader.c b/src/backend/access/transam/xlogreader.c
index 3596af06172..0851b62af93 100644
--- a/src/backend/access/transam/xlogreader.c
+++ b/src/backend/access/transam/xlogreader.c
@@ -1165,7 +1165,7 @@ ValidXLogRecordHeader(XLogReaderState *state, XLogRecPtr RecPtr,
 		 * check guards against torn WAL pages where a stale but valid-looking
 		 * WAL record starts on a sector boundary.
 		 */
-		if (record->xl_prev != PrevRecPtr)
+		if (false && record->xl_prev != PrevRecPtr)
 		{
 			report_invalid_record(state,
 								  "record with incorrect prev-link %X/%X at %X/%X",
--
2.43.0

From 189981c2e7dfe94ff86c4f9406e740b368aad79d Mon Sep 17 00:00:00 2001
From: Yura Sokolov <y.sokolov@postgrespro.ru>
Date: Sun, 19 Jan 2025 17:40:28 +0300
Subject: [PATCH v4] Lock-free XLog Reservation using lock-free hash-table

Removed PrevBytePos to eliminate lock contention, allowing atomic updates
to CurrBytePos. Use lock-free hash-table based on 4-way Cuckoo Hashing
to store link to PrevBytePos.
---
 src/backend/access/transam/xlog.c | 582 +++++++++++++++++++++++++++---
 src/tools/pgindent/typedefs.list  |   2 +
 2 files changed, 530 insertions(+), 54 deletions(-)

diff --git a/src/backend/access/transam/xlog.c b/src/backend/access/transam/xlog.c
index bf3dbda901d..de9bbbfbbb6 100644
--- a/src/backend/access/transam/xlog.c
+++ b/src/backend/access/transam/xlog.c
@@ -68,6 +68,8 @@
 #include "catalog/pg_database.h"
 #include "common/controldata_utils.h"
 #include "common/file_utils.h"
+#include "common/hashfn.h"
+#include "common/pg_prng.h"
 #include "executor/instrument.h"
 #include "miscadmin.h"
 #include "pg_trace.h"
@@ -384,6 +386,94 @@ typedef union WALInsertLockPadded
 	char		pad[PG_CACHE_LINE_SIZE];
 } WALInsertLockPadded;

+/* #define WAL_LINK_64 0 */
+#ifndef WAL_LINK_64
+#ifdef PG_HAVE_ATOMIC_U64_SIMULATION
+#define WAL_LINK_64 0
+#else
+#define WAL_LINK_64 1
+#endif
+#endif
+
+/*
+ * It links current position with previous one.
+ * - CurrPosId is (CurrBytePos ^ (CurrBytePos>>32))
+ *   Since CurrBytePos grows monotonically and it is aligned to MAXALIGN,
+ *   CurrPosId correctly identifies CurrBytePos for at least 4*2^32 = 32GB of
+ *   WAL logs.
+ * - CurrPosHigh is (CurrBytePos>>32), it is stored for strong uniqueness check.
+ * - PrevSize is difference between CurrBytePos and PrevBytePos
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	uint64		CurrPos;
+	uint64		PrevPos;
+#define WAL_PREV_EMPTY (~((uint64)0))
+#define WALLinkEmpty(l) ((l).PrevPos == WAL_PREV_EMPTY)
+#define WALLinkSamePos(a, b) ((a).CurrPos == (b).CurrPos)
+#define WALLinkCopyPrev(a, b) do {(a).PrevPos = (b).PrevPos;} while(0)
+#else
+	uint32		CurrPosId;
+	uint32		CurrPosHigh;
+	uint32		PrevSize;
+#define WALLinkEmpty(l) ((l).PrevSize == 0)
+#define WALLinkSamePos(a, b) ((a).CurrPosId == (b).CurrPosId && (a).CurrPosHigh == (b).CurrPosHigh)
+#define WALLinkCopyPrev(a, b) do {(a).PrevSize = (b).PrevSize;} while(0)
+#endif
+} WALPrevPosLinkVal;
+
+/*
+ * This is an element of lock-free hash-table.
+ * In 32 bit mode PrevSize's lowest bit is used as a lock, relying on fact it is MAXALIGN-ed.
+ * In 64 bit mode lock protocol is more complex.
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	pg_atomic_uint64 CurrPos;
+	pg_atomic_uint64 PrevPos;
+#else
+	pg_atomic_uint32 CurrPosId;
+	uint32		CurrPosHigh;
+	pg_atomic_uint32 PrevSize;
+	uint32		pad;			/* to align to 16 bytes */
+#endif
+} WALPrevPosLink;
+
+StaticAssertDecl(sizeof(WALPrevPosLink) == 16, "WALPrevPosLink should be 16 bytes");
+
+#define PREV_LINKS_HASH_CAPA (NUM_XLOGINSERT_LOCKS * 2)
+StaticAssertDecl(!(PREV_LINKS_HASH_CAPA & (PREV_LINKS_HASH_CAPA - 1)),
+				 "PREV_LINKS_HASH_CAPA should be power of two");
+StaticAssertDecl(PREV_LINKS_HASH_CAPA < UINT16_MAX,
+				 "PREV_LINKS_HASH_CAPA is too large");
+
+/*-----------
+ * PREV_LINKS_HASH_STRATEGY - the way slots are chosen in hash table
+ *   1 - 4 positions h1,h1+1,h2,h2+2 - it guarantees at least 3 distinct points,
+ *     but may spread at 4 cache lines.
+ *   2 - 4 positions h,h^1,h^2,h^3 - 4 points in single cache line.
+ *   3 - 8 positions h1,h1^1,h1^2,h1^4,h2,h2^1,h2^2,h2^3 - 8 distinct points in
+ *     in two cache lines.
+ */
+#ifndef PREV_LINKS_HASH_STRATEGY
+#define PREV_LINKS_HASH_STRATEGY 3
+#endif
+
+#if PREV_LINKS_HASH_STRATEGY <= 2
+#define PREV_LINKS_LOOKUPS 4
+#else
+#define PREV_LINKS_LOOKUPS 8
+#endif
+
+struct WALPrevLinksLookups
+{
+	uint16		pos[PREV_LINKS_LOOKUPS];
+};
+
+#define SWAP_ONCE_IN 128
+
 /*
  * Session status of running backup, used for sanity checks in SQL-callable
  * functions to start and stop backups.
@@ -395,17 +485,18 @@ static SessionBackupState sessionBackupState = SESSION_BACKUP_NONE;
  */
 typedef struct XLogCtlInsert
 {
-	slock_t		insertpos_lck;	/* protects CurrBytePos and PrevBytePos */
-
 	/*
 	 * CurrBytePos is the end of reserved WAL. The next record will be
-	 * inserted at that position. PrevBytePos is the start position of the
-	 * previously inserted (or rather, reserved) record - it is copied to the
-	 * prev-link of the next record. These are stored as "usable byte
-	 * positions" rather than XLogRecPtrs (see XLogBytePosToRecPtr()).
+	 * inserted at that position.
+	 *
+	 * The start position of the previously inserted (or rather, reserved)
+	 * record (it is copied to the prev-link of the next record) will be
+	 * stored in PrevLinksHash.
+	 *
+	 * These are stored as "usable byte positions" rather than XLogRecPtrs
+	 * (see XLogBytePosToRecPtr()).
 	 */
-	uint64		CurrBytePos;
-	uint64		PrevBytePos;
+	pg_atomic_uint64 CurrBytePos;

 	/*
 	 * Make sure the above heavily-contended spinlock and byte positions are
@@ -442,8 +533,37 @@ typedef struct XLogCtlInsert
 	 * WAL insertion locks.
 	 */
 	WALInsertLockPadded *WALInsertLocks;
+
+	/*
+	 * PrevLinksHash is a lock-free hash table based on Cuckoo algorithm.
+	 *
+	 * With default PREV_LINKS_HASH_STRATEGY == 1 it is mostly 4 way: for
+	 * every element computed two positions h1, h2, and neighbour h1+1 and
+	 * h2+2 are used as well. This way even on collision we have 3 distinct
+	 * position, which provide us ~75% fill rate without unsolvable cycles
+	 * (due to Cuckoo's theory). But chosen slots may be in 4 distinct
+	 * cache-lines.
+	 *
+	 * With PREV_LINKS_HASH_STRATEGY == 3 it takes two buckets 4 elements each
+	 * - 8 positions in total, but guaranteed to be in two cache lines. It
+	 * provides very high fill rate - upto 90%.
+	 *
+	 * With PREV_LINKS_HASH_STRATEGY == 2 it takes only one bucket with 4
+	 * elements. Strictly speaking it is not Cuckoo-hashing, but should work
+	 * for our case.
+	 *
+	 * Certainly, we rely on the fact we will delete elements with same speed
+	 * as we add them, and even unsolvable cycles will be destroyed soon by
+	 * concurrent deletions.
+	 */
+	WALPrevPosLink *PrevLinksHash;
+
 } XLogCtlInsert;

+StaticAssertDecl(offsetof(XLogCtlInsert, RedoRecPtr) / PG_CACHE_LINE_SIZE !=
+				 offsetof(XLogCtlInsert, CurrBytePos) / PG_CACHE_LINE_SIZE,
+				 "offset ok");
+
 /*
  * Total shared-memory state for XLOG.
  */
@@ -568,6 +688,9 @@ static XLogCtlData *XLogCtl = NULL;
 /* a private copy of XLogCtl->Insert.WALInsertLocks, for convenience */
 static WALInsertLockPadded *WALInsertLocks = NULL;

+/* same for XLogCtl->Insert.PrevLinksHash */
+static WALPrevPosLink *PrevLinksHash = NULL;
+
 /*
  * We maintain an image of pg_control in shared memory.
  */
@@ -700,6 +823,19 @@ static void CopyXLogRecordToWAL(int write_len, bool isLogSwitch,
 								XLogRecData *rdata,
 								XLogRecPtr StartPos, XLogRecPtr EndPos,
 								TimeLineID tli);
+
+static void WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos);
+static void WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos);
+static void CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos);
+
+static bool WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val);
+static bool WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static bool WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static void LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos,
+							   XLogRecPtr *PrevPtr);
+static void LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec);
+static XLogRecPtr ReadInsertCurrBytePos(void);
+
 static void ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos,
 									  XLogRecPtr *EndPos, XLogRecPtr *PrevPtr);
 static bool ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos,
@@ -1086,6 +1222,341 @@ XLogInsertRecord(XLogRecData *rdata,
 	return EndPos;
 }

+static pg_attribute_always_inline void
+WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos)
+{
+#if WAL_LINK_64
+	val->CurrPos = StartPos;
+	val->PrevPos = PrevPos;
+#else
+	val->CurrPosHigh = StartPos >> 32;
+	val->CurrPosId = StartPos ^ val->CurrPosHigh;
+	val->PrevSize = StartPos - PrevPos;
+#endif
+}
+
+static pg_attribute_always_inline void
+WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos)
+{
+#if WAL_LINK_64
+	*PrevPos = val.PrevPos;
+#else
+	XLogRecPtr	StartPos = val.CurrPosHigh;
+
+	StartPos ^= (StartPos << 32) | val.CurrPosId;
+	*PrevPos = StartPos - val.PrevSize;
+#endif
+}
+
+static pg_attribute_always_inline void
+CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos)
+{
+	uint32		hash;
+#if PREV_LINKS_HASH_STRATEGY == 3
+	uint32		offset;
+#endif
+
+
+#if WAL_LINK_64
+	hash = murmurhash32(linkval.CurrPos ^ (linkval.CurrPos >> 32));
+#else
+	hash = murmurhash32(linkval.CurrPosId);
+#endif
+
+#if PREV_LINKS_HASH_STRATEGY == 1
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = (pos->pos[0] + 1) % PREV_LINKS_HASH_CAPA;
+	pos->pos[2] = (hash >> 16) % PREV_LINKS_HASH_CAPA;
+	pos->pos[3] = (pos->pos[2] + 2) % PREV_LINKS_HASH_CAPA;
+#else
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = pos->pos[0] ^ 1;
+	pos->pos[2] = pos->pos[0] ^ 2;
+	pos->pos[3] = pos->pos[0] ^ 3;
+#if PREV_LINKS_HASH_STRATEGY == 3
+	/* use multiplication compute 0 <= offset < PREV_LINKS_HASH_CAPA-4 */
+	offset = (hash / PREV_LINKS_HASH_CAPA) * (PREV_LINKS_HASH_CAPA - 4);
+	offset /= UINT32_MAX / PREV_LINKS_HASH_CAPA + 1;
+	/* add start of next bucket */
+	offset += (pos->pos[0] | 3) + 1;
+	/* get position in strictly other bucket */
+	pos->pos[4] = offset % PREV_LINKS_HASH_CAPA;
+	pos->pos[5] = pos->pos[4] ^ 1;
+	pos->pos[6] = pos->pos[4] ^ 2;
+	pos->pos[7] = pos->pos[4] ^ 3;
+#endif
+#endif
+}
+
+/*
+ * Attempt to write into empty link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val)
+{
+#if WAL_LINK_64
+	uint64		empty = WAL_PREV_EMPTY;
+
+	if (pg_atomic_read_u64(&link->PrevPos) != WAL_PREV_EMPTY)
+		return false;
+	if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &empty, val.PrevPos))
+		return false;
+	/* we could ignore concurrent lock of CurrPos */
+	pg_atomic_write_u64(&link->CurrPos, val.CurrPos);
+	return true;
+#else
+	uint32		empty = 0;
+
+	/* first check it read-only */
+	if (pg_atomic_read_u32(&link->PrevSize) != 0)
+		return false;
+	if (!pg_atomic_compare_exchange_u32(&link->PrevSize, &empty, 1))
+		/* someone else occupied the entry */
+		return false;
+
+	pg_atomic_write_u32(&link->CurrPosId, val.CurrPosId);
+	link->CurrPosHigh = val.CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val.PrevSize);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to consume matched link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+
+	if (pg_atomic_read_u64(&link->CurrPos) != val->CurrPos)
+		return false;
+	/* lock against concurrent swapper */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr != val->CurrPos)
+	{
+		/* link was swapped */
+		pg_atomic_write_u64(&link->CurrPos, oldCurr);
+		return false;
+	}
+	val->PrevPos = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, WAL_PREV_EMPTY);
+
+	/*
+	 * concurrent inserter may already reuse this link, so we don't check
+	 * result of compare_exchange
+	 */
+	oldCurr |= 1;
+	pg_atomic_compare_exchange_u64(&link->CurrPos, &oldCurr, 0);
+	return true;
+#else
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId)
+		return false;
+
+	/* Try lock */
+	val->PrevSize = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (val->PrevSize & 1)
+		/* Lock failed */
+		return false;
+
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId ||
+		link->CurrPosHigh != val->CurrPosHigh)
+	{
+		/* unlock with old value */
+		pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+		return false;
+	}
+
+	pg_atomic_write_u32(&link->CurrPosId, 0);
+	link->CurrPosHigh = 0;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, 0);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to swap entry: remember existing link and write our.
+ * It could happen we consume empty entry. Caller will detect it by checking
+ * remembered value.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+	uint64		oldPrev;
+
+	/* lock against concurrent swapper or consumer */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr == 0)
+	{
+		/* link was empty */
+		oldPrev = WAL_PREV_EMPTY;
+		/* but concurrent inserter may concurrently insert */
+		if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &oldPrev, val->PrevPos))
+			return false;		/* concurrent inserter won. It will overwrite
+								 * CurrPos */
+		/* this write acts as unlock */
+		pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+		val->CurrPos = 0;
+		val->PrevPos = WAL_PREV_EMPTY;
+		return true;
+	}
+	oldPrev = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, val->PrevPos);
+	pg_write_barrier();
+	/* write acts as unlock */
+	pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+	val->CurrPos = oldCurr;
+	val->PrevPos = oldPrev;
+	return true;
+#else
+	uint32		oldPrev;
+	uint32		oldCurId;
+	uint32		oldCurHigh;
+
+	/* Attempt to lock entry against concurrent consumer or swapper */
+	oldPrev = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (oldPrev & 1)
+		/* Lock failed */
+		return false;
+
+	oldCurId = pg_atomic_read_u32(&link->CurrPosId);
+	oldCurHigh = link->CurrPosHigh;
+	pg_atomic_write_u32(&link->CurrPosId, val->CurrPosId);
+	link->CurrPosHigh = val->CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+
+	val->CurrPosId = oldCurId;
+	val->CurrPosHigh = oldCurHigh;
+	val->PrevSize = oldPrev;
+	return true;
+#endif
+}
+
+/*
+ * Write new link (EndPos, StartPos) and find PrevPtr for StartPos.
+ *
+ * Links are stored in lock-free Cuckoo based hash-table.
+ * We use mostly-4 way Cuckoo hashing which provides high fill rate without
+ * hard cycle collisions. Also we rely on concurrent consumers of existing
+ * entry, so cycles will be broken in mean time.
+ *
+ * Cuckoo hashing relies on re-insertion for balancing, so we occasionally
+ * swaps entry and try to insert swapped instead of our.
+ */
+static void
+LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos, XLogRecPtr *PrevPtr)
+{
+	SpinDelayStatus spin_stat;
+	WALPrevPosLinkVal lookup;
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups lookup_pos;
+	struct WALPrevLinksLookups insert_pos;
+	uint32		i;
+	uint32		rand = 0;
+	bool		inserted = false;
+	bool		found = false;
+
+	/* pass StartPos second time to set PrevSize = 0 */
+	WALPrevPosLinkValCompose(&lookup, StartPos, StartPos);
+	WALPrevPosLinkValCompose(&insert, EndPos, StartPos);
+
+	CalcCuckooPositions(lookup, &lookup_pos);
+	CalcCuckooPositions(insert, &insert_pos);
+
+	init_local_spin_delay(&spin_stat);
+
+	while (!inserted || !found)
+	{
+		for (i = 0; !found && i < PREV_LINKS_LOOKUPS; i++)
+			found = WALPrevPosLinkConsume(&PrevLinksHash[lookup_pos.pos[i]], &lookup);
+
+		if (inserted)
+		{
+			/*
+			 * we may sleep only after we inserted our value, since other
+			 * backend waits for it
+			 */
+			perform_spin_delay(&spin_stat);
+			goto next;
+		}
+
+		for (i = 0; !inserted && i < PREV_LINKS_LOOKUPS; i++)
+			inserted = WALPrevPosLinkInsert(&PrevLinksHash[insert_pos.pos[i]], insert);
+
+		if (inserted)
+			goto next;
+
+		rand = pg_prng_uint32(&pg_global_prng_state);
+		if (rand % SWAP_ONCE_IN != 0)
+			goto next;
+
+		i = rand / SWAP_ONCE_IN % PREV_LINKS_LOOKUPS;
+		if (!WALPrevPosLinkSwap(&PrevLinksHash[insert_pos.pos[i]], &insert))
+			goto next;
+
+		if (WALLinkEmpty(insert))
+			/* Lucky case: entry become empty and we inserted into */
+			inserted = true;
+		else if (WALLinkSamePos(lookup, insert))
+		{
+			/*
+			 * We occasionally replaced entry we looked for. No need to insert
+			 * it again.
+			 */
+			inserted = true;
+			Assert(!found);
+			found = true;
+			WALLinkCopyPrev(lookup, insert);
+			break;
+		}
+		else
+			CalcCuckooPositions(insert, &insert_pos);
+
+next:
+		pg_spin_delay();
+		pg_read_barrier();
+	}
+
+	WALPrevPosLinkValGetPrev(lookup, PrevPtr);
+}
+
+static pg_attribute_always_inline void
+LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec)
+{
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups insert_pos;
+
+	WALPrevPosLinkValCompose(&insert, EndOfLog, LastRec);
+	CalcCuckooPositions(insert, &insert_pos);
+#if WAL_LINK_64
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].CurrPos, insert.CurrPos);
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].PrevPos, insert.PrevPos);
+#else
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].CurrPosId, insert.CurrPosId);
+	PrevLinksHash[insert_pos.pos[0]].CurrPosHigh = insert.CurrPosHigh;
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].PrevSize, insert.PrevSize);
+#endif
+}
+
+static pg_attribute_always_inline XLogRecPtr
+ReadInsertCurrBytePos(void)
+{
+	return pg_atomic_read_u64(&XLogCtl->Insert.CurrBytePos);
+}
+
 /*
  * Reserves the right amount of space for a record of given size from the WAL.
  * *StartPos is set to the beginning of the reserved section, *EndPos to
@@ -1118,25 +1589,9 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
 	/* All (non xlog-switch) records should contain data. */
 	Assert(size > SizeOfXLogRecord);

-	/*
-	 * The duration the spinlock needs to be held is minimized by minimizing
-	 * the calculations that have to be done while holding the lock. The
-	 * current tip of reserved WAL is kept in CurrBytePos, as a byte position
-	 * that only counts "usable" bytes in WAL, that is, it excludes all WAL
-	 * page headers. The mapping between "usable" byte positions and physical
-	 * positions (XLogRecPtrs) can be done outside the locked region, and
-	 * because the usable byte position doesn't include any headers, reserving
-	 * X bytes from WAL is almost as simple as "CurrBytePos += X".
-	 */
-	SpinLockAcquire(&Insert->insertpos_lck);
-
-	startbytepos = Insert->CurrBytePos;
+	startbytepos = pg_atomic_fetch_add_u64(&Insert->CurrBytePos, size);
 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;
-
-	SpinLockRelease(&Insert->insertpos_lck);
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);
@@ -1172,26 +1627,24 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 	uint32		segleft;

 	/*
-	 * These calculations are a bit heavy-weight to be done while holding a
-	 * spinlock, but since we're holding all the WAL insertion locks, there
-	 * are no other inserters competing for it. GetXLogInsertRecPtr() does
-	 * compete for it, but that's not called very frequently.
+	 * Currently ReserveXLogInsertLocation is protected with exclusive
+	 * insertion lock, so there is no contention against CurrBytePos, But we
+	 * still do CAS loop for being uniform.
+	 *
+	 * Probably we'll get rid of exclusive lock in a future.
 	 */
-	SpinLockAcquire(&Insert->insertpos_lck);

-	startbytepos = Insert->CurrBytePos;
+repeat:
+	startbytepos = pg_atomic_read_u64(&Insert->CurrBytePos);

 	ptr = XLogBytePosToEndRecPtr(startbytepos);
 	if (XLogSegmentOffset(ptr, wal_segment_size) == 0)
 	{
-		SpinLockRelease(&Insert->insertpos_lck);
 		*EndPos = *StartPos = ptr;
 		return false;
 	}

 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-
 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);

@@ -1202,10 +1655,19 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 		*EndPos += segleft;
 		endbytepos = XLogRecPtrToBytePos(*EndPos);
 	}
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;

-	SpinLockRelease(&Insert->insertpos_lck);
+	if (!pg_atomic_compare_exchange_u64(&Insert->CurrBytePos,
+										&startbytepos,
+										endbytepos))
+	{
+		/*
+		 * Don't use spin delay here: perform_spin_delay primary case is for
+		 * solving single core contention. But on single core we will succeed
+		 * on the next attempt.
+		 */
+		goto repeat;
+	}
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*PrevPtr = XLogBytePosToRecPtr(prevbytepos);

@@ -1507,7 +1969,6 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 	XLogRecPtr	inserted;
 	XLogRecPtr	reservedUpto;
 	XLogRecPtr	finishedUpto;
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	int			i;

 	if (MyProc == NULL)
@@ -1522,9 +1983,7 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 		return inserted;

 	/* Read the current insert position */
-	SpinLockAcquire(&Insert->insertpos_lck);
-	bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
+	bytepos = ReadInsertCurrBytePos();
 	reservedUpto = XLogBytePosToEndRecPtr(bytepos);

 	/*
@@ -4898,6 +5357,8 @@ XLOGShmemSize(void)

 	/* WAL insertion locks, plus alignment */
 	size = add_size(size, mul_size(sizeof(WALInsertLockPadded), NUM_XLOGINSERT_LOCKS + 1));
+	/* prevlinkshash, abuses alignment of WAL insertion locks. */
+	size = add_size(size, mul_size(sizeof(WALPrevPosLink), PREV_LINKS_HASH_CAPA));
 	/* xlblocks array */
 	size = add_size(size, mul_size(sizeof(pg_atomic_uint64), XLOGbuffers));
 	/* extra alignment padding for XLOG I/O buffers */
@@ -4999,6 +5460,9 @@ XLOGShmemInit(void)
 		WALInsertLocks[i].l.lastImportantAt = InvalidXLogRecPtr;
 	}

+	PrevLinksHash = XLogCtl->Insert.PrevLinksHash = (WALPrevPosLink *) allocptr;
+	allocptr += sizeof(WALPrevPosLink) * PREV_LINKS_HASH_CAPA;
+
 	/*
 	 * Align the start of the page buffers to a full xlog block size boundary.
 	 * This simplifies some calculations in XLOG insertion. It is also
@@ -5017,12 +5481,24 @@ XLOGShmemInit(void)
 	XLogCtl->InstallXLogFileSegmentActive = false;
 	XLogCtl->WalWriterSleeping = false;

-	SpinLockInit(&XLogCtl->Insert.insertpos_lck);
 	SpinLockInit(&XLogCtl->info_lck);
 	pg_atomic_init_u64(&XLogCtl->logInsertResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logWriteResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logFlushResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->unloggedLSN, InvalidXLogRecPtr);
+
+	pg_atomic_init_u64(&XLogCtl->Insert.CurrBytePos, 0);
+
+	for (i = 0; i < PREV_LINKS_HASH_CAPA; i++)
+	{
+#if WAL_LINK_64
+		pg_atomic_init_u64(&PrevLinksHash[i].CurrPos, 0);
+		pg_atomic_init_u64(&PrevLinksHash[i].PrevPos, WAL_PREV_EMPTY);
+#else
+		pg_atomic_init_u32(&PrevLinksHash[i].CurrPosId, 0);
+		pg_atomic_init_u32(&PrevLinksHash[i].PrevSize, 0);
+#endif
+	}
 }

 /*
@@ -6018,8 +6494,13 @@ StartupXLOG(void)
 	 * previous incarnation.
 	 */
 	Insert = &XLogCtl->Insert;
-	Insert->PrevBytePos = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
-	Insert->CurrBytePos = XLogRecPtrToBytePos(EndOfLog);
+	{
+		XLogRecPtr	endOfLog = XLogRecPtrToBytePos(EndOfLog);
+		XLogRecPtr	lastRec = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
+
+		pg_atomic_write_u64(&Insert->CurrBytePos, endOfLog);
+		LinkStartPrevPos(endOfLog, lastRec);
+	}

 	/*
 	 * Tricky point here: lastPage contains the *last* block that the LastRec
@@ -7005,7 +7486,7 @@ CreateCheckPoint(int flags)

 	if (shutdown)
 	{
-		XLogRecPtr	curInsert = XLogBytePosToRecPtr(Insert->CurrBytePos);
+		XLogRecPtr	curInsert = XLogBytePosToRecPtr(ReadInsertCurrBytePos());

 		/*
 		 * Compute new REDO record ptr = location of next XLOG record.
@@ -9434,14 +9915,7 @@ register_persistent_abort_backup_handler(void)
 XLogRecPtr
 GetXLogInsertRecPtr(void)
 {
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
-	uint64		current_bytepos;
-
-	SpinLockAcquire(&Insert->insertpos_lck);
-	current_bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
-
-	return XLogBytePosToRecPtr(current_bytepos);
+	return XLogBytePosToRecPtr(ReadInsertCurrBytePos());
 }

 /*
diff --git a/src/tools/pgindent/typedefs.list b/src/tools/pgindent/typedefs.list
index d5aa5c295ae..118aa487adf 100644
--- a/src/tools/pgindent/typedefs.list
+++ b/src/tools/pgindent/typedefs.list
@@ -3123,6 +3123,8 @@ WALAvailability
 WALInsertLock
 WALInsertLockPadded
 WALOpenSegment
+WALPrevPosLink
+WALPrevPosLinkVal
 WALReadError
 WALSegmentCloseCB
 WALSegmentContext
--
2.43.0

From 8cc3f9c7d629ce7fedd15f224df7566fd723cb06 Mon Sep 17 00:00:00 2001
From: Yura Sokolov <y.sokolov@postgrespro.ru>
Date: Sun, 19 Jan 2025 17:40:28 +0300
Subject: [PATCH v5] Lock-free XLog Reservation using lock-free hash-table

Removed PrevBytePos to eliminate lock contention, allowing atomic updates
to CurrBytePos. Use lock-free hash-table based on 4-way Cuckoo Hashing
to store link to PrevBytePos.
---
 src/backend/access/transam/xlog.c | 585 +++++++++++++++++++++++++++---
 src/tools/pgindent/typedefs.list  |   2 +
 2 files changed, 532 insertions(+), 55 deletions(-)

diff --git a/src/backend/access/transam/xlog.c b/src/backend/access/transam/xlog.c
index 4b6c694a3f7..82d6dc0732c 100644
--- a/src/backend/access/transam/xlog.c
+++ b/src/backend/access/transam/xlog.c
@@ -68,6 +68,8 @@
 #include "catalog/pg_database.h"
 #include "common/controldata_utils.h"
 #include "common/file_utils.h"
+#include "common/hashfn.h"
+#include "common/pg_prng.h"
 #include "executor/instrument.h"
 #include "miscadmin.h"
 #include "pg_trace.h"
@@ -384,6 +386,94 @@ typedef union WALInsertLockPadded
 	char		pad[PG_CACHE_LINE_SIZE];
 } WALInsertLockPadded;

+/* #define WAL_LINK_64 0 */
+#ifndef WAL_LINK_64
+#ifdef PG_HAVE_ATOMIC_U64_SIMULATION
+#define WAL_LINK_64 0
+#else
+#define WAL_LINK_64 1
+#endif
+#endif
+
+/*
+ * It links current position with previous one.
+ * - CurrPosId is (CurrBytePos ^ (CurrBytePos>>32))
+ *   Since CurrBytePos grows monotonically and it is aligned to MAXALIGN,
+ *   CurrPosId correctly identifies CurrBytePos for at least 4*2^32 = 32GB of
+ *   WAL logs.
+ * - CurrPosHigh is (CurrBytePos>>32), it is stored for strong uniqueness check.
+ * - PrevSize is difference between CurrBytePos and PrevBytePos
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	uint64		CurrPos;
+	uint64		PrevPos;
+#define WAL_PREV_EMPTY (~((uint64)0))
+#define WALLinkEmpty(l) ((l).PrevPos == WAL_PREV_EMPTY)
+#define WALLinkSamePos(a, b) ((a).CurrPos == (b).CurrPos)
+#define WALLinkCopyPrev(a, b) do {(a).PrevPos = (b).PrevPos;} while(0)
+#else
+	uint32		CurrPosId;
+	uint32		CurrPosHigh;
+	uint32		PrevSize;
+#define WALLinkEmpty(l) ((l).PrevSize == 0)
+#define WALLinkSamePos(a, b) ((a).CurrPosId == (b).CurrPosId && (a).CurrPosHigh == (b).CurrPosHigh)
+#define WALLinkCopyPrev(a, b) do {(a).PrevSize = (b).PrevSize;} while(0)
+#endif
+} WALPrevPosLinkVal;
+
+/*
+ * This is an element of lock-free hash-table.
+ * In 32 bit mode PrevSize's lowest bit is used as a lock, relying on fact it is MAXALIGN-ed.
+ * In 64 bit mode lock protocol is more complex.
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	pg_atomic_uint64 CurrPos;
+	pg_atomic_uint64 PrevPos;
+#else
+	pg_atomic_uint32 CurrPosId;
+	uint32		CurrPosHigh;
+	pg_atomic_uint32 PrevSize;
+	uint32		pad;			/* to align to 16 bytes */
+#endif
+} WALPrevPosLink;
+
+StaticAssertDecl(sizeof(WALPrevPosLink) == 16, "WALPrevPosLink should be 16 bytes");
+
+#define PREV_LINKS_HASH_CAPA (NUM_XLOGINSERT_LOCKS * 2)
+StaticAssertDecl(!(PREV_LINKS_HASH_CAPA & (PREV_LINKS_HASH_CAPA - 1)),
+				 "PREV_LINKS_HASH_CAPA should be power of two");
+StaticAssertDecl(PREV_LINKS_HASH_CAPA < UINT16_MAX,
+				 "PREV_LINKS_HASH_CAPA is too large");
+
+/*-----------
+ * PREV_LINKS_HASH_STRATEGY - the way slots are chosen in hash table
+ *   1 - 4 positions h1,h1+1,h2,h2+2 - it guarantees at least 3 distinct points,
+ *     but may spread at 4 cache lines.
+ *   2 - 4 positions h,h^1,h^2,h^3 - 4 points in single cache line.
+ *   3 - 8 positions h1,h1^1,h1^2,h1^4,h2,h2^1,h2^2,h2^3 - 8 distinct points in
+ *     in two cache lines.
+ */
+#ifndef PREV_LINKS_HASH_STRATEGY
+#define PREV_LINKS_HASH_STRATEGY 3
+#endif
+
+#if PREV_LINKS_HASH_STRATEGY <= 2
+#define PREV_LINKS_LOOKUPS 4
+#else
+#define PREV_LINKS_LOOKUPS 8
+#endif
+
+struct WALPrevLinksLookups
+{
+	uint16		pos[PREV_LINKS_LOOKUPS];
+};
+
+#define SWAP_ONCE_IN 128
+
 /*
  * Session status of running backup, used for sanity checks in SQL-callable
  * functions to start and stop backups.
@@ -395,17 +485,18 @@ static SessionBackupState sessionBackupState = SESSION_BACKUP_NONE;
  */
 typedef struct XLogCtlInsert
 {
-	slock_t		insertpos_lck;	/* protects CurrBytePos and PrevBytePos */
-
 	/*
 	 * CurrBytePos is the end of reserved WAL. The next record will be
-	 * inserted at that position. PrevBytePos is the start position of the
-	 * previously inserted (or rather, reserved) record - it is copied to the
-	 * prev-link of the next record. These are stored as "usable byte
-	 * positions" rather than XLogRecPtrs (see XLogBytePosToRecPtr()).
+	 * inserted at that position.
+	 *
+	 * The start position of the previously inserted (or rather, reserved)
+	 * record (it is copied to the prev-link of the next record) will be
+	 * stored in PrevLinksHash.
+	 *
+	 * These are stored as "usable byte positions" rather than XLogRecPtrs
+	 * (see XLogBytePosToRecPtr()).
 	 */
-	uint64		CurrBytePos;
-	uint64		PrevBytePos;
+	pg_atomic_uint64 CurrBytePos;

 	/*
 	 * Make sure the above heavily-contended spinlock and byte positions are
@@ -442,8 +533,37 @@ typedef struct XLogCtlInsert
 	 * WAL insertion locks.
 	 */
 	WALInsertLockPadded *WALInsertLocks;
+
+	/*
+	 * PrevLinksHash is a lock-free hash table based on Cuckoo algorithm.
+	 *
+	 * With default PREV_LINKS_HASH_STRATEGY == 1 it is mostly 4 way: for
+	 * every element computed two positions h1, h2, and neighbour h1+1 and
+	 * h2+2 are used as well. This way even on collision we have 3 distinct
+	 * position, which provide us ~75% fill rate without unsolvable cycles
+	 * (due to Cuckoo's theory). But chosen slots may be in 4 distinct
+	 * cache-lines.
+	 *
+	 * With PREV_LINKS_HASH_STRATEGY == 3 it takes two buckets 4 elements each
+	 * - 8 positions in total, but guaranteed to be in two cache lines. It
+	 * provides very high fill rate - upto 90%.
+	 *
+	 * With PREV_LINKS_HASH_STRATEGY == 2 it takes only one bucket with 4
+	 * elements. Strictly speaking it is not Cuckoo-hashing, but should work
+	 * for our case.
+	 *
+	 * Certainly, we rely on the fact we will delete elements with same speed
+	 * as we add them, and even unsolvable cycles will be destroyed soon by
+	 * concurrent deletions.
+	 */
+	WALPrevPosLink *PrevLinksHash;
+
 } XLogCtlInsert;

+StaticAssertDecl(offsetof(XLogCtlInsert, RedoRecPtr) / PG_CACHE_LINE_SIZE !=
+				 offsetof(XLogCtlInsert, CurrBytePos) / PG_CACHE_LINE_SIZE,
+				 "offset ok");
+
 /*
  * Total shared-memory state for XLOG.
  */
@@ -568,6 +688,9 @@ static XLogCtlData *XLogCtl = NULL;
 /* a private copy of XLogCtl->Insert.WALInsertLocks, for convenience */
 static WALInsertLockPadded *WALInsertLocks = NULL;

+/* same for XLogCtl->Insert.PrevLinksHash */
+static WALPrevPosLink *PrevLinksHash = NULL;
+
 /*
  * We maintain an image of pg_control in shared memory.
  */
@@ -700,6 +823,19 @@ static void CopyXLogRecordToWAL(int write_len, bool isLogSwitch,
 								XLogRecData *rdata,
 								XLogRecPtr StartPos, XLogRecPtr EndPos,
 								TimeLineID tli);
+
+static void WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos);
+static void WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos);
+static void CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos);
+
+static bool WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val);
+static bool WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static bool WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static void LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos,
+							   XLogRecPtr *PrevPtr);
+static void LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec);
+static XLogRecPtr ReadInsertCurrBytePos(void);
+
 static void ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos,
 									  XLogRecPtr *EndPos, XLogRecPtr *PrevPtr);
 static bool ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos,
@@ -1086,6 +1222,341 @@ XLogInsertRecord(XLogRecData *rdata,
 	return EndPos;
 }

+static pg_attribute_always_inline void
+WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos)
+{
+#if WAL_LINK_64
+	val->CurrPos = StartPos;
+	val->PrevPos = PrevPos;
+#else
+	val->CurrPosHigh = StartPos >> 32;
+	val->CurrPosId = StartPos ^ val->CurrPosHigh;
+	val->PrevSize = StartPos - PrevPos;
+#endif
+}
+
+static pg_attribute_always_inline void
+WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos)
+{
+#if WAL_LINK_64
+	*PrevPos = val.PrevPos;
+#else
+	XLogRecPtr	StartPos = val.CurrPosHigh;
+
+	StartPos ^= (StartPos << 32) | val.CurrPosId;
+	*PrevPos = StartPos - val.PrevSize;
+#endif
+}
+
+static pg_attribute_always_inline void
+CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos)
+{
+	uint32		hash;
+#if PREV_LINKS_HASH_STRATEGY == 3
+	uint32		offset;
+#endif
+
+
+#if WAL_LINK_64
+	hash = murmurhash32(linkval.CurrPos ^ (linkval.CurrPos >> 32));
+#else
+	hash = murmurhash32(linkval.CurrPosId);
+#endif
+
+#if PREV_LINKS_HASH_STRATEGY == 1
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = (pos->pos[0] + 1) % PREV_LINKS_HASH_CAPA;
+	pos->pos[2] = (hash >> 16) % PREV_LINKS_HASH_CAPA;
+	pos->pos[3] = (pos->pos[2] + 2) % PREV_LINKS_HASH_CAPA;
+#else
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = pos->pos[0] ^ 1;
+	pos->pos[2] = pos->pos[0] ^ 2;
+	pos->pos[3] = pos->pos[0] ^ 3;
+#if PREV_LINKS_HASH_STRATEGY == 3
+	/* use multiplication compute 0 <= offset < PREV_LINKS_HASH_CAPA-4 */
+	offset = (hash / PREV_LINKS_HASH_CAPA) * (PREV_LINKS_HASH_CAPA - 4);
+	offset /= UINT32_MAX / PREV_LINKS_HASH_CAPA + 1;
+	/* add start of next bucket */
+	offset += (pos->pos[0] | 3) + 1;
+	/* get position in strictly other bucket */
+	pos->pos[4] = offset % PREV_LINKS_HASH_CAPA;
+	pos->pos[5] = pos->pos[4] ^ 1;
+	pos->pos[6] = pos->pos[4] ^ 2;
+	pos->pos[7] = pos->pos[4] ^ 3;
+#endif
+#endif
+}
+
+/*
+ * Attempt to write into empty link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val)
+{
+#if WAL_LINK_64
+	uint64		empty = WAL_PREV_EMPTY;
+
+	if (pg_atomic_read_u64(&link->PrevPos) != WAL_PREV_EMPTY)
+		return false;
+	if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &empty, val.PrevPos))
+		return false;
+	/* we could ignore concurrent lock of CurrPos */
+	pg_atomic_write_u64(&link->CurrPos, val.CurrPos);
+	return true;
+#else
+	uint32		empty = 0;
+
+	/* first check it read-only */
+	if (pg_atomic_read_u32(&link->PrevSize) != 0)
+		return false;
+	if (!pg_atomic_compare_exchange_u32(&link->PrevSize, &empty, 1))
+		/* someone else occupied the entry */
+		return false;
+
+	pg_atomic_write_u32(&link->CurrPosId, val.CurrPosId);
+	link->CurrPosHigh = val.CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val.PrevSize);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to consume matched link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+
+	if (pg_atomic_read_u64(&link->CurrPos) != val->CurrPos)
+		return false;
+	/* lock against concurrent swapper */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr != val->CurrPos)
+	{
+		/* link was swapped */
+		pg_atomic_write_u64(&link->CurrPos, oldCurr);
+		return false;
+	}
+	val->PrevPos = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, WAL_PREV_EMPTY);
+
+	/*
+	 * concurrent inserter may already reuse this link, so we don't check
+	 * result of compare_exchange
+	 */
+	oldCurr |= 1;
+	pg_atomic_compare_exchange_u64(&link->CurrPos, &oldCurr, 0);
+	return true;
+#else
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId)
+		return false;
+
+	/* Try lock */
+	val->PrevSize = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (val->PrevSize & 1)
+		/* Lock failed */
+		return false;
+
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId ||
+		link->CurrPosHigh != val->CurrPosHigh)
+	{
+		/* unlock with old value */
+		pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+		return false;
+	}
+
+	pg_atomic_write_u32(&link->CurrPosId, 0);
+	link->CurrPosHigh = 0;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, 0);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to swap entry: remember existing link and write our.
+ * It could happen we consume empty entry. Caller will detect it by checking
+ * remembered value.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+	uint64		oldPrev;
+
+	/* lock against concurrent swapper or consumer */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr == 0)
+	{
+		/* link was empty */
+		oldPrev = WAL_PREV_EMPTY;
+		/* but concurrent inserter may concurrently insert */
+		if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &oldPrev, val->PrevPos))
+			return false;		/* concurrent inserter won. It will overwrite
+								 * CurrPos */
+		/* this write acts as unlock */
+		pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+		val->CurrPos = 0;
+		val->PrevPos = WAL_PREV_EMPTY;
+		return true;
+	}
+	oldPrev = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, val->PrevPos);
+	pg_write_barrier();
+	/* write acts as unlock */
+	pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+	val->CurrPos = oldCurr;
+	val->PrevPos = oldPrev;
+	return true;
+#else
+	uint32		oldPrev;
+	uint32		oldCurId;
+	uint32		oldCurHigh;
+
+	/* Attempt to lock entry against concurrent consumer or swapper */
+	oldPrev = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (oldPrev & 1)
+		/* Lock failed */
+		return false;
+
+	oldCurId = pg_atomic_read_u32(&link->CurrPosId);
+	oldCurHigh = link->CurrPosHigh;
+	pg_atomic_write_u32(&link->CurrPosId, val->CurrPosId);
+	link->CurrPosHigh = val->CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+
+	val->CurrPosId = oldCurId;
+	val->CurrPosHigh = oldCurHigh;
+	val->PrevSize = oldPrev;
+	return true;
+#endif
+}
+
+/*
+ * Write new link (EndPos, StartPos) and find PrevPtr for StartPos.
+ *
+ * Links are stored in lock-free Cuckoo based hash-table.
+ * We use mostly-4 way Cuckoo hashing which provides high fill rate without
+ * hard cycle collisions. Also we rely on concurrent consumers of existing
+ * entry, so cycles will be broken in mean time.
+ *
+ * Cuckoo hashing relies on re-insertion for balancing, so we occasionally
+ * swaps entry and try to insert swapped instead of our.
+ */
+static void
+LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos, XLogRecPtr *PrevPtr)
+{
+	SpinDelayStatus spin_stat;
+	WALPrevPosLinkVal lookup;
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups lookup_pos;
+	struct WALPrevLinksLookups insert_pos;
+	uint32		i;
+	uint32		rand = 0;
+	bool		inserted = false;
+	bool		found = false;
+
+	/* pass StartPos second time to set PrevSize = 0 */
+	WALPrevPosLinkValCompose(&lookup, StartPos, StartPos);
+	WALPrevPosLinkValCompose(&insert, EndPos, StartPos);
+
+	CalcCuckooPositions(lookup, &lookup_pos);
+	CalcCuckooPositions(insert, &insert_pos);
+
+	init_local_spin_delay(&spin_stat);
+
+	while (!inserted || !found)
+	{
+		for (i = 0; !found && i < PREV_LINKS_LOOKUPS; i++)
+			found = WALPrevPosLinkConsume(&PrevLinksHash[lookup_pos.pos[i]], &lookup);
+
+		if (inserted)
+		{
+			/*
+			 * we may sleep only after we inserted our value, since other
+			 * backend waits for it
+			 */
+			perform_spin_delay(&spin_stat);
+			goto next;
+		}
+
+		for (i = 0; !inserted && i < PREV_LINKS_LOOKUPS; i++)
+			inserted = WALPrevPosLinkInsert(&PrevLinksHash[insert_pos.pos[i]], insert);
+
+		if (inserted)
+			goto next;
+
+		rand = pg_prng_uint32(&pg_global_prng_state);
+		if (rand % SWAP_ONCE_IN != 0)
+			goto next;
+
+		i = rand / SWAP_ONCE_IN % PREV_LINKS_LOOKUPS;
+		if (!WALPrevPosLinkSwap(&PrevLinksHash[insert_pos.pos[i]], &insert))
+			goto next;
+
+		if (WALLinkEmpty(insert))
+			/* Lucky case: entry become empty and we inserted into */
+			inserted = true;
+		else if (WALLinkSamePos(lookup, insert))
+		{
+			/*
+			 * We occasionally replaced entry we looked for. No need to insert
+			 * it again.
+			 */
+			inserted = true;
+			Assert(!found);
+			found = true;
+			WALLinkCopyPrev(lookup, insert);
+			break;
+		}
+		else
+			CalcCuckooPositions(insert, &insert_pos);
+
+next:
+		pg_spin_delay();
+		pg_read_barrier();
+	}
+
+	WALPrevPosLinkValGetPrev(lookup, PrevPtr);
+}
+
+static pg_attribute_always_inline void
+LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec)
+{
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups insert_pos;
+
+	WALPrevPosLinkValCompose(&insert, EndOfLog, LastRec);
+	CalcCuckooPositions(insert, &insert_pos);
+#if WAL_LINK_64
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].CurrPos, insert.CurrPos);
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].PrevPos, insert.PrevPos);
+#else
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].CurrPosId, insert.CurrPosId);
+	PrevLinksHash[insert_pos.pos[0]].CurrPosHigh = insert.CurrPosHigh;
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].PrevSize, insert.PrevSize);
+#endif
+}
+
+static pg_attribute_always_inline XLogRecPtr
+ReadInsertCurrBytePos(void)
+{
+	return pg_atomic_read_u64(&XLogCtl->Insert.CurrBytePos);
+}
+
 /*
  * Reserves the right amount of space for a record of given size from the WAL.
  * *StartPos is set to the beginning of the reserved section, *EndPos to
@@ -1118,25 +1589,9 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
 	/* All (non xlog-switch) records should contain data. */
 	Assert(size > SizeOfXLogRecord);

-	/*
-	 * The duration the spinlock needs to be held is minimized by minimizing
-	 * the calculations that have to be done while holding the lock. The
-	 * current tip of reserved WAL is kept in CurrBytePos, as a byte position
-	 * that only counts "usable" bytes in WAL, that is, it excludes all WAL
-	 * page headers. The mapping between "usable" byte positions and physical
-	 * positions (XLogRecPtrs) can be done outside the locked region, and
-	 * because the usable byte position doesn't include any headers, reserving
-	 * X bytes from WAL is almost as simple as "CurrBytePos += X".
-	 */
-	SpinLockAcquire(&Insert->insertpos_lck);
-
-	startbytepos = Insert->CurrBytePos;
+	startbytepos = pg_atomic_fetch_add_u64(&Insert->CurrBytePos, size);
 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;
-
-	SpinLockRelease(&Insert->insertpos_lck);
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);
@@ -1172,26 +1627,24 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 	uint32		segleft;

 	/*
-	 * These calculations are a bit heavy-weight to be done while holding a
-	 * spinlock, but since we're holding all the WAL insertion locks, there
-	 * are no other inserters competing for it. GetXLogInsertRecPtr() does
-	 * compete for it, but that's not called very frequently.
+	 * Currently ReserveXLogInsertLocation is protected with exclusive
+	 * insertion lock, so there is no contention against CurrBytePos, But we
+	 * still do CAS loop for being uniform.
+	 *
+	 * Probably we'll get rid of exclusive lock in a future.
 	 */
-	SpinLockAcquire(&Insert->insertpos_lck);

-	startbytepos = Insert->CurrBytePos;
+repeat:
+	startbytepos = pg_atomic_read_u64(&Insert->CurrBytePos);

 	ptr = XLogBytePosToEndRecPtr(startbytepos);
 	if (XLogSegmentOffset(ptr, wal_segment_size) == 0)
 	{
-		SpinLockRelease(&Insert->insertpos_lck);
 		*EndPos = *StartPos = ptr;
 		return false;
 	}

 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-
 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);

@@ -1202,10 +1655,19 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 		*EndPos += segleft;
 		endbytepos = XLogRecPtrToBytePos(*EndPos);
 	}
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;

-	SpinLockRelease(&Insert->insertpos_lck);
+	if (!pg_atomic_compare_exchange_u64(&Insert->CurrBytePos,
+										&startbytepos,
+										endbytepos))
+	{
+		/*
+		 * Don't use spin delay here: perform_spin_delay primary case is for
+		 * solving single core contention. But on single core we will succeed
+		 * on the next attempt.
+		 */
+		goto repeat;
+	}
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*PrevPtr = XLogBytePosToRecPtr(prevbytepos);

@@ -1507,7 +1969,6 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 	XLogRecPtr	inserted;
 	XLogRecPtr	reservedUpto;
 	XLogRecPtr	finishedUpto;
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	int			i;

 	if (MyProc == NULL)
@@ -1522,9 +1983,7 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 		return inserted;

 	/* Read the current insert position */
-	SpinLockAcquire(&Insert->insertpos_lck);
-	bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
+	bytepos = ReadInsertCurrBytePos();
 	reservedUpto = XLogBytePosToEndRecPtr(bytepos);

 	/*
@@ -4944,6 +5403,8 @@ XLOGShmemSize(void)

 	/* WAL insertion locks, plus alignment */
 	size = add_size(size, mul_size(sizeof(WALInsertLockPadded), NUM_XLOGINSERT_LOCKS + 1));
+	/* prevlinkshash, abuses alignment of WAL insertion locks. */
+	size = add_size(size, mul_size(sizeof(WALPrevPosLink), PREV_LINKS_HASH_CAPA));
 	/* xlblocks array */
 	size = add_size(size, mul_size(sizeof(pg_atomic_uint64), XLOGbuffers));
 	/* extra alignment padding for XLOG I/O buffers */
@@ -4998,8 +5459,9 @@ XLOGShmemInit(void)
 		/* both should be present or neither */
 		Assert(foundCFile && foundXLog);

-		/* Initialize local copy of WALInsertLocks */
+		/* Initialize local copy of WALInsertLocks and PrevLinksHash */
 		WALInsertLocks = XLogCtl->Insert.WALInsertLocks;
+		PrevLinksHash = XLogCtl->Insert.PrevLinksHash;

 		if (localControlFile)
 			pfree(localControlFile);
@@ -5045,6 +5507,9 @@ XLOGShmemInit(void)
 		WALInsertLocks[i].l.lastImportantAt = InvalidXLogRecPtr;
 	}

+	PrevLinksHash = XLogCtl->Insert.PrevLinksHash = (WALPrevPosLink *) allocptr;
+	allocptr += sizeof(WALPrevPosLink) * PREV_LINKS_HASH_CAPA;
+
 	/*
 	 * Align the start of the page buffers to a full xlog block size boundary.
 	 * This simplifies some calculations in XLOG insertion. It is also
@@ -5063,12 +5528,24 @@ XLOGShmemInit(void)
 	XLogCtl->InstallXLogFileSegmentActive = false;
 	XLogCtl->WalWriterSleeping = false;

-	SpinLockInit(&XLogCtl->Insert.insertpos_lck);
 	SpinLockInit(&XLogCtl->info_lck);
 	pg_atomic_init_u64(&XLogCtl->logInsertResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logWriteResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logFlushResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->unloggedLSN, InvalidXLogRecPtr);
+
+	pg_atomic_init_u64(&XLogCtl->Insert.CurrBytePos, 0);
+
+	for (i = 0; i < PREV_LINKS_HASH_CAPA; i++)
+	{
+#if WAL_LINK_64
+		pg_atomic_init_u64(&PrevLinksHash[i].CurrPos, 0);
+		pg_atomic_init_u64(&PrevLinksHash[i].PrevPos, WAL_PREV_EMPTY);
+#else
+		pg_atomic_init_u32(&PrevLinksHash[i].CurrPosId, 0);
+		pg_atomic_init_u32(&PrevLinksHash[i].PrevSize, 0);
+#endif
+	}
 }

 /*
@@ -6064,8 +6541,13 @@ StartupXLOG(void)
 	 * previous incarnation.
 	 */
 	Insert = &XLogCtl->Insert;
-	Insert->PrevBytePos = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
-	Insert->CurrBytePos = XLogRecPtrToBytePos(EndOfLog);
+	{
+		XLogRecPtr	endOfLog = XLogRecPtrToBytePos(EndOfLog);
+		XLogRecPtr	lastRec = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
+
+		pg_atomic_write_u64(&Insert->CurrBytePos, endOfLog);
+		LinkStartPrevPos(endOfLog, lastRec);
+	}

 	/*
 	 * Tricky point here: lastPage contains the *last* block that the LastRec
@@ -7051,7 +7533,7 @@ CreateCheckPoint(int flags)

 	if (shutdown)
 	{
-		XLogRecPtr	curInsert = XLogBytePosToRecPtr(Insert->CurrBytePos);
+		XLogRecPtr	curInsert = XLogBytePosToRecPtr(ReadInsertCurrBytePos());

 		/*
 		 * Compute new REDO record ptr = location of next XLOG record.
@@ -9469,14 +9951,7 @@ register_persistent_abort_backup_handler(void)
 XLogRecPtr
 GetXLogInsertRecPtr(void)
 {
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
-	uint64		current_bytepos;
-
-	SpinLockAcquire(&Insert->insertpos_lck);
-	current_bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
-
-	return XLogBytePosToRecPtr(current_bytepos);
+	return XLogBytePosToRecPtr(ReadInsertCurrBytePos());
 }

 /*
diff --git a/src/tools/pgindent/typedefs.list b/src/tools/pgindent/typedefs.list
index bfa276d2d35..54f8a1e0d16 100644
--- a/src/tools/pgindent/typedefs.list
+++ b/src/tools/pgindent/typedefs.list
@@ -3180,6 +3180,8 @@ WALAvailability
 WALInsertLock
 WALInsertLockPadded
 WALOpenSegment
+WALPrevPosLink
+WALPrevPosLinkVal
 WALReadError
 WALSegmentCloseCB
 WALSegmentContext
--
2.43.0

From 4ea25d6feb655a072d1e9f40a547dc6aeab762ac Mon Sep 17 00:00:00 2001
From: Yura Sokolov <y.sokolov@postgrespro.ru>
Date: Sun, 19 Jan 2025 17:40:28 +0300
Subject: [PATCH v6] Lock-free XLog Reservation using lock-free hash-table

Removed PrevBytePos to eliminate lock contention, allowing atomic updates
to CurrBytePos. Use lock-free hash-table based on 4-way Cuckoo Hashing
to store link to PrevBytePos.
---
 src/backend/access/transam/xlog.c | 585 +++++++++++++++++++++++++++---
 src/tools/pgindent/typedefs.list  |   2 +
 2 files changed, 532 insertions(+), 55 deletions(-)

diff --git a/src/backend/access/transam/xlog.c b/src/backend/access/transam/xlog.c
index 2d4c346473b..0dff9addfe1 100644
--- a/src/backend/access/transam/xlog.c
+++ b/src/backend/access/transam/xlog.c
@@ -68,6 +68,8 @@
 #include "catalog/pg_database.h"
 #include "common/controldata_utils.h"
 #include "common/file_utils.h"
+#include "common/hashfn.h"
+#include "common/pg_prng.h"
 #include "executor/instrument.h"
 #include "miscadmin.h"
 #include "pg_trace.h"
@@ -379,6 +381,94 @@ typedef union WALInsertLockPadded
 	char		pad[PG_CACHE_LINE_SIZE];
 } WALInsertLockPadded;

+/* #define WAL_LINK_64 0 */
+#ifndef WAL_LINK_64
+#ifdef PG_HAVE_ATOMIC_U64_SIMULATION
+#define WAL_LINK_64 0
+#else
+#define WAL_LINK_64 1
+#endif
+#endif
+
+/*
+ * It links current position with previous one.
+ * - CurrPosId is (CurrBytePos ^ (CurrBytePos>>32))
+ *   Since CurrBytePos grows monotonically and it is aligned to MAXALIGN,
+ *   CurrPosId correctly identifies CurrBytePos for at least 4*2^32 = 32GB of
+ *   WAL logs.
+ * - CurrPosHigh is (CurrBytePos>>32), it is stored for strong uniqueness check.
+ * - PrevSize is difference between CurrBytePos and PrevBytePos
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	uint64		CurrPos;
+	uint64		PrevPos;
+#define WAL_PREV_EMPTY (~((uint64)0))
+#define WALLinkEmpty(l) ((l).PrevPos == WAL_PREV_EMPTY)
+#define WALLinkSamePos(a, b) ((a).CurrPos == (b).CurrPos)
+#define WALLinkCopyPrev(a, b) do {(a).PrevPos = (b).PrevPos;} while(0)
+#else
+	uint32		CurrPosId;
+	uint32		CurrPosHigh;
+	uint32		PrevSize;
+#define WALLinkEmpty(l) ((l).PrevSize == 0)
+#define WALLinkSamePos(a, b) ((a).CurrPosId == (b).CurrPosId && (a).CurrPosHigh == (b).CurrPosHigh)
+#define WALLinkCopyPrev(a, b) do {(a).PrevSize = (b).PrevSize;} while(0)
+#endif
+} WALPrevPosLinkVal;
+
+/*
+ * This is an element of lock-free hash-table.
+ * In 32 bit mode PrevSize's lowest bit is used as a lock, relying on fact it is MAXALIGN-ed.
+ * In 64 bit mode lock protocol is more complex.
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	pg_atomic_uint64 CurrPos;
+	pg_atomic_uint64 PrevPos;
+#else
+	pg_atomic_uint32 CurrPosId;
+	uint32		CurrPosHigh;
+	pg_atomic_uint32 PrevSize;
+	uint32		pad;			/* to align to 16 bytes */
+#endif
+} WALPrevPosLink;
+
+StaticAssertDecl(sizeof(WALPrevPosLink) == 16, "WALPrevPosLink should be 16 bytes");
+
+#define PREV_LINKS_HASH_CAPA (NUM_XLOGINSERT_LOCKS * 2)
+StaticAssertDecl(!(PREV_LINKS_HASH_CAPA & (PREV_LINKS_HASH_CAPA - 1)),
+				 "PREV_LINKS_HASH_CAPA should be power of two");
+StaticAssertDecl(PREV_LINKS_HASH_CAPA < UINT16_MAX,
+				 "PREV_LINKS_HASH_CAPA is too large");
+
+/*-----------
+ * PREV_LINKS_HASH_STRATEGY - the way slots are chosen in hash table
+ *   1 - 4 positions h1,h1+1,h2,h2+2 - it guarantees at least 3 distinct points,
+ *     but may spread at 4 cache lines.
+ *   2 - 4 positions h,h^1,h^2,h^3 - 4 points in single cache line.
+ *   3 - 8 positions h1,h1^1,h1^2,h1^4,h2,h2^1,h2^2,h2^3 - 8 distinct points in
+ *     in two cache lines.
+ */
+#ifndef PREV_LINKS_HASH_STRATEGY
+#define PREV_LINKS_HASH_STRATEGY 3
+#endif
+
+#if PREV_LINKS_HASH_STRATEGY <= 2
+#define PREV_LINKS_LOOKUPS 4
+#else
+#define PREV_LINKS_LOOKUPS 8
+#endif
+
+struct WALPrevLinksLookups
+{
+	uint16		pos[PREV_LINKS_LOOKUPS];
+};
+
+#define SWAP_ONCE_IN 128
+
 /*
  * Session status of running backup, used for sanity checks in SQL-callable
  * functions to start and stop backups.
@@ -390,17 +480,18 @@ static SessionBackupState sessionBackupState = SESSION_BACKUP_NONE;
  */
 typedef struct XLogCtlInsert
 {
-	slock_t		insertpos_lck;	/* protects CurrBytePos and PrevBytePos */
-
 	/*
 	 * CurrBytePos is the end of reserved WAL. The next record will be
-	 * inserted at that position. PrevBytePos is the start position of the
-	 * previously inserted (or rather, reserved) record - it is copied to the
-	 * prev-link of the next record. These are stored as "usable byte
-	 * positions" rather than XLogRecPtrs (see XLogBytePosToRecPtr()).
+	 * inserted at that position.
+	 *
+	 * The start position of the previously inserted (or rather, reserved)
+	 * record (it is copied to the prev-link of the next record) will be
+	 * stored in PrevLinksHash.
+	 *
+	 * These are stored as "usable byte positions" rather than XLogRecPtrs
+	 * (see XLogBytePosToRecPtr()).
 	 */
-	uint64		CurrBytePos;
-	uint64		PrevBytePos;
+	pg_atomic_uint64 CurrBytePos;

 	/*
 	 * Make sure the above heavily-contended spinlock and byte positions are
@@ -437,8 +528,37 @@ typedef struct XLogCtlInsert
 	 * WAL insertion locks.
 	 */
 	WALInsertLockPadded *WALInsertLocks;
+
+	/*
+	 * PrevLinksHash is a lock-free hash table based on Cuckoo algorithm.
+	 *
+	 * With default PREV_LINKS_HASH_STRATEGY == 1 it is mostly 4 way: for
+	 * every element computed two positions h1, h2, and neighbour h1+1 and
+	 * h2+2 are used as well. This way even on collision we have 3 distinct
+	 * position, which provide us ~75% fill rate without unsolvable cycles
+	 * (due to Cuckoo's theory). But chosen slots may be in 4 distinct
+	 * cache-lines.
+	 *
+	 * With PREV_LINKS_HASH_STRATEGY == 3 it takes two buckets 4 elements each
+	 * - 8 positions in total, but guaranteed to be in two cache lines. It
+	 * provides very high fill rate - upto 90%.
+	 *
+	 * With PREV_LINKS_HASH_STRATEGY == 2 it takes only one bucket with 4
+	 * elements. Strictly speaking it is not Cuckoo-hashing, but should work
+	 * for our case.
+	 *
+	 * Certainly, we rely on the fact we will delete elements with same speed
+	 * as we add them, and even unsolvable cycles will be destroyed soon by
+	 * concurrent deletions.
+	 */
+	WALPrevPosLink *PrevLinksHash;
+
 } XLogCtlInsert;

+StaticAssertDecl(offsetof(XLogCtlInsert, RedoRecPtr) / PG_CACHE_LINE_SIZE !=
+				 offsetof(XLogCtlInsert, CurrBytePos) / PG_CACHE_LINE_SIZE,
+				 "offset ok");
+
 /*
  * Total shared-memory state for XLOG.
  */
@@ -579,6 +699,9 @@ static XLogCtlData *XLogCtl = NULL;
 /* a private copy of XLogCtl->Insert.WALInsertLocks, for convenience */
 static WALInsertLockPadded *WALInsertLocks = NULL;

+/* same for XLogCtl->Insert.PrevLinksHash */
+static WALPrevPosLink *PrevLinksHash = NULL;
+
 /*
  * We maintain an image of pg_control in shared memory.
  */
@@ -711,6 +834,19 @@ static void CopyXLogRecordToWAL(int write_len, bool isLogSwitch,
 								XLogRecData *rdata,
 								XLogRecPtr StartPos, XLogRecPtr EndPos,
 								TimeLineID tli);
+
+static void WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos);
+static void WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos);
+static void CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos);
+
+static bool WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val);
+static bool WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static bool WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static void LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos,
+							   XLogRecPtr *PrevPtr);
+static void LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec);
+static XLogRecPtr ReadInsertCurrBytePos(void);
+
 static void ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos,
 									  XLogRecPtr *EndPos, XLogRecPtr *PrevPtr);
 static bool ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos,
@@ -1097,6 +1233,341 @@ XLogInsertRecord(XLogRecData *rdata,
 	return EndPos;
 }

+static pg_attribute_always_inline void
+WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos)
+{
+#if WAL_LINK_64
+	val->CurrPos = StartPos;
+	val->PrevPos = PrevPos;
+#else
+	val->CurrPosHigh = StartPos >> 32;
+	val->CurrPosId = StartPos ^ val->CurrPosHigh;
+	val->PrevSize = StartPos - PrevPos;
+#endif
+}
+
+static pg_attribute_always_inline void
+WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos)
+{
+#if WAL_LINK_64
+	*PrevPos = val.PrevPos;
+#else
+	XLogRecPtr	StartPos = val.CurrPosHigh;
+
+	StartPos ^= (StartPos << 32) | val.CurrPosId;
+	*PrevPos = StartPos - val.PrevSize;
+#endif
+}
+
+static pg_attribute_always_inline void
+CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos)
+{
+	uint32		hash;
+#if PREV_LINKS_HASH_STRATEGY == 3
+	uint32		offset;
+#endif
+
+
+#if WAL_LINK_64
+	hash = murmurhash32(linkval.CurrPos ^ (linkval.CurrPos >> 32));
+#else
+	hash = murmurhash32(linkval.CurrPosId);
+#endif
+
+#if PREV_LINKS_HASH_STRATEGY == 1
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = (pos->pos[0] + 1) % PREV_LINKS_HASH_CAPA;
+	pos->pos[2] = (hash >> 16) % PREV_LINKS_HASH_CAPA;
+	pos->pos[3] = (pos->pos[2] + 2) % PREV_LINKS_HASH_CAPA;
+#else
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = pos->pos[0] ^ 1;
+	pos->pos[2] = pos->pos[0] ^ 2;
+	pos->pos[3] = pos->pos[0] ^ 3;
+#if PREV_LINKS_HASH_STRATEGY == 3
+	/* use multiplication compute 0 <= offset < PREV_LINKS_HASH_CAPA-4 */
+	offset = (hash / PREV_LINKS_HASH_CAPA) * (PREV_LINKS_HASH_CAPA - 4);
+	offset /= UINT32_MAX / PREV_LINKS_HASH_CAPA + 1;
+	/* add start of next bucket */
+	offset += (pos->pos[0] | 3) + 1;
+	/* get position in strictly other bucket */
+	pos->pos[4] = offset % PREV_LINKS_HASH_CAPA;
+	pos->pos[5] = pos->pos[4] ^ 1;
+	pos->pos[6] = pos->pos[4] ^ 2;
+	pos->pos[7] = pos->pos[4] ^ 3;
+#endif
+#endif
+}
+
+/*
+ * Attempt to write into empty link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val)
+{
+#if WAL_LINK_64
+	uint64		empty = WAL_PREV_EMPTY;
+
+	if (pg_atomic_read_u64(&link->PrevPos) != WAL_PREV_EMPTY)
+		return false;
+	if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &empty, val.PrevPos))
+		return false;
+	/* we could ignore concurrent lock of CurrPos */
+	pg_atomic_write_u64(&link->CurrPos, val.CurrPos);
+	return true;
+#else
+	uint32		empty = 0;
+
+	/* first check it read-only */
+	if (pg_atomic_read_u32(&link->PrevSize) != 0)
+		return false;
+	if (!pg_atomic_compare_exchange_u32(&link->PrevSize, &empty, 1))
+		/* someone else occupied the entry */
+		return false;
+
+	pg_atomic_write_u32(&link->CurrPosId, val.CurrPosId);
+	link->CurrPosHigh = val.CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val.PrevSize);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to consume matched link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+
+	if (pg_atomic_read_u64(&link->CurrPos) != val->CurrPos)
+		return false;
+	/* lock against concurrent swapper */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr != val->CurrPos)
+	{
+		/* link was swapped */
+		pg_atomic_write_u64(&link->CurrPos, oldCurr);
+		return false;
+	}
+	val->PrevPos = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, WAL_PREV_EMPTY);
+
+	/*
+	 * concurrent inserter may already reuse this link, so we don't check
+	 * result of compare_exchange
+	 */
+	oldCurr |= 1;
+	pg_atomic_compare_exchange_u64(&link->CurrPos, &oldCurr, 0);
+	return true;
+#else
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId)
+		return false;
+
+	/* Try lock */
+	val->PrevSize = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (val->PrevSize & 1)
+		/* Lock failed */
+		return false;
+
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId ||
+		link->CurrPosHigh != val->CurrPosHigh)
+	{
+		/* unlock with old value */
+		pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+		return false;
+	}
+
+	pg_atomic_write_u32(&link->CurrPosId, 0);
+	link->CurrPosHigh = 0;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, 0);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to swap entry: remember existing link and write our.
+ * It could happen we consume empty entry. Caller will detect it by checking
+ * remembered value.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+	uint64		oldPrev;
+
+	/* lock against concurrent swapper or consumer */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr == 0)
+	{
+		/* link was empty */
+		oldPrev = WAL_PREV_EMPTY;
+		/* but concurrent inserter may concurrently insert */
+		if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &oldPrev, val->PrevPos))
+			return false;		/* concurrent inserter won. It will overwrite
+								 * CurrPos */
+		/* this write acts as unlock */
+		pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+		val->CurrPos = 0;
+		val->PrevPos = WAL_PREV_EMPTY;
+		return true;
+	}
+	oldPrev = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, val->PrevPos);
+	pg_write_barrier();
+	/* write acts as unlock */
+	pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+	val->CurrPos = oldCurr;
+	val->PrevPos = oldPrev;
+	return true;
+#else
+	uint32		oldPrev;
+	uint32		oldCurId;
+	uint32		oldCurHigh;
+
+	/* Attempt to lock entry against concurrent consumer or swapper */
+	oldPrev = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (oldPrev & 1)
+		/* Lock failed */
+		return false;
+
+	oldCurId = pg_atomic_read_u32(&link->CurrPosId);
+	oldCurHigh = link->CurrPosHigh;
+	pg_atomic_write_u32(&link->CurrPosId, val->CurrPosId);
+	link->CurrPosHigh = val->CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+
+	val->CurrPosId = oldCurId;
+	val->CurrPosHigh = oldCurHigh;
+	val->PrevSize = oldPrev;
+	return true;
+#endif
+}
+
+/*
+ * Write new link (EndPos, StartPos) and find PrevPtr for StartPos.
+ *
+ * Links are stored in lock-free Cuckoo based hash-table.
+ * We use mostly-4 way Cuckoo hashing which provides high fill rate without
+ * hard cycle collisions. Also we rely on concurrent consumers of existing
+ * entry, so cycles will be broken in mean time.
+ *
+ * Cuckoo hashing relies on re-insertion for balancing, so we occasionally
+ * swaps entry and try to insert swapped instead of our.
+ */
+static void
+LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos, XLogRecPtr *PrevPtr)
+{
+	SpinDelayStatus spin_stat;
+	WALPrevPosLinkVal lookup;
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups lookup_pos;
+	struct WALPrevLinksLookups insert_pos;
+	uint32		i;
+	uint32		rand = 0;
+	bool		inserted = false;
+	bool		found = false;
+
+	/* pass StartPos second time to set PrevSize = 0 */
+	WALPrevPosLinkValCompose(&lookup, StartPos, StartPos);
+	WALPrevPosLinkValCompose(&insert, EndPos, StartPos);
+
+	CalcCuckooPositions(lookup, &lookup_pos);
+	CalcCuckooPositions(insert, &insert_pos);
+
+	init_local_spin_delay(&spin_stat);
+
+	while (!inserted || !found)
+	{
+		for (i = 0; !found && i < PREV_LINKS_LOOKUPS; i++)
+			found = WALPrevPosLinkConsume(&PrevLinksHash[lookup_pos.pos[i]], &lookup);
+
+		if (inserted)
+		{
+			/*
+			 * we may sleep only after we inserted our value, since other
+			 * backend waits for it
+			 */
+			perform_spin_delay(&spin_stat);
+			goto next;
+		}
+
+		for (i = 0; !inserted && i < PREV_LINKS_LOOKUPS; i++)
+			inserted = WALPrevPosLinkInsert(&PrevLinksHash[insert_pos.pos[i]], insert);
+
+		if (inserted)
+			goto next;
+
+		rand = pg_prng_uint32(&pg_global_prng_state);
+		if (rand % SWAP_ONCE_IN != 0)
+			goto next;
+
+		i = rand / SWAP_ONCE_IN % PREV_LINKS_LOOKUPS;
+		if (!WALPrevPosLinkSwap(&PrevLinksHash[insert_pos.pos[i]], &insert))
+			goto next;
+
+		if (WALLinkEmpty(insert))
+			/* Lucky case: entry become empty and we inserted into */
+			inserted = true;
+		else if (WALLinkSamePos(lookup, insert))
+		{
+			/*
+			 * We occasionally replaced entry we looked for. No need to insert
+			 * it again.
+			 */
+			inserted = true;
+			Assert(!found);
+			found = true;
+			WALLinkCopyPrev(lookup, insert);
+			break;
+		}
+		else
+			CalcCuckooPositions(insert, &insert_pos);
+
+next:
+		pg_spin_delay();
+		pg_read_barrier();
+	}
+
+	WALPrevPosLinkValGetPrev(lookup, PrevPtr);
+}
+
+static pg_attribute_always_inline void
+LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec)
+{
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups insert_pos;
+
+	WALPrevPosLinkValCompose(&insert, EndOfLog, LastRec);
+	CalcCuckooPositions(insert, &insert_pos);
+#if WAL_LINK_64
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].CurrPos, insert.CurrPos);
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].PrevPos, insert.PrevPos);
+#else
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].CurrPosId, insert.CurrPosId);
+	PrevLinksHash[insert_pos.pos[0]].CurrPosHigh = insert.CurrPosHigh;
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].PrevSize, insert.PrevSize);
+#endif
+}
+
+static pg_attribute_always_inline XLogRecPtr
+ReadInsertCurrBytePos(void)
+{
+	return pg_atomic_read_u64(&XLogCtl->Insert.CurrBytePos);
+}
+
 /*
  * Reserves the right amount of space for a record of given size from the WAL.
  * *StartPos is set to the beginning of the reserved section, *EndPos to
@@ -1129,25 +1600,9 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
 	/* All (non xlog-switch) records should contain data. */
 	Assert(size > SizeOfXLogRecord);

-	/*
-	 * The duration the spinlock needs to be held is minimized by minimizing
-	 * the calculations that have to be done while holding the lock. The
-	 * current tip of reserved WAL is kept in CurrBytePos, as a byte position
-	 * that only counts "usable" bytes in WAL, that is, it excludes all WAL
-	 * page headers. The mapping between "usable" byte positions and physical
-	 * positions (XLogRecPtrs) can be done outside the locked region, and
-	 * because the usable byte position doesn't include any headers, reserving
-	 * X bytes from WAL is almost as simple as "CurrBytePos += X".
-	 */
-	SpinLockAcquire(&Insert->insertpos_lck);
-
-	startbytepos = Insert->CurrBytePos;
+	startbytepos = pg_atomic_fetch_add_u64(&Insert->CurrBytePos, size);
 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;
-
-	SpinLockRelease(&Insert->insertpos_lck);
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);
@@ -1183,26 +1638,24 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 	uint32		segleft;

 	/*
-	 * These calculations are a bit heavy-weight to be done while holding a
-	 * spinlock, but since we're holding all the WAL insertion locks, there
-	 * are no other inserters competing for it. GetXLogInsertRecPtr() does
-	 * compete for it, but that's not called very frequently.
+	 * Currently ReserveXLogInsertLocation is protected with exclusive
+	 * insertion lock, so there is no contention against CurrBytePos, But we
+	 * still do CAS loop for being uniform.
+	 *
+	 * Probably we'll get rid of exclusive lock in a future.
 	 */
-	SpinLockAcquire(&Insert->insertpos_lck);

-	startbytepos = Insert->CurrBytePos;
+repeat:
+	startbytepos = pg_atomic_read_u64(&Insert->CurrBytePos);

 	ptr = XLogBytePosToEndRecPtr(startbytepos);
 	if (XLogSegmentOffset(ptr, wal_segment_size) == 0)
 	{
-		SpinLockRelease(&Insert->insertpos_lck);
 		*EndPos = *StartPos = ptr;
 		return false;
 	}

 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-
 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);

@@ -1213,10 +1666,19 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 		*EndPos += segleft;
 		endbytepos = XLogRecPtrToBytePos(*EndPos);
 	}
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;

-	SpinLockRelease(&Insert->insertpos_lck);
+	if (!pg_atomic_compare_exchange_u64(&Insert->CurrBytePos,
+										&startbytepos,
+										endbytepos))
+	{
+		/*
+		 * Don't use spin delay here: perform_spin_delay primary case is for
+		 * solving single core contention. But on single core we will succeed
+		 * on the next attempt.
+		 */
+		goto repeat;
+	}
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*PrevPtr = XLogBytePosToRecPtr(prevbytepos);

@@ -1518,7 +1980,6 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 	XLogRecPtr	inserted;
 	XLogRecPtr	reservedUpto;
 	XLogRecPtr	finishedUpto;
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	int			i;

 	if (MyProc == NULL)
@@ -1533,9 +1994,7 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 		return inserted;

 	/* Read the current insert position */
-	SpinLockAcquire(&Insert->insertpos_lck);
-	bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
+	bytepos = ReadInsertCurrBytePos();
 	reservedUpto = XLogBytePosToEndRecPtr(bytepos);

 	/*
@@ -5079,6 +5538,8 @@ XLOGShmemSize(void)

 	/* WAL insertion locks, plus alignment */
 	size = add_size(size, mul_size(sizeof(WALInsertLockPadded), NUM_XLOGINSERT_LOCKS + 1));
+	/* prevlinkshash, abuses alignment of WAL insertion locks. */
+	size = add_size(size, mul_size(sizeof(WALPrevPosLink), PREV_LINKS_HASH_CAPA));
 	/* xlblocks array */
 	size = add_size(size, mul_size(sizeof(pg_atomic_uint64), XLOGbuffers));
 	/* extra alignment padding for XLOG I/O buffers */
@@ -5133,8 +5594,9 @@ XLOGShmemInit(void)
 		/* both should be present or neither */
 		Assert(foundCFile && foundXLog);

-		/* Initialize local copy of WALInsertLocks */
+		/* Initialize local copy of WALInsertLocks and PrevLinksHash */
 		WALInsertLocks = XLogCtl->Insert.WALInsertLocks;
+		PrevLinksHash = XLogCtl->Insert.PrevLinksHash;

 		if (localControlFile)
 			pfree(localControlFile);
@@ -5180,6 +5642,9 @@ XLOGShmemInit(void)
 		WALInsertLocks[i].l.lastImportantAt = InvalidXLogRecPtr;
 	}

+	PrevLinksHash = XLogCtl->Insert.PrevLinksHash = (WALPrevPosLink *) allocptr;
+	allocptr += sizeof(WALPrevPosLink) * PREV_LINKS_HASH_CAPA;
+
 	/*
 	 * Align the start of the page buffers to a full xlog block size boundary.
 	 * This simplifies some calculations in XLOG insertion. It is also
@@ -5198,7 +5663,6 @@ XLOGShmemInit(void)
 	XLogCtl->InstallXLogFileSegmentActive = false;
 	XLogCtl->WalWriterSleeping = false;

-	SpinLockInit(&XLogCtl->Insert.insertpos_lck);
 	SpinLockInit(&XLogCtl->info_lck);
 	pg_atomic_init_u64(&XLogCtl->logInsertResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logWriteResult, InvalidXLogRecPtr);
@@ -5208,6 +5672,19 @@ XLOGShmemInit(void)
 	pg_atomic_init_u64(&XLogCtl->InitializeReserved, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->InitializedUpTo, InvalidXLogRecPtr);
 	ConditionVariableInit(&XLogCtl->InitializedUpToCondVar);
+
+	pg_atomic_init_u64(&XLogCtl->Insert.CurrBytePos, 0);
+
+	for (i = 0; i < PREV_LINKS_HASH_CAPA; i++)
+	{
+#if WAL_LINK_64
+		pg_atomic_init_u64(&PrevLinksHash[i].CurrPos, 0);
+		pg_atomic_init_u64(&PrevLinksHash[i].PrevPos, WAL_PREV_EMPTY);
+#else
+		pg_atomic_init_u32(&PrevLinksHash[i].CurrPosId, 0);
+		pg_atomic_init_u32(&PrevLinksHash[i].PrevSize, 0);
+#endif
+	}
 }

 /*
@@ -6203,8 +6680,13 @@ StartupXLOG(void)
 	 * previous incarnation.
 	 */
 	Insert = &XLogCtl->Insert;
-	Insert->PrevBytePos = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
-	Insert->CurrBytePos = XLogRecPtrToBytePos(EndOfLog);
+	{
+		XLogRecPtr	endOfLog = XLogRecPtrToBytePos(EndOfLog);
+		XLogRecPtr	lastRec = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
+
+		pg_atomic_write_u64(&Insert->CurrBytePos, endOfLog);
+		LinkStartPrevPos(endOfLog, lastRec);
+	}

 	/*
 	 * Tricky point here: lastPage contains the *last* block that the LastRec
@@ -7193,7 +7675,7 @@ CreateCheckPoint(int flags)

 	if (shutdown)
 	{
-		XLogRecPtr	curInsert = XLogBytePosToRecPtr(Insert->CurrBytePos);
+		XLogRecPtr	curInsert = XLogBytePosToRecPtr(ReadInsertCurrBytePos());

 		/*
 		 * Compute new REDO record ptr = location of next XLOG record.
@@ -9611,14 +10093,7 @@ register_persistent_abort_backup_handler(void)
 XLogRecPtr
 GetXLogInsertRecPtr(void)
 {
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
-	uint64		current_bytepos;
-
-	SpinLockAcquire(&Insert->insertpos_lck);
-	current_bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
-
-	return XLogBytePosToRecPtr(current_bytepos);
+	return XLogBytePosToRecPtr(ReadInsertCurrBytePos());
 }

 /*
diff --git a/src/tools/pgindent/typedefs.list b/src/tools/pgindent/typedefs.list
index e5879e00dff..f0bfb4762c3 100644
--- a/src/tools/pgindent/typedefs.list
+++ b/src/tools/pgindent/typedefs.list
@@ -3211,6 +3211,8 @@ WALAvailability
 WALInsertLock
 WALInsertLockPadded
 WALOpenSegment
+WALPrevPosLink
+WALPrevPosLinkVal
 WALReadError
 WALSegmentCloseCB
 WALSegmentContext
--
2.43.0

From 4e3fbbd66382c6a6dfd4abae802eda8e79d8d892 Mon Sep 17 00:00:00 2001
From: Zhiguo Zhou <zhiguo.zhou@intel.com>
Date: Mon, 27 Oct 2025 17:11:30 +0800
Subject: [PATCH] Lock-free XLog Reservation using lock-free hash-table

Removed PrevBytePos to eliminate lock contention, allowing atomic updates
to CurrBytePos. Use lock-free hash-table based on 4-way Cuckoo Hashing
to store link to PrevBytePos.
---
 src/backend/access/transam/xlog.c | 587 +++++++++++++++++++++++++++---
 src/tools/pgindent/typedefs.list  |   2 +
 2 files changed, 532 insertions(+), 57 deletions(-)

diff --git a/src/backend/access/transam/xlog.c b/src/backend/access/transam/xlog.c
index eceab341255..1c9830f89af 100644
--- a/src/backend/access/transam/xlog.c
+++ b/src/backend/access/transam/xlog.c
@@ -68,6 +68,8 @@
 #include "catalog/pg_database.h"
 #include "common/controldata_utils.h"
 #include "common/file_utils.h"
+#include "common/hashfn.h"
+#include "common/pg_prng.h"
 #include "executor/instrument.h"
 #include "miscadmin.h"
 #include "pg_trace.h"
@@ -385,6 +387,94 @@ typedef union WALInsertLockPadded
 	char		pad[PG_CACHE_LINE_SIZE];
 } WALInsertLockPadded;

+/* #define WAL_LINK_64 0 */
+#ifndef WAL_LINK_64
+#ifdef PG_HAVE_ATOMIC_U64_SIMULATION
+#define WAL_LINK_64 0
+#else
+#define WAL_LINK_64 1
+#endif
+#endif
+
+/*
+ * It links current position with previous one.
+ * - CurrPosId is (CurrBytePos ^ (CurrBytePos>>32))
+ *   Since CurrBytePos grows monotonically and it is aligned to MAXALIGN,
+ *   CurrPosId correctly identifies CurrBytePos for at least 4*2^32 = 32GB of
+ *   WAL logs.
+ * - CurrPosHigh is (CurrBytePos>>32), it is stored for strong uniqueness check.
+ * - PrevSize is difference between CurrBytePos and PrevBytePos
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	uint64		CurrPos;
+	uint64		PrevPos;
+#define WAL_PREV_EMPTY (~((uint64)0))
+#define WALLinkEmpty(l) ((l).PrevPos == WAL_PREV_EMPTY)
+#define WALLinkSamePos(a, b) ((a).CurrPos == (b).CurrPos)
+#define WALLinkCopyPrev(a, b) do {(a).PrevPos = (b).PrevPos;} while(0)
+#else
+	uint32		CurrPosId;
+	uint32		CurrPosHigh;
+	uint32		PrevSize;
+#define WALLinkEmpty(l) ((l).PrevSize == 0)
+#define WALLinkSamePos(a, b) ((a).CurrPosId == (b).CurrPosId && (a).CurrPosHigh == (b).CurrPosHigh)
+#define WALLinkCopyPrev(a, b) do {(a).PrevSize = (b).PrevSize;} while(0)
+#endif
+} WALPrevPosLinkVal;
+
+/*
+ * This is an element of lock-free hash-table.
+ * In 32 bit mode PrevSize's lowest bit is used as a lock, relying on fact it is MAXALIGN-ed.
+ * In 64 bit mode lock protocol is more complex.
+ */
+typedef struct
+{
+#if WAL_LINK_64
+	pg_atomic_uint64 CurrPos;
+	pg_atomic_uint64 PrevPos;
+#else
+	pg_atomic_uint32 CurrPosId;
+	uint32		CurrPosHigh;
+	pg_atomic_uint32 PrevSize;
+	uint32		pad;			/* to align to 16 bytes */
+#endif
+} WALPrevPosLink;
+
+StaticAssertDecl(sizeof(WALPrevPosLink) == 16, "WALPrevPosLink should be 16 bytes");
+
+#define PREV_LINKS_HASH_CAPA (NUM_XLOGINSERT_LOCKS * 2)
+StaticAssertDecl(!(PREV_LINKS_HASH_CAPA & (PREV_LINKS_HASH_CAPA - 1)),
+				 "PREV_LINKS_HASH_CAPA should be power of two");
+StaticAssertDecl(PREV_LINKS_HASH_CAPA < UINT16_MAX,
+				 "PREV_LINKS_HASH_CAPA is too large");
+
+/*-----------
+ * PREV_LINKS_HASH_STRATEGY - the way slots are chosen in hash table
+ *   1 - 4 positions h1,h1+1,h2,h2+2 - it guarantees at least 3 distinct points,
+ *     but may spread at 4 cache lines.
+ *   2 - 4 positions h,h^1,h^2,h^3 - 4 points in single cache line.
+ *   3 - 8 positions h1,h1^1,h1^2,h1^4,h2,h2^1,h2^2,h2^3 - 8 distinct points in
+ *     in two cache lines.
+ */
+#ifndef PREV_LINKS_HASH_STRATEGY
+#define PREV_LINKS_HASH_STRATEGY 3
+#endif
+
+#if PREV_LINKS_HASH_STRATEGY <= 2
+#define PREV_LINKS_LOOKUPS 4
+#else
+#define PREV_LINKS_LOOKUPS 8
+#endif
+
+struct WALPrevLinksLookups
+{
+	uint16		pos[PREV_LINKS_LOOKUPS];
+};
+
+#define SWAP_ONCE_IN 128
+
 /*
  * Session status of running backup, used for sanity checks in SQL-callable
  * functions to start and stop backups.
@@ -396,17 +486,18 @@ static SessionBackupState sessionBackupState = SESSION_BACKUP_NONE;
  */
 typedef struct XLogCtlInsert
 {
-	slock_t		insertpos_lck;	/* protects CurrBytePos and PrevBytePos */
-
 	/*
 	 * CurrBytePos is the end of reserved WAL. The next record will be
-	 * inserted at that position. PrevBytePos is the start position of the
-	 * previously inserted (or rather, reserved) record - it is copied to the
-	 * prev-link of the next record. These are stored as "usable byte
-	 * positions" rather than XLogRecPtrs (see XLogBytePosToRecPtr()).
+	 * inserted at that position.
+	 *
+	 * The start position of the previously inserted (or rather, reserved)
+	 * record (it is copied to the prev-link of the next record) will be
+	 * stored in PrevLinksHash.
+	 *
+	 * These are stored as "usable byte positions" rather than XLogRecPtrs
+	 * (see XLogBytePosToRecPtr()).
 	 */
-	uint64		CurrBytePos;
-	uint64		PrevBytePos;
+	pg_atomic_uint64 CurrBytePos;

 	/*
 	 * Make sure the above heavily-contended spinlock and byte positions are
@@ -443,8 +534,37 @@ typedef struct XLogCtlInsert
 	 * WAL insertion locks.
 	 */
 	WALInsertLockPadded *WALInsertLocks;
+
+	/*
+	 * PrevLinksHash is a lock-free hash table based on Cuckoo algorithm.
+	 *
+	 * With default PREV_LINKS_HASH_STRATEGY == 1 it is mostly 4 way: for
+	 * every element computed two positions h1, h2, and neighbour h1+1 and
+	 * h2+2 are used as well. This way even on collision we have 3 distinct
+	 * position, which provide us ~75% fill rate without unsolvable cycles
+	 * (due to Cuckoo's theory). But chosen slots may be in 4 distinct
+	 * cache-lines.
+	 *
+	 * With PREV_LINKS_HASH_STRATEGY == 3 it takes two buckets 4 elements each
+	 * - 8 positions in total, but guaranteed to be in two cache lines. It
+	 * provides very high fill rate - upto 90%.
+	 *
+	 * With PREV_LINKS_HASH_STRATEGY == 2 it takes only one bucket with 4
+	 * elements. Strictly speaking it is not Cuckoo-hashing, but should work
+	 * for our case.
+	 *
+	 * Certainly, we rely on the fact we will delete elements with same speed
+	 * as we add them, and even unsolvable cycles will be destroyed soon by
+	 * concurrent deletions.
+	 */
+	WALPrevPosLink *PrevLinksHash;
+
 } XLogCtlInsert;

+StaticAssertDecl(offsetof(XLogCtlInsert, RedoRecPtr) / PG_CACHE_LINE_SIZE !=
+				 offsetof(XLogCtlInsert, CurrBytePos) / PG_CACHE_LINE_SIZE,
+				 "offset ok");
+
 /*
  * Total shared-memory state for XLOG.
  */
@@ -568,6 +688,9 @@ static XLogCtlData *XLogCtl = NULL;
 /* a private copy of XLogCtl->Insert.WALInsertLocks, for convenience */
 static WALInsertLockPadded *WALInsertLocks = NULL;

+/* same for XLogCtl->Insert.PrevLinksHash */
+static WALPrevPosLink *PrevLinksHash = NULL;
+
 /*
  * We maintain an image of pg_control in shared memory.
  */
@@ -700,6 +823,19 @@ static void CopyXLogRecordToWAL(int write_len, bool isLogSwitch,
 								XLogRecData *rdata,
 								XLogRecPtr StartPos, XLogRecPtr EndPos,
 								TimeLineID tli);
+
+static void WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos);
+static void WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos);
+static void CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos);
+
+static bool WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val);
+static bool WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static bool WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val);
+static void LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos,
+							   XLogRecPtr *PrevPtr);
+static void LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec);
+static XLogRecPtr ReadInsertCurrBytePos(void);
+
 static void ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos,
 									  XLogRecPtr *EndPos, XLogRecPtr *PrevPtr);
 static bool ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos,
@@ -1089,6 +1225,341 @@ XLogInsertRecord(XLogRecData *rdata,
 	return EndPos;
 }

+static pg_attribute_always_inline void
+WALPrevPosLinkValCompose(WALPrevPosLinkVal *val, XLogRecPtr StartPos, XLogRecPtr PrevPos)
+{
+#if WAL_LINK_64
+	val->CurrPos = StartPos;
+	val->PrevPos = PrevPos;
+#else
+	val->CurrPosHigh = StartPos >> 32;
+	val->CurrPosId = StartPos ^ val->CurrPosHigh;
+	val->PrevSize = StartPos - PrevPos;
+#endif
+}
+
+static pg_attribute_always_inline void
+WALPrevPosLinkValGetPrev(WALPrevPosLinkVal val, XLogRecPtr *PrevPos)
+{
+#if WAL_LINK_64
+	*PrevPos = val.PrevPos;
+#else
+	XLogRecPtr	StartPos = val.CurrPosHigh;
+
+	StartPos ^= (StartPos << 32) | val.CurrPosId;
+	*PrevPos = StartPos - val.PrevSize;
+#endif
+}
+
+static pg_attribute_always_inline void
+CalcCuckooPositions(WALPrevPosLinkVal linkval, struct WALPrevLinksLookups *pos)
+{
+	uint32		hash;
+#if PREV_LINKS_HASH_STRATEGY == 3
+	uint32		offset;
+#endif
+
+
+#if WAL_LINK_64
+	hash = murmurhash32(linkval.CurrPos ^ (linkval.CurrPos >> 32));
+#else
+	hash = murmurhash32(linkval.CurrPosId);
+#endif
+
+#if PREV_LINKS_HASH_STRATEGY == 1
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = (pos->pos[0] + 1) % PREV_LINKS_HASH_CAPA;
+	pos->pos[2] = (hash >> 16) % PREV_LINKS_HASH_CAPA;
+	pos->pos[3] = (pos->pos[2] + 2) % PREV_LINKS_HASH_CAPA;
+#else
+	pos->pos[0] = hash % PREV_LINKS_HASH_CAPA;
+	pos->pos[1] = pos->pos[0] ^ 1;
+	pos->pos[2] = pos->pos[0] ^ 2;
+	pos->pos[3] = pos->pos[0] ^ 3;
+#if PREV_LINKS_HASH_STRATEGY == 3
+	/* use multiplication compute 0 <= offset < PREV_LINKS_HASH_CAPA-4 */
+	offset = (hash / PREV_LINKS_HASH_CAPA) * (PREV_LINKS_HASH_CAPA - 4);
+	offset /= UINT32_MAX / PREV_LINKS_HASH_CAPA + 1;
+	/* add start of next bucket */
+	offset += (pos->pos[0] | 3) + 1;
+	/* get position in strictly other bucket */
+	pos->pos[4] = offset % PREV_LINKS_HASH_CAPA;
+	pos->pos[5] = pos->pos[4] ^ 1;
+	pos->pos[6] = pos->pos[4] ^ 2;
+	pos->pos[7] = pos->pos[4] ^ 3;
+#endif
+#endif
+}
+
+/*
+ * Attempt to write into empty link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkInsert(WALPrevPosLink *link, WALPrevPosLinkVal val)
+{
+#if WAL_LINK_64
+	uint64		empty = WAL_PREV_EMPTY;
+
+	if (pg_atomic_read_u64(&link->PrevPos) != WAL_PREV_EMPTY)
+		return false;
+	if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &empty, val.PrevPos))
+		return false;
+	/* we could ignore concurrent lock of CurrPos */
+	pg_atomic_write_u64(&link->CurrPos, val.CurrPos);
+	return true;
+#else
+	uint32		empty = 0;
+
+	/* first check it read-only */
+	if (pg_atomic_read_u32(&link->PrevSize) != 0)
+		return false;
+	if (!pg_atomic_compare_exchange_u32(&link->PrevSize, &empty, 1))
+		/* someone else occupied the entry */
+		return false;
+
+	pg_atomic_write_u32(&link->CurrPosId, val.CurrPosId);
+	link->CurrPosHigh = val.CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val.PrevSize);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to consume matched link.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkConsume(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+
+	if (pg_atomic_read_u64(&link->CurrPos) != val->CurrPos)
+		return false;
+	/* lock against concurrent swapper */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr != val->CurrPos)
+	{
+		/* link was swapped */
+		pg_atomic_write_u64(&link->CurrPos, oldCurr);
+		return false;
+	}
+	val->PrevPos = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, WAL_PREV_EMPTY);
+
+	/*
+	 * concurrent inserter may already reuse this link, so we don't check
+	 * result of compare_exchange
+	 */
+	oldCurr |= 1;
+	pg_atomic_compare_exchange_u64(&link->CurrPos, &oldCurr, 0);
+	return true;
+#else
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId)
+		return false;
+
+	/* Try lock */
+	val->PrevSize = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (val->PrevSize & 1)
+		/* Lock failed */
+		return false;
+
+	if (pg_atomic_read_u32(&link->CurrPosId) != val->CurrPosId ||
+		link->CurrPosHigh != val->CurrPosHigh)
+	{
+		/* unlock with old value */
+		pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+		return false;
+	}
+
+	pg_atomic_write_u32(&link->CurrPosId, 0);
+	link->CurrPosHigh = 0;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, 0);
+	return true;
+#endif
+}
+
+/*
+ * Attempt to swap entry: remember existing link and write our.
+ * It could happen we consume empty entry. Caller will detect it by checking
+ * remembered value.
+ */
+static pg_attribute_always_inline bool
+WALPrevPosLinkSwap(WALPrevPosLink *link, WALPrevPosLinkVal *val)
+{
+#if WAL_LINK_64
+	uint64		oldCurr;
+	uint64		oldPrev;
+
+	/* lock against concurrent swapper or consumer */
+	oldCurr = pg_atomic_fetch_or_u64(&link->CurrPos, 1);
+	if (oldCurr & 1)
+		return false;			/* lock failed */
+	if (oldCurr == 0)
+	{
+		/* link was empty */
+		oldPrev = WAL_PREV_EMPTY;
+		/* but concurrent inserter may concurrently insert */
+		if (!pg_atomic_compare_exchange_u64(&link->PrevPos, &oldPrev, val->PrevPos))
+			return false;		/* concurrent inserter won. It will overwrite
+								 * CurrPos */
+		/* this write acts as unlock */
+		pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+		val->CurrPos = 0;
+		val->PrevPos = WAL_PREV_EMPTY;
+		return true;
+	}
+	oldPrev = pg_atomic_read_u64(&link->PrevPos);
+	pg_atomic_write_u64(&link->PrevPos, val->PrevPos);
+	pg_write_barrier();
+	/* write acts as unlock */
+	pg_atomic_write_u64(&link->CurrPos, val->CurrPos);
+	val->CurrPos = oldCurr;
+	val->PrevPos = oldPrev;
+	return true;
+#else
+	uint32		oldPrev;
+	uint32		oldCurId;
+	uint32		oldCurHigh;
+
+	/* Attempt to lock entry against concurrent consumer or swapper */
+	oldPrev = pg_atomic_fetch_or_u32(&link->PrevSize, 1);
+	if (oldPrev & 1)
+		/* Lock failed */
+		return false;
+
+	oldCurId = pg_atomic_read_u32(&link->CurrPosId);
+	oldCurHigh = link->CurrPosHigh;
+	pg_atomic_write_u32(&link->CurrPosId, val->CurrPosId);
+	link->CurrPosHigh = val->CurrPosHigh;
+	pg_write_barrier();
+	/* This write acts as unlock as well. */
+	pg_atomic_write_u32(&link->PrevSize, val->PrevSize);
+
+	val->CurrPosId = oldCurId;
+	val->CurrPosHigh = oldCurHigh;
+	val->PrevSize = oldPrev;
+	return true;
+#endif
+}
+
+/*
+ * Write new link (EndPos, StartPos) and find PrevPtr for StartPos.
+ *
+ * Links are stored in lock-free Cuckoo based hash-table.
+ * We use mostly-4 way Cuckoo hashing which provides high fill rate without
+ * hard cycle collisions. Also we rely on concurrent consumers of existing
+ * entry, so cycles will be broken in mean time.
+ *
+ * Cuckoo hashing relies on re-insertion for balancing, so we occasionally
+ * swaps entry and try to insert swapped instead of our.
+ */
+static void
+LinkAndFindPrevPos(XLogRecPtr StartPos, XLogRecPtr EndPos, XLogRecPtr *PrevPtr)
+{
+	SpinDelayStatus spin_stat;
+	WALPrevPosLinkVal lookup;
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups lookup_pos;
+	struct WALPrevLinksLookups insert_pos;
+	uint32		i;
+	uint32		rand = 0;
+	bool		inserted = false;
+	bool		found = false;
+
+	/* pass StartPos second time to set PrevSize = 0 */
+	WALPrevPosLinkValCompose(&lookup, StartPos, StartPos);
+	WALPrevPosLinkValCompose(&insert, EndPos, StartPos);
+
+	CalcCuckooPositions(lookup, &lookup_pos);
+	CalcCuckooPositions(insert, &insert_pos);
+
+	init_local_spin_delay(&spin_stat);
+
+	while (!inserted || !found)
+	{
+		for (i = 0; !found && i < PREV_LINKS_LOOKUPS; i++)
+			found = WALPrevPosLinkConsume(&PrevLinksHash[lookup_pos.pos[i]], &lookup);
+
+		if (inserted)
+		{
+			/*
+			 * we may sleep only after we inserted our value, since other
+			 * backend waits for it
+			 */
+			perform_spin_delay(&spin_stat);
+			goto next;
+		}
+
+		for (i = 0; !inserted && i < PREV_LINKS_LOOKUPS; i++)
+			inserted = WALPrevPosLinkInsert(&PrevLinksHash[insert_pos.pos[i]], insert);
+
+		if (inserted)
+			goto next;
+
+		rand = pg_prng_uint32(&pg_global_prng_state);
+		if (rand % SWAP_ONCE_IN != 0)
+			goto next;
+
+		i = rand / SWAP_ONCE_IN % PREV_LINKS_LOOKUPS;
+		if (!WALPrevPosLinkSwap(&PrevLinksHash[insert_pos.pos[i]], &insert))
+			goto next;
+
+		if (WALLinkEmpty(insert))
+			/* Lucky case: entry become empty and we inserted into */
+			inserted = true;
+		else if (WALLinkSamePos(lookup, insert))
+		{
+			/*
+			 * We occasionally replaced entry we looked for. No need to insert
+			 * it again.
+			 */
+			inserted = true;
+			Assert(!found);
+			found = true;
+			WALLinkCopyPrev(lookup, insert);
+			break;
+		}
+		else
+			CalcCuckooPositions(insert, &insert_pos);
+
+next:
+		pg_spin_delay();
+		pg_read_barrier();
+	}
+
+	WALPrevPosLinkValGetPrev(lookup, PrevPtr);
+}
+
+static pg_attribute_always_inline void
+LinkStartPrevPos(XLogRecPtr EndOfLog, XLogRecPtr LastRec)
+{
+	WALPrevPosLinkVal insert;
+	struct WALPrevLinksLookups insert_pos;
+
+	WALPrevPosLinkValCompose(&insert, EndOfLog, LastRec);
+	CalcCuckooPositions(insert, &insert_pos);
+#if WAL_LINK_64
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].CurrPos, insert.CurrPos);
+	pg_atomic_write_u64(&PrevLinksHash[insert_pos.pos[0]].PrevPos, insert.PrevPos);
+#else
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].CurrPosId, insert.CurrPosId);
+	PrevLinksHash[insert_pos.pos[0]].CurrPosHigh = insert.CurrPosHigh;
+	pg_atomic_write_u32(&PrevLinksHash[insert_pos.pos[0]].PrevSize, insert.PrevSize);
+#endif
+}
+
+static pg_attribute_always_inline XLogRecPtr
+ReadInsertCurrBytePos(void)
+{
+	return pg_atomic_read_u64(&XLogCtl->Insert.CurrBytePos);
+}
+
 /*
  * Reserves the right amount of space for a record of given size from the WAL.
  * *StartPos is set to the beginning of the reserved section, *EndPos to
@@ -1121,25 +1592,9 @@ ReserveXLogInsertLocation(int size, XLogRecPtr *StartPos, XLogRecPtr *EndPos,
 	/* All (non xlog-switch) records should contain data. */
 	Assert(size > SizeOfXLogRecord);

-	/*
-	 * The duration the spinlock needs to be held is minimized by minimizing
-	 * the calculations that have to be done while holding the lock. The
-	 * current tip of reserved WAL is kept in CurrBytePos, as a byte position
-	 * that only counts "usable" bytes in WAL, that is, it excludes all WAL
-	 * page headers. The mapping between "usable" byte positions and physical
-	 * positions (XLogRecPtrs) can be done outside the locked region, and
-	 * because the usable byte position doesn't include any headers, reserving
-	 * X bytes from WAL is almost as simple as "CurrBytePos += X".
-	 */
-	SpinLockAcquire(&Insert->insertpos_lck);
-
-	startbytepos = Insert->CurrBytePos;
+	startbytepos = pg_atomic_fetch_add_u64(&Insert->CurrBytePos, size);
 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;
-
-	SpinLockRelease(&Insert->insertpos_lck);
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);
@@ -1175,26 +1630,23 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 	uint32		segleft;

 	/*
-	 * These calculations are a bit heavy-weight to be done while holding a
-	 * spinlock, but since we're holding all the WAL insertion locks, there
-	 * are no other inserters competing for it. GetXLogInsertRecPtr() does
-	 * compete for it, but that's not called very frequently.
+	 * Currently ReserveXLogInsertLocation is protected with exclusive
+	 * insertion lock, so there is no contention against CurrBytePos, But we
+	 * still do CAS loop for being uniform.
+	 *
+	 * Probably we'll get rid of exclusive lock in a future.
 	 */
-	SpinLockAcquire(&Insert->insertpos_lck);
-
-	startbytepos = Insert->CurrBytePos;
+repeat:
+	startbytepos = pg_atomic_read_u64(&Insert->CurrBytePos);

 	ptr = XLogBytePosToEndRecPtr(startbytepos);
 	if (XLogSegmentOffset(ptr, wal_segment_size) == 0)
 	{
-		SpinLockRelease(&Insert->insertpos_lck);
 		*EndPos = *StartPos = ptr;
 		return false;
 	}

 	endbytepos = startbytepos + size;
-	prevbytepos = Insert->PrevBytePos;
-
 	*StartPos = XLogBytePosToRecPtr(startbytepos);
 	*EndPos = XLogBytePosToEndRecPtr(endbytepos);

@@ -1205,10 +1657,18 @@ ReserveXLogSwitch(XLogRecPtr *StartPos, XLogRecPtr *EndPos, XLogRecPtr *PrevPtr)
 		*EndPos += segleft;
 		endbytepos = XLogRecPtrToBytePos(*EndPos);
 	}
-	Insert->CurrBytePos = endbytepos;
-	Insert->PrevBytePos = startbytepos;
-
-	SpinLockRelease(&Insert->insertpos_lck);
+	if (!pg_atomic_compare_exchange_u64(&Insert->CurrBytePos,
+										&startbytepos,
+										endbytepos))
+	{
+		/*
+		 * Don't use spin delay here: perform_spin_delay primary case is for
+		 * solving single core contention. But on single core we will succeed
+		 * on the next attempt.
+		 */
+		goto repeat;
+	}
+	LinkAndFindPrevPos(startbytepos, endbytepos, &prevbytepos);

 	*PrevPtr = XLogBytePosToRecPtr(prevbytepos);

@@ -1510,7 +1970,6 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 	XLogRecPtr	inserted;
 	XLogRecPtr	reservedUpto;
 	XLogRecPtr	finishedUpto;
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
 	int			i;

 	if (MyProc == NULL)
@@ -1525,9 +1984,7 @@ WaitXLogInsertionsToFinish(XLogRecPtr upto)
 		return inserted;

 	/* Read the current insert position */
-	SpinLockAcquire(&Insert->insertpos_lck);
-	bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
+	bytepos = ReadInsertCurrBytePos();
 	reservedUpto = XLogBytePosToEndRecPtr(bytepos);

 	/*
@@ -4940,6 +5397,8 @@ XLOGShmemSize(void)

 	/* WAL insertion locks, plus alignment */
 	size = add_size(size, mul_size(sizeof(WALInsertLockPadded), NUM_XLOGINSERT_LOCKS + 1));
+	/* prevlinkshash, abuses alignment of WAL insertion locks. */
+	size = add_size(size, mul_size(sizeof(WALPrevPosLink), PREV_LINKS_HASH_CAPA));
 	/* xlblocks array */
 	size = add_size(size, mul_size(sizeof(pg_atomic_uint64), XLOGbuffers));
 	/* extra alignment padding for XLOG I/O buffers */
@@ -4994,8 +5453,9 @@ XLOGShmemInit(void)
 		/* both should be present or neither */
 		Assert(foundCFile && foundXLog);

-		/* Initialize local copy of WALInsertLocks */
+		/* Initialize local copy of WALInsertLocks and PrevLinksHash */
 		WALInsertLocks = XLogCtl->Insert.WALInsertLocks;
+		PrevLinksHash = XLogCtl->Insert.PrevLinksHash;

 		if (localControlFile)
 			pfree(localControlFile);
@@ -5041,6 +5501,9 @@ XLOGShmemInit(void)
 		WALInsertLocks[i].l.lastImportantAt = InvalidXLogRecPtr;
 	}

+	PrevLinksHash = XLogCtl->Insert.PrevLinksHash = (WALPrevPosLink *) allocptr;
+	allocptr += sizeof(WALPrevPosLink) * PREV_LINKS_HASH_CAPA;
+
 	/*
 	 * Align the start of the page buffers to a full xlog block size boundary.
 	 * This simplifies some calculations in XLOG insertion. It is also
@@ -5059,12 +5522,24 @@ XLOGShmemInit(void)
 	XLogCtl->InstallXLogFileSegmentActive = false;
 	XLogCtl->WalWriterSleeping = false;

-	SpinLockInit(&XLogCtl->Insert.insertpos_lck);
 	SpinLockInit(&XLogCtl->info_lck);
 	pg_atomic_init_u64(&XLogCtl->logInsertResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logWriteResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->logFlushResult, InvalidXLogRecPtr);
 	pg_atomic_init_u64(&XLogCtl->unloggedLSN, InvalidXLogRecPtr);
+
+	pg_atomic_init_u64(&XLogCtl->Insert.CurrBytePos, 0);
+
+	for (i = 0; i < PREV_LINKS_HASH_CAPA; i++)
+	{
+#if WAL_LINK_64
+		pg_atomic_init_u64(&PrevLinksHash[i].CurrPos, 0);
+		pg_atomic_init_u64(&PrevLinksHash[i].PrevPos, WAL_PREV_EMPTY);
+#else
+		pg_atomic_init_u32(&PrevLinksHash[i].CurrPosId, 0);
+		pg_atomic_init_u32(&PrevLinksHash[i].PrevSize, 0);
+#endif
+	}
 }

 /*
@@ -6064,8 +6539,13 @@ StartupXLOG(void)
 	 * previous incarnation.
 	 */
 	Insert = &XLogCtl->Insert;
-	Insert->PrevBytePos = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
-	Insert->CurrBytePos = XLogRecPtrToBytePos(EndOfLog);
+	{
+		XLogRecPtr	endOfLog = XLogRecPtrToBytePos(EndOfLog);
+		XLogRecPtr	lastRec = XLogRecPtrToBytePos(endOfRecoveryInfo->lastRec);
+
+		pg_atomic_write_u64(&Insert->CurrBytePos, endOfLog);
+		LinkStartPrevPos(endOfLog, lastRec);
+	}

 	/*
 	 * Tricky point here: lastPage contains the *last* block that the LastRec
@@ -7057,7 +7537,7 @@ CreateCheckPoint(int flags)

 	if (shutdown)
 	{
-		XLogRecPtr	curInsert = XLogBytePosToRecPtr(Insert->CurrBytePos);
+		XLogRecPtr	curInsert = XLogBytePosToRecPtr(ReadInsertCurrBytePos());

 		/*
 		 * Compute new REDO record ptr = location of next XLOG record.
@@ -9478,14 +9958,7 @@ register_persistent_abort_backup_handler(void)
 XLogRecPtr
 GetXLogInsertRecPtr(void)
 {
-	XLogCtlInsert *Insert = &XLogCtl->Insert;
-	uint64		current_bytepos;
-
-	SpinLockAcquire(&Insert->insertpos_lck);
-	current_bytepos = Insert->CurrBytePos;
-	SpinLockRelease(&Insert->insertpos_lck);
-
-	return XLogBytePosToRecPtr(current_bytepos);
+	return XLogBytePosToRecPtr(ReadInsertCurrBytePos());
 }

 /*
diff --git a/src/tools/pgindent/typedefs.list b/src/tools/pgindent/typedefs.list
index 43fe3bcd593..8dda440df50 100644
--- a/src/tools/pgindent/typedefs.list
+++ b/src/tools/pgindent/typedefs.list
@@ -3240,6 +3240,8 @@ WALAvailability
 WALInsertLock
 WALInsertLockPadded
 WALOpenSegment
+WALPrevPosLink
+WALPrevPosLinkVal
 WALReadError
 WALSegmentCloseCB
 WALSegmentContext
--
2.43.0
